atd models ATD033 User manual

ATD033 - OO (1:76 Scale)
Traditional Market Stall - Style 2
- Instruction Manual
Tools Required
Modellers Knife (with a fresh blade)
Cutting Mat
Modelling Glue (we recommend Deluxe Materials Roket Card Glue)
Fine Tip Applicator
Low-tac Masking Tape
Clips / Clamps
Tips
Prior to starting your build, we recommend reading through the instructions to
familiarise yourself with the build style of the kit.
We recommend painting any white edges as you remove the components from
the sheet to improve the nished look. We advise watercolour paints for the best
nish.
Each component is held in the sheet using score lines, indicated by a scissor
symbol. To remove the component from the sheet, carefully run the tip of your
modelling knife through the score line.
Remove each component as it is required to prevent losing or mixing it up with
another component.
Ensure that glue is distributed evenly and not too close to the edge as it may ooze
out when pressure is applied.
Use low-tac masking tape, clamps and weights to aid the assembly process.

1. Detach component A and place it face down on your work surface. Then,
locate the glazing sheet, cut out the three windows and glue them into
position.
Optional: Carefully run the blade of your modelling knife down the scored
line on the door to achieve an ‘open’ look.
2. Fold the crease lines on
component A. Next, apply glue to
the tab and bond it to the inside
of the adjacent wall. This will form
the shell of the stall.
3. Open the window shutter by
folding the top crease outwards.
Then, fold the lower section of
the shutter underneath the upper
section and glue them together.
4. Detach component B and place it face down on your worksurface. Then fold
the crease lines and glue the two tabs to the oor. This will form the counter
tops.

5. Apply glue to two of the outer
edges of component B. Then,
carefully slide component B
inside component A.
6. Detach component C and fold
the crease lines. Then, apply glue
to the two tabs and position it
below the serving window,
between the two counters.
7. Carefully apply a bead of glue across
the top of all four walls. Then, detach
component D, fold it along the crease
line to form the roof and position on
top of the stall.
You have now completed the Traditional Market Stall. We hope you enjoyed
and successfully built the kit! To view our other card kits, more products and
nd your local stockist, visit www.atdmodels.co.uk
We’d love to see photos of your nished models. Please send them to
[email protected] for a chance to be featured on our social media pages.
