AT&T E5640 User manual

User Manual (Part 2)
5.8 GHz Expansion
Handset E560-2
For use with AT&T
model
E5640/E5643B/E5644B/E5655
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 1

You must charge the
battery and register the
handset before use. STOP! See pages 2-3
for easy instructions.
Table of contents
For customer service or product
information, visit our web site at
www.telephones.att.com
or call 1-800-222-3111.
Please also read
Important Product
Information
Enclosed in product package.
Before you begin........................................1
Parts checklist ............................................1
Battery & charging installation ...............2
Registration.................................................3
Replacing a Handset..................................5
Re-Registering a Handset ........................7
Belt clip & optional headset....................9
Quick reference guide............................10
Copyright © 2005 Advanced American Telephones.All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones.
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 2

Before you begin
This cordless telephone
operates with the maximum
power allowed by the
Federal Communications
Commission (FCC). Even
so, this handset and base
can communicate over only
a certain distance — which
can vary with the locations
of the base and handset, the
weather, and the
construction of your home
or office.
If you receive a call
while you are out of
range, the handset might
not ring — or if it does
ring, the call might not
connect when you press
PHONE. Move closer to the
base, then press PHONE to
answer the call.
If you move out of range
during a phone
conversation, you might
hear noise or interference.
To improve reception, move
closer to the base.
If you move out of range
without pressing OFF,
your phone will be left off
the hook.To hang up
properly, walk back toward
the telephone base,
periodically pressing OFF
until the call is
disconnected.
Parts checklist
Remember to save your sales receipt and original packaging in
case you ever need to ship your telephone for warranty service.
Check to make sure the telephone package includes the
following:
CHARGING
Handset charger
Telephone
handset Power
adapter
Belt clip
Battery
1
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 3

2
Battery & charger installation
After installation, place the handset in the charger and allow the
battery to charge for 16 hours before use.You can keep the battery
charged by returning the handset to the charger after each use.
When battery power is fully depleted, a full recharge takes about 10
hours.Average talk time on a fully charged battery is about eight
hours depending on environmental conditions, standby time is
approximately four days.
Light remains on while
battery is charging.
Plug power cord into jack on
underside of the charger, then plug
power adapter into an electrical outlet
not controlled by a wall switch.
Plug the battery pack
connector into handset.
Low battery indicator
Return handset to base or
charger to recharge when this
symbol flashes. (Handset will
beep when battery is low.)
Caution: Use only supplied
rechargeable battery or AT&T
replacement battery model
27910 (P/N: 89-1323-00-00).
LOW BATTERY
Press tab to open
battery
compartment.
NOTE: Use only the power cord
supplied with this product. If you need
a replacement, call 1-800-222-111.
Be sure to use an electrical outlet not
controlled by a wall switch.
Replace compartment cover.
Place the battery
pack and wires in
the compartment.
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 4

Registration
3
HANDSET 2
Before using a new E560-2 handset, you must register it with the
E5640 /E5643B/E5655 base. During registration, you must enter the
15-digit ID number of the telephone base.The Base ID of the
E5640/E5643B is located on the bottom of the base unit. For the
E5655, you can find the Base ID Code in the E5655 base menu.
The handset provided with your
E5640/E5655 is automatically registered as
Handset 1. Additional handsets will be
assigned numbers in the order they are
registered (Handset 2, Handset 3, or Handset
4). You can register a maximum of 4
handsets.
The E5643B has 3 handsets automatically
registered as Handset 1, 2 and 3.You can
register one additional handset, which will be
assigned number 4.
Enter base ID, then press SELECT.
ENTER BASE ID
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 5

Registration
Handset 1 Handset 2
Handset 3 Handset 4
To add a new handset:
• Make sure your handset battery is properly
installed and charged.
• Your handset will display "ENTER BASE
ID".
• Enter the 15-digit Base ID number.The
number is located on the bottom of the
E5640 and E5643B base unit. To find the
number on the E5655, go to the base, press
MENU, scroll down to highlight DISPLAY
BASE ID, then press SELECT.
• After entering the code, press SELECT to
accept the code and complete registration.
NOTE: If an invalid base ID code is entered you will hear an error
tone and the handset will continue to display “ ENTER BASE ID ”. To
make corrections while entering the code, you can erase digits by
pressing the DELETE key.
Once a valid base ID code is entered and
accepted by the base unit, the new handset
will be assigned the next available handset
number (Handset 2, Handset 3, or Handset 4).
You can register a maximum of four handsets
per base unit.
4
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 6

Replacing a handset
If you are replacing a handset on a system that has the maximum
number of handsets registered (4), or wish to change the
assigned handset number of your registered handsets, you must
first de-register the handsets, then re-register all handsets.
To de-register all handsets (E5640/E5643B/E5644B)
• Unplug the power supply from the base unit.
• Remove all handsets from the charge cradles and
base.
• Plug in the power supply while pressing and holding the
HANDSET LOCATOR button.
• Continue pressing HANDSET LOCATOR until the IN USE and
CHARGING indicators are lit.
• Release the HANDSET LOCATOR button.
All handsets will display:
Once the base indicators turn off (can take up to 30 seconds),
the handsets have been de-registered from the base, and can now
be re-registered (see page 7).
ENTER BASE ID
5
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 7

Replacing a handset
To de-register all handsets (E5655 ONLY)
• Press * 8 8 3 2 4 4 # on the base dial pad.
• Press SELECT/MENU on the base.
All handsets will lose registration with the base and the handsets will
display (can take up to 30 seconds):
The handsets have been de-registered from the base, and can now
be re-registered (see page 7).
ENTER BASE ID
6
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 8

You can re-register handsets after de-registering from the base.
Or you can re-register handsets to a new base unit, if you have
replaced your base unit for any reason.
To re-register a handset:
• Make sure your handset battery is properly installed and
charged.
• Your handset will display “SEARCHING...”
• Press and hold the SELECT key until the handset displays
“ENTER BASE ID”.
• Enter the 15-digit Base ID number. The number is located on
the bottom of the E5640, E5643B and E5644B base unit.To
find the number on the E5655, go to the base, press MENU,
scroll down to highlight DISPLAY BASE ID, then press
SELECT.
• After entering the code, press SELECT to accept the code and
complete registration.
NOTE: If an invalid base ID code is entered you will hear an error tone and the
handset will continue to display “ENTER BASE ID”. To make corrections while entering the
code, you can erase digits by pressing the DELETE key.
Once a valid base ID code is entered and accepted by the base
unit, the new handset will be assigned the next available handset
number (Handset 1, Handset 2, Handset 3, or Handset 4).You can
register a maximum of four handsets per base unit.
Re-Registering a handset
7
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 9

Re-Registering a handset
To re-register a handset to a new base unit:
• Make sure your handset battery is properly installed and
charged.
• Unplug the old base unit.Your handset will display
"SEARCHING...".
• Install the new base unit by plugging it into an electrical
outlet and phone jack.
• Press and hold the SELECT key until the handset displays
“ENTER BASE ID”.
• Enter the 15-digit Base ID number. The number is located on
the bottom of the E5640, E5643B and E5644B base unit.To
find the number on the E5655, go to the base, press MENU,
scroll down to highlight DISPLAY BASE ID, then press
SELECT.
• After entering the code, press SELECT to accept the code and
complete registration.
NOTE: If an invalid base ID code is entered you will hear an error tone and the
handset will continue to display “ENTER BASE ID”. To make corrections while entering the
code, you can erase digits by pressing the DELETE key.
Once a valid base ID code is entered and accepted by the base
unit, the new handset will be assigned the next available handset
number (Handset 1, Handset 2, Handset 3, or Handset 4).You can
register a maximum of four handsets per base unit.
8
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 10

Belt clip & optional headset
Install belt clip as shown below if desired.
For hands-free telephone conversations, you can use any industry
standard 2.5 mm headset (purchased separately). For best results
use an AT&T 2.5 mm headset.
9
Snap belt clip into notches on
side of handset. Rotate and pull
to remove.
Plug 2.5 mm headset
into jack on side of
handset (beneath
small rubber cap)
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 11

For complete instructions, please refer to the manual provided with
your E5640, E5643B, E5644B or E5655 telephone.
Quick reference guide
10
Feature menu
>DIRECTORY
CALL LOG
Menu
Feature Menu
Directory
Call Log
Ringer Volume
Ringer Tone
Key Tone
Language
CLR Voice Mail
Dial Type
Press ^ or V to scroll
through menu items.
Press SELECT to select or
modify a highlighted item.
Press OFF to cancel an
operation, back up to the
previous menu, or exit the
menu display.
>shows highlighted item
Off/Clear
During a call, press to hang up.
While using menus, press to cancel an
operation, back up to the previous
menu, or exit the menu display.
Redial/Pause
Press to view redial memory.
While entering numbers, press and hold
to insert a dialing pause .
^CID
Press to scroll up in menus.
Press when phone is not in use to
display Caller ID information . While
entering names or numbers, press to
move the cursor to the left.
Speaker
Press to activate handset speakerphone.
Press again to resume normal handset
use (earpiece).
VDIR
Press to scroll down in menus.
Press when phone is not in use to
display directory entries. While entering
names, press to advance cursor.
Phone/Flash
Press to make or answer a call.
During a call, press to receive an
incoming call, if Call Waiting is activated.
Mute/Delete
While on a call, press to mute
microphone. While reviewing the call log,
press to delete an individual entry or
press and hold to clear the Caller ID log.
While pre-dialing, press to delete digits
from a string.
Intercom
Press to initiate an intercom
conversation or transfer a call.
Handset Select/Menu
Press to display menu, or to select
highlighted item from menu.
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 12

www.telephones.att.com
Copyright © 2005 Advanced American Telephones.All Rights Reserved.
AT&T and the Globe Design are trademarks of AT&T Corp.,
licensed to Advanced American Telephones. Printed in China. Issue 1 AT&T 06/05.
91-000432-010-000
91-000432-010-000-E560-2 Manual July04,2005.qxd 2/13/1950 7:21 PM Page 13
