ZEUS-WHI0
4U Rackmount Server System
User’s Manual 1st Ed

Preface II
4U Rackmount Server System ZEUS-WHI0
Copyright Notice
This document is copyrighted, 2023. All rights are reserved. The original manufacturer
reserves the right to make improvements to the products described in this manual at
any time without notice.
No part of this manual may be reproduced, copied, translated, or transmitted in any
form or by any means without the prior written permission of the original manufacturer.
Information provided in this manual is intended to be accurate and reliable. However,
the original manufacturer assumes no responsibility for its use, or for any infringements
upon the rights of third parties that may result from its use.
The material in this document is for product information only and is subject to change
without notice. While reasonable efforts have been made in the preparation of this
document to assure its accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information contained herein.
AAEON reserves the right to make changes in the product design without notice to its
users.
.

Preface III
4U Rackmount Server System ZEUS-WHI0
Acknowledgement
All other products’ name or trademarks are properties of their respective owners.
⚫Microsoft Windows® is a registered trademark of Microsoft Corp.
⚫Intel® Xeon® is a registered trademark of Intel Corporation.
⚫ITE is a trademark of Integrated Technology Express, Inc.
⚫IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines
Corporation.
⚫CentOS is a trademark of Red Hat, Inc.
⚫Realtek® is a trademark of Realtek Semiconductor Corporation.
All other product names or trademarks are properties of their respective owners. The
publisher of this document does not assume nor imply ownership of any trademarked
product not listed herein.

Preface IV
4U Rackmount Server System ZEUS-WHI0
Packing List
Before setting up your product, please make sure the following items have been
shipped:
Item
Quantity
⚫ZEUS-WHI0
1
If any of these items are missing or damaged, please contact your distributor or sales
representative immediately.

Preface V
4U Rackmount Server System ZEUS-WHI0
About this Document
This User’s Manual contains all the essential information, such as detailed descriptions
and explanations on the product’s hardware and software features (if any), its
specifications, dimensions, jumper/connector settings/definitions, and driver installation
instructions (if any), to facilitate users in setting up their product.
Users may refer to the product page at AAEON.com for the latest version of this
document.

Preface VI
4U Rackmount Server System ZEUS-WHI0
Safety Precautions
Please read the following safety instructions carefully. It is advised that you keep this
manual for future references
1. All cautions and warnings on the device should be noted.
2. Make sure the power source matches the power rating of the device.
3. Position the power cord so that people cannot step on it. Do not place anything
over the power cord.
4. Always completely disconnect the power before working on the system’s
hardware.
5. No connections should be made when the system is powered as a sudden rush
of power may damage sensitive electronic components.
6. If the device is not to be used for a long time, disconnect it from the power
supply to avoid damage by transient over-voltage.
7. Always disconnect this device from any AC supply before cleaning.
8. While cleaning, use a damp cloth instead of liquid or spray detergents.
9. Make sure the device is installed near a power outlet and is easily accessible.
10. Keep this device away from humidity.
11. Place the device on a solid surface during installation to prevent falls
12. Do not cover the openings on the device to ensure optimal heat dissipation.
13. Watch out for high temperatures when the system is running.
14. Do not touch the heat sink or heat spreader when the system is running
15. Never pour any liquid into the openings. This could cause fire or electric shock.
16. As most electronic components are sensitive to static electrical charge, be sure to
ground yourself to prevent static charge when installing the internal components.
Use a grounding wrist strap and contain all electronic components in any
static-shielded containers.

Preface VII
4U Rackmount Server System ZEUS-WHI0
17. If any of the following situations arises, please the contact our service personnel:
i. Damaged power cord or plug
ii. Liquid intrusion to the device
iii. Exposure to moisture
iv. Device is not working as expected or in a manner as described in
this manual
v. The device is dropped or damaged
vi. Any obvious signs of damage displayed on the device
18. DO NOT LEAVE THIS DEVICE IN AN UNCONTROLLED ENVIRONMENT WITH
TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES
(SEE CHAPTER 1) TO PREVENT DAMAGE.

Preface VIII
4U Rackmount Server System ZEUS-WHI0
FCC Statement
This device complies with Part 15 FCC Rules. Operation is
subject to the following two conditions: (1) this device may not
cause harmful interference, and (2) this device must accept any
interference received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions and your local government’s recycling or
disposal directives.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur.
Recycler les batteries usées en accord avec les instructions du fabricant et les directives
gouvernementales de recyclage.

Preface IX
4U Rackmount Server System ZEUS-WHI0
China RoHS Requirements (CN)
产品中有毒有害物质或元素名称及含量
AAEON System QO4-381 Rev.A0
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
○
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
○
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
电池
×
○
○
○
○
○
本表格依据 SJ/T 11364 的规定编制。
○ ：表示该有毒有害物质在该部件所有均质材料中的含量均在
GB/T 26572标准规定的限量要求以下。
×：表示该有害物质的某一均质材料超出了GB/T 26572的限量要求，然而该部件
仍符合欧盟指令2011/65/EU 的规范。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、电源为选购品。
三、上述部件物质液晶模块、触控模块仅一体机产品适用。

Preface X
4U Rackmount Server System ZEUS-WHI0
China RoHS Requirement (EN)
Hazardous and Toxic Materials List
AAEON System QO4-381 Rev.A0
Component
Name
Hazardous or Toxic Materials or Elements
Lead (Pb)
Mercury (Hg)
Cadmium (Cd)
Hexavalent Chromium (Cr(VI))
Polybrominat ed biphenyls (PBBs)
Polybrominat ed diphenyl ethers (PBDEs)
PCB and
Components
X
O
O
O
O
O
Wires &
Connectors for
Ext.Connections
X
O
O
O
O
O
Chassis
O
O
O
O
O
O
CPU & RAM
X
O
O
O
O
O
HDD Drive
X
O
O
O
O
O
LCD Module
X
O
O
O
O
O
Optical Drive
X
O
O
O
O
O
Touch Control
Module
X
O
O
O
O
O
PSU
X
O
O
O
O
O
Battery
X
O
O
O
O
O
This form is prepared in compliance with the provisions of SJ/T 11364.
O: The level of toxic or hazardous materials present in this component and its parts is
below the limit specified by GB/T 26572.
X: The level of toxic of hazardous materials present in the component exceed the
limits specified by GB/T 26572, but is still in compliance with EU Directive 2011/65/EU
(RoHS 2).
Notes:
1. The Environment Friendly Use Period indicated by labelling on this product is
applicable only to use under normal conditions.
2. Individual components including the CPU, RAM/memory, HDD, optical drive, and
PSU are optional.
3. LCD Module and Touch Control Module only applies to certain products which
feature these components.

Preface XI
4U Rackmount Server System ZEUS-WHI0
Table of Contents
Chapter 1 - Product Specifications.......................................................................................... 1
1.1 Specifications ..............................................................................................................2
Chapter 2 –Hardware Information ....................................................................................... 5
2.1 Dimensions.................................................................................................................. 6
2.2 Jumpers and Connectors ........................................................................................10
2.3 List of Jumpers........................................................................................................... 11
2.3.1 RTC Reset (CMOS1).......................................................................................... 11
2.3.2 Auto Power Button Selection (JP1) ............................................................... 11
2.3.3 ME Recover (JP2) ............................................................................................. 11
2.4 List of Connectors .....................................................................................................12
2.4.1 Digital I/O: 2.0mm Pin Header 2x5P (DIO1)...............................................13
2.4.2 USB 2.0: 2.0mm Box Header 2x10P (CN5)..................................................14
2.4.3 Front Panel Pin Header (FP1).........................................................................15
2.4.4 Case Open (CN9).............................................................................................15
2.5 Hardware Installation................................................................................................16
2.5.1 2.5" or 3.5" Hard Disk Drive Installation ......................................................16
2.5.2 IPMI Module Installation.................................................................................19
Chapter 3 - AMI BIOS Setup ................................................................................................ 22
3.1System Test and Initialization.................................................................................23
3.2 AMI BIOS Setup........................................................................................................24
3.3 Setup Submenu: Main.............................................................................................25
3.4 Setup Submenu: Advanced ...................................................................................26
3.4.1 Trusted Computing.......................................................................................27
3.4.2 Hardware Monitor ........................................................................................29
3.4.3 SIO Configuration..........................................................................................31
3.4.3.1 Serial Port Configuration.................................................................32

Preface XII
4U Rackmount Server System ZEUS-WHI0
3.4.4 PCI Subsystem Settings ...............................................................................33
3.4.5 Serial Port Console Configuration.............................................................34
3.4.5.1 COM0 Console Redirection Settings ............................................35
3.4.5.2 Legacy Console Redirection Settings............................................37
3.4.5.3 Console Redirection EMS Settings ................................................38
3.4.6 NVMe Configuration....................................................................................40
3.4.7 Power Management......................................................................................41
3.4.8 Digital IO Port Configuration......................................................................42
3.4.9 Case Open Configuration...........................................................................43
3.5 Setup Submenu: Platform Configuration............................................................44
3.5.1 PCH Configuration .......................................................................................45
3.5.1.1 PCH SATA Configuration .................................................................46
3.5.1.2 PCH sSATA Configuration................................................................47
3.5.2 Server ME Configuration.............................................................................48
3.6 Setup Submenu: Socket Configuration ...............................................................49
3.6.1 Processor Configuration..............................................................................50
3.6.2 Memory Configuration.................................................................................51
3.6.2.1 Memory Topology ............................................................................52
3.6.3IIO Configuration..........................................................................................53
3.6.4 Intel® VT for Directed I/O (VT-d).............................................................54
3.6.5 Advanced Power Management Configuration.......................................55
3.6.5.1 CPU C State Control.......................................................................56
3.7 Setup Submenu: Server Mgmt..............................................................................57
3.7.1 System Event Log .........................................................................................59
3.7.2 BMC Self-Test Log...........................................................................................60
3.7.3 BMC Network Event Log ................................................................................61
3.7.4 View System Event Log..................................................................................62
3.7.5 BMC User Settings ..........................................................................................63

Preface XIII
4U Rackmount Server System ZEUS-WHI0
3.7.5.1 Add User.............................................................................................64
3.7.5.2 Delete User.........................................................................................65
3.7.6 Change User Settings.....................................................................................66
3.8Setup Submenu: Security .......................................................................................67
3.8.1 Secure Boot....................................................................................................68
3.8.1.1 Key Management..............................................................................69
3.9 Setup Submenu: Boot..............................................................................................71
3.10 Setup Submenu: Save & Exit .................................................................................72
Chapter 4 –Driver Installation ............................................................................................. 73
4.1 Driver Download/Installation.................................................................................74
Appendix A –AMI BMC Firmware User Guide .................................................................. 76
A.1 Login WebUI .............................................................................................................77
A.2 Power Control...........................................................................................................82
A.3 Field Replace Unit (FRU) .........................................................................................85
A.4 Remote Control........................................................................................................86
A.5 Sensors Monitor .......................................................................................................88
A.6 Virtual Media.............................................................................................................89
A.7 Alarm Email Settings.................................................................................................91

4U Rackmount Server System ZEUS-WHI0
Chapter 1
Chapter 1 - Product Specifications

Chapter 1 –Product Specifications 2
4U Rackmount Server System ZEUS-WHI0
1.1 Specifications
System
Form Factor
4U Rackmount Server System
Processor
Single Intel® Xeon® Ice Lake-SP Processor,
Supports up to 205W
System Memory
DDR4 2666MHz R-DIMM Slot x 6
Supports up to 192GB (32GB per DIMM)
Chipset
Intel®C621A
Ethernet
Intel® i210 GbE x 2
BIOS
AMI BIOS
COM
RS-232 x 1
USB
USB 3.1 Gen 1 x 6 (Type-A)
USB 2.0 x 2 (2 x 5P 2.0mm Pin Header)
Audio
Realtek® ALC892-CG
Line-In x 1
Line-Out x 1
Serial ATA
SATA III x 8, Supports RAID 0, 1, 5,10
Storage
4-Bay Internal 2.5”/3.5” SATA Drive Bay x 2
M.2 2280 M-Key x 1 (PCIe Gen 3 Speed)
Expansion Interface
PCIe 1: PCIe [x16] x 1 (Gen 4 x16)
PCIe 2: PCIe [x8] x 1 (Gen 3 x4)
PCIe 3: PCIe [x16] x 1 (Gen 4 x16)
PCIe 4: PCIe [x8] x 1 (Gen 4 x4)
PCIe 5: PCIe [x16] x 1 (Gen 4 x16)
PCIe 6: PCIe [x8] x 1 (Gen 3 x4)
PCIe 7: PCIe [x8] x 1 (Gen 4 x8)
Watchdog Timer
1~255 Steps by Software Programming

Chapter 1 –Product Specifications 3
4U Rackmount Server System ZEUS-WHI0
System
IPMI
IPMI Module (Optional)
RTC
Internal RTC
TPM
TPM 2.0
System Fan
Middle Fan x 3 (Default)
Rear Fan x 2 (Optional)
Front I/O Panel
HDD Active LED x 1
Power On/Off x 1
USB 3.0 x 2 (USB 2.0 Signal)
Rear I/O Panel
USB 3.1 Gen 1 x 6 (Type-A)
1Gb RJ-45 LAN x 2
VGA x 1
COM x 1
Audio Jack Line-in x 1
Audio Jack Line-out x 1
DIO
8-bit Internal Pin Header Digital I/O Interface 2 x 5
(2.0mm)
Color
Black
Power Supply
800W Mini Redundant PSU
1600W CRPS PSU (Optional)
Dimension
23.5" x 17" x 6.88"(597.2mm x 430mm x 174.8mm)
Display
Chipset
SM750
Resolution
1920 x 1080 (Windows® Server 2019)
800 x 600 (CentOS 7.3)
Connector
VGA x 1

Chapter 1 –Product Specifications 4
4U Rackmount Server System ZEUS-WHI0
Environmental
Operating Temperature
32°F ~ 104°F (0°C ~ 40°C)
Storage Temperature
-40°F ~ 185°F (-40°C ~ 85°C)
Operating Humidity
10% ~ 90% Relative Humidity, non-condensing
Storage Humidity
10% ~ 80% @40°C; non-condensing
Vibration
0.5 Grms/ 5 ~ 500Hz / operation (3.5” HDD)
1.5 Grms/ 5 ~ 500Hz / non-operation
Shock
10 G Peak Acceleration (11 m sec. duration), operation
20 G Peak Acceleration (11 m sec. duration),
non-operation
Certification
CE / FCC Class A

4U Rackmount Server System ZEUS-WHI0
Chapter 2
Chapter 2 –Hardware Information

Chapter 2 –Hardware Information 6
4U Rackmount Server System ZEUS-WHI0
2.1 Dimensions
System Top
637.20
430.00
482.60
75.00
165.00
299.90
450.00
485.00
545.00
465.00
174.80
597.20
65.60
88.90
44.45

Chapter 2 –Hardware Information 7
4U Rackmount Server System ZEUS-WHI0
System Bottom
Note: While the chassis contains several LEDs, only the Power LED and HDD LED are
functional, as shown.
637.20
430.00
482.60
75.00
165.00
299.90
450.00
485.00
545.00
465.00
174.80
597.20
65.60
88.90
44.45
