Atmel CAP AT91CAP7X-DK User manual

The AT91CAP7X-DK development board implements the fixed portion of the AT91CAP7 device as a
microcontroller standard product, tightly coupled to a high-density FPGA that emulates the MP Block.
The boards also include a range of memories and physical interfaces/connectors representing
external system components. This configuration enables parallel hardware/software testing of
the application under development at close to operational speed, with no
penalty for hardware modifications. This enables software development
to proceed in parallel with hardware development, and significantly
reduces the design cycle time, increasing confidence in a right-first-time
system solution.
The AT91CAP7X-DK development board or “kit” is composed of three
associated boards, namely Motherboard, Mezzanine and Memory
Extension to be used jointly in order to develop AT91CAP7 processor
applications.
AT91CAP7X-DK Motherboard
The AT91CAP7X-DK motherboard features the following on-board interfaces:
AT91CAP7X-DK Development Kit
for CAP Customizable Microcontroller
CAPTM CUSTOMIZABLE MICROCONTROLLERS
nATX power supply connector
n2x Full-speed Host USB interfaces
n100-base TX Ethernet PHY with three status
LEDs
nDBGU serial communication port
n4x analog inputs
nAC97 interface with three 3.5 mm audio jack
connectors (MIC IN, LINE IN, LINE OUT)
nI2S audio codec with two 3.5 mm audio jack
connectors (LINE IN, LINE OUT)
n2x SD/MMC card slots
nAtmel TWI serial EEPROM
n1/4 inch TFT LCD VGA interface
nTouch Screen Controller
nImage Sensor expansion connector
n16 push buttons arranged in a keypad form
nCAN bus interface
nSoftware controlled Power LED
n2x general-purpose LEDs
nPIO expansion connectors (PIOA, PIOB, PIOC,
PIOD)
nCAP Mezzanine extension connectors
(2x 320 pins)
nPCI64 form FPGA I/O extension connector
nCustom mezzanine-style FPGA I/O extension
connector
n3x USB device PHY interfaces with USB B
connectors (FPGA controlled)

Headquarters
Atmel Corporation
2325 Orchard Parkway
San Jose, CA 95131
USA
TEL [phone]
FAX [phone]
International
Atmel Asia
Room 1219
Chinachem Golden Plaza
77 Mody Road Tsimshatsui
East Kowloon
Hong Kong
TEL [phone]
FAX [phone]
Atmel Europe
Le Krebs
8, Rue Jean-Pierre Timbaud
BP 309
78054 St.-Quentin-en-Yvelines
Cedex, France
Tel: [phone]
Fax: [phone]
Atmel Japan
9F, Tonetsu Shinkawa Bldg.
1-24-8 Shinkawa
Chuo-ku, Tokyo 104-0033
Japan
TEL [phone]
FAX [phone]
Product Contacts
Technical Support
www.atmel.com/products/AT91CAP
Sales Contacts
www.atmel.com/contacts
Web Site
www.atmel.com
© 2008 Atmel Corporation.
All rights reserved.
Atmel®, logo and combinations thereof,
and others, are registered trademarks,
CAP™ and others are trademarks of
Atmel Corporation or its subsidiaries.
ARM®and ARM7TDMI®are registered
trademarks of ARM Ltd. Other terms
and product names may be trademarks
of others.
REV.: 8522A-03/08
Disclaimer: The information in this document is provided in connection with Atmel products. No license, express or implied, by estoppel or otherwise, to any intellectual property right is granted by this document or in connection with
the sale of Atmel products. EXCEPT AS SET FORTH IN ATMEL’S TERMS AND CONDITIONS OF SALE LOCATED ON ATMEL’S WEB SITE, ATMEL ASSUMES NO LIABILITY WHATSOEVER AND DISCLAIMS ANY EXPRESS, IMPLIED OR
STATUTORY WARRANTY RELATING TO ITS PRODUCTS INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NON-INFRINGEMENT. IN NO EVENT SHALL
ATMEL BE LIABLE FOR ANY DIRECT, INDIRECT, CONSEQUENTIAL, PUNITIVE, SPECIAL OR INCIDENTAL DAMAGES (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF PROFITS, BUSINESS INTERRUPTION, OR LOSS OF
INFORMATION) ARISING OUT OF THE USE OR INABILITY TO USE THIS DOCUMENT, EVEN IF ATMEL HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Atmel makes no representations or warranties with respect to the
accuracy or completeness of the contents of this document and reserves the right to make changes to specifications and product descriptions at any time without notice. Atmel does not make any commitment to update the information
contained herein. Unless specifically provided otherwise, Atmel products are not suitable for, and shall not be used in, automotive applications. Atmel’s products are not intended, authorized, or warranted for use as components in applications
intended to support or sustain life.
AT91CAP7X-DK Development Kit
for CAP Customizable Microcontroller
The CAP Customizable Microcontroller
Atmel’s CAP is an ARM microcontroller-based system-on-chip with fast local memory, a wide range
of industry standard peripherals and interfaces, and a Metal Programmable (MP) Block that allows the
designer to add custom logic. By combining the performance, density and low power consumption of
the fixed portion of the device with the flexibility of the MP Block, CAP enables application-specific
products to be developed in a fraction of the time and at a fraction of the cost of standard-cell ASICs,
but at a unit price close to that of standard cell devices. CAP also offers superior performance, smaller
form factor and lower power consumption at a unit price significantly lower than an MCU-plus-FPGA
combination for the same functionality.
AT91CAP7X Features
n160 KB of fast on-chip SRAM
nA large MP Block of 450K ASIC gates (2-input NAND equivalents)
nMicro Core = ARM7TDMI®at 80 MHz
nMPRAM = 2x DPRAM 2K x 16
nROM = 256 KB
nA minimal number of ARM peripherals are instantiated in the fixed portion
of the design to address low cost applications
nFlexibility to instantiate other peripherals in the MP Block using IP
available in Atmel's vast library
