Atmos LC 27 User manual

Operating Instructions
ATMOS LC 27
ATMOS LC 27 Battery
English
2022-03 Index 10
GA1GB.310301.0
E349855

2
Table of contents
1.0 Introduction.....................................................4
1.1 Notes on operating instructions ...................................... 4
1.2 Explanation of pictures and symbols .................................. 5
1.3 Intended use ...................................................... 8
1.4 Function ......................................................... 10
1.5 Intended users.................................................... 11
1.6 Scope of delivery .................................................. 11
1.7 Transport and storage ............................................. 13
2.0 Notices for your safety ..........................................14
2.1 General safety instructions ......................................... 14
2.2 Danger for users, patients and third parties........................... 14
2.3 Avoiding damage to the device...................................... 16
3.0 Setting up and starting up .......................................17
3.1 Device overview................................................... 17
3.1.1 Front/rear view (with single-patient secretion canister system)........ 17
3.1.2 Front/rear view (with Serres®secretion canister system).............. 18
3.1.3 Front/rear view (with Medi-Vac®secretion canister system) ........... 19
3.1.4 Control panel .................................................. 20
3.1.5 Hose connection DDS ........................................... 20
3.2 Prepare the device with the single-patient secretion canister ............ 20
3.3 Prepare the device with the disposable system Serres®or Medi-Vac®..... 21
3.4 Charging the battery .............................................. 22
3.5 Charging using the mains power unit ................................ 22
3.6 Connecting and removing single-patient secretion canister system and hoses22
3.6.1 Connecting the single-patient secretion canister system ............. 22
3.6.2 NotesontheDDSbacterialandviralltercartridge ................. 24
3.6.3 RemovingtheDDSbacterialandviralltercartridge ................ 24
3.6.4 InsertingtheDDSbacterialandviralltercartridge ................. 24
3.6.5 ConnectingthesuctionhosewithDDSadapterandngertip ......... 25
3.6.6 Connecting the DDS hose adaptor ................................ 25
3.6.7 Holder for suction hose ......................................... 25
3.7 Connecting the Serres®secretion canister system ...................... 26
3.7.1 Connection .................................................... 26
3.7.2 Removal ...................................................... 27
3.7.3 NotesontheDDSbacterialandviralltercartridgefordisposablesystem28
3.8 Connecting the Medi-Vac®secretion canister system ................... 29
3.8.1 Connection .................................................... 29
3.8.2 Removal ...................................................... 30
3.8.3 NotesontheDDSbacterialandviralltercartridgefordisposablesystem31

3
4.0 Operation ......................................................32
4.1 Switching on the device ............................................ 32
4.2 Switchothedevice............................................... 32
4.3 Vacuum adjustment ............................................... 32
4.4 Suction .......................................................... 33
4.5 After use ......................................................... 33
4.5.1 Removing the single-patient secretion canister system .............. 34
4.5.2 RemovingthesuctionhosewithDDSadapterandngertip .......... 34
4.5.3 Removing the DDS hose adaptor ................................. 34
5.0 Cleaning and disinfection ........................................35
5.1 Safety instructions for reprocessing.................................. 35
5.1.1 General safety instructions ...................................... 35
5.1.2 Danger for users, patients and third parties........................ 35
5.1.3 Avoiding damage to the device ................................... 35
5.2 Preparing/completing reprocessing .................................. 36
5.3 Prepare surfaces .................................................. 37
5.3.1 Overview ...................................................... 37
5.3.2 Select process chemicals ........................................ 37
5.3.3 Pre-cleaning ................................................... 38
5.3.4 Wipe cleaning.................................................. 38
5.3.5 Wipe disinfection............................................... 38
5.4 Reprocessing the accessories ....................................... 38
5.4.1 Replacing accessories ........................................... 38
6.0 Maintenance and service ........................................41
6.1 Function check.................................................... 41
6.2 Sending in the device .............................................. 41
6.3 Handling batteries................................................. 41
7.0 Troubleshooting ................................................42
8.0 Accessories and consumables ....................................44
8.1 Accessories....................................................... 44
8.2 Consumables ..................................................... 44
9.0 Disposal/recycling ..............................................45
9.1 Expected service life ............................................... 45
10.0 Technical data ..................................................46
10.1 ATMOS LC 27 ..................................................... 46
10.2 ATMOS LC 27 Battery .............................................. 47
10.3 DDSbacterialandviralltercartridge................................ 48
11.0 Notes on EMC ..................................................49
12.0 Notice .........................................................50

4Introduction
1.0 Introduction
1.1 Notes on operating instructions
These operating instructions contain important notes on how to
operate the ATMOS LC 27 and ATMOS LC 27 Battery safely, correctly
andeectively.
These operating instructions are designed for training and instructing
new operating personnel in the use of the system, and also for use as
a reference manual. This document may only be reprinted, either in
part or in whole, with written permission from ATMOS.
These operating instructions must always be kept available near
the device.
Care, period tests, regular cleaning and proper application are
essential. They guarantee the operational safety and usability of the
ATMOS LC 27 and ATMOS LC 27 Battery.
Maintenance, repairs and period tests may only be carried out by
persons who have the appropriate technical knowledge and are
familiar with the product. The person in question must possess the
necessary test devices and original spare parts required to carry out
these measures.
§
Read chapter “2.0 Notices for your safety” on page 14 before using
thedeviceforthersttime.Thiswillhelpyoutoavoidpotentially
dangerous situations.
The ATMOS LC 27 and ATMOS LC 27 Battery bear the CE marking CE
in accordance with the European Medical Device Regulation (MDR)
2017/745.
The products ATMOS LC 27 and ATMOS LC 27 Battery comply with
all applicable requirements of the directive 2011/65/EC restricting
the use of certain hazardous substances in electrical and electronic
equipment (“RoHS”).
The Declaration of Conformity and our general standard terms and
conditions can be viewed on our website at www.atmosmed.com.
ThequalitymanagementsystematATMOShasbeencertied
according to international standard EN ISO 13485.
These operating instructions are valid for the following devices:
Mains-powered suction devices:
ATMOS LC 27 / DDS 321.1000.0
ATMOS LC 27 / DDS Universal 321.1300.0
ATMOS LC 27 / Serres®321.1100.0
ATMOS LC 27 / Medi-Vac 321.1200.0
Battery-powered suction devices:
ATMOS LC 27 Battery / DDS 321.2000.0

5
Introduction
ATMOS LC 27 Battery / DDS Universal 321.2300.0
ATMOS LC 27 Battery / Serres®321.2100.0
ATMOS LC 27 Battery / Medi-Vac®321.2200.0
1.2 Explanation of pictures and symbols
In the operating instructions
DANGER
Warning of a danger that will result in immediate fatal or serious injury. Observe the
necessary measures.
WARNING
Warning of a danger that can cause fatal or serious injury. Observe the necessary
measures.
CAUTION
Warning of a danger that can cause minor injury. Observe the necessary measures.
NOTICE
Notice of a danger that can damage the product or other objects. Observe the
necessary measures.
Warning of a danger that can cause fatal or serious injury.
Notice of potential material damage.
Useful information on the handling of the device.
1. Action. Proceed step by step.
• Numeration.
»Result of an action.
Move, plug in this direction.
click Engage,checkcorrectt.
On device, type plate, and packaging
Follow operating instructions (blue)
Consult operating instructions
Warning; pay special attention
This device complies with the relevant requirements of EU regulations.
This device complies with the relevant requirements of EU regulations.

6Introduction
E349855
UL listing test label
MEDICAL — GENERAL MEDICAL EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND MECHANICAL HAZARDS ONLY IN ACCORDANCE WITH
ANSI/AAMI ES60601-1 (2005) + AMD 1 (2012)
CAN/CSA-C22.2 No. 60601-1 (2014)
IEC 60601-1-6 (2013)
ANSI/AAMI HA60601-1-11 (2015)
Manufacturer
CC
Date of manufacture
Country of manufacture
Distributor
REF Reference number
UDI UniqueDeviceIdentierofamedicaldevice
MD Medical device
SN Serial number
LOT Batch code
Expiry date
IP21
Protected against ingress of:
• SolidforeignparticlesØ≥12.5mm
• Dripping water from above
Application part type BF
Professional disposal
Not for reuse (designed for repeated use for a single patient)
NON
STERILE
Not sterile
PATIENT Connection for suction hose/patient
Device does not contain latex
Short-term operation (max. 30 minutes ON, min. 30 minutes OFF)
Protection class II device

7
Introduction
On/Obutton
Direction of vacuum setting
-min. vacuum setting
+max. vacuum setting
Fragile, handle with care
Keep dry
Keep away from sunlight
Temperature limit
Humidity limitation
700
1060
Atmospheric pressure limitation
Do not use if the packaging is damaged
UDI application identier
(01) UDI-DI:Identicationofthemanufacturerandthedevice
(10) Batch code
(11) Date of manufacture
(17) Expiry date
(21) Serial number
(30) Quantity in pieces
On the battery
This product complies with the relevant requirements of the EU Directives.
Contains lead, recyclable

8Introduction
Contains lead, dispose of professionally
Certicationmarking(RecognizedComponentMark)
On the mains power unit
Protection class II
Professional disposal
This product complies with the relevant requirements of the EU Directives.
Devices with this symbol may only be used indoors (dry surroundings)
IP52
Protected against:
• Dust in harmful quantities
• Dripping water from above when the housing is tilled up to 15°
Safety test seal
1.3 Intended use
Name: ATMOSLC27
• ATMOS LC 27 / DDS
• ATMOS LC 27 / Serres®
• ATMOS LC 27 / Medi-Vac®
• ATMOS LC 27 / DDS Universal
ATMOS LC 27 Battery
• ATMOS LC 27 Battery / DDS
• ATMOS LC 27 Battery / Serres®
• ATMOS LC 27 Battery / Medi-Vac®
• ATMOS LC 27 Battery / DDS Universal
Main functions: Temporary and spontaneous suction of suction material
(includingsecretions,blood,serumuids,foodparticles)from
the oral cavity, pharynx and bronchial system
Suction during ENT treatments.
Intended use: Suction of the upper and lower respiratory tract as well as in
the ear.
Intended users /
User prole:
• Trained medical personnel
• Non-medical users, e.g. patients and/or relatives (after
medical instruction)

9
Introduction
Intended Patient
population:
Patients of all ages with and without restrictions
Disease state to be
diagnosed, treated
or monitored:
Not applicable
Application organ: • Upper respiratory tract (nose, nasal cavity, pharynx)
• Lower respiratory tract (larynx, trachea, bronchial system)
• Ear
Application time: Temporary use on the patient (<60 min)
Area of application: • Home (homecare sector)
• Outpatient and hospital care
Criteria for patient
selection:
• Patientswhowillbenetfromupper/lowerrespiratory
tract suction
• PatientswhowillbenetfromsuctionduringENT
treatments.
Indications: In case of damage to respiratory and cough function
with disturbance of tracheal, bronchial or oral secretion
elimination:
• Suction during tracheotomy
• Suction during laryngectomy
• Suction if breathing is impeded
Suction for muscular and/or neurological disorders:
• Suction if swallowing is impeded
• Suction of blood, secretions and food particles from the
oral cavity, pharynx and bronchial system
• Suction during ENT treatments.
Medical contra-
indications:
Not suitable for:
• Continuous operation for drainage procedures in the low
vacuum range (e.g. cardiothoracic or wound drainage)
• Permanent endoscopic use
• Vacuum extraction
• Smoke evacuation
• Liposuction
• Emergency and rescue use
Other
contraindications:
Not suitable for:
• Suction outdoors/during transport
• Suctionofammable,corrosiveorexplosivesubstances
• Suction in potentially explosive areas

10 Introduction
Warning notes: The following complications may occur during suction:
• Bleeding in the nasal pharyngeal area
• Injury to the vocal cords
• Tracheal injury
• Hypoxemia
• Cardiovascular instability
• Bradycardia, arrhythmia and asystole (caused by vagus
stimulation)
• Tachycardia (caused by stress)
• Choking, nausea, vomiting and coughing
• Nosocomial infection of the respiratory tract
• Seizures in patients who tend to develop cramps
The product is: active
Sterility / specic
microbial condition:
Product not sterile
Single-use product /
reprocessing:
The product is intended for multiple use. The device and parts
of the accessories are conditionally reusable. For information
on reprocessing, cleaning and disinfection, please see the
operating instructions.
1.4 Function
General description
The devices are mobile, portable medical suction devices designed for temporary,
preferably spontaneous suction of the upper and lower respiratory tract. The suction
material(includingsecretion,blood,serumuids,andfoodparticles)willbetemporarily
collected in a collecting container and then disposed of.
Principles of operation and its moed of action
Thedevicesareelectricaloperatedandtakestheirmedicaleectbygeneratingvacuum
and suction performance. The devices are operated by an electromotive mainte-
nance-free piston pump.
The products have a suction capacity of max. 27 l/min ± 3 l/min and can build up a max.
vacuum of -80 kPa ± -5kPa (-800 mbar ± -50 mbar; -600 mmHg ± -37.5 mmHg).
The ATMOS LC 27 is a mains-powered bronchial suction unit, operation of which
requires the mains power unit (100 - 240 V) to be connected to the power supply grid.
The ATMOS LC 27 Battery is a bronchial suction device powered by a rechargeable
battery, which can be operated either using the permanently installed rechargeable
battery or an external DC power supply (13.8 V) as desired. To charge the battery, the
mains power unit (100 - 240 V) needs to be plugged into the power supply grid.
Thedevicesaredesignedforshort-termoperation.Thedevicesmustbeswitchedo
after no more than 30 minutes to prevent them from overheating. They must remain
switchedoforaperiodofatleast30minutestoensureadequatecooling.
During operation the pump generates a vacuum inside the single-patient secretion
canisterandhosesystem,thussuckingosecretion,bloodandbodyuidsaswell
asliquidandsolidpiecesoffood.Theuidiscollectedinthesingle-patientsecretion
canister.
Thevacuumsettingallowsyoutoinnitelyadjustthenalvacuumandthusthesuction
capacity. The vacuum gauge shows the set vacuum.

11
Introduction
The ATMOS LC 27 and the ATMOS LC 27 Battery cannot be operated when in motion
and therefore need to be kept stationary when operated.
Single-patient secretion canister (DDS):
The single-patient secretion canister is fastened to the side of the device and connects
directly to the suction unit by means of the Direct-Docking-System (DDS). The user
then merely needs to connect the suction hose to the lid of the single-patient secretion
canister.ADDSbacterialandviralltercartridgewithahydrophobicbacterialandviral
lterinstalledinthedevicepreventsbacteria,virusesandliquidsfromenteringthe
device.
Key features:
• Vacuum generation (high vacuum)
• Suctioncapacity(highow)
1.5 Intended users
The ATMOS LC 27 or ATMOS LC 27 Battery may be operated by the patient themselves,
a patient’s relative, the mobile care service, a nurse or trained medical personnel.
Suction is performed after the patient or the assistant / caregiver has been instructed
byadoctor,takingintoaccountthespecicvacuumrequireddependingontheage.
Prior to application, the user must be familiar with the device. Please note the country-
specicrequirementsandregulations.
ATMOS recommends: Instruction on the operation of the device must be performed by
an authorized person.
1.6 Scope of delivery
Please compare the contents on completeness immediately upon receipt (see
delivery note).
321.1000.0 ATMOS LC 27 / DDS
1 x basic device
1 x single-patient secretion canister system 321.0300.0
1xDDSbacterialandviralltercartridge(1pc.) 321.0027.0
1xsuctionhosewithDDSadapterandngertip(1pc.) 321.0100.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0
321.1300.0 ATMOS LC 27 / DDS Universal
1 x basic device
1 x single-patient secretion canister system 321.0300.0
1 x DDS hose adapter (1 pc.) 321.0040.0
1xDDSbacterialandviralltercartridge(1pc.) 321.0027.0
1 x suction hose, silicone, Ø 6 mm, L = 1.30 m, (1 pc.) 000.0013.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0

12 Introduction
321.1100.0 ATMOS LC 27 / Serres®
1 x basic device
1 x support for canister system Serres®321.0032.0
1 x canister extension for the use of disposable systems 321.0033.0
1 x Serres®outer canister 1 l 312.0465.0
1 x vacuum hose Serres®(14.5 cm) 006.0009.0
1xDDSbacterialandviralltercartridgefordisposablesystem 321.0034.0
10xsuctionhosewithfunnelandngertip 006.0057.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0
321.1200.0 ATMOS LC 27 / Medi-Vac®
1 x basic device
1 x support for canister system Medi-Vac®321.0036.0
1 x canister extension for the use of disposable systems 321.0033.0
1 x Medi-Vac®outer canister 1 l 312.0473.0
1 x vacuum hose Medi-Vac®(22 cm) 006.0009.0
1xDDSbacterialandviralltercartridgefordisposablesystem 321.0034.0
10xsuctionhosewithfunnelandngertip 006.0057.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0
321.2000.0 ATMOS LC 27 Battery / DDS
1 x basic device
1 x single-patient secretion canister system 321.0300.0
1xDDSbacterialandviralltercartridge(1pc.) 321.0027.0
1xsuctionhosewithDDSadapterandngertip(1pc.) 321.0100.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0
321.2300.0 ATMOS LC 27 Battery / DDS Universal
1 x basic device
1 x single-patient secretion canister system 321.0300.0
1 x DDS hose adapter (1 pc.) 321.0040.0
1xDDSbacterialandviralltercartridge(1pc.) 321.0027.0
1 x suction hose, silicone, Ø 6 mm, L = 1.30 m, (1 pc.) 000.0013.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0
321.2100.0 ATMOS LC 27 Battery / Serres®
1 x basic device
1 x support for canister system Serres®321.0032.0

13
Introduction
1 x canister extension for the use of disposable systems 321.0033.0
1 x Serres®outer canister 1 l 312.0465.0
1 x vacuum hose Serres®(14.5 cm) 006.0009.0
1xDDSbacterialandviralltercartridgefordisposablesystem 321.0034.0
10xsuctionhosewithfunnelandngertip 006.0057.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0
321.2200.0 ATMOS LC 27 Battery / Medi-Vac®
1 x basic device
1 x support for canister system Medi-Vac®321.0036.0
1 x canister extension for the use of disposable systems 321.0033.0
1 x Medi-Vac®outer canister 1 l 312.0473.0
1 x vacuum hose Medi-Vac®(22 cm) 006.0009.0
1xDDSbacterialandviralltercartridgefordisposablesystem 321.0034.0
10xsuctionhosewithfunnelandngertip 006.0057.0
1 x ATMOS mains power unit 011.1363.0
1 x operating instructions GA1DE.310301.0
Not included in the scope of delivery:
• ATMOS LC 27 bag (321.0350.0)
• ATMOS LC 27 / DDS consumables set, 10 pcs. (321.0340.0)
• Serres®disposable suction liner 1 l, without gelling agent (321.0466.0)
• Serres®disposable suction liner 1 l with gelling agent (312.0467.0)
• Medi-Vac®disposable suction liner 1 l (312.0474.0)
1.7 Transport and storage
Onlytransportthedeviceinashippingcartonthatispaddedandoerssucient
protection.
If damage occurs during transport:
1. Document and report the transport damage.
2. Fill in the form QD 434 “delivery complaint/return shipment”.
3. Send the device to ATMOS (chapter “6.2 Sending in the device” on page 41).
Ambient conditions for transport and storage:
• Temperature: -30...+70° C
• Relative humidity: 5...90%
• Air pressure: 700...1060 hPa

14 Notices for your safety
2.0 Notices for your safety
The safety of the ATMOS LC 27 and the ATMOS LC 27 Battery complies with all the
recognized rules of technology and the guidelines of the Medical Products Law.
2.1 General safety instructions
Report all serious incidents that have occurred in connection with this product to the
manufacturer and your national competent authority.
Make yourself familiar with the device in good time, so that you are capable of
operating it when it is needed.
The product will only meet the safety requirements of users, patients and third
parties when it is fully functional. Therefore read the following instructions
carefully:
Never operate the device if it shows any obvious safety defects.
2.2 Danger for users, patients and third parties
WARNING
Ensure that the device is always operational and ready for use!
Thepatientcouldsuocate.
• Ensure that the device is always ready for use.
• Place the device where it will be easily accessible.
• Make sure that the mains power unit is working.
• Always carry out a function check before using the device.
• ATMOS recommends always having another suction device ready to hand in case of
any device failure.
• Observe the notes on electromagnetic compatibility (EMC).
• Only use the recommended original accessories and original spare parts.
WARNING
Avoid misuse!
Risk of severe injury to your patient.
• Use the device only as intended.
• Never use the device for low-vacuum suction.
• Too many suction operations may cause minor bleeding.
• Always observe the applicable guidelines.
• Using the device on children requires a lower vacuum setting. Observe the
instructions issued by the attending physician.
• Observe the notes on hygiene and cleaning.
WARNING
Reduce the risk of infection for you and your patients!
Risk of deadly diseases being transmitted.
• Always wear disposable gloves.
• Never use components which are marked with 2more than once.
• Always use a suitable sterile catheter for suction. The suction hose must never
come into direct contact with the application site.
• Sterile packaged parts may only be used when the packaging is undamaged.

15
Notices for your safety
• NeveroperatethedevicewithoutDDSbacterialandvirallter.Alwayscheckthat
thebacterialandvirallterintheDDSbacterialandviralltercartridgeisdryand
clean before using the device to ensure that it will operate correctly.
WARNING
Protect yourself against an electric shock!
Damage from incorrect power supply.
• Risk of burns, cardiac arrhythmias and even fatal injury.
• Before switching on the device, make sure that the power supply grid is designed
for connecting a device that operates in the range from 100 - 240 VDC at a grid
frequency of 50/60 Hz. Use only the included mains power unit for the device (type:
GTM46402-3713.4).
• Do not operate the device in damp rooms, bathrooms or shower cubicles. Keep the
mains power unit, control panel and mains power connection point dry.
• Do not use the device in areas where there could be a torrent of water.
• Neversubmergethedeviceinwaterorotheruids.
• Do not operate the device if it has been dropped. In this case clean the device and
send it in to ATMOS for repair.
• Disconnect the device from the mains power supply prior to cleaning or
disinfection.
• Always check the device and power cable for damage before use. Do not operate
the device if you notice any damage. In this case clean the device and send it in to
ATMOS for repair.
• Ensure that no liquid penetrates the device. If liquid enters the device, operation of
the device must cease immediately. In this case clean the device and send it in to
ATMOS for repair.
• The ATMOS LC 27 and ATMOS LC 27 Battery are not suitable for sterilisation.
• Only use the mains power unit in dry surroundings.
• Only use the mains power unit according to the operating instructions.
• Only use original accessories and original spare parts from ATMOS.
• Observethespecicationsregardingperiodtestsinchapter“6.0 Maintenance and
service” on page 41.
• Assembly, new settings, alterations, extensions and repairs may only be carried out
by authorised persons.
• Do not modify the device without the manufacturer’s permission.
WARNING
Explosion and re hazard!
There is a risk of burns and injuries.
• Neversuctionanyexplosive,ammableorcorrosivegasesorliquids.Refertothe
explanations under intended use.
• Never operate the device in potentially explosive areas or areas which are
oxygenated.
• Only use original accessories and original spare parts from ATMOS.
WARNING
Risk of suocation or strangling for children and animals through accessory
parts!
Smallpartsmaycausechildrenoranimalstosuocateorbeinjured.

16 Notices for your safety
• Hoses or power cables may strangle people or animals, especially if the hoses or
cables are particularly long.
• Keep unauthorised persons away from the device during suction.
• Keep children away from swallowable small parts.
• Keep the device and all its accessories out of reach of children when not using it.
WARNING
Contact may cause allergic reactions!
The materials used have been tested for their tolerability. In very rare cases, contact
with accessible materials on the device and its accessories may cause allergic reactions.
This applies in particular to contact injuries in conjunction with prolonged contact. If
this occurs, seek medical attention immediately.
WARNING
Tripping hazard from cables!
Injuries and fractures are possible.
• Lay connecting cables properly.
2.3 Avoiding damage to the device
NOTICE
Damage to device from heat build-up!
Risk of damage to the device.
• Do not cover the device during suction.
• Keep the device and the mains power unit away from other heat sources.
• Do not place the device directly next to other devices as this may cause excessive
heating of the device.
NOTICE
Storage and operation in an unsuitable environment!
Risk of damage to the device.
• Please observe the ambient conditions regarding transport, storage, operation and
recharging of the battery.
• After transporting the device at low temperatures, keep the device at room
temperature for at least six hours before initial start-up. If the device has not
acclimatised,itmaysuerinternaldamage.
NOTICE
Damage to the device through improper use!
The device may become damaged.
• Ensure that no liquid penetrates the device. In case that liquid has penetrated the
device it may no longer be operated. In this case clean the device and send it in to
ATMOS for repair.
• Alwaysplacethedeviceonrm,levelsurface.Thedevicemustalwaysbeina
vertical position, when you use it.
• Only use mains power units and extension cables that are in perfect condition.

17
Setting up and starting up
3.0 Setting up and starting up
Pleaseobservethatinsucientbatterychargecanresultindamagetothebattery.
1. Fully charge the battery for the ATMOS LC 27 Battery before using the device.
3.1 Device overview
3.1.1 Front/rear view (with single-patient secretion canister system)
Front view






Control panel
Carrying handle
Vacuum gauge
Vacuum adjustment (from - to +)
Single-patient secretion canister lid
Single-patient secretion canister
Rear view


Brief instructions
Connection for the mains power unit/
car connecting cable
Single-patient secretion canister system



Connection for suction hose
Single-patient secretion canister lid
Single-patient secretion canister

18 Setting up and starting up
3.1.2 Front/rear view (with Serres®secretion canister system)
Front view








11


Control panel
Carrying handle
Vacuum gauge
Vacuum adjustment (from - to +)
Connection for the mains power unit
Serres® outer canister
Support for Serres® outer canister
Serres® suction liner
Angle (connection for the disposable
suction hose)
DDSbacterialandvirallter
cartridge for disposable system
11
Vacuum hose
Rear view


Brief instructions
Connection for the mains power
unit/car connecting cable
Serres®secretion canister system



Serres® outer canister
Angle (connection for the disposable
suction hose)
Serres® suction liner

19
Setting up and starting up
3.1.3 Front/rear view (with Medi-Vac®secretion canister system)
Front view








11
Control panel
Carrying handle
Vacuum gauge
Vacuum adjustment (from - to +)
Connection for the mains power unit
Medi-Vac®outer canister
Support for the Medi-Vac®outer
system
Medi-Vac®suction liner
Angle (connection for the disposable
suction hose)
DDSbacterialandviralltercartridge
for disposable system
11
Vacuum hose
Rear view


Brief instructions
Connection for the mains power unit/
car connecting cable
Medi-Vac®secretion canister system



Medi-Vac®outer canister
Angle (connection for the disposable
suction hose)
Medi-Vac®suction liner

20 Setting up and starting up
3.1.4 Control panel



ATMOS LC 27
On/Obutton
Release button
Holder for suction hose
Connection for suction hose
Operation status display

 
  ATMOS LC 27 Battery
On/Obutton
Release button
Fastener for suction hose
Connection for suction hose
Battery charge indicator
Operation status display
The battery charge level of the ATMOS LC 27 Battery must be visually monitored by
checking the indicator.
If only the red LED lights up, although the battery has been loaded for a longer
period, the battery is defective.
3.1.5 Hose connection DDS
Suction hose with DDS adapter and
ngertip(REF321.0100.0)
DDS hose adapter (REF 321.0040.0)
Connect the suction hose with the
DDS hose adapter.
3.2 Prepare the device with the single-patient secretion
canister
1. Aftertransportationofthedeviceatlowtemperaturesandpriortorststart-up,it
should be kept at room temperature for at least six hours.
2. Take the device and the accessories out of the packaging.
3. Read the safety notes before initial start-up.
4. Check the device for any transport damage.
5. If the device is damaged: Document and report the damages in transit, see “6.2
Sending in the device” on page 41 and spare parts can be requested (see back).
