Atmos S 351 OT User manual

Operating Instructions
ATMOS S 351 OT
English
0124
GA1GB.210301.0
2020-05 Index 02
E349855

2
Table of contents
1 Introduction.......................................................................................................4
1.1 Notes on operating instructions ..............................................................................4
1.2 Explanation of pictures and symbols ......................................................................5
1.3 Intended use...............................................................................................................7
1.4 Function.......................................................................................................................8
1.5 Intended users ...........................................................................................................9
1.6 Scope of delivery........................................................................................................9
1.7 Transport and storage............................................................................................ 10
2 Notes for your safety......................................................................................11
2.1 General safety instructions.................................................................................... 11
2.2 Danger for users, patients and third parties ....................................................... 11
2.3 Avoiding damage to the device ............................................................................. 13
3 Setting up and starting up .............................................................................15
3.1 Device overview....................................................................................................... 15
3.1.1 Secretion canister .............................................................................................. 16
3.2 Preparing the device............................................................................................... 17
3.3 Connecting to the mains power supply ............................................................... 18
3.4 Connecting the secretion canister system and hoses........................................ 18
4 Operation.........................................................................................................20
4.1 Ambient conditions during operation .................................................................. 20
4.2 Control panel ........................................................................................................... 20
4.3 Switching on the device.......................................................................................... 20
4.4 Switchingothedevice.......................................................................................... 21
4.5 Explanation of the display...................................................................................... 21
4.6 Intermittent mode .................................................................................................. 21
4.7 User menu ............................................................................................................... 22
4.7.1 Language ............................................................................................................ 22
4.7.2 Vacuum unit ....................................................................................................... 23
4.7.3 Intermittent ........................................................................................................ 23
4.7.4 Brightness........................................................................................................... 24
4.7.5 Date ..................................................................................................................... 25
4.7.6 Time..................................................................................................................... 25
4.7.7 Vacuum steps..................................................................................................... 25
4.8 Suction...................................................................................................................... 26
4.8.1 Adjusting the vacuum ....................................................................................... 26
4.8.2 AUTO mode ........................................................................................................ 26
4.9 Electronicll-levelmonitoringsystem.................................................................. 27
4.10 Changing the secretion canister............................................................................ 27
4.11 Warning messages.................................................................................................. 27
4.12 Trolley ....................................................................................................................... 28
4.13 Foot controller......................................................................................................... 28
4.14 Checkingthebacteriallter................................................................................... 29
5 Reprocessing....................................................................................................30
5.1 Safety instructions for reprocessing..................................................................... 30
5.1.1 General safety instructions............................................................................... 30
5.1.2 Danger for users, patients and third parties.................................................. 30

3
5.1.3 Avoiding damage to the device........................................................................ 30
5.2 Preparing and completing reprocessing .............................................................. 31
5.3 Preparing surfaces .................................................................................................. 31
5.3.1 Overview ............................................................................................................. 31
5.3.2 Selecting process chemicals............................................................................. 32
5.3.3 Wipe cleaning ..................................................................................................... 32
5.3.4 Wipe disinfection ............................................................................................... 33
5.4 Reprocessing the accessories................................................................................ 33
5.4.1 Overview ............................................................................................................. 33
5.4.2 Selecting process chemicals............................................................................. 33
5.4.3 Secretion canister system................................................................................. 34
5.4.4 Hoses................................................................................................................... 35
6 Maintenance and service...............................................................................37
6.1 Periodic tests ........................................................................................................... 37
6.2 Sending in the device.............................................................................................. 37
7 Troubleshooting ..............................................................................................38
8 Accessories ......................................................................................................40
9 Consumables ...................................................................................................41
10 Disposal............................................................................................................42
11 Technical data .................................................................................................43
12 Notes on EMC ..................................................................................................45
13 Notes ................................................................................................................46
14 Notes ................................................................................................................47

4Introduction
1 Introduction
1.1 Notes on operating instructions
These operating instructions contain important instructions on how to
operateyourproductsafely,correctlyandeectively.
These operating instructions are designed for training and instructing
new operating personnel in the use of the system, and they are also
intended for use as a reference manual. This document may only be
reprinted, either in part or in whole, with written permission from
ATMOS.
These operating instructions must always be kept available near
the product.
Care, periodic tests, regular cleaning and proper application are essen-
tial. They ensure the operational safety and usability of the product.
Maintenance, repairs and periodic tests may only be carried out by
persons who have the appropriate technical knowledge and who are
familiar with the product. The person must possess the test devices
and original spare parts required to carry out these measures.
Read chapter „2 Notes for your safety“ on page 11 before using the
productforthersttime.Thiswillhelpyoutoavoidpotentiallydanger-
ous situations.
The product bears the CE marking CE 0124 in accordance with EC
Council Directive 93/42/EEC concerning medical devices and meets the
basic requirements of Annex I to this directive.
The product complies with all the applicable requirements of Directive
2011/65/EU on the restriction of the use of certain hazardous sub-
stances in electrical and electronic equipment (‘RoHS’).
The Declarations of Conformity and our General Terms and Conditions
can be viewed on our website at www.atmosmed.com.
ThequalitymanagementsystematATMOShasbeencertiedaccord-
ing to international standard EN ISO 13485.
These operating instructions are valid for the following devices:
ATMOS S 351 OT, 230 V 444.0405.0
ATMOS S 351 OT, 100 V 444.0405.1
ATMOS S 351 OT, 115 V 444.0405.2
ATMOS S 351 OT, 127 V 444.0405.3
ATMOS S 351 OT – basic set, 230 V 444.0460.0
ATMOS S 351 OT – basic set, 100 V 444.0460.1
ATMOS S 351 OT – basic set, 115 V 444.0460.2
ATMOS S 351 OT – basic set, 127 V 444.0460.3
ATMOS S 351 OT (1.5 l canister), 230 V 444.0462.0
ATMOS S 351 OT (1.5 l canister), 100 V 444.0462.1
ATMOS S 351 OT (1.5 l canister), 115 V 444.0462.2
ATMOS S 351 OT (1.5 l canister), 127 V 444.0462.3

5Introduction
ATMOS S 351 OT mobile, 230 V 444.0470.0
ATMOS S 351 OT mobile, 100 V 444.0470.1
ATMOS S 351 OT mobile, 115 V 444.0470.2
ATMOS S 351 OT mobile, 127 V 444.0470.3
ATMOS S 351 OT mobile (2 x 3 l canister), 230 V 444.0476.0
ATMOS S 351 OT mobile (2 x 3 l canister), 100 V 444.0476.1
ATMOS S 351 OT mobile (2 x 3 l canister), 115 V 444.0476.2
ATMOS S 351 OT mobile (2 x 3 l canister), 127 V 444.0476.3
ATMOS S 351 OT – basic set, 230 V (Medi-Vac®) 444.0496.0
ATMOS S 351 OT – basic set, 230 V (Serres®) 444.0497.0
1.2 Explanation of pictures and symbols
In the operating instructions
DANGER
Warning of a danger that will result in immediate fatal or serious injury. Observe the
necessary measures.
WARNING
Warning of a danger that can cause fatal or serious injury. Observe the necessary
measures.
CAUTION
Warning of a danger that can cause minor injury. Observe the necessary measures.
ATTENTION
Notice of a danger that can damage the product or other objects. Observe the neces-
sary measures.
Warning of a danger that can cause fatal or serious injury.
Notice of potential material damage.
Useful information on the handling of the device.
1. Action. Proceed step by step.
»Result of an action.
Move in this direction, plug in.
On device and type plate
Follow operating instructions (blue)
Observe the operating instructions
Warning; pay special attention

6Introduction
0124
This product complies with the relevant requirements of EU Directives.
This product complies with the relevant requirements of EU Directives.
UL Mark
MEDICAL — GENERAL MEDICAL EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND MECHANICAL HAZARDS ONLY IN ACCORDANCE WITH
ANSI/AAMI ES60601-1 (2005) + AMD 1 (2012)
CAN/CSA-C22.2 No. 60601-1 (2014)
IEC 60601-1-6 (2013)
Eurasian conformity
GOSTCerticate(Russia)
Manufacturer
Manufacturing date
SN Serial number
REF Order number
EAN European Article Number
Applied part type B
IPX0 No protection from water
Professional disposal
For single use only (symbol located on consumables)
STERILE Product is sterile (unless packaging is damaged or opened)
AUTOCLAVE
Autoclavable
PATIENT Connection suction hose / patient (Serres® canister system)
LATEX
No natural rubber latex
Potential equalisation
E349855

7Introduction
Fuse
Standby automatic (AUTO)
-Reduce vacuum
+Increase vacuum
MAX Maximum vacuum
INT Intermittent mode (INT)
Switchdeviceon/o
Connected with trolley
Foot controller
Fragile, handle with care
Store in a dry place
Protect from sunlight
1.3 Intended use
Product name: ATMOS S 351 OT
Main function: Drainageandtemporarycollectionofbodyuids.Anelectric
suction pump controlled by a microprocessor generates
negative pressure. An additional secretion canister must be
attached to allow for temporary collection of drained body
uids.
The microprocessor allows for intermittent suctioning as well
as for a controlled shutdown of the pump.
Intended use / intend-
ed purpose:
Surgical suction
Intended user / user
prole:
Medicalsta(amongothers:doctors,operatingtheatre/room
sta,doctor’sassistants)
Intended patient
group:
Patients of all ages with and without restrictions
Disease state to be
diagnosed, treated or
monitored:
Inapplicable

8Introduction
Application organ: Naturaloricesaswellasopeningsresultingfromsurgical
procedures (entire body)
Application time: Short-term use on the patient (< 30 days)
Area of application: The areas of application are the clinical, outpatient as well as
practice-basedsettings.Thedevicemayonlybeusedbysta
who have been medically trained and instructed.
Criteria for patient
selection:
Patientswhobenetfromasurgicalprocedure.
Indications: • In surgical procedures, for the aspiration of wound pock-
ets, abscesses, etc.
• Inendoscopyforthesuctionofsecretionorrinsinguids
• In cardiological procedures
• For intermittent suction
Medical contraindica-
tions:
Not suitable for:
• Continuous operation for drainage procedures in the low
vacuum range (e.g. cardiothoracic or wound drainage)
• Vacuum extraction
• Smoke evacuation
• Liposuction
• Emergency and rescue operations
Other contraindica-
tions:
• Noapplicationoutsideofmedicalelds
• Nosuctionofammable,corrosiveorexplosiveuids/
gases
Warning notes: The following complications may occur during suction:
• Bleeding
• Injuries to vessels and nerves
• Adhesion of the suction instrument
The product is: Active
Single-use product /
reprocessing:
The device and parts of the accessories are reusable. For
information on reprocessing, cleaning and disinfection, refer
to chapter „5 Reprocessing“ on page 30.
1.4 Function
The ATMOS S 351 OT is a mains-operated medical suction device. The device is operated
with an electronically controlled, maintenance-free diaphragm pump.
During operation, the pump generates a vacuum in the secretion canister and hoses,
bymeansofwhichsecretion,bloodandbodyuidsarewithdrawnbysuction.Theuid
iscollectedinthesecretioncanister.Thebuttonsallowyoutosetthenalvacuumand
thus the suction capacity in steps. The set value can be read on the vacuum display.

9Introduction
Oncethenalvacuumisreached,thepumpturnsoandonlycontinuesworkingif
suctioncapacityfallsbelowthenalvacuumvalue.
Intermittent suction is used for gastric drainage. Suction is divided into four phases that
repeat periodically (build-up time, holding time, release time, pause). The user can set
the duration of the individual phases as well as the level of vacuum to be built up in the
user menu.
1.5 Intended users
The device may only be used by trained and instructed medical professionals.
1.6 Scope of delivery
Legend:
Name REF Number
Power cable 5 m 008.0629.0 1
Safetycanister250ml(withoutbacteriallter) 444.0646.0 2
Hydrophobicbacterialandvirallter 443.0738.0 3
Vacuum hoses (1 pc. each) 999.0128.0
443.0046.0
999.0127.0
4
Suction hose, silicone, Ø 10 mm, L = 2 m 000.0243.0 5
Suction hose, silicone, Ø 6 mm, L = 2 m 000.0013.0 6
Hose holder, for attaching to a standard rail 444.0450.0 7
Secretion canister 1.5 l (PC) 444.0100.0 8
Nipplesetwithoverowelectrode 444.0012.0 9
Secretion canister lid incl. standard rail holder 444.0015.0 10
Trolley 444.0020.0 11
Secretion canister 3 l (PC) 444.0099.0 12
Standard rail holder Medi-Vac®444.0451.0 13
Medi-Vac®outer canister 1 l 312.0473.0 14
Standard rail holder Serres® complete 444.0484.0 15
Serres®outer canister 312.0456.0 16
Scope of delivery:
Device version REF Includes number
ATMOS S 351 OT, 230 V 444.0405.0 1
ATMOS S 351 OT, 100 V 444.0405.1 1
Device version REF Includes number
ATMOS S 351 OT, 115 V 444.0405.2 1
ATMOS S 351 OT, 127 V 444.0405.3 1
ATMOS S 351 OT, basic set, 230 V 444.0460.0 1, 2, 3, 4, 5, 6, 7
ATMOS S 351 OT, basic set, 100 V 444.0461.0 1, 2, 3, 4, 5, 6, 7
ATMOS S 351 OT, basic set, 115 V 444.0460.2 1, 2, 3, 4, 5, 6, 7
ATMOS S 351 OT, basic set, 127 V 444.0460.3 1, 2, 3, 4, 5, 6, 7

10 Introduction
ATMOS S 351 OT (1.5 l canister), 230 V 444.0462.0 1, 2, 3, 4, 5, 6, 7, 8, 9,
10
ATMOS S 351 OT (1.5 l canister), 100 V 444.0462.1 1, 2, 3, 4, 5, 6, 7, 8, 9,
10
ATMOS S 351 OT (1.5 l canister), 115 V 444.0462.2 1, 2, 3, 4, 5, 6, 7, 8, 9,
10
ATMOS S 351 OT (1.5 l canister), 127 V 444.0462.3 1, 2, 3, 4, 5, 6, 7, 8, 9,
10
ATMOS S 351 OT mobile, 230 V 444.0470.0 1, 2, 3, 4, 5, 6, 7, 11
ATMOS S 351 OT mobile, 100 V 444.0470.1 1, 2, 3, 4, 5, 6, 7, 11
ATMOS S 351 OT mobile, 115 V 444.0470.2 1, 2, 3, 4, 5, 6, 7, 11
ATMOS S 351 OT mobile, 127 V 444.0470.3 1, 2, 3, 4, 5, 6, 7, 11
ATMOS S 351 OT mobile (2 x 3 l canister), 230 V 444.0476.0 1, 2, 3, 4, 5, 6, 7, 9,
2x10, 11, 2x12
ATMOS S 351 OT mobile (2 x 3 l canister), 100 V 444.0476.1 1, 2, 3, 4, 5, 6, 7, 9,
2x10, 11, 2x12
ATMOS S 351 OT mobile (2 x 3 l canister), 115 V 444.0476.2 1, 2, 3, 4, 5, 6, 7, 9,
2x10, 11, 2x12
ATMOS S 351 OT mobile (2 x 3 l canister), 127 V 444.0476.3 1, 2, 3, 4, 5, 6, 7, 9,
2x10, 11, 2x12
ATMOS S 351 OT, basic set, 230 V, Medi-Vac® 444.0496.0 1, 3, 4, 5, 6, 7, 13, 14
ATMOS S 351 OT, basic set, 230 V, Serres® 444.0497.0 1, 3, 4, 5, 6, 7, 15, 16
1.7 Transport and storage
Onlytransporttheproductinashippingcartonthatispaddedandoerssucient
protection.
If damage occurs during transport:
1. Document and report damages in transit.
2. Send the device to ATMOS, see chapter „6.2 Sending in the device“ on page 37.
Ambient conditions for transport and storage:
• Temperature: −10...+60°C
• Relative humidity: 30...95% without condensation
• Atmospheric pressure: 700...1060hPa

11Notes for your safety
2 Notes for your safety
The safety of the ATMOS S 351 OT complies with the accepted standards of technology
and the guidelines of the German Medical Devices Act.
2.1 General safety instructions
Familiarise yourself with the device in good time so that you are capable of operating it
at any time.
Only a fully functional product meets the safety requirements of users, patients
and third parties. Therefore, please observe the following instructions on your
product:
Never operate the device if it shows any obvious safety defects.
2.2 Danger for users, patients and third parties
WARNING
Electric shock due to unsuitable mains power connection, incorrect handling of
the product or damage to product components.
Burns, cardiac arrhythmias and even fatal injury are possible.
• Do not operate the device if it has been dropped. In this case, clean and disinfect the
device and send it to ATMOS for repair.
• Prior to each use, check for damage to the device and the power cable. Do not oper-
ate the device if you notice any damage. In this case, clean and disinfect the device
and send it to ATMOS for repair.
• You can only disconnect the device from the mains power supply by pulling out the
power plug.
• Position the device in such a way that you can easily disconnect it from the mains
power supply at any time.
• When disconnecting the device from the mains power supply, pull the power plug
rstandthenthedeviceplug.
• Disconnect the device from the mains power supply before cleaning or disinfecting
it.
• Never touch the power plug or power cable with wet hands.
• Never immerse the device in water or other liquids.
• The device is not sterilisable.
• Use the power cable only in dry surroundings. The surroundings must be non-con-
ductive.
• Ensure that no liquid enters the device. If liquid gets into the device, operation of the
device must cease immediately. In this case, clean and disinfect the device and send
it to ATMOS for repair.
• Use only original accessories and original spare parts from ATMOS. This applies to
the power cable in particular.
• Follow the instructions on periodic tests in chapter „6 Maintenance and service“ on
page 37.
• Assembly, new settings, alterations, extensions and repairs may only be carried out
by authorised persons.
• Do not modify the device without the manufacturer’s permission.

12 Notes for your safety
WARNING
Risk of infection due to patient secretion on the device!
Deadly diseases can be transmitted.
• Always wear disposable gloves if you could come into contact with secretion.
• Never use components marked with 2more than once. These components are
intended for single use only.
• Sterile-packed parts may only be used if the packaging is undamaged.
• Donotoperatethedevicewithoutabacteriallter.
• Beforeeachuse,checkthatthebacteriallterisdryandcleantoensurethatit
operates correctly.
• A suction catheter, suction attachment or suction instrument must always be con-
nected to the suction hose. The suction hose must never come into direct contact
with the suction area.
• Clean and disinfect the device after every use.
• Clean and disinfect the device according to the operating instructions.
• The device must not be used following oversuction.
WARNING
Ensure that the device is always functional and ready for use.
Your patient can be severely injured.
• Ensure that the device is always ready for use.
• Place the device where it is easily accessible.
• Perform a function check after each use.
• ATMOS recommends always having another suction device ready at hand. That way
you can also perform suctioning if a device should fail.
• Please observe the notes on the electromagnetic compatibility (EMC) of the device.
WARNING
Avoid improper use.
Your patient can be severely injured.
• Employ the device only according to its intended use.
• The product may only be used by medically trained persons who have been instruct-
ed in the handling of the medical suction system.
• Please select the vacuum according to the patient and the application.
• Observe the valid guidelines.
• Observe the notes on hygiene and cleaning.

13Notes for your safety
WARNING
Explosion and re hazard.
Burns and injuries are possible.
• Neversuctionanyexplosive,ammableorcorrosivegasesorliquids.Pleaseobserve
the intended use in chapter „1.3 Intended use“ on page 7.
• Never operate the product in potentially explosive areas or in areas that are oxygen-
ated.
• Only use original accessories and original spare parts from ATMOS. This applies to
the power cable in particular.
WARNING
Tripping hazard due to cables.
Injuries and fractures are possible.
• Lay the power cable properly.
WARNING
Contact may cause allergic reactions!
• The materials used have been tested for their tolerability. In very rare cases, con-
tact with accessible materials on the device and its accessories may cause allergic
reactions. This applies in particular to contact injuries in conjunction with prolonged
contact. If this occurs, seek medical attention immediately.
Only a fully functional product meets the safety requirements of users, patients and
third parties. Therefore, please observe the following instructions on your product:
2.3 Avoiding damage to the device
ATTENTION
Storage and operation in an unsuitable environment.
The electronics could become damaged.
• Please observe the ambient conditions for transport, storage and operation.
• Alwaysplacethedeviceonrm,levelground.Thedevicemustalwaysbeinavertical
position when you use it. Otherwise, secretion may enter the device.
ATTENTION
Damage to device due to heat build-up!
The device may become damaged.
• Do not cover the device during suction.
• Keep the device and the power cable away from other heat sources.
• Do not place the device directly next to other devices as this may cause excessive
heating of the device.

14 Notes for your safety
ATTENTION
Damage to the device due to improper use!
The device may become damaged.
• Ensure that no liquid enters the device. Once liquid has entered the device, it may no
longer be used. In this case, clean the device and send it to ATMOS for repair.
• Alwaysplacethedeviceonrm,levelground.Thedevicemustalwaysbeinavertical
position when you use it.
• Use only power cables that function properly.

15Setting up and starting up
3 Setting up and starting up
3.1 Device overview
Front view
5
4
6
7
1
2
3
1ON / OFF switch
2Display
3Support for canister system
4Connection for hose from pump to
overowcanister
5Connection for suction hose
6Secretion canister lid
7Bacteriallter
Rear view
5
4
3
2
1
1Pump connection
2Connection for foot controller
3Service interface
4Potential equalisation
5Mains supply

16 Setting up and starting up
3.1.1 Secretion canister
Reusable canister system
12
4
3
56
7
1Locking handle
2Knurled screw for locking the lid insert and for adjusting the clamping force
3Release button
4Fill-level sensor with anti-foaming device
5Lid rim
6Aperture for double hose connector
7Contactsforll-levelmonitoring
Disposable canister systems
Serres® canister system (1 l)
2
1
3
4
1Angle (connection for disposable
suction hose)
2Serres® suction liner
3Serres® outer canister
4Grey angle on the Serres® outer
canister (connection vacuum hose)

17Setting up and starting up
Medi-Vac® canister system (1 l)
1
2
4
5
3
1Angle (connection for disposable
suction hose)
2Red hose
3Medi-Vac® suction liner
4Connection vacuum hose
5Medi-Vac® outer canister
Receptal® canister system (3 l)
1
2
3
4
1Angle (connection for disposable
suction hose)
2Receptal® suction liner
3Receptal® outer canister
4Connection vacuum hose
Safety canister
1
2
3
4
1Safety canister
2Safety canister lid with connection
forDDSbacteriallter
3Connection vacuum hose
4Connection for suction hose
3.2 Preparing the device
Read the safety information in chapter „1.1 Notes on operating instructions“ on page
4 carefully before using the product.
Damaged pump diaphragms due to cold temperatures during transport.
1. Incasethedevicewastransportedattemperaturesbelow−5°C:letthedevicestand
at room temperature for at least 6 hours before proceeding with the next steps.
2. Check the device, secretion canisters, power cable, accessories and hoses for possi-
ble damage.
3. If the device is damaged: document and report the damages in transit. Send the
device to ATMOS (chapter „6.2 Sending in the device“ on page 37).

18 Setting up and starting up
4. If the device is not damaged: place the device on a safe, level surface.
3.3 Connecting to the mains power supply
1. Check whether the voltage and frequency data listed on the device correspond to
the values of the mains power supply.
2. Connect the device to the mains.
3. Secure the power cable against accidental removal by using the safety clamp.
For surgical procedures, we recommend additionally connecting the device via the
connection to the potential equalisation of the examination room.
3.4 Connecting the secretion canister system and hoses
1. The anti-foaming device must be placed on the
ll-levelsensorforstronglyfoamingsecretion.
2. Slide the secretion canister lid with the release
button pointing forward onto the secretion
canister.
Make sure that the lid rim is under the bead of
the secretion canister. This seals the secretion
canister tightly and the desired vacuum can be
built up in the secretion canister.
3. Press the locking handle downwards until it
clicks into place.
4. Hang the secretion canister in the left or right
support for the canister system.
Using the support for the canister system for
purposes other than what it was designed for can
cause malfunctions.
1. Push the double hose connector into the
canister lid twisting gently.
» The double hose connector locks into place.

19Setting up and starting up
1. Connect a short hose to the pipe connection on
thedeviceandtothebacteriallter.
2. Connect a second short hose to the printed
sideofthebacteriallterandtothesafety
canister lid.
3. Connect a longer hose to the inlet on the safety
canisterandtotheverticalttingofthedouble
hose connector.
Whenusingtheoptionalbacteriallterinthe
overowcanister,thebacteriallterbetween
the pipe connection of the device and the
safety canister lid can be omitted.
Never operate the device without a bacterial
lter.
1231. Connect the suction hose (Ø 10 mm) to the
angledtting(2)ofthedoublehoseconnector.
Use a hose reducer (3) for suction hoses with a
Ø of 6 mm.

20 Operation
4 Operation
4.1 Ambient conditions during operation
• Temperature: +5...+40°C
• Relative humidity: 30 ... 95% without condensation
• Air pressure: 700 ... 1060 hPa
4.2 Control panel
1
+MAX
INT
-
S 351 OT
high vacuum / high ow
AUTO
2
3
4
5 6 7
1AUTO mode button (auto standby)
2INT mode button (intermittent)
3LEDs for indicating the active function
4Display
5Button for reducing the vacuum
6Button for increasing the vacuum
7Button for selecting the maximum vacuum
4.3 Switching on the device
1. Press the ON / OFF switch.
» The start screen appears.
» The pump starts. The vacuum that was last selected is set.
Ifthetargetvacuumis0beforethedeviceisswitchedo,itwillbestartedwith
−100mbarwhenitisswitchedon.
» The ON / OFF switch remains lit as long as the device is on.
