Audiovox AVXMTG10U User manual

10-Inch Roof-Mount DVD Player
With DVD/CD/MP3SYSTEM
AVXMTG10U
OPERATION
MANUAL

TABLE OF CONTENTS
Important Notices......................................................................................................................................... 2
Congratulations.............................................................................................................................................. 3
Features ............................................................................................................................................................... 3
Controls and Indicators Diagram......................................................................................................... 4
Remote Control Operation...................................................................................................................... 6
DVD Basics .......................................................................................................................................................10
Loading and Playing Discs.....................................................................................................................12
Settings and Adjustments......................................................................................................................12
Playing JPG Files ...........................................................................................................................................16
Playing MP3 Files .........................................................................................................................................17
Source Features ............................................................................................................................................18
Troubleshooting...........................................................................................................................................20
Specifications.................................................................................................................................................22
Notes...................................................................................................................................................................23
1

IMPORTANT NOTICES
2
An LCD panel and/or video monitor may be installed in a motor vehicle and
visible to the driver only if the LCD panel or video monitor is used for vehicle
information, system control, rear or side observation or navigation. If the
LCD panel or video monitor is used for television reception, video or DVD
play, the LCD panel or video monitor must be installed so that these features
will only function when the vehicle is in “park” or when the vehicle’s parking
brake is applied.
When connecting power and ground in a mobile video installation, insure
that the ACC wire is fused at the point where it is connected to the vehicle’s
ACC wiring. Failure to do so can result in damage to the vehicle if a short
circuit develops between the vehicle connection point and the mobile video
product.
An LCD panel and/or video monitor used for television reception, video or
DVD play that operates when the vehicle is in gear or when the parking
brake is not applied must be installed to the rear of the driver seat where it
will not be visible, directly or indirectly, to the operator of the motor vehicle.
WARNINGS
• Do not use any solvents or cleaning materials when cleaning the video
monitor.
• Do not use any abrasive cleaners, they may scratch the screen.
• Use only lightly dampened lint free cloth to wipe the screen if it is dirty.
• Lock the LCD screen in fully closed position when not in use.
• Before putting on headphones, always adjust the volume setting to OFF or
lowest position.
• Remember to leave the dome light switch in the off or auto position when
the vehicle is unattended, as the dome lights, if left on, can drain the
vehicle battery.
• Do not put pressure on the screen.
• Caution children to avoid touching or scratching the screen, as it may
become dirty or damaged.
Safety Precautions
For safety reasons, when changing video media, it is recommended that
the vehicle is not in motion, and that you do not allow children to unfasten
seat-belts to change video media or make any adjustments to the system.
System adjustments can be accomplished using the remote control, while
seat-belts remain fastened. Enjoy your AUDIOVOX entertainment system but
remember that the safety of all passengers remains the number one priority.
Licensed under one or more of the following patents, Patent Numbers
5,775,762, 5,927,784, and 6,678,892.

3
CONGRATULATIONS
FEATURES
Congratulations on your purchase of the AUDIOUVOX AVXMTG10U DVD player with Drop-Down Video/Monitor. The AVXMTG10U player has been designed to
give you and your family many years of video entertainment in the mobile environment. Please read the directions that follow in order to familiarize yourself
with the product to ensure that you obtain the best results from your equipment.
• 10” TFT LCD monitor
• Built-in DVD Player
• Selectable (A and B) IR receive and transmit codes
• Multi-Lingual On Screen Display (OSD) for control of picture quality and functions
• Audio/Video source inputs
• Dome lights with built-in three way switch
• Last memory for DVD
• Built-in 16 channel frequency wireless FM modulator
• Headphone jack
• Screen mode selection (16:9, 4:3)
• Backlight controls
• Day/night picture modes
• A/V output
• USB/SD support

4
CONTROLS AND INDICATORS DIAGRAM
1
2
345678910 11 12 1
13
14
15
16
17
Front View
1. Dome Lights - Provides additional interior illumination.
2. SOURCE (S) Button - Press this button to select one of the sources: DVD, AV
IN, CARD, USB.
3. VOLUME ( +) Button - Press this button to increase the volume or increase
the level of selected picture controls.
4. PIC Button - Press this button to enter the picture adjustment mode. Press
to adjust in the following sequence: Brightness, Contrast, Color, Reset.
5. VOLUME ( -) Button - Press this button to decrease the volume of wired
headphones and decrease the level of selected picture controls.
6. PLAY/PAUSE ( ) Button - Press to start playback or to pause playing.
7. SCREEN RELEASE (PRESS) Button - Press this button to release the LCD
screen. The screen will drop down slightly. Pivot the screen downward until
a comfortable viewing angle is reached.
8. POWER ( ) Button - Press this button to turn the system on or off. The
button is lit blue when power is available.
9. FMM Button - Used to select the frequentcy in sequence rotaion: FM OFF,
CH 1 88.1 MHz, CH 2 88.3 MHz, CH 3 88.5 MHz,
CH 4 88.7 MHz, CH 5 88.9 MHz, CH 6 89.1 MHz,
CH 7 89.3 MHz, CH 8 89.5 MHz, CH 9 89.7 MHz,
CH10 89.9 MHz, CH 11 90.1 MHz, CH 12 90.3 MHz,
CH 13 90.5 MHz, CH 14 90.7 MHz, CH 15 90.9 MHz,
CH 16 91.1 MHz
10. EJECT ( ) Button - Press this button to eject a disc from the
disc compartment.
11. SCREEN MODE ( ) Button - Press this button to select Wide (16:9) or
Normal (4:3) aspect ratios.
12. STOP ( ) Button - Press this button to stop playback.
13. Ventilation Openings
14. LCD Cut Off Switch - Used to turn off the LCD screen when it is in the
closed position.
15. 10 “ LCD Screen
16. Wireless Headphones Transmitter - Transmits audio to an optional
wireless headphone.
17. Infrared Remote Sensor - Allows remote control to operate the unit.

5
12
345
Side Views
Back View
123
1. DVD Disc insertion Slot - For loading and removing disks. Turn the unit on
before loading a disc. Insert a disc with the label facing up towards the
headliner. The player will load a disc when a disc is inserted.
2. DISC Indicator light - Illuminates green when a disc is inserted.
3. Three Position Dome Light Switch:
ON - Turn on the dome lights.
OFF - The dome Lights will not turn on in this position.
AUTO - Automatically switches on the dome lights in conjunction with the
vehicle’s interior illumination.
4. SD Card Slot - Insert SD card for playback of audio/video files.
5. USB 2.0 Port - Insert USB device for playback of audio/video files.
1. Infrared Remote Sensor - Allows the remote control to operate the unit.
2. A/V IN Jack - This jack is used for audio and video input.
3. Headphone Jack - Allows the use of wired headphones with a 1/8”(3.5 mm)
plug for listening to audio output.

6
1
2
CR2025 CR2025
REMOTE CONTROL OPERATION
Battery Installation
Before attempting to operate your remote control, install the battery as described below:
1. Using your finger, press the tab (1) down in the direction of the arrow.
2. Slide the battery holder (2) out in the direction of the arrow.
3. Install one CR2025 battery. Make sure that the proper polarity (+ or -) is observed.
4. Slide the battery holder into the remote control until it locks.
Back View

7
Remote Control Functional Description
1. POWER ( ) Button - Press this button to turn the unit ON and OFF.
2. NUMBER Buttons - Press to enter the numbers 0 to 9 for selection of CD
tracks, DVD chapters or password setting.
3. PREVIOUS/CURSOR ( ) Button - Go to the previous chapter or track. The
cursor is used to select menus on the screen.
4. MENU Button - Press this button to access the DVD root menu (DVD MODE).
5. OK Button - Used to implement a selected setting or menu option.
6. SCAN BACKWARD/CURSOR ( ) Button - Scans backward at 2, 4, 8, 16,
and 32 times speed. The cursor is used to select menus on the screen.
7. PLAY/PAUSE ( ) Button - Used to start playback or pause playing.
8. NEXT/CURSOR ( ) Button - Go to the next chapter or track. The cursor is
used to select menus on the screen.
9. A-B Button - Allows the user to repeat the playback from point A to point B.
Press DVD Player
Once Repeat A - Marks the beginning of the section to repeat
(set point A).
Twice Repeat AB - Marks the end of the section to repeat (set point B).
3 times Repeat Off - Cancels the A-B repeat function.
10. REPEAT Button - Allows the user to repeat a selected title, chapter or track.
For MP3 disc, press “REPEAT” to repeat playing present file; press it again to
repeat playing the folder.
1
2
4
6
3
5
7
8
9
10

8
Remote Control Functional Description
11. MUTE Button - Press this button to mute the audio for wireless FMM.
12. DAY/NIGHT Button- This control toggles the unit between“ DAY” and
“NIGHT” LCD illumination modes. In the “DAY” mode, the LCD backlight
intensity is at maximum. In the “NIGHT” mode, the LCD backlight is dimmed
to a preset level that is more suitable for low light operation.
13. FMM ON/OFF Button - Turns the wireless FM Modulator ON or OFF.
14. CHANNEL SELECT Button - Selects wireless FM Modulator Frequency.
Ch 1 88.1 MHz, Ch 2 88.3 MHz, Ch 3 88.5 MHz,
Ch 4 88.7 MHz, Ch 5 88.9 MHz, Ch 6 89.1 MHz,
Ch 7 89.3 MHz, Ch 8 89.5 MHz, Ch 9 89.7 MHz,
Ch 10 89.9 MHz, Ch 11 90.1 MHz, Ch 12 90.3 MHz,
Ch 13 90.5 MHz, Ch 14 90.7 MHz, Ch 15 90.9 MHz,
Ch16 91.1 MHz
15. VOLUME ( +/ -) Button - Press to increase or decrease the volume level, or
increase or decrease the level of the selected the picture adjustment.
16. SUBTILE Button - Press to display and select an available subtitle language
in DVD mode.
17. SCREEN MODE SELECTION ( ) Button - Press this button to switch
between Wide (16:9) or Normal (4:3) aspect ratios.
18. AUDIO Button - Press this button to display and select an available audio
language in DVD mode.
19. DISPLAY Button - Press this button to display current disc information while
the disc is playing.
20. ZOOM Button - Press this button to change picture size when playing a
DVD disc.
Press: DVD player performs:
Once Enlarges the picture to 2 times the original size.
Twice Enlarges the picture to 3 times the original size.
3 times Enlarges the picture to 4 times the original size.
4 times Reduces the picture to 1/2 times the original size.
5 times Reduces the picture to 1/3 times the original size.
6 times Reduces the picture to 1/4 times the original size.
7 times Picture returns to the original size.
11
12
13
14
15
16
17
18
19
20

9
Remote Control Functional Description
21. STOP ( ) Button - Press this button to stop playback.
22. SOURCE Button - Press to select the source menu (DVD/AV1/CARD/USB).
23. SCAN FORWARD/CURSOR ( ) Button - Scan forward at 2, 4, 8, 16, and 32
times speed. The cursor is used to select menus on the screen.
24. PIC Button - Press this button to enter the picture adjustment mode Press
repeatedly to adjust in the following sequence: Brightness, Contrast, Color,
Reset. Once the desired adjustment bar is displayed, use the VOLUME (+)/
VOLUME (-) button to adjust the setting. The display will automatically turn
off in 6 seconds, or if any other button is pressed.
25. SETUP Button - Press this button to display the setup menu. The setup
menu allows the user to change DVD player options such as OSD
LANGUAGE, PARENTAL CONTROL etc.
26. RETURN Button:
Press Return once: Go to disc menu.
Press Return twice: Go to movie playback.
27. ANGLE Button - Press this button to display and select different camera
angles in DVD mode. Not all discs contain this option.
28. EJECT ( ) Button - Press this button to eject the disc.
29. IRT A-B - Press this button to change the IRT transmitter band between
A & B.
30. IRT ON/OFF - Press this button to turn the IRT ON or OFF.
21
22
23
24
25
26
27
28
29
30

10
DVD BASICS
To get the optimum use out of the DVD player, please read this section.
DVD Region Code
The DVD player is preset to a region code at the factory depending on where the unit is sold. DVDs are also coded by region. These region codes must match in
order for the disc to play. If the region codes do not match, the disc will not play. This system is set to Region 1 (USA) and will not play discs that have a region
code different from Region 1. The system will display“WRONG REGION.”
Region 1 - USA, Canada
Region 2 - Japan, Europe, South Africa, Middle East,
Greenland
Region 3 - South Korea, Taiwan, Hong Kong, Parts of
South East Asia
Region4 - Australia, New Zealand, Latin America
(including Mexico)
Region5 - Eastern Europe, Russia, India, Africa
Region6 - China

11
Types of Discs Your System Will Play
Your system will play the following types of discs:
• DVD disc - DVD discs that contain video.
• Audio discs - Audio CDs that contain musical or sound content only.
• MP3 discs - A disc that contains audio files (for example, a CD-R with downloaded MP3 files).
This unit is capable of playing most recordable DVD formats. However, due to the variety of disc manufacturers and software, playback can not be guaranteed
for every disc.
Disc Compatibility
Before a disc is loaded, make sure that it is compatible with the player. The following discs can not be played with this player:
• MiniDisc
• Laserdisc
• CD-I, CD-ROM, DVD-ROM, Super Audio CD (SACD) or DVD Audio
• Blue-RayDisc™

12
LOADING AND PLAYING DISCS
SETTINGS AND ADJUSTMENTS
1. Press the Screen Release (PRESS) button to unlock the LCD screen. The LCD screen will drop down slightly.
2. Pivot the screen downward until a conformable viewing angle is reached. The hinge friction will hold the screen in position while the unit is in use.
3. Press the power ( ) button on the unit or remote control to turn the unit on.
4. Insert a disc into the disc insertion slot with the label facing up towards the headliner.
5. After the unit has been turned on and is displaying a picture, adjust the viewing angle. Pivot the screen to optimize the picture quality.
6. Remember to turn the unit off and pivot the screen to the locked position when not in use.
The General, Password or Preference Setup Page menus contains features and options that let you customize your DVD player. For example, you can choose a
language for the On Screen Display (OSD) or control DVD playback content for children.
Main Menu
TV Display Wide
Angle Mark O
TV Type NTSC
Screen Saver On
OSD Lang ENG
Last Memory On
Go To General Setup Page
- - General Setup Page - -
1. Press the“SETUP” button. The Main Menu will appear on the screen.
2. Press the “” or “” button to select the General, Password or Preference Setup Pages.
3. Press the“OK”button to access the selected setup page.
4. Press the “” or “” cursor button to select a menu item.
5. Press the “” cursor button to enter the option submenu.
6. Press the “” or “” cursor button to select an option.
7. Press the“OK”button to confirm your selection.
8. Press the “” cursor button to return to the setup page or the“SETUP” button to exit.

General Setup Page Menu
TV Display Wide Normal/PS
Angle Mark O Normal/LB
TV Type NTSC Wide
Screen Saver On
OSD Lang ENG
Last Memory On
Set TV Display Mode
- - General Setup Page - -
TV Display
This item allows you to set the screen display format.
Optional Settings: Normal/PS, Normal/LB, Wide
The default setting is Wide.
Note: This function depends on the aspect ratio with which the DVD disc is recorded.
TV Display Wide
Angle Mark O On
TV Type NTSC O
Screen Saver On
OSD Lang ENG
Last Memory On
Set Angle Mark
- - General Setup Page - -
Angle Mark
This item allows you to turn angle mode playback on or off. Angle mode allows you to select different camera
angles in DVD playback.
Optional settings: On, Off
The default setting is Off.
Note: The number of angles vary from disc to disc. Not all discs contain this option.
TV Display Wide
Angle Mark O
TV Type NTSC PAL
Screen Saver On NTSC
OSD Lang ENG
Last Memory On
Set TV Standard
- - General Setup Page - -
TV Type
This item allows you to select a TV type.
Optional Settings: PAL, NTSC
The default setting is NTSC.
Note: For best system performance, the selected setting should remain at NTSC.
TV Display Wide
Angle Mark O
TV Type NTSC
Screen Saver On On
OSD Lang ENG O
Last Memory On
Set Screen Saver
- - General Setup Page - -
Screen Saver
This item allows you to turn the screen saver on or off.
Optional Settings: On, Off
The default setting is On.
Note: The DVD player will enter screen saver mode if the unit is inactive for approximately four minutes.
13

14
General Setup Page Menu (continued)
TV Display Wide
Angle Mark O
TV Type NTSC English
Screen Saver On French
OSD Lang ENG Spanish
Last Memory On Italian
Set OSD Language
- - General Setup Page - -
OSD Language
This item allows you to choose an On Screen Display menu language.
Optional Settings: English, Spanish, French, Italian
The default setting is English.
TV Display Wide
Angle Mark O
TV Type NTSC
Screen Saver On
OSD Lang ENG On
Last Memory On O
Set Last Memory State
- - General Setup Page - -
Last Memory
This item allows you to turn the Last Memory feature on or off. When the Last Memory feature is on, video will
resume playback from its last location if power is interrupted and restored.
Optional Settings: On, Off
The default setting is On.
Password Setup Page Menu
Password Change
- - Password Setup Page - -
Password
This item allows you to set a four number password.
1. Select the Change option.
2. Press the "OK" button. The Change Password screen (shown below) appears.
Note: The default password is 3308. This password is always accepted even after a new password has been entered.
To avoid the possibility of others using the default password to change passwords, record this default password in
another area and delete it from this manual.
Old Password
New Password
Conrm PWD
OK
Change Password
1. Enter the default or old four number password. The "Please Enter New Password" prompt appears.
2. Enter a new four number password. The "Please Reenter Password" prompt appears.
3. Reenter the password again. The "Change" prompt appears.
4. Press the "OK" button.

15
Preference Page Menu
Audio ENG English
Subtitle OFF French
Disc Menu ENG Spanish
Parental Italian
Default
Preferred Audio Language
- - Preference Page - -
Audio
This item allows you to select an audio language for DVD playback. The audio language depends on the
information available on each disc.
Optional Settings: English, Spanish, French, Italian.
The default setting is English.
Note: You can also change the audio language during playback by pressing the Audio button.
Audio ENG
Subtitle OFF English
Disc Menu ENG French
Parental Spanish
Default Italian
O
Preferred Subtitle Language
- - Preference Page - -
Subtitle
This item allows you to select a subtitle language to be shown on the screen. The subtitle language depends on
the information available on each disc.
Optional Settings: English, Spanish, French, Italian, Off.
The default setting is Off.
Note: You can also change the subtitle language during playback by pressing the Subtitle button.
Audio ENG
Subtitle OFF
Disc Menu ENG English
Parental French
Default Spanish
Italian
Preferred Menu Language
- - Preference Page - -
Disc Menu
This item allows you to choose the menu language stored on the disc.
Optional Settings: English, Spanish, French, Italian
The default setting is English.
Note: This function is only available for DVD playback.
Audio ENG
Subtitle OFF
Disc Menu ENG
Parental
Default
Set Parental Control
- - Preference Page - -
1 KID SAFE
2 G
3 PG
4 PG 13
5 PGR
6 R
7 NC 17
8 ADULT
Parental
This function prevents children from watching unsuitable DVD content. You can limit the content of movie
playback from 1. Kid Safe to 8. Adult. The lower the value, the more strict the control. The restriction of viewing disc
content by younger viewers may be available on some discs but not others.
Optional Settings: 1. KID SAFE; 2. G; 3. PG; 4. PG 13; 5. PGR; 6. R; 7. NC 17; 8. ADULT.
The default setting is 8. ADULT.
Note: Parental Control features are password protected. The rating level can only be changed when the correct
password has been entered.

16
PLAYING JPG FILES
1. Place a JPG disc into the disc insertion slot, the unit will start reading the disc and play.
2. Press the“MENU”button to browse JPG files.
3. Press the “” or “” cursor button to select a JPG file and press the “OK” button to confirm.
4. Press the ““ cursor button to rotate the picture counter-clockwise; press the ““ cursor button to rotate the picture clockwise.
5. Press the“DISPLAY” button when viewing pictures. You can select different refresh modes as follows:
a. From top to bottom
b. From bottom to top
c. From left side to right side
d. From right side to left side
e. From left top to right bottom
f. From right top to left bottom
g. From left bottom to right top
h. From right bottom to let top
i. From horizontal center to both sides
j. From vertical center to both sides
k. From top and bottom to center
l. From right and left to center
m. From four window's top side to bottom side
n. From four window's left side to right side
o. From four edges to center.
6. When viewing files, “ ” may appear when pressing “Subtitle”or “Audio” etc. In this situation, these options are unavailable.
7. When viewing JPG files, press“”. Pictures will be displayed in thumbnail mode. Press “///“ or press the “ OK ”button to select one picture to view.
Preference Page Menu (continued)
Audio ENG
Subtitle OFF
Disc Menu ENG
Parental
Default Reset
Load Factory Setting
- - Preference Page - -
Default
This item allows you to reset all settings to the original factory settings. Select this item and press the“OK” button.
Note: This function does not reset the Parental level to the original factory setting.

17
PLAYING MP3 FILES
MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into the MP3 format with very little loss of quality, while taking up much
less space. CD-R discs that have been encoded in MP3 format can be played on a DVD player. The DVD player plays the songs in the order they were burned on
to the disc. When playback is started, the elapsed time of the track that is playing will be displayed.
1. Place a MP3 disc into the disc insertion slot, insert an USB drive into the USB
port, or insert a SD card into the SD card slot.
2. Press the “/” cursor button or the “ OK ” button to choose a MP3 file.
3. Press the “ ”button or the “ OK ” button to play the file selected.

18
SOURCE FEATURES
1. Press the“SOURCE” button on the unit or remote control. The following menu will appear on the screen:
2. Press the “
” or “ ” cursor button to choose an item.
3. Press the “OK” button.
DVD
Last Memory for the DVD mode: If the unit is turned off and then on, and the DVD disc is not removed, the unit will play the DVD from the point it
stopped last time.
At power OFF mode, the unit will turn on automatically when a disc is inserted.
AV IN
The unit will accept an audio/video input through the 3 RCA jacks located on the rear of the unit. The audio/video device can be a video game
system, video camera or other input device.
CARD
Insert a SD card (compatible with normal SD/MMC/MS) and play the content.
Supported formats: MP3, JPEG, AVI, MPEG I, MPEG II etc.
USB
Insert a USB device and play the content.
Supported formats: MP3, JPEG, AVI, MPEG I, MPEG II etc.
DVD
AV IN
CARD
USB
