Atlantic Furniture Columbia Staircase Bookshelf User manual

Page 1 of 13
Size of Mattress and Foundation
The length and width of the upper and lower bunk mattress and foundation are as follows :
Width
37 ½”- 38 ½”
52”- 53”
LengthSize
74”- 75”
74”- 75”
Twin
Full
Thickness
9 ½” max
9 ½” max
You must use only this size mattress.
Ensure thickness of upper and lower mattress and foundation combined does not exceed 9 ½”
and that the mattress is at least 5” below upper edge of guardrails.
This bunk bed uses a slat kit for mattress foundation.
Replacement Parts
SAFETY WARNINGS
! !
( 1 )
( 2 )
( 3 )
( 4 )
( 5 )
( 6 )
( 7 )
( 8 )
( 9 )
(10)
(11)
(12)
(13)
Follow the information on the warnings appearing on the upper bunk end structure
and on the carton. Do not remove warning label from bed.
Always use the recommended size mattresses or mattress support, or both,
to help prevent the likehood of entrapment or falls.
Surface of mattress must be at least 5 in. (127mm) below the upper edge of guardrails.
Do not allow children under 6 years of age to use the upper bunk.
Periodically check and ensure that the guardrail, ladder, and other component are
in their proper position, free from damage, and that all connectors are tight.
Do not allow horseplay on or under the bed and prohibit jumping on the bed.
Always use ladder for entering or leaving upper bunk.
Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
Use of a night light may provide added safety precaution for a child using the upper bunk.
Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed
next to the wall, the guardrail that runs the full length of the bed should be placed against
the wall to prevent entrapment between the bed and the wall.
The use of water or sleep flotation mattresses is prohibited.
STRANGULATION HAZARD : Never attach or hang items to any part of the bunk bed
that are not designed for use with the bed; for example, but not limited to, hooks, belts
and jump ropes.
Keep these instructions for future reference.
Replacement parts, including additional guardrails, may be obtained from any
dealer

ASSEMBLY INSTRUCTIONS
Before assembling your columbia staircase bookshelf, please read through these
(TWIN - TWIN) (TWIN - FULL) (FULL - FULL)
Adult assembly
Allen wrench
Phillips head
Customer supplied
screwdriver
instructions carefully. Familiarize yourself with the different parts.
Please note that you will require a phillips head screwdriver and an allen wrench.
STAIRCASE CAN BE SET UP AT EITHER
END OF THE BUNK BED
Page 2 of 13
AJCB M6 X 3 ½”(90mm) - 24 pcs
Spare - 2 pcs Spare - 2 pcs Spare - 1 pc
Spare - 1 pc
Spare - 2 pcs
Spare - 2 pcs
Spare - 2 pcs
Spare - 1 pc
Spare - 1 pc
BJCB M6 X 3/4”(20mm) - 1 pc
with Flat washer
Allen screw 2” (50mm) - 17 pcs
Allen screw 1 5/8” (40mm) - 6 pcs
Allen screw 3 1/8” (80mm) - 4 pcs
C
Wood screw 1 1/4” - 2 pcs
TWIN / TWIN FULL / FULL
E
E
E
K
L
M
Wood screw 5/8” - 7 pcs
Mini L Bracket - 1 pc
Flat Bracket - 2 pcs
E
GMetal pins - 4 pcs
TWIN OVER FULL SHOWN
E
E
D
E
E
H
Cap nut - 1 pc
FBarrel nuts - 24 pcs J
N
O
L bracket - 1 pc
Wood button - 4 pcs
In Full lower panel carton
PAllen wrench - 1 pc
IWooden dowel - 26 pcs
10 X 30mm
HARDWARE
READY
ASSEMBLE
TO
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
STAIRCASE BOOKSHELF

PARTS LIST
Page 3 of 13
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
HARDWARE
A UPPER PANEL
B UPPER PANEL
LEFT, RIGHT END CAP
END GUARD RAIL
BACK GUARD RAIL
SIDE GUARD RAIL
HAND GUARD RAIL
BOTTOM SHELF
MIDDLE SHELF
TOP SHELF
BACK PANEL
LOWER PANEL
FRONT, BACK GUARDRAIL
SIDE RAILS
TOP DRAWER
BOTTOM DRAWER
SPECIAL BLOCK TWIN
SPECIAL BLOCK FULL
MIDDLE DRAWERS
TWIN SLAT KIT
FULL UPPER BUNK SLAT KIT
FULL LOWER BUNK SLAT KIT
OR
02
03
14
14
15
15
15
15
13
20
20
16
17
18
19
06
07
08
09
12
10
11
01
04
05
04
21
23
13
TWIN OVER FULL SHOWN
24
OR
TWIN LOWER BUNK SLAT KIT
STAIRCASE BOOKSHELF

STEP 1
STEP 2
Attach the side rails (15) to the A upper panel (02) and B upper panel (03),
using JCB M6 X 3 ½” (A), and barrel nut (F). Tighten with the Allen wrench (P).
Twin upper panel shown. Full over Full bunk use Full upper panel. A
F
P
JCB M6 X 3 ½”
Barrel nut
Allen wrench
Page 4 of 13
02
03
15
15
A
A
A
F
F
F
F
Lay the twin slat kit (21) onto the bed. Fix in place using wood screws provided in the slat kit box.
FOR SLAT KIT ASSEMBLY follow assembly instructions included with slat kit.
Customer supplied
Phillips screwdriver
21
Twin size shown
Full Upper panel uses Full upper slat kit
Adult assembly
Adult assembly
STAIRCASE BOOKSHELF

Page 5 of 13
A
F
P
JCB M6 X 3 ½”
Barrel nut
Allen wrench
Attach the guard rails (14) to the upper panel assemblies using JCB M6 X 3 ½” (A),
and barrel nut (F). Tighten with the Allen wrench (P).
A
C
C
I
I
I
I
A
A
A
A
F
F
F
F
F
F
F
A
A
Attach the end guard rail (05) to the end caps (04), using wood dowels (I) and Allen screw M6 X 2”(C).
Tighten with the Allen wrench (P).
14
14
Note : Screw holes on end caps
go on inside of guard rails.
05
04
04
Adult assembly
STEP 3
STEP 4
C
ALLEN SCREW
M6 X 2” (50mm)
P
Allen wrench
Adult assembly
I
WOODEN DOWEL
STAIRCASE BOOKSHELF

Attach the end guard rail assemblies to the upper panel assemblies as shown below,
using wood screw (J), tighten with the Phillips head screwdriver. ( Customer supplied )
Page 6 of 13
END GUARD RAIL ASSEMBLIES
INSIDE VIEW
J
J
J
Note : Screw holes on end caps
go on inside of guard rails.
ZOOM IN
Attach the side rails (15) to the lower panels (13) using JCB M6 X 3 ½” (A), and barrel nut (F).
Tighten with the Allen wrench (P).
Full lower panel shown. Twin over Twin bunk use Twin lower panel.
A
F
P
JCB M6 X 3 ½”
Barrel nut
Allen wrench
A
A
A
F
F
F15
15
13
13
Customer supplied
Phillips screwdriver
J
WOOD SCREW
1 1/4”
STEP 5
Adult assembly
Adult assembly
STEP 6
STAIRCASE BOOKSHELF

Page 7 of 13
23
23
Lay the full slat kit (23) onto the bed. Fix in place using wood screws provided in the slat kit box.
FOR SLAT KIT ASSEMBLY follow assembly instructions included with slat kit.
Customer supplied
Phillips screwdriver
Insert metal pins (G) into the holes on top of the lower panels. Lift the upper panels onto the lower
panels as shown, and fit the metal pins into the holes in the bottom of the upper panel legs.
Full size shown
Twin lower panel uses Twin slat kit
G
G
G
G
G
G
G
This step requires
two strong people.
This step requires
two strong people.
CAUTION
!
Metal pins
G
TWIN / TWIN FULL / FULL
TWIN / FULL
GG
STEP 7
Adult assembly
Adult assembly
STEP 8
STAIRCASE BOOKSHELF

Insert wooden dowels (I) into the shelves (09)(10)(11) as shown below.
Insert wooden dowels (I) into the bottom drawer (17) and middle drawer (20) as shown below.
Page 8 of 13
I
WOODEN DOWEL
I
I
I
I
I
I
I
I
II
II
I
I
I
I
I
I
09
10
STEP 9
Adult assembly
I
WOODEN DOWEL
Adult assembly
STEP 10
11
17
20
20
STAIRCASE BOOKSHELF

C
ALLEN SCREW
M6 X 2” (50mm)
P
Allen wrench
Adult assembly
C
ALLEN SCREW
M6 X 2” (50mm)
P
Allen wrench
Adult assembly
Page 9 of 13
20
10
12
STEP 11
STEP 12
Attach the bottom shelf (09) to the bottom drawer (17) and back panel (12). Using Allen screw
M6 X 2” (C). Tighten with Allen wranch (P).
Attach the middle shelf (10) to the middle drawer (20) and back panel (12). Using Allen screw
M6 X 2” (C). Tighten with Allen wranch (P).
C
C
C
12
09
17
C
C
C
STAIRCASE BOOKSHELF

Page 10 of 13
STEP 13
STEP 14
C
ALLEN SCREW
M6 X 2” (50mm)
P
Allen wrench
Adult assembly
Attach the top shelf (11) to the middle drawer (20) and back panel (12). Using Allen screw
M6 X 2” (C). Tighten with Allen wranch (P).
Attach the top drawer (16) as shown below. Using wood dowels (I) and Allen screw M6 X 2” (C).
Tighten with Allen wranch (P).
20 11
12
C
CC
C
C
I
C
ALLEN SCREW
M6 X 2” (50mm)
P
Allen wrench
Adult assembly
I
WOODEN DOWEL
16
STAIRCASE BOOKSHELF

Page 11 of 13
STEP 15
STEP 16
E
ALLEN SCREW
M6 X 3 1/8” (80mm)
P
Allen wrench
Adult assembly
D
ALLEN SCREW
M6 X 1 5/8” (40mm)
P
Allen wrench
Adult assembly
Attach back guard rail (06) as shown below. Using Allen screw M6 X 3 1/8” (E).
Tighten with Allen wranch (P).
Attach side guard rail (07) as shown below. Using Allen screw M6 X 1 5/8” (D).
Tighten with Allen wranch (P).
06
E
E
D
D
D
07
STAIRCASE BOOKSHELF

Page 12 of 13
STEP 17
STEP 18
E
ALLEN SCREW
M6 X 3 1/8” (80mm)
P
Allen wrench
Adult assembly
Attach hand guard rail (08) as shown below. Using Allen screw M6 X 3 1/8” (E) and M6 X 1 5/8” (D).
Tighten with Allen wranch (P).
Attach special block full (19) as shown below. Using wood dowels (I) and Allen screw M6 X 2” (C).
Tighten with Allen wranch (P).
Note: Using special block twin (18)
for lower panel twin size.
08
E
E
D
D
D
I
C
I
19
D
ALLEN SCREW
M6 X 1 5/8” (40mm)
C
ALLEN SCREW
M6 X 2” (50mm)
P
Allen wrench
Adult assembly
I
WOODEN DOWEL
STAIRCASE BOOKSHELF

Congratulations!
Your staircase bunk bed is now ready for use.
We recommend that you double check that all screws are tight,
and that all parts are secure before use and periodically check that all screws are tight to ensure lasting safety.
Page 13 of 13
Move the bunk bed and staircase assemblies where you want to place them in the room.
Attach staircase assembly to the bunk bed assembly as shown below.
O
K
BMN
H
L
O
Wood screw
JCB M6 X 3/4”
Flat washer Flat bracket L bracket
BACK VIEW
Cap nut
D6 X 5/8”
Mini L-Bracket
Wood Button
Using mini L bracket (L), wood screw D6 X 5/8” (K). Using flat bracket (M), wood screw D6 X 5/8” (K).
Using L-Bracket (N), JCB M6 X 3/4”+ washer (B) and wood screw D6 X 5/8” (K).
Tighten with Allen wrench (P) and Phillips head screwdriver. (Customer supplied).
Lastly, cover holes with wood buttons (O)(Twin Full, Full Full ).
TWIN OVER FULL SHOWN
BK
H
O
K
LK
K
K
K
K
M
M
STEP 19
STAIRCASE BOOKSHELF
