Audiovox RVM35 Instruction Manual

Rearview Mirror with Integrated 3.5" TFT
Monitor
Model: RVM35
Installation/User’s Manual
Features:
•Rearview mirror with 3.5" TFT color monitor
•Mounts to your existing rear view mirror w/tension spring
clamps
•Rearview camera input
•Automatically displays backup camera image when vehicle is in
reverse

Warnings
This product is intended to assist in safe driving by signaling the driver of
obstacles behind the vehicle while the vehicle is in reverse. You, as the
driver, are solely responsible for the safe operation of your vehicle and the
safety of your passengers according to your local traffic regulations. Do
not use any features of this system to the extent it distracts you from safe
driving. Your first priority while driving should always be the safe
operation of your vehicle. Audiovox Electronics Corporation cannot
accept any responsibility whatsoever for accidents resulting from failure to
observe these precautions or safety instructions.
1. This product utilizes high voltage. Any unauthorized
modifications or damage to the product may result in electrical
shock. Handle all components with care. Inspect regularly for
damage to components and cabling.
2. You are responsible for ensuring that the installation of this
product does not void or affect the vehicle manufacturer’s
warranty. Audiovox Electronics Corporation or its subsidiaries are
not liable in full or in part for improper installation resulting in
loss or damage to your property, or for voiding all or part of the
vehicle manufacturer’s warranty.
3. Do not apply excessive force to any of the components contained
within this kit. Excessive force used before, during or after
installation that results in a damaged or non-functional part will
void all warranties.
4. Please follow the procedures in this installation manual. Improper
installation or modification of this product will void all warranties.
Warning: Backing up vehicle
Do not back up vehicle while watching the mirror/monitor screen. Always
look in the direction of vehicle motion. Use the mirror/monitor as an aid in
safety confirmation. The actual distance is shorter than it looks in the
monitor. The range of image is limited. Beware of blind spots.
1

TABLE OF CONTENTS
Warnings 1
Product Description 2
Packing List 3
Installation Instructions 4
Operation 6
Maintenance 6
Troubleshooting 7
Warranty Card 8
Product Description
This Rearview Mirror/Monitor, when used with a backup camera, is designed
to assist the driver by providing a clear and wide image of the area behind the
vehicle whenever the vehicle is shifted into reverse. Never rely solely on this
product to ensure the area is clear of children and or obstructions. Use your
monitor and look both ways. This product is not intended to replace existing
safety procedures, but to add an additional safety tool for your vehicle.
2

Packing List
Description Figure
Rear View Mirror
Power Cable
Tap Connectors
Alcohol Wipe
3

Installation Instructions
Mounting the Mirror/Monitor
1. Place the monitor spring tabs at the top of the existing mirror and gentle
pull down expanding the spring tabs until the bottom tabs fit under the
existing mirror.
Spring Tabs
2. Connect the power cable to the Monitor/Mirror cable. Place (hide) the
monitor cable behind the windshield trim piece and continue along
under the head liner to the rear of the vehicle and into the truck if
applicable.
4

Wiring the Monitor
1. Wire the Power Cable to the vehicle’s reverse lamp.
a) Locate the reverse lamp in the tail light assembly. Using the tap
connector supplied, perform the following steps:
i. Place the un-stripped positive lead wire on the run channel.
ii. Insert the un-stripped red power wire completely.
iii. Fold the tap connector back over the wires and make the
connection by crimping the u-contact down flush with the
plastic insulator.
iv. Close the top hinged cover until latched.
b) Attach the black wire to the ground.
i. Place the un-stripped ground lead wire on the
run channel.
ii. Insert the un-stripped black ground wire completely.
iii. Fold the tap connector back over the wires and make the
connection by crimping the u-contact down flush with the
plastic insulator.
iv. Close the top hinged cover until latched.
c) Connect the RCA video connector from the existing camera to the
monitor cable.
Tap/Run Connection
5

Operation
The monitor will automatically display the rear observation camera
image whenever the vehicle is engaged in reverse.
.
Maintenance
Though your backup system requires minimum care, you should maintain
its condition and performance using the following the guidelines:
•Keep your system away from excessive moisture, extreme
heat or cold and magnetic fields.
•Keep liquids away from the display mirror.
•To avoid damage, do not place auxiliary devices or other objects on
the top of the mirror.
•Occasionally clean the surface of the mirror with soft cloth moistened
with water or window cleaner.
6

Troubleshooting
Symptoms Solutions
Ensure that the parallel red and black line from
the control box is connected properly.
The ON/OFF signal light
<D> is not on after the car
is started
No video signal appears
while reversing the car
1. Verify that the LCD Contrast
(Brightness) control knob is not set too
low
2. Check the rearview Camera lens.
3. Check the rearview Camera wiring and
connection.
4. Confirm that the cable from the monitor
is connected properly.
Video image is not sharp
enough Clean the camera lens.
7

8

© 2008 Audiovox Electronics Corp., 150 Marcus Blvd., Hauppauge, N.Y. 11788
