RT-20
TORQUE CHART
This chart shows the correlation
between pump gauge psi reading
and torque output for your Rapid-Torc
RT-20 hydraulic torque wrench.
PSI FT.LB.
1500 2964
1600 3162
1800 3557
2000 3952
2200 4347
2400 4742
2600 5138
2800 5533
3000 5928
3200 6323
3400 6718
3600 7 11 4
3800 7509
4000 7904
4200 8299
4400 8694
4600 9090
4800 9485
5000 9880
5200 10275
5400 10670
5600 11066
PSI FT.LB.
5800 11461
6000 11856
6200 12251
6400 12646
6600 13042
6800 13437
7000 13832
7200 14227
7400 14622
760 0 15018
7800 15413
8000 15808
8200 16203
8400 16598
8600 16994
8800 17389
9000 17784
9200 18179
9400 18574
9600 18970
9800 19365
10000 19760
BAR NM
104 4019
110 4287
124 4822
138 5358
152 5894
165 6430
179 6966
193 7501
207 8037
220 8573
234 9109
248 9645
262 10181
276 10716
290 11252
303 11788
317 12324
331 12860
345 13395
358 13931
372 14467
386 15003
BAR NM
400 15539
414 16075
427 16610
441 17146
455 17682
468 18218
482 18754
496 19289
510 19825
524 20361
538 20897
552 21433
565 21969
579 22504
593 23040
607 23576
620 24112
634 24648
648 25184
662 25719
676 26255
690 26791
2
Set the pressure on the pump that
corresponds to the torque value.
1Find the closest torque value for
your application, either in ft-lbs
or in Nm.
FOOT-POUNDS NEWTON-METERS
RT-PTCen-RT-20 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised October 2014
The above torque values are only applicable when using a calibrated RT-20 hydraulic torque wrench powered by a 10,000 psi pump
fitted with a calibrated class 1 gauge.
All manuals and user guides at all-guides.com

QUICK SETUP
GUIDE
Setting up your hydraulic torque wrench for use is easy.
Please read the included user manual and safety instruc-
tion booklet for additional guidelines.
1
Wear personal protec-
tive equipment, such as
eyeglasses and steel-toe
shoes.
3
1
2
3
SET PRESSURE
Make sure the hoses are
free of any defects. The
couplers are on pump
and the tool should be
securely connected.
Place tool on at surface.
Turn pump on. Cycle the
tool. Press the “ON’ but-
ton on the remote, hold
until tool clicks. Release,
wait for the tool to click.
Repeat the cycle. Ensure
there is no leak.
4
Use the torque conver-
sion chart to set the psi
for the torque you need.
Press the remote’s “ON”
button and slowly turn
the pressure regulator
clockwise to reach the
right pressure.
FOUR BASIC STEPS TO OPERATE YOUR RT-20
2
4
Scan the code to see a brief overview video on how to use the document or go to
rapidtorc.com/torque_setup
RT-PTCen-RT-20 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised September 2014
CYCLE YOUR TOOL
CONNECT HOSES
WEAR PPE
