RT-1
TORQUE CHART
This chart shows the correlation
between pump gauge psi reading
and torque output for your Rapid-Torc
RT-1 hydraulic torque wrench.
PSI FT.LB.
1500 209
1600 222
1800 250
2000 278
2200 306
2400 334
2600 361
2800 389
3000 417
3200 445
3400 473
3600 500
3800 528
4000 556
4200 584
4400 612
4600 639
4800 667
5000 695
5200 723
5400 751
5600 778
PSI FT.LB.
5800 806
6000 834
6200 862
6400 890
6600 917
6800 945
7000 973
7200 10 01
7400 1029
760 0 1056
7800 1084
8000 111 2
8200 11 4 0
8400 11 6 8
8600 11 9 5
8800 1223
9000 1251
9200 1279
9400 1307
9600 1334
9800 1362
10000 1390
BAR NM
104 283
110 302
124 339
138 377
152 415
165 452
179 490
193 528
207 565
220 603
234 641
248 678
262 716
276 754
290 792
303 829
317 867
331 905
345 942
358 980
372 1018
386 1055
BAR NM
400 1093
414 11 3 1
427 11 6 8
441 1206
455 1244
468 1282
482 1319
496 1357
510 1395
524 1432
538 1470
552 1508
565 1545
579 1583
593 1621
607 1658
620 1696
634 1734
648 1772
662 1809
676 1847
690 1885
2
Set the pressure on the pump that
corresponds to the torque value.
1Find the closest torque value for
your application, either in ft-lbs
or in Nm.
FOOT-POUNDS NEWTON-METERS
RT-PTCen-RT-1 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised October 2014
The above torque values are only applicable when using a calibrated RT-1 hydraulic torque wrench powered by a 10,000 psi pump
fitted with a calibrated class 1 gauge.

QUICK SETUP
GUIDE
Setting up your hydraulic torque wrench for use is easy.
Please read the included user manual and safety instruc-
tion booklet for additional guidelines.
1
Wear personal protec-
tive equipment, such as
eyeglasses and steel-toe
shoes.
3
1
2
3
SET PRESSURE
Make sure the hoses are
free of any defects. The
couplers are on pump
and the tool should be
securely connected.
Place tool on at surface.
Turn pump on. Cycle the
tool. Press the “ON’ but-
ton on the remote, hold
until tool clicks. Release,
wait for the tool to click.
Repeat the cycle. Ensure
there is no leak.
4
Use the torque conver-
sion chart to set the psi
for the torque you need.
Press the remote’s “ON”
button and slowly turn
the pressure regulator
clockwise to reach the
right pressure.
FOUR BASIC STEPS TO OPERATE YOUR RT-1
2
4
Scan the code to see a brief overview video on how to use the document or go to
rapidtorc.com/torque_setup
RT-PTCen-RT-1 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised September 2014
CYCLE YOUR TOOL
CONNECT HOSES
WEAR PPE
