OPERATION
MANUAL
128-8466
HR7008APKG
Two Custom Vehicle Headrests
with 7” LCD Monitors Touch Screen Control
and Built-in
DVD Player for Rear Entertainment
AUX AUX

IMPORTANT
An LCD panel and/or video monitor may be installed in a motor vehicle and visible to the driver if the LCD panel or video monitor is used
for vehicle information, system control, rear or side observation or navigation. If the LCD panel or video monitor is used for television
reception, video or DVD play, the LCD panel or video monitor must be installed so that these features will only function when the vehicle is
in “park” or when the vehicle’s parking brake is applied.
An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the
parking is not applied must be installed to the rear of the driver’s seat where it will not be visible, directly or indirectly, to be operator of the
motor vehicle.
An LCD panel or video monitor used for television reception, video or DVD play that operates when the vehicle is in gear or when the
parking is not applied must be installed to the rear of the driver’s seat where it will not be visible, directly or indirectly, to be operator of the
motor vehicle.
Licensed under one or more of the following patents:
Patent NOS. 7,245,274 and 6,899,365

3
HR7008APKG
The HR7008APKG contains two vehicle specific head-rests. Each has a 7” Monitor with touch screen control and built-in DVD Player. This
system allows the users to either watch individual DVD’s or watch the same DVD on both monitors. Both users can also share each others
program. The full function remote control can operate either unit by selecting M1 or M2 on the remote.
Quick Start Guide
1. Turn on the M1 monitor, to gain access to the DVD slot push at the top center of the screen frame, the screen will tilt forward.
2. Insert a DVD, CD or MP3 disc into the slot, disc label toward driver. Push down gently on the disc until the player pulls the disc in.
3. Use the touch screen to access the DVD mode.
4. Tilt the monitor to a comfortable viewing position (the headrest itself can be tilted forward to help achieve a comfortable viewing
position).
5. Each wireless headphone has a CH A/CH B switch. Turn the volume down to its lowest setting before putting them on your head.
When sitting in front of the M1 screen, use the CH A switch setting. When sitting in front of the M2 screen, use the CH B switch setting.
Set the headphone to the proper channel and press the Power On/Off switch. The power indicator will light up red.
6. When the DVD menu appears, select the menu item using the cursor keys and touch the OK or play button.
7. If audio playback through the vehicle radio is preferred, use the FM transmitter On/Off button on the remote control. Set the vehicle
radio to the channel selected on the M1 monitor. If interference with a local radio station occurs, set the FM modulator to one of the
other 15 radio frequencies using the CHANNEL SELECT button on the remote control.
8. Turn on the M2 Monitor using the power button on the front of the screen or remote control.
9. Tilt the screen to a comfortable viewing position (the headrest itself can be tilted forward to help achieve a comfortable viewing
position).
10. Touch the screen and touch on M1 or use remote control to press SOURCE button to view program from M1 or select from the other
available sources DVD, MEMORY CARD, USB, AV, AUX and MEDIA for M2 Monitor.
NOTE: To operate the M1 screen, press M1 on the remote control.
To operate the M2 screen, press M2 on the remote control.

4
HR7008APKG SYSTEM OVERVIEW
1) The HR7008APKG SYSTEM is a versatile headrest system. The headrests are referred to as M1 and M2 in this manual.
2) The M1 Monitor is comprised of a 7" Touch Screen TFT LCD monitor with built-in DVD player that allows the user to select from several sources (DVD,
SD, USB, M2, AV, AUX, MEDIA and GAME Source). The M1 monitor has a built-in infrared audio transmitter channel (CH A) for use with the two-
channel wireless headphones (CH A)
NOTE: When the DVD menu appears on the screen, touch the desired DVD menu selection to start the DVD playing. Refer to page for 6 operation.
3) The M2 monitor is comprised of a 7" Touch Screen TFT LCD monitor with built-in DVD player that allows the user to select from several sources (DVD,
SD, USB, M1, AV, AUX and MEDIA Source). The M2 monitor has a built-in infrared audio transmitter channel (CH B) for use with the two-channel
wireless headphones (CH B).
NOTE: When the DVD menu appears on the screen, touch the desired DVD menu selection to start the DVD playing. Refer to page for 6 operation.
4) The monitors will display all of the functions with the comprehensive Graphical User Interface (GUI) and can be accessed using the touch screen.
5) The two-channel wireless headphone sets have an A-B switch that allow the users to select the audio from either the M1 (CH A) or the
M2 (CH B).
6) When using the IR remote control, the M1 Monitor will only respond to the remote control unit when the Monitor Select (M1) button on remote control is
pressed. The M2 Monitor only respond to the Remote Control unit when the Monitor Select (M2) button on remote control is pressed.
7) Optional wired headphones allow the user to listen to audio from the system.
8) The M1 and M2 Monitor will accept an audio / video input through the 1/8” jack located on the front of the unit. The audio / video device could be a video
game system, video camera or other input device.
AUX
WIRED HEADPHONE
USB
AUX
TOUCH SCREEN GRAPHICAL USER INTERFACE (GUI)
HR7008A M1/HR7008A

5
9) Press and release the screen at the top of the screen to release the screen for disc insertion. The headrest itself can be tilted forward to help achieve a
comfortable viewing position. Pressing it again will lock the screen back in the closed position.
PULL UP
AUX
USB JACK
WIRED HEADPHONE
PUSH IN
Inner Ring
Hook
Shaft Angle
Closed Position
10) Insert/Eject disc and SD Card
Insert/Eject Disc
Insert/Eject
SD Card 19 Degrees
19 degrees

6
HR7008APKG Touch Screen
The touch screen of the HR7008APKG allows the user to start DVD play by touching PLAY MOVIE or any of the DVD menu features on the LCD screen.
Some DVD’s will not allow this function. One method is to use the remote control instead of the touch screen. The other method is to touch any of
four corners of the screen to pop up the DVD menu navigation screen (below)
Use the up/down/left/right icons to select an item from the DVD menu. Use the Enter to start DVD play.

1
32
AUX
4
5678
M1/M2 Panel Control
1. DVD disc insertion slot.
2. EJECT Button -Press this button to eject the disc.
3. SD Card Reader
4. MENU/POWER Button with Power Indicator LED.
5. Wired Headphone Jack
6. IR Transmitter LEDS.
7. USB Port
8. AUX Jack
9. IR Sensor
10. Graphical User Interface (GUI) Touch Screen
CONTROLS AND INDICATORS DIAGRAM
Control Function Description for M1 and M2 Monitor
7

8
Touch Screen For HR7008AM1/M2
Main Page
Turn on the unit by
pressing
the power button located
on
The lower left of the unit.
I) Touch the panel then
touch the Home icon to
display the Main Menu. The
Main Menu can also be
accessed by pressing the
MENU button on the unit’s
front panel.
ii) The Main Menu screens
for M1 and M2 contains
the following icons:
M1 Unit
DVD, MEMORY CARD,
USB, M2, AV, AUX,
MEDIA, GAME, PIX,
SCREEN OFF, MUTE,
FMM.
M2 Unit
DVD, MEMORY CARD,
USB,M1, AV, AUX, MEDIA,
PIX, SCREEN OFF, MUTE
Main Menu
SCREEN
OFF MUTE
MEDIA
FMM
GAMEAUX
MEMORY
CARD USB M2DVD
Main Menu
AV
AV
PIX
M1
SCREEN
OFF MUTE
MEDIA
FMM
GAMEAUX
MEMORY
CARD USB M1DVD
Main Menu
AV
AV
PIX
M2
MEMORY CARD
Insert Memory Card / SD Card into SD CARD slot.
Touch the Main Menu MEMORY CARD icon to set unit’ source
to SD.
USB
Insert the USB to the USB Slot. Touch the Main Menu USB icon
to set the unit’s source to USB.
M2
Touch the Main Menu M2 icon on the M1 unit to link the M1 unit
to the M2 unit. The M1 unit will now receive its AV from M2.
M1
Touch the Main Menu M1 icon on the M2 unit to link the M2 unit
to the M1 unit. The M2 unit will now receive its AV from M1.
AV
Touch the Main Menu A/V icon to route external audio and video
supplied to the system’s AV IN RCA connectors.
NOTE: May not be available on all installations. Contact your
dealer for more information.
AUX
Touch the Main Menu AUX icon to route external audio and
video supplied to the unit via the cable adapter.
MEDIA
Touch the Main Menu MEDIA icon to select the MEDIA display.
GAME
Touch the Main Menu GAME icon on (for M1 only). The GAME
selection is controlled by wireless game controller.
DVD
Touch the Main Menu DVD icon to set the source to DVD. Then
insert the DVD into slot with label face toward driver. Gently push
down on the disc and the disc will load automatically.

PIX
Touch the Main Menu PIX icon to gain access to the display’s
picture controls. The controls available are BRIGHTNESS,
CONTRAST, COLOR, TINT and RESET.
Adjustment of each control is made by touching + (increase) or
- (decrease), then touch
(enter) to exit.
The on screen DVD menu of most DVD’s can be used to select a
DVD menu feature such as “Play Movie”, “Scene Select”, etc. by
touching the menu item on the touch screen. For example,
touching “Play Movie” in the below screen will start movie play.
NOTE: A small number of DVD discs will not function like this. In
that event use the remote control to start the movie or select the
different DVD options.
9
MUTE
Touch the Main Menu MUTE icon to toggle the unit’s audio
between on and off.
SCREEN OFF
Touch the Main Menu SCREEN OFF icon and the screen will
shut off. Touch the screen again to turn it back on. The screen
will turn back on after cycling power.
FMM
Touch the Main Menu FM MODULATOR icon (For M1 only) to
gain access to the FM Modulator controls
To turn on FM Modulator touch +or - icon, then select the FM
modulator transmission frequency by touching - (decrease) or
+ (increase) [88.1MHz ~ 91.1MHz]. Touch (enter) to exit.
Set the vehicle radio to the selected frequency to listen to the
movie over the vehicle sound system.
To turn off the FM Modulator function, touch OFF icon. Then
touch (enter) to exit.
OFF
FMM 88.1 MHZ
PIX
COLOR 16
COLOR 16
Scene Select
•
Extras
•
ETC
•
Audio
•
Play Movie
•

Back View
10
REMOTE CONTROL WITH
WIRELESS GAME CONTROL OPERATION
DIRECTION KEYS
M1/M2
P1/P2
SELECT
TB
A
TA
B
GAME/REMOTE
SELECTOR SWITCH
BATTERY COVER
START
RESET
Battery Installation
Before attempting to operate your remote control, install the
batteries as described below.
1) Turn the remote control face down. Using a finger, slide
battery cover off in the direction of the arrow.
2) Install three “AAA” batteries. Make sure that proper polarity
(+ or -) is observed.
3) Align the cover tabs with the remote control and slide the
cover until it locks.
The remote control will operate the M1/M2. It is not a universal
remote control and will not control equipment from other
manufacturers.
1. Position the GAME/REMOTE selector switch to Game
position.
2. Use the select button (page up & page down) to display the
games (1-32). Then use the direction buttons to move the
arrow to the desired game. Press Start to select the game.
3. A Key : “A Function Key” activates the jump and optional
weapons.
4. B Key : “ B Function Key” activates Bullet fire and attack.
5. TA Key : TURBO “A” Function Key.
6. TB Key : TURBO “B” Function Key.
7. Press Start to begin the game. Press Start again at any time
to pause the game.
8. Press RESET to return to the game menu.
9. P1/P2 selector switch is used for playing 2 player games. P1
is M1 player, P2 is for M2 player.
10. M1/M2 selector switch to M1 position only for games.
11. Return the GAME/REMOTE selector switch to Remote
position after use.
WIRELESS GAME CONTROLLER FUNCTIONAL
DESCRIPTION

11
* Function control is available on the unit and the remote control.
1. POWER Button*
Press this button to turn the unit ON and OFF.
2. MONITOR SELECT
M1 Button – Sets the remote control codes to enable the
control of M1 Monitor.
M2 Button – Sets the remote control codes to enable the
control of M2 Monitor.
3. TV Mode Select Button
TV function not available in this model.
Note: Pressing the TV button will disable the DVD, SD, and
USB functions. To regain control of the functions, press the
DVD button.
4. DVD Mode Select Button*
Switches certain function keys on the remote control for DVD
functions. See page 13.
Note: Pressing the TV button will disable the DVD, SD, and USB
functions. To regain control of the functions, press the DVD
button.
5. SYSTEM MENU Button
Function not available in this model.
6. SOURCE Button*
For M1: Each time the button is pressed, the audio / video
source will change in the following sequence:
DVD > M2 > AV > AUX > MEDIA > GAME.
For M2: Each time the button is pressed, the audio / video
source will change in the following sequence:
DVD > M1 > AV > AUX > MEDIA.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
37
36
35
34
33
32
31
30
29
28
27
26
25
24
23
22
MAIN FUNCTION DESCRIPTION

7. AUTO MEMORY Button (AUTO PROGRAM Button)
Function not available in this model.
8. SKIP / SEARCH Button
Function not available in this model.
9. ERASE / WRITE Button
Function not available in this model.
10. DISPLAY
Press to display current disc information while the disc is playing. Press cursor (pq) buttons to select the Title or Chapter.
For Title/Chapter selection use the numeric buttons to enter the desired Title Chapter selection.
11. FMM ON/OFF Button*
Turn the wireless FM Modulator on or off.
12. CHANNEL SELECT Button*
Select the wireless FM Modulator Frequency:
(Ch1 88.1MHz, CH2 88.3MHz, CH3 88.5MHz, CH4 88.7MHz, CH5 88.9MHz, CH6 89.1MHz, CH7 89.3MHz, CH8 89.5MHz, CH9
89.7MHz, CH10 89.9MHz, CH11 90.1MHz, CH12 90.3MHz, CH13 90.5MHz, CH14 90.7MHz, CH15 90.9MHz, CH16 91.1MHz).
13. RETURN Button
Press Return Once: Go to disc menu.
Press Return Twice: Go to movies playback.
14. REPEAT Button
Allows the user to repeat a selected title, chapter or track.
12

13
15. AUDIO Button
Press to display and select the available AUDIO languages in DVD mode. Each time you press the button, the language changes.
Note: The audio languages vary from disc to disc.
16. MENU Button
Pressing the MENU button in DVD mode will cause the DVD root menu to be displayed. When using the SD card or a USB device, pressing
the MENU button will cause the root menu to be displayed. Pressing the MENU button while listening to MP3 files has no effect. The
operation is prohibited.
Note: Pressing the TV button will disable the DVD, SD, and USB functions. To regain control of the functions, press the DVD button.
17. SUBTITLE Button
Press to display and select the available subtitle language in DVD mode. Each time you press the button, the subtitle language changes.
Note: The type and number of subtitle languages vary from disc to disc.
18. PAUSE ( II ) Button*
Allows the user to pause the playback. Pressing pause again or pressing the Play Button will resume normal playback.
19. PREVIOUS (9) Button*
Press to return to the previous chapter or track.
20. STOP (n) Button*
Press to stop playback.
21. SCAN BACKWARD (7) Button*
Press to search in the backward direction. Press repeatedly to change the search speed from 2, 4, 8 and 16 times the normal speed.
22. PLAY (u) Button*
Press to activate the play mode when a disc is loaded in the disc compartment.

14
23. SCAN FORWARD (8) Button*
Press to search in the forward direction. Press repeatedly to change the search speed from 2, 4, 8 and 16 times the normal speed.
24. NEXT (:) Button*
Press to skip to the next chapter or track.
25. OK Button (ENTER)*
Used to implement a selected setting or menu option.
26. CURSOR (pqt u)*
Use these buttons to navigate the menu selection on the screen.
27. SETUP Button
Press the DVD button and SETUP button to display the Setup Menu which allows the user to change the DVD player options such as
OSD Language, Video, Rating etc. Refer to the settings and adjustment section for more information.
28. ZOOM Button
Press this button to enlarge the picture when playing a DVD disc.
Press ZOOM button DVD Player perform
Once Enlarge the picture
Twice Enlarge the picture
3 Times Enlarge the picture
4 Times Picture is returned to original size
29. A-B Button
Allow user to repeat disc playback from point A to point B.
Press A-B button On-Screen Display DVD Player
Once Repeat A- Mark the beginning of the section to repeat (Set point A)
Twice Repeat A-B Mark the end of the section to repeat (Set point B)
3 Times AB Off Cancel the A-B repeat function

15
30. IRT ON/OFF Button
Turn the Infrared Transmitter ON or OFF for IR Wireless Headphones. Pressing M1 then IRT ON/OFF will control the IR
Transmitter for M1. Pressing M2 then IRT ON/OFF will control the IR Transmitter for M2.
31. MUTE Button*
Press this button to mute all the audio.
Pressing the button again restores the sound to the previously set level.
32. DAY / NIGHT Mode Button
Function not available in this model.
33. PIX Button (Picture Select)*
Each time this button is pressed, the on screen picture adjustment displays the “adjustment bar” for BRIGHTNESS, CONTRAST, COLOR,
TINT or RESET. Once the desired adjustment bar is displayed, use the VOLUME (+) / VOLUME (-) button to adjust the setting. The display
will automatically turn off if no adjustments are made within 6 seconds.
34. VOLUME DOWN (-) or UP (+)*
Press to select the level of the picture adjustments when the unit is in picture adjustment mode or to increase or decrease the volume for
the wired headphones.
35. NUMBER Buttons
Allow the user to enter numbers 0 to 9 for selection of selection of CD tracks, DVD chapters and password.
36. DVD Source*
This button is only active when remote control is in DVD mode. Each time the button is pressed one of the source (DVD, Card
Reader and USB) will be selected. If the Card Reader and USB are not plugged in, it will remain on DVD Source. Press to change
source in sequence of DVD > SD > USB.
37. EJECT () Button
This button is used to eject the disc.
NOTE: This function is not available on this model. Use the eject button on the DVD player.

The Setup Menu contains features and options that let you customize your DVD player. For example, you can set a language for the on-
screen display or control DVD playback content for children. You can use the remote control or the touch screen to navigate the setup
menu.
Using the DVD Setup Menu
Setup Menu
Setup Menu be
Setup Menu
Setup Menu.
.
.
Setup Menu
LANGUAGE SETUP
Language for On-Screen Display
OSD MENU: The OSD MENU setup allows you to select the language for the on-screen display.
The user can either select English, French, Spanish, German or Italian for the OSD language.
The can be accessed using either the remote control or the touch screen. To access
the using the touch screen you must have a DVD in the unit and in DVD Mode.
The remote control can access the DVD by pressing DVD and SETUP.
Touch Screen:
1. Touch the touch screen to bring up the DVD control menu.
2. Touch the (tool) icon to bring up the DVD
3. Touch any of the four settings (Language/Video/Rating/Misc) to access the submenu for that item.
4. Touch the submenu item on the right side of the screen to select it, a submenu will appear. Touch the submenu item to select it
5. Touch the RETURN icon to return to the DVD movie
Note: The cursor keys at the bottom of the screen can be used to navigate through the touch screen menu.
Remote Control:
1. Press DVD and SETUP on the remote control to bring up the DVD Setup Menu.
2. Use the UP/DOWN buttons to select any of the four settings (Language/Video/Rating/Misc) to access the submenu for that item.
3. Use the RIGHT ARROW button to highlight the desired menu item. A submenu will appear. Use the UP/DOWN arrow button to
highlight the desired submenu item. Press the OK key to set the item.
4. Use the LEFT ARROW button to return to the settings on the left.
5. Use the SETUP button on the remote control to exit the DVD and return to the movie.
Vi deo
Rating
Misc
Subtit l e
Audio
: English
: Off
: English
Language Language
SETTINGS AND ADJUSTMENTS
Vi deo
Rating
Misc
Language
Subtit l e
Audio
Language Engl i s h
Fren c h
Span i s h
Ge rma n
Ital i a n
ü
16

SUBTITLE SETUP
Select "SUBTITLE" using pqbutton, then press ubutton to enter the Sub menu. Select the subtitle you
desire using pqbutton, then press OK / to confirm the setting. Press tbutton to return.
Note: The subtitle selection is only available for discs that are recorded in the above listed languages. If the selected,
language is not available, the player will play and display on the screen the original language contained in the disc.
AUDIO SETUP
Select "AUDIO" using pqbutton, then press ubutton to enter the Sub menu. Select the audio you
desire using pqbutton, then press OK / to confirm the setting. Press tbutton to return.
Note: The audio selection is only available for discs that are recorded in the above listed languages. If the selected,
language is not available, the player will play and display on the screen the original language contained in the disc.
VIDEO SETUP
TV Display
The TV DISPLAY setup allows you to adjust screen setting (aspect ratio) from 4:3 or 16:9. Depending
on the DVD format, the screen will appear full or with black bands.
TV Type
The TV Type setup allows you to select the system to fit to the color system of the TV to be connected.
NTSC - Select this type for NTSC TV
PAL - Select this type for PAL TV
Vi deo
Rating
Misc
Language
Subtit l e
Audio
Language Engl i s h
Fren c h
Span i s h
Ge rma n
Ital i a n
Japa n e se
Thai
Chin e s e
Of f
ü
Vi deo
Rating
Misc
Language
Subtit l e
Audio
Language Engl i s h
Fren c h
Span i s h
Ge rma n
Ital i a n
Japa n e se
Thai
Chin e s e
Of f
ü
Vi deo
Rating
Misc
Language
TV Type
TV Di splay
NTSC
PAL
ü
Vi deo
Rating
Misc
Language
TV Type
TV Di splay 4 : 3
16 : 9
ü
17

Vi deo
Rating
Mi sc
Language : Ad u l tParent a l c o n trol
Set Pass w o r d
RATING SETUP
Parental Control
This item allows you to limit the content of movie playback from G to Adult. The lower the value,
the more strict the control.
1. G
2. PG
3. PG – 13
4. R
5. NC – 17
6. Adult
The rating level can only be changed when the correct password is provided. For first time use to change
the parental control, use cursor u button to enter parental mode. Press OK / and key in the default
password (3308) and press OK / .
Press OK / button again to select the parental level, select the level and press OK / .
Change Password
To change the password to your own password select “Set Password” mode and press OK / . Enter the default password (3308) and
press OK / . Press OK / button again and key in a new four digit password. A prompt will appear to “Confirm Password” Enter the
new password again and press OK / . You will then see a prompt that states “Set Password Successful”.
Note: The Default Password is 3308. This password is always effective even after you have selected your own password and changed it. To avoid the possibility
of others using the default password to set the parental level and change the password, you can record this default password in another area and delete it from this
manual. Playback of some discs can be limited depending on the age of users while some discs cannot.
18
Vi deo
Rating
Mi sc
Language
1 2 3 456
7 8 90 D E L
: AdultPa r e ntal control
Set Pass w o r d
Enter Pa s s w o rd

Misc SETUP
Select "MISC” using pq button, then press u button to enter the Misc menu. Select the option you
want to change using pq button, then press “OK” / .
Use Default Setting
This option allows you to reset all options to settings.
* This function will not affect the Rating control settings.
Screen Saver
This option allows the operator to set the Screen saver mode.
ON -Screen saver will appear
OFF -Screen saver will not appear
Note: The DVD player will enter Screen Saver mode if the unit is inactive for approximately 2 minutes.
Touch Cal
This option allows you to calibrate the touch screen. Select ‘TOUCH CAL” and press OK / .
Use the q button to select ‘YES”. Press OK/ . Touch each of the panel calibration symbols (+) on
the panel’s four points. Once the four points have been touched the unit will display “CAL OK” or
“INVALID CAL”. If the calibration is invalid, repeat the procedure until the prompt “CAL OK” is displayed.
After the calibration, the new record will overwrite the old one.
Playing DVDs
1. Press the DISPLAY button on the remote control to display the status banner.
The banner includes title, chapter, angle, audio, subtitle, tittle selection and chapter selection .
2. Title Selection
Press numeric (0~9) buttons to initiate a change of title selection. Then press OK button to implement the selection.
3. Chapter selection
Press numeric (0~9) buttons to initiate a change of chapter selection. Then press OK button to implement the selection.
Vi deo
Rating
Misc
Language
Screen Sa ver
Use De fault Se t t i n gs
: On
Tou c h Ca l
Do you wa n t t o us e de fault setting ?
Yes No
Vi deo
Rating
Misc
Language
Tou c h Ca l
Screen Sa ver
Use De fault Se t t i n gs
Off
On
ü
Vi deo
Rating
Misc
Language Use De fault Setting s
Off
No
ü
Tou c h Ca l
Screen Sa ver
Yes
19

Playing MP3 Discs
MP3 is a format for storing digital audio. An audio CD-quality song can be compressed into the MP3 format with very little loss of quality,
while taking up much less space. CD-R discs that have been encoded in MP3 format can be played on DVD player. The DVD player plays
the songs in the order they were burned on to the disc. When playback is started the elapsed time of the track that is playing will be
displayed.
Selecting Folders and Songs
When a device containing MP3 files is loaded in the player, the navigation menu appears automatically.
1. Press p or q to move the highlight to the desired folder (if present) on the left side of the menu and press OK. The songs in the folder will be
displayed on screen.
2. Press p or q to move the highlight to the desired track containing the song and press OK to begin track playback or touch on the track title on
the screen.
Skipping Songs
Use the Next (:) button on the remote control to move to the next song. Use the Previous (9) button to move to the previous song.
Selecting a Play Mode
Filter (For MP3 & JPEG only)
Filter Mode enables or disables the display of files contained on the media based on their file extension.
The filter function applies to the following formats:
Audio - Audio data format (MP3, WMA)
Photo - Photo data format (JPEG)
Video - Video data format (MPEG , )
Filter
Repeat
Mo de
Select
Progra m Mo de
Track 001
Track 002
Track 003
Track 004
Track 005
Track 006
1/15 00:00:59
Repeat
Mo de
Select
Progra m Mo de
Track 001
Track 002
Track 003
Track 004
Track 005
Track 006
1/15 00:00:59
Filter A u d i o
Vi deo
ü
ü
ü
20
