Atlona AT-HDVS-200-TX-WP User manual

The AT-HDVS-200-TX-WP is a 2×1 wall plate switcher for HDMI and VGA inputs with HDBaseT
output. It features a US, two-gang, Decora form factor with one HDMI and one VGA input with an
always-on 3.5mm audio connector. HDMI signals up to 4K/UHD @ 60Hz (YUV 4:2:0 color sub-sampling),
VGA input signals up to 1920×1200, embedded audio, and control signals can be extended up to
328 feet (100 meters). The switcher receives power from the AT-HDVS-200-RX scaler via Power over
Ethernet and together they create a standalone AV switching and control system with scaling for
classrooms and huddle rooms. Display control and volume commands are transmitted via CEC, IP,
or RS-232 to any display, control system, switcher or other controllable device.
• 1 x AT-HDVS-200-TX-WP (w/face plate - LAN port exposed)
• 1 x Captive screw connector (3 pin: RS-232)
• 1 x Face plate (w/LAN port covered)
• 1 x Installation Guide
Package Contents
AT-HDVS-200-TX-WP Installation Guide
Please check http://www.atlona.com/product/AT-HDVS-200-
TX-WP for the most recent firmware update or manual.
Two-Input Wall Plate Switcher
for HDMI and VGA with
Ethernet-Enabled HDBaseT
Output
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515

2
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
LINK
PWR
DISPLAY
INPUT
VOL -
VOL +
HDMI IN
VGA IN
AUDIO IN
RS-232
RX TX
Panel Description
1. INPUT button:Use to switch between VGA and HDMI sources
2. DISPLAY button:Can be programmed to perform different functions
Default action will turn video output on/off for the switcher
Send on/off command to CEC, RS-232, or TCP/IP controllable displays or other connected
devices
Sends RS-232 or TCP/IP trigger command when used with a compatible switcher
(e.g. CLSO PoE series)
3. PW LED:Will illuminate when receiving power
LINK LED:Illuminates when receiving signal from the receiver
4. VOLUME buttons:Adjust output volume of the switcher or connected device when programmed
Note: To mute or unmute output audio, press both volume buttons together. LED will turn red when muted
5. AUDIO IN port:Connect analog audio here
6. HDMI IN port:Connect HDMI source here
7. LAN (black) port:Connect network switch or router to this port for Ethernet, TCP/IP, or
webGUI control
8. VGA IN port:Connect VGA source here
9. RS-232 port:Connect control system to RS-232 port
10. HDBaseT (blue) port:Connect to an HDBaseT PoE receiver
e.g. AT-HDVS-200-RX or UHD-CLSO PoE series switcher/scalers
4 5
9
10
87
6
1
2
3
Note: To ensure compatibility, please be certain both transmitter and receiver have blue or blue bordered
HDBaseT ports. This ensures both products are PoE (48V) compliant. The HDVS-200-TX is not compatible
with PoCC (black RJ45, 24V) devices

3
Connecting
The captive screw connectors have
a contact bar that is adjusted to
compress the wire against the top
contact plate. Use the screws at the
top of the connector to compress
the wire against the contact plate.
When connecting the cables to the female captive screw connector it is important that the wires be
terminated correctly. The female captive screw connector has a contact plate at the top and must
have the wires touching it for signal to pass. When wired correctly (see picture A) the signal will pass,
incorrectly (see picture B) no signal will pass.
Clockwise Counter
Clockwise
Turn the screws clockwise to
raise the contact bar to the
upper contact plate and hold
the wires in place.
Turn the screws counter
clockwise to lower the
contact bar to release the
wires.
AB
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
RS-232 captive screw connector is included. RS-232 pin out will be determined by the RS-232
cable and will connect as Rx (receiver), Tx (transmitter), and (ground). (See picture 1)
RS-232
Typical pin out:
2 - TX - Transmitter
3 - RX - Receiver
5 - GND - Ground
Pin out color will differ
per RS-232 cable.
154 3 2
9876
1
RS-232
RS-232
RX TX
The captive screw connectors allow you to cut cables to a suitable length, reducing cable clutter
while providing a more reliable connection.
Captive Screw
Note: IP addresses may also be found using common free IP scanner software such as “Advanced IP Scanner”
*Atlona does not assume responsibility for damage caused by other programs installed onto a computer, verify programs before installing*
webGUI
Atlona has created an easy to use webGUI for setup and changes to the configuration of the
HDVS-200-TX-WP.
To begin, plug a LAN cable into the LAN port of the HDVS-200-TX-WP and the network switch,
then type the IP address of the unit into a web browser of a PC connected to the same network (as
seen below).
Important: If any stability issues are experienced, disable any anti-virus or firewall that may interfere with
network communication to the switcher. Once set up is done and the switcher webGUI is no
longer being used, the firewall and anti-virus can be re-enabled.

4
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
A login screen will appear (this is the same log in for admin and general users). For the first log in (and future
admin changes) the username is “root” and password is “Atlona”.
Note: Only the admin password can be changed (see User Manual). The username will always remain “root”.

5
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
LINK
PWR
DISPLAY
INPUT
VOL -
VOL +
HDMI IN
VGA IN
AUDIO IN
RS-232
RX TX
Connection Diagram (with HDVS-200-RX)
Video
HDBaseT
Audio
Ethernet
Dry CC
Control
AT-HDVS-200-TX-WP
Laptop
FW
RELAY
AT-HDVS-200-RX
C1 C2COM
HDBaseT INLAN HDMI OUT
L1
-+-
+
R2
RX RXTX TX
AUDIO RS-232 MENU AUTO
^
^
PW
LINK
-+
DC 48V
ROUTER
2.4 5 1234
i
AT-PA100-G2
Drop down projector screen
(contact closure controlled)
AT-HDVS-200-RX
Router
Projector
Dry CC
Audio
HDBaseT
Video Control
Ethernet
Audio
Video
Document Camera
Audio Video

6
atlona.com Toll free: 1-877-536-3976
Local: 1-408-962-0515
LINK
PWR
DISPLAY
INPUT
VOL -
VOL +
HDMI IN
VGA IN
AUDIO IN
RS-232
RX TX
Connection Diagram (with PoE UHD-CLSO series)
Video
HDBaseT
Audio
Ethernet
LAN
1
12 1 2
34LRL R
2 3 4
INPUT
AT-UHD-CLSO-824
OUTPUT
5 6 7 8
RX
RS-232 MIC/LINE IN
LINE
MIC
48V
AUDIO IN
TX RX TX RX TX RX TX +-+ +
PWRIR
- -
+ - + -
<
<
DC 48V
-+
FW
RS-232IRAUDIO OUT
MASTER
OUTIN
RX TX
+-+-
56
12 3 4
5ENTER
MENU
678
RX TX RX TX
78
8
1
12
2
RS-232
RX TX RX TX
910
RX TX RX TX
LINE
MIC
48V
+-+-
L R
+-+-
AUDIO OUT
FW LINK
POWER
AT-UHD-EX-100CE-RX
RS-232
RXTX
IR IN
PS
IR OUT
S
HDBaseT IN
ETHERNET
HDMI OUT
ROUTER
2.4 5 1234
i
Router
AT-UHD-EX-100CE-RX
AT-UHD-CLSO-824
Display
HDBaseT
Ethernet
Ethernet
HDBaseT
Audio Video
Video
Video
AT-HDVS-200-TX-WP
Laptop
Document Camera

7
Troubleshooting
1. The Auto-Switch feature isn’t working. How do I enable it?
You can enable Auto-switching by using the AutoSW on command via TCP/IP or RS-232, or
through the WebGU.
2. I want to pass only analog audio without video. How do I do this?
Place the unit in “standalone” mode. This mode can be enabled using the FreeRun on
command via TCP/IP or RS-232, or through the webGUI.
3. How do I update the firmware?
The firmware can be updated using the USB port or through the webGUI.
4. How do I find the IP address?
Run the IPCFG command using either RS-232 or TCP/IP. You can also get the IP address
through the webGUI and AMS.
5. How do I switch between DHCP and Static IP modes?
For the AT-HDVS-200-TX, DHCP can be turned on/off by pressing the INPUT button for 15
seconds. For the AT-HDVS-200-RX, DHCP can be turned on/off by pressing the AUTO button
for 15 seconds. You can also toggle between DHCP and Static IP modes using the IPDHCP
command via TCP/IP or RS-232, or by using the webGUI or AMS.
6. What is the default IP address?
The default static IP address is 192.168.1.254. Please note that the default static IP for both
the wall plate/transmitter (HDVS-200-TX-WP) and the receiver (HDVS-200-RX) are the same.
7. I can’t control my display. What’s wrong?
First, check that the desired control method is selected (TCP/IP, RS-232, or CEC). If you are
using RS-232, make sure that the baud rate for RXZone 1 (found under the webGUI)
matches your display settings. The baud rate can be set through the webGUI or by using the
RxRSparaZ1 command via TCP/IP or RS-232. When using the RxRSparaZ1 command, use the
following syntax: RxRSparaZ1[baudrate,data-bits,parity,stop-bits].
Example: RxRSparaZ1[115200,8,0,1]
