Asus GIGAX2024 User manual

GigaX2024/2048
User Manual
Layer 2 Managed Switch

E2301
October 2005 V2.3
Copyright © 2005 ASUSTeK COMPUTER INC. All Rights Reserved. No part
of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language in any form or by any means, except documentation kept by
the purchaser for backup purposes, without the express written permission of
ASUSTeK COMPUTER INC. (ASUS).
Product warranty or service will not be extended if: (1) the product is repaired,
modified or altered, unless such repair, modification of alteration is authorized in
writing by ASUS; or (2) the serial number of the product is defaced or missing.
ASUS provides this manual “as is” without warranty of any kind, either express
or implied, including but not limited to the implied warranties or conditions of
merchantability or fitness for a particular purpose. In no event shall ASUS,
its directors, officers, employees, or agents be liable for any indirect, special,
incidental, or consequential damages (including damages for loss of profits,
loss of business, loss of use or data, interruption of business and the like), even
if ASUS has been advised of the possibility of such damages arising from any
defect or error in this manual or product.
Specifications and information contained in this manual are furnished for
informational use only, and are subject to change at any time without notice,
and should not be construed as a commitment by ASUS. ASUS assumes no
responsibility or liability for any errors or inaccuracies that may appear in this
manual, including the products and software described in it.
Products and corporate names appearing in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used
only for identification or explanation and to the ownersʼ benefit, without intent to
infringe.

GigaX2024/2048 L2 Managed Switch User Manual
i
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with manufacturerʼs
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
WARNING! The use of shielded cables for connection of the monitor to the
graphics card is required to assure compliance with FCC regulations. Changes
or modifications to this unit not expressly approved by the party responsible for
compliance could void the userʼs authority to operate this equipment.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference Regulations of
the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.

GigaX2024/2048 L2 Managed Switch User Manual
ii
ASUS contact information
ASUSTeK COMPUTER INC. (Asia-Pacific)
Address: 150 Li-Te Road, Peitou, Taipei, Taiwan
General Tel: [phone]
General Fax: [phone]
Web Site: www.asus.com.tw
Technical Support
MB/Others (Tel): [phone] (English)
Notebook (Tel): [phone] (English)
Desktop/Server (Tel): [phone] (English)
Support Fax: [phone]
ASUS COMPUTER INTERNATIONAL (America)
Address: 44370 Nobel Drive, Fremont, CA 94538, USA
General Fax: [phone]
General Email: [email protected]
Web Site: usa.asus.com
Technical Support
Support Fax: [phone]
General Support: [phone]
Notebook Support: [phone] x5110
Support Email: [email protected]
ASUS COMPUTER GmbH (Germany and Austria)
Address: Harkort Str. 25, D-40880 Ratingen, BRD, Germany
General Fax: [phone]
General Email: [email protected] (for marketing requests only)
Technical Support
Support Hotlines: (Components) [phone]
(Notebook PC) [phone]
Support Fax: [phone]
Support Email: www.asuscom.de/de/support (for online support)
Web Site: www.asuscom.de
ASUS COMPUTER (Middle East and North Africa)
Address: P.O. Box 64133, Dubai, U.A.E.
General Tel.: [phone]
General Fax: [phone]
General Email: www.ASUSarabia.com

GigaX2024/2048 L2 Managed Switch User Manual
iii
Table of Contents
1 Introduction .............................................................................. 1
1.1 GigaX2024/2048 features ........................................................... 1
1.2 Conventions used in this document ........................................... 2
1.2.1 Notations ........................................................................................ 2
1.2.2 Typography ..................................................................................... 2
1.2.3 Symbols .......................................................................................... 2
2 Getting to know the GigaX ...................................................... 3
2.1 Package contents ....................................................................... 3
2.2 Front Panel .................................................................................. 4
2.3 Rear Panel .................................................................................. 5
2.4 Technical specifications ............................................................... 5
3 Quick start guide ..................................................................... 6
3.1 Part 1 — Installing the hardware .................................................. 6
3.1.1 Installing the switch on a flat surface .............................................. 6
3.1.2 Mounting the switch on a rack ........................................................ 6
3.2 Part 2 — Setting up the switch ..................................................... 6
3.2.1 Connect the console port ................................................................ 6
3.2.2 Connect to the computers or a LAN ............................................... 7
3.2.3 Attach the RPS module ................................................................. 7
3.2.4 Attach the power adapter ............................................................... 7
3.3 Part 3 — Basic switch setting for management ........................... 8
3.3.1 Setting up through the console port ............................................... 8
3.3.2 Setting up through the Web interface ............................................. 9
4 Management with the Web Interface ................................... 12
4.1 Log into Web user interface ....................................................... 12
4.2 Functional layout ........................................................................ 14
4.2.1 Menu navigation tips ..................................................................... 15

GigaX2024/2048 L2 Managed Switch User Manual
iv
4.2.2 Commonly used buttons and icons ............................................. 16
4.3 System Pages ............................................................................ 16
4.3.1 Management ................................................................................. 16
4.3.2 IP Setup ........................................................................................ 17
4.3.3 Administration .............................................................................. 18
4.3.4 Reboot ......................................................................................... 18
4.3.5 Firmware Upgrade ........................................................................ 18
4.4 Physical Interface ..................................................................... 19
4.5 Bridge ......................................................................................... 20
4.5.1 Spanning Tree .............................................................................. 20
4.5.2 Link Aggregation ........................................................................... 21
4.5.3 Mirroring ....................................................................................... 23
4.5.4 Static Multicast ............................................................................. 24
4.5.5 IGMP Snooping ............................................................................ 25
4.5.6 Traffic Control ............................................................................... 25
4.5.7 Dynamic Addresses ...................................................................... 26
4.5.8 Static Addresses ........................................................................... 27
4.5.9 Tagged VLAN ............................................................................... 27
4.5.10 Default Port VLAN and CoS ....................................................... 29
4.5.11 DHCP Snooping ......................................................................... 30
4.6 SNMP ......................................................................................... 31
4.6.1 Community Table .......................................................................... 31
4.6.2 Host Table ..................................................................................... 31
4.6.3 Trap Setting .................................................................................. 32
4.6.4 VACM Group ................................................................................ 32
4.6.5 VACM View ................................................................................... 33
4.6.6 USM User ..................................................................................... 34
4.7 Filters ......................................................................................... 35
4.7.1 Filter Set ....................................................................................... 35

GigaX2024/2048 L2 Managed Switch User Manual
v
4.7.2 Filter Attach ................................................................................... 37
4.8 Security ...................................................................................... 38
4.8.1 Port Access Control ...................................................................... 38
4.8.2 Dial-In User ................................................................................... 40
4.8.3 RADIUS ........................................................................................ 40
4.8.4 Port Security ................................................................................. 41
4.8.4.1 Port Configuration ................................................................. 41
4.8.4.2 Port Status ............................................................................ 42
4.8.4.3 Secure MAC Addresses ....................................................... 44
4.9 QoS ............................................................................................ 44
4.9.1 Trust State .................................................................................... 45
4.9.2 Mapping ........................................................................................ 46
4.9.3 Class Set ...................................................................................... 46
4.9.4 Policy Set ...................................................................................... 47
4.9.5 Policy Attach ................................................................................. 49
4.9.6 CoS ............................................................................................... 49
4.10 Statistics Chart ........................................................................ 50
4.10.1 Traffic Comparison ...................................................................... 50
4.10.2 Error Group ................................................................................. 51
4.10.3 Historical Status .......................................................................... 52
4.11 Save Configuration .................................................................. 53
5 Console Interface .................................................................. 54
5.1 Power On Self Test .................................................................... 54
5.1.1 Boot ROM Command Mode ......................................................... 55
5.1.2 Boot ROM Commands ................................................................. 55
5.2 Login and Logout ....................................................................... 57
5.3 CLI Commands .......................................................................... 57
5.3.1 System Commands ...................................................................... 57
5.3.2 Physical Interface Commands ...................................................... 60

GigaX2024/2048 L2 Managed Switch User Manual
vi
5.3.3 Bridge Commands ........................................................................ 60
5.3.4 SNMP ........................................................................................... 68
5.3.5 Filters Commands ........................................................................ 74
5.3.6 Security Commands ..................................................................... 77
5.3.7 QoS Commands ........................................................................... 82
5.4 Miscellaneous Commands ......................................................... 85
6 IP Addresses, Network Masks, and Subnets ...................... 86
6.1 IP Addresses .............................................................................. 86
6.1.1 Structure of an IP address ............................................................ 86
6.1.2 Network classes ........................................................................... 87
6.2 Subnet masks ............................................................................ 87
7 Troubleshooting .................................................................... 89
7.1 Diagnosing problems using IP utilities ....................................... 89
7.1.1 ping ............................................................................................... 89
7.1.2 nslookup ....................................................................................... 90
7.2 Replacing defective fans ............................................................ 91
7.3 Simple fixes ................................................................................ 93
8 Glossary ................................................................................. 95
9 Index ..................................................................................... 101

GigaX2024/2048 L2 Managed Switch User Manual
vii
List of Figures
Figure 1. GigaX L2 managed switch package contents ..................................... 3
Figure 2. Front panel (GigaX 2048) .................................................................... 4
Figure 3. Front panel (GigaX 2024) .................................................................... 4
Figure 4. Rear panel ........................................................................................... 5
Figure 5. Overview of Hardware Connections .................................................... 7
Figure 6. Login and IP setup Screen .................................................................. 9
Figure 7. Login Screen ..................................................................................... 10
Figure 8. IP Setup (GigaX 2048) ...................................................................... 11
Figure 9. IP Setup (GigaX 2024) ...................................................................... 11
Figure 10. Configuration manager login screen ............................................... 12
Figure 11. Home page (GigaX 2048) ................................................................ 13
Figure 12. Home page (GigaX 2024) ............................................................... 13
Figure 13. Top frame (GigaX 2048) .................................................................. 14
Figure 14. Top frame (GigaX 2024) .................................................................. 14
Figure 15. Expanded Menu List ........................................................................ 15
Figure 16. Management ................................................................................... 17
Figure 17. IP Setup ........................................................................................... 17
Figure 18. Administration .................................................................................. 18
Figure 19. Reboot ............................................................................................. 18
Figure 20. Firmware Upgrade ........................................................................... 19
Figure 21. Physical Interface ........................................................................... 20
Figure 22. Spanning Tree ................................................................................. 21
Figure 23. Link aggregation (GigaX 2048) ....................................................... 23
Figure 24. Link aggregation (GigaX 2024) ....................................................... 23
Figure 25. Mirroring page (GigaX 2048) ........................................................... 24
Figure 26. Mirroring page (GigaX 2024) ........................................................... 24
Figure 27. Static Multicast (GigaX 2048) .......................................................... 25
Figure 28. Static Multicast (GigaX 2024) .......................................................... 25

GigaX2024/2048 L2 Managed Switch User Manual
viii
Figure 29. IGMP Snooping ................................................................................ 25
Figure 30. Traffic Control .................................................................................. 26
Figure 31. Dynamic Address ............................................................................. 26
Figure 32.Static Address ................................................................................... 27
Figure 33. Tagged VLAN (GigaX 2048) ............................................................ 29
Figure 34. Tagged VLAN (GigaX 2024) ............................................................ 29
Figure 35. Default Port VLAN and CoS ........................................................... 30
Figure 36. DHCP Snooping (GigaX 2048) ........................................................ 30
Figure 37. DHCP Snooping (GigaX 2024) ........................................................ 30
Figure 38. Community Table ............................................................................ 31
Figure 39. Host Table ........................................................................................ 31
Figure 40. Trap Setting ..................................................................................... 32
Figure 41. VACM Group .................................................................................... 33
Figure 42. VACM View ...................................................................................... 34
Figure 43. USM User ........................................................................................ 35
Figure 44. Filter Set .......................................................................................... 36
Figure 45. Filter Rule in MAC mode .................................................................. 36
Figure 46. Filter Rule in IP mode ...................................................................... 36
Figure 47. Filter Attach (GigaX 2048) ............................................................... 37
Figure 48. Filter Attach (GigaX 2024) ............................................................... 38
Figure 49. Port Access Control ......................................................................... 39
Figure 50. Dial-In user ...................................................................................... 40
Figure 51. RADIUS .......................................................................................... 41
Figure 52. Port Configuration ............................................................................ 42
Figure 53. Port Status ....................................................................................... 43
Figure 54. Secure MAC Addresses ................................................................... 44
Figure 55. Trust State ....................................................................................... 46
Figure 56. Mapping ........................................................................................... 46
Figure 57. Class Set ......................................................................................... 47

GigaX2024/2048 L2 Managed Switch User Manual
ix
Figure 58. Policy Set ........................................................................................ 48
Figure 59. Policy Edit ........................................................................................ 49
Figure 60. Policy Attach .................................................................................... 49
Figure 61. CoS ................................................................................................. 50
Figure 62. Traffic comparison (GigaX 2048) ..................................................... 51
Figure 63. Traffic comparison (GigaX 2024) ..................................................... 51
Figure 64. Error group ...................................................................................... 52
Figure 65. Historical Status .............................................................................. 52
Figure 66. Save Configuration .......................................................................... 53
Figure 67. CLI interface .................................................................................... 54
Figure 68. Boot ROM Command Mode ............................................................ 55
Figure 69. SYS commands ............................................................................... 58
Figure 70. Using the ping utility ........................................................................ 89
Figure 71. Using the nslookup utility ................................................................. 90
Figure 72. Loosening the thumbscrew ............................................................. 91
Figure 73. Removing the fan module ............................................................... 91
Figure 74. Detaching the fan from the module ................................................. 92

GigaX2024/2048 L2 Managed Switch User Manual
x
List of Tables
Table 1. Front panel labels and LEDs ................................................................. 4
Table 2. Rear panel labels .................................................................................. 5
Table 3. Technical specifications ........................................................................ 5
Table 4. LED Indicators ...................................................................................... 8
Table 5. Port color description .......................................................................... 14
Table 6. Commonly used buttons and icons ..................................................... 16
Table 7. Boot ROM commands ......................................................................... 56
Table 8. IP address structure ............................................................................ 86
Table 9. Troubleshooting .................................................................................. 93

1
GigaX2024/2048 L2 Managed Switch User Manual
1 Introduction
Congratulations on becoming the owner of the ASUS GigaX2024/2048 Layer 2
managed switch! You may now manage your LAN (local area network) through
a friendly and powerful user interface.
This user manual tells how to set up the GigaX2024/2048 switch, and how to
customize its configuration to get the most out of this product.
1.1 GigaX2024/2048 features
• (GigaX 2048) 48 x 10/100BASE-TX auto-sensing Fast Ethernet ports
• (GigaX 2024) 24 x 10/100BASE-TX auto-sensing Fast Ethernet ports
• Two 10/100/1000BASE-T auto-sensing Gigabit Ethernet switching ports
• Two small form factor (SFP) Gigabit interface converter (GBIC) slots
• Automatic MDI/MDIX supported on 10/100BASE-TX and 10/100/1000BASE-T
ports
• Compliant with 802.3u, 802.3z and 802.3ab specifications
• 802.1D transparent bridge/spanning tree protocol
• 802.1w RSTP (Rapid Spanning Tree Protocol)
• 802.1X port-based network access control
• RADIUS remote authentication dial-in user service
• 8K MAC address cache with hardware-assisted aging
• 802.3x flow control
• 802.1Q-based tagged VLAN, up to 255 VLANs
• 802.1p class of service, 4 queues per port
• IGMP snooping support
• 802.3ad link aggregation (trunking), up to 6 trunk groups
• LACP (Link Aggregation Control Protocol)
• Port Mirroring
• Access Control List
• RMON: support 4 groups (1, 2, 3, 9)
• SNMP v1, v2, v3
• MIB-II

2
GigaX2024/2048 L2 Managed Switch User Manual
• Enterprise MIB for PSU, fan, and system temperature, voltage
• Telnet or SSH2 remote login
• FTP for firmware update and configuration backup
• IEEE 802.1x authentication (with dynamic VLAN assignment)
• DHCP snooping
• Syslog
• Command Line Interpreter through console, telnet and SSH
• Web-based Graphic User Interface (GUI)
• LEDs for port link status
• LEDs for system, redundant power supply (RPS), and fan status
1.2 Conventions used in this document
1.2.1 Notations
• Acronyms are defined the first time they appear in text and in the glossary.
• For brevity, the GigaX2024/2048 switch is referred to as “the switch.”
• The terms LAN and network are used interchangeably to refer to a group of
Ethernet-connected computers at one site.
• The illustrations and web interface screens refer to both the GigaX 2048 and
GigaX 2024 models, except otherwise indicated.
1.2.2 Typography
Boldface type text is used for items you select from menus and drop-down
lists, and text strings you type when prompted by the program.
1.2.3 Symbols
This document uses the following icons to call your attention to specific
instructions or explanations.
Provides clarification or additional information on the current
topic.
Explains terms or acronyms that may be unfamiliar to many
readers. These terms are also included in the Glossary.
Provides messages of high importance, including messages
relating to personal safety or system integrity.
Note
Definition
Warning

3
GigaX2024/2048 L2 Managed Switch User Manual
2 Getting to know the GigaX
2.1 Package contents
The GigaX2024/2048 switch package comes with the following items:
• GigaX 2048 (48-port) or GigaX 2024 (24-port) L2 managed switch
• AC power cord
• Null modem cable for console interface (DB9)
• Rack installation kit (two brackets with six #6-32 screws)
• USB cable for console interface
• Installation CD-ROM
• Quick installation guide
Figure 1. GigaX L2 managed switch package contents

4
GigaX2024/2048 L2 Managed Switch User Manual
2.2 Front Panel
The front panel includes 24/48 RJ-45 10/100Base-T ports, two 10/100/1000Base-T
ports, two SPF GBIC port and LED indicators that show the status of the system,
RPS, fan, and ports.
Figure 2. Front panel (GigaX 2048)
Figure 3. Front panel (GigaX 2024)
Table 1. Front panel labels and LEDs
Label Color Status Description
SYSTEM Green On Unit is powered on
Flashing Self-test, initiating, or downloading
Amber On Abnormal temperature or voltage
Off No power
RPS Green On The Power Supply Unit (PSU) is working properly
and the switch has a good redundant power supply
Amber On The PSU is abnormal and the switch is powered by RPS
Off No power (system LED is also off); RPS does not work
properly or not installed (system LED is on)
FAN Green On Both fans are working properly
Amber On Both or either one of the fans stopped
10/100 ports Green On Ethernet link is established
Flashing Data is being transmitted/received
Off No Ethernet link
10/100/1000
port status
Green On Link (RJ-45 or SFP) is present; port is enabled
Flashing Data is being transmitted/received
Amber On Link is present, but port is disabled either manually or
by spanning tree
Flashing Port is in one of the STP blocking, listening and
learning state
Off No Ethernet link
10/100/1000
port speed
Green On 1000Mbps
Amber On 100Mbps
Off 10Mbps

5
GigaX2024/2048 L2 Managed Switch User Manual
2.3 Rear Panel
The switch rear panel contains the fan modules, two console ports (USB and
DB9) and one RPS port..
Figure 4. Rear panel
Table 2. Rear panel labels
No. Label Description
1 Power Connector Connects to the supplied power cord
2 FAN1-FAN2 Replaceable system fans
3 Console RS232 RS232 serial port for console management
4 Console USB USB port for console management
5 RPS Redundant Power Supply connector
2.4 Technical specifications
Table 3. Technical specifications
Physical
Dimensions
43.5mm(H) x 444 mm(W) x 265mm(D)
Power
Input Consumption
100-240V AC/
2.5A 50-60Hz
< 90 watts
Redundant
Power Supply
(RPS)
Input Output
100-240V AC/
1.8A 50-60Hz
12V DC/12.5A
Environmental
Ranges
Operating Storage
Temperature -10 to 50°C (14 to 122°F) -40 to 70°C (-40 to 158°F)
Humidity 15 to 90% 0 to 95%
Altitude up to 10,000ft (3,000m) up to 40,000 ft (12,000m)
Replaceable
Fans
Dimensions Voltage and Current Speed
40 x 40 x 20 mm 12VDC, 0.13A 8200RPM

6
GigaX2024/2048 L2 Managed Switch User Manual
3 Quick start guide
This section provides the basic instructions to set up the switch environment.
Refer also to the GigaX2024/2048 Installation Guide.
Part 1 shows how to install the GigaX2024/2048 on a flat surface or on a rack.
Part 2 provides instructions to set up the hardware.
Part 3 shows how to configure basic settings on the GigaX2024/2048 switch.
Before start, obtain the following information from your network administrator:
IP address for the switch
Default gateway for the network
Network mask for this network
3.1 Part 1 — Installing the hardware
3.1.1 Installing the switch on a flat surface
The switch must be installed on a level surface that can support the weight of
the switch and its accessories. Attach four rubber pads on the marked location
on the bottom of the switch.
3.1.2 Mounting the switch on a rack
1. Position the bracket posts with the holes on both sides of the switch.
2. Use three screws to secure the bracket to the switch.
3. Repeat the above steps for the other side of the switch.
4. Use four rack-mount screws to mount the switch to the rack (The rack-
mount screws are not provided in the package).
3.2 Part 2 — Setting up the switch
3.2.1 Connect the console port
For console management, use an RS232 (DB9) or a USB cable (requiring
installation of the USB driver included in the support CD) to connect the switch.
If you want to use Web interface, connect your PC to the switch using an
Ethernet cable.

7
GigaX2024/2048 L2 Managed Switch User Manual
3.2.2 Connect to the computers or a LAN
You can use Ethernet cable to connect computers, hubs and other switches to
the switch ports. Either crossover or straight-through Ethernet cable can apply
for connecting these devices.
Use a twisted-pair Category 5 Ethernet cable to connect the
1000BASE-T port. Otherwise, the link speed can not reach
1Gbps.
3.2.3 Attach the RPS module
Connect your Redundant Power Supply (RPS) module (optional) to the RPS jack on
the rear panel of the switch and make sure the other end of the RPS is connected to
the power cord. Connect to the power cord to a grounded power outlet.
3.2.4 Attach the power adapter
1. Connect the AC power cord to the POWER receptacle on the back of the
switch and plug the other end of the power cord into a wall outlet or a power
strip.
2. Check the front LED indicators with the description in Table 4. If the LEDs
light up as described, the switch hardware is working properly.
Figure 5. Overview of Hardware Connections
Note
Console Management
RS-232
RPS
USB
Expension Hub/ Switch
LAN Computers
Cat.5 Ethernet Cables

8
GigaX2024/2048 L2 Managed Switch User Manual
Table 4. LED Indicators
No. LED Description
1 System Solid green indicates that the switch is turned on. If this
light is off, check if the power adapter if attached to the
switch and plugged into a power source.
2 Switch ports
[1] to [50] (2048)
[1] to [26] (2024)
Solid green indicates that the connection between the
switch and other devices is built. Flashing means the
switch is transmitting data .
3 RPS Solid green indicates that an RPS module is successfully
installed.
4 Fan Solid green indicates that all fans are working properly
3.3 Part 3 — Basic switch setting for management
After completing the hardware connections, configure the basic settings for your
switch. You can manage the switch using the following methods:
• Web interface: the switch features a set of web pages which enable easy
management via Java®-enabled IE5.0 or higher version.
• Command Line Interface: using console port to configure the switch.
3.3.1 Setting up through the console port
1. Use the supplied crossover RS-232 cable to connect to the console port on
the back of the switch. This port is a male DB-9 connector, implemented as a
data terminal equipment (DTE) connection. Tighten the retaining screws on
the cable to secure it on the connector. Connect the other end of the cable to
a PC running terminal emulation software. e.g Hyper Terminal.
2. Use the supplied USB cable to connect to a PC. You have to install the USB
driver from the switch CD-ROM before connection. The USB driver simulates
an additional COM port under Windows Me/2K/XP OS.
3. Make sure the settings of your terminal emulation software as follows:
a) Choose the appropriate serial port number
b) Set the data baud rate to 115200 (or 9600 on some models)
c) Set the data format to no parity, 8 data bits and 1 stop bit
d) No flow control
e) Set VT1000 for emulation mode
4. After setting up the terminal, you can see the prompt “(ASUS)%” on the
terminal.
