Audiovox D8000XP User manual

D8000XP
PORTABLE 8" LCD MONITOR AND DVDPLAYER

2
AnLCDpanel and/or videomonitor maybeinstalled in amotor
vehicleandvisibleto thedriver if the LCDpanelorvideomonitoris
usedfor vehicle information, system control, rear or side observa-
tion ornavigation.If the LCDpanelor video monitor isusedfor
televisionreception,videoorDVDplay,theLCDpanel or video
monitor must be installedso that these features will onlyfunction
when thevehicle isin park”or whenthe vehicle’sparkingbrakeis
applied.
AnLCD panelor video monitor used for television reception, videoor
DVD playthat operates when the vehicleisingear or when the
parkingbrake is notappliedmust be installedto therearof the
driver’sseat where it willnotbe visible, directly or indirectly, to the
operatorof themotor vehicle.
Notice:
This Product incorporates copyright protectiontechnologythatis pro-
tected by method claims of certain U.S. Patents andotherintellectual
propertyrights owned byMacrovision Corporationand other rights
owners. Useofthis copyright protection technologymust be autho-
rizedby MacrovisionCorporation,andis intendedfor homeand other
limited viewingusesonly unless otherwiseauthorizedby Macrovision
Corporation. Reverse engineeringor disassemblyis prohibited.

3
Content
A.Introduction......................................................................................4
B.CautionsandWarnings...................................................................4
C.Contents............................................................................................6
D.Poweringand Installation................................................................6
E.InstallinginaVehicle........................................................................7
F.Controls, Indicators andConnectors...............................................8
G.RemoteControl.................................................................................9
H.Loadingand PlayingaDisc.............................................................10
I.BasicOperation................................................................................10
J.Menu..................................................................................................11
K.Display...............................................................................................11
L.PlayingAudioCDs............................................................................15
M.PlayingMP3Discs............................................................................17
N.PlayingSD/MMS/MCCard................................................................18
O.UsingAnUSB MemoryDevice.........................................................19
P.Setup..................................................................................................20
Q.ClockandCalendarDisplay.............................................................26
R.ConnectingtoaTVorAnotherMonitor............................................26
S.Rechargeable BatteryInstallation and Use......................................27
T.Specifications...................................................................................29
U.Troubleshooting...............................................................................30

4
A.Introduction
Thankyou for choosingtheD8000XPportable DVD player. The
mainfeaturesinclude a8" WideScreen(16:9Aspect Ratio) Liquid
CrystalDisplay (LCD)swivelmonitorandaDVD player. Theunit
alsocontainsa 3 in1 cardreaderand a USBport. The unitisde-
signedforusewithSD/MMC, MSmemory cardsand USBmemory
devices.Inaddition toplaying DVDs theunit can displayimagesin
slideshowmodeandserveas aclockorcalendar. Theunitapplies
the latest stateoftheartelectronics andis designedfor use in ho-
tels,offices oryour home. Theunit is constructedto provideyears
ofreliable,trouble-free service,andiscompact sothat youcantake
itwithyouanywhereandisdesignedforquickandeasy installation.
Pleasereadtheentireinstructionmanualsupplied withthis product
prior to using. The documentation will assist you in installing the
systemproperlyto obtainthebestequipment performance.Please
savethis manualforlateruse.
B. Cautions and Warnings
1. Placement
Topreventfire or electric shock, do notexpose this appliance to
rain ormoisture. Donot place the set on an unstablecart, stand,
tripod,bracketortabletopreventitfromfalling.Keeptheunitaway
fromstrong magnets, heat sources, direct sunlight, excessive
dust.If theunit is broughtdirectly fromacoldto awarmlocation,
moisturemaycondenseinside theunit. Whenyoumove itfroma
coldtoawarmlocation,waitfor about onehourbeforeoperating
theunit, or removethedisc and leavetheunitturned onuntil the
moisture evaporates.
2. Installation
Ensurethat the8”portable DVD player isused in accordance
withthe instructions andillustrations providedinthis manual.
3. Caution
Do not push objects ofanykind into theunit through openings;
do not spill or sprayliquid ofanykind on or in the system (this

5
5. Cleaning Unit
Whencleaning, makesurethe system isunplugged fromthepower
source. Donotuseliquid cleaners or aerosolcleaners. Usea cloth
lightly dampenedwith waterfor cleaningtheexterior ofthe system
only.
6. Disc
Do not use irregularlyshaped discs such asheart orstar-shaped
discs as theymay cause the unittomalfunction.Donotstickpaper,
tapeor glue on the disc. Do not expose thedisc to direct sunlight
or heat sources. Do not touchthe surface ofdisc. Handle thedisc
by itsedge. Cleanthedisc bywipingthedisc from the center out
with acleaning cloth. Removethe disc from the unit and store it in
its case after playing. Some playbackoperationsofdiscs maybe
intentionally fixed bysoftwareproducers. Since this unitplays discs
according to the disc contentsthesoftwareproducers designed,
some playbackfeatures maynot be available. Also refer to the in-
structionssuppliedwiththediscs.
7.RegionalCoding
Both the DVDplayer and discarecodedbyregion. These re-
gional codesmust match inorder for the discto play.Ifthe codes
don’t match, the disc won’t play. This unit’s codeis region1.
DVD’swith other regional codes cannot be played in thisunit.
may resultin a fire or electricshock). Donot placeanythingheavy
onthe unit.Toensureproperventilation and properoperation,never
cover or block and openingswith acloth or other material.It is
hazardousto replacethebatteryincorrectly.Replace thebattery
only with the sameor equivalent type,andin order toprotectthe
enviromnent, pleasedispose the batteryproperly. Do notuse the
unit intemperatures higher than95 degrees Fahrenheit or35 de-
grees Celsius.
4.Disassembly
Do not attempt to disassemble the cabinet. There is ariskofelec-
tricshock and/orexposure to LaserRadiation. Contact qualified
service personnel ifyour system needs repair.

6
C. Contents
1. 1 x 8""LCD Monitor& DVD Player
2. 1 xRemote Control with battery(CR2025)
3. 1xAudio/Video Cable
4. 1 xUSBAdapter Cable
5. 1 xAC to DCAdapter
6. 1 xDC Power Adapter
7. 1x Instruction Manual
8. 1 x Rechargeable Battery
9. 1 x Strap
10. 1 x Carrybag
D. Powering and Installation
1. Powering the system indoors (Refer to Figure 1)
Plugone end of theACto DC adapterinto theDCinputjackon the
left side ofthe main unit, then plugthe otherendintothe 110~240V
AC power receptacle.
2. Powering the systemin a car
Plug one end ofthe DC Power adapter into the DC input jackon
theunit, then plug the other end intothe vehiclepower outlet.
Figure 1
Note: If the DVD player is not going to be used for a long period of
time, disconnect the unit from power source.

7
E. Installing in a Vehicle
Installingthe DVD Player onto the seat back ina car
(Refer to Figure 2)
Figure 2
1).Position theheadrest strap throughthe two DVD strap holders
locatedon the back ofthe DVDplayer.
2).Openand rotate the DVDplayer LCD monitor 180 degreesand
fold down as shown.
3).Securethe DVDplayerto headrestusingtheheadrest strapand
headrest strap buckle. Adjust theheadreststrap until the DVD
player is firmlysecured to the vehicle headrest.
Headrest
Strap
Rear of DVDPlayer
Headrest
Strap
Buckle
Rear ofVehicleSeat
Headrest
DVD Strap
Holders

8
1) Menu Button
2) Wide Button
3) Stop Button
4)Pause Button
5) UpButton
6) Play/OK Button
7) Right / Fast Forward Button
8)DownButton
9) Left / Fast Reverse Button
10) DC Input Jack
11)AVJack
12)AV in/out SW
F. Controls, Indicators and Connectors
1. Unit View (Refer to Figure 3)
13)SD/MMC/MS Card Slot
14)USB Slot
15)Power ON/OFF Switch
16) Power ON LED Indicator
17) RemoteControl Sensor
18) OpenSwitch
19)Brightness Up/Down Control
20) Volume Up/Down Control
21)Headphone Jack2
22)HeadphoneJack1*
23)Charge Indicated LED
Figure 3
*Using headphonejack 1 willdisabletheinternalspeakers
16
17
18
1
2
3
4
5
6
7
8
9
9
10 1112131415
20
19
21
22
23

9
G. Remote Control
•Pull out the insulatingtab to connect the battery.Aim the front
ofthe remote directlyat the sensor on the player. Ifthe remote
control rangegraduallydecreases the battery probablyneeds
replacingwith a new CR2025 or equivalent coin cell type. In-
structions to replace the batteryare illustrated on the underside
ofthe remote control .
•Ifthe Remote Control is not to be used for a longtime, remove
the batteryto avoid corrosion damagecaused bybattery
leakage.
WARNING: Dispose ofthelithium battery in an enviromentally
responsible manner. Do not dispose ofa lithium batteryin a fire
as the batterywill explode! Please observe lithium batterywarn-
ingonpage5.
1)Setup Button
2)UpButton
3)Skip- Button
4)Enter Button
5)Reverse/Left Keypad
6)DownButton
7)NumericButtons
8)DisplayButton
9)ZoomButton
10)SD/DVDButton
11)Skip+Button
12)A-BRepeat Button
13)Forward/Right Keypad
14)1/All Repeat Button
15)Stop Button
16)MenuButton
17)SubtitleButton
18)AudioButton
19)Play/PauseButton
Pull out plastic tabto connect thebattery.

10
H. Loading and Playing a Disc
a.After connecting powerto theunit, poweron DVDplayer”with the
power switch. The powerindicator will light.
b.Openthedisctrayby sliding theOPEN switch inthe directionof
the arrow. Place a disc in the traywith label sidefacingup.
c. Close thetray bypressingthe area marked PRESS”.Theunitwill
load the discand start playing.
d.Rotate BRIGHTNESS andVOLUME toadjust theLCD’sbright-
nessand the DVD player’s volume.
e.Pressthe STOP ( )buttonduring playback.One pressallows
re-start from thestoppingpoint bypressingtheplaybutton. Two
pressesand playwill re-start from the beginningofthe disc.
POWER
OPEN
PLAY
PAUSE
STOP
SKIP+/NEXT
SKIP-/PREVIOUS
FORWARD/RIGHT
REVERSE/LEFT
UP/DOWN
ENTER
NUMBERS
MENU
1/ALL REPEAT
A-B REPEAT
Turnthe uniton/off
Remove/ load disc
Start Play/Execute item or setting
Pressfor stillpicture and againto re-start play.
Press once to stop and restart at thestop point
Press twice to stop and restart at the beginning
ofthe disk.
Goto thenextchapter,trackorsceneduringplay
back
Goback tothepreviouschapter,track, scene,
photo or songduring play back
Scanforwardat2, 4, 8,16or 32 timesspeed;
move rightinMenuNavigation
Scanbackwardat2, 4,8,16 or32 timesspeed;
move left inMenuNavigation
Usedtomove up ordownforMenuNavigation
Confirm choiceor executefuntion.
Select track,chapter or file number.
Display the mainmenu ofthe disc
Repeatplaytitle,chapter, trackorsong.
Repeat a specific portion from point A to point B
ofthe disc.
I.BasicOperation

11
DISPLAYDisplayinformation(title, chapter, track,time, etc.)
SUBTITLESelectthesubtitlelanguage andturn it on/off
AUDIOSelecttheaudio language
ZOOMEnlarge animage to2,3, 4 ,1/2,1/3 or 1/4
times the originalsize.
SETUPDisplay the setup menu to select and set items,
and exit the setupmenu.
WIDEOn the player only: change betweenwide screen
and 4:3 picture aspect ratio.
J.Menu
A DVD is divided into sections called titlesandchapters. When you
play a DVD,aroot menu ofthedisc will appearonthescreen ofyour
TV orMonitor. Thecontentsof themenu varyfrom disc todisc.Press
MENU duringplaybackto display the menu. Some DVDs onlyallow
you to select disc playbackoptionsusingtheDVD root menu.
K. Display
1. PLAYINGTIME AND REMAININGTIME
a. Duringplaybackpress the ‘DISPLAY’button to displaythe cur-
rent Title Number (1), the total Number ofTitles (2), the current
ChapterNumber (3), thetotal Numberof Chapters (4), andthe
Playingelapsed Time for the title (5).
TITLEELAPSED
TT0101CH0217 //
00000 ::
4
3
2
1
5
Title, ChapterNumber and Time ScreenDisplay

12
2. SUBTITLE
During disc playbackpress ‘SUBTITLE’to select the subtitlelan-
guageyou desire*, withthe current Subtitle Language Number (1)
andthe total NumberofSubtitle Languages (2) displayed. Ifthere
aremultiple languages press ‘SUBTITLE’againto selectanother
subtitle language. Toturn subtitles OFF,press the ‘SUBTITLE’but-
ton until ‘SUBTITLE OFF’is displayed. The Subtitle display willdis-
appear automaticallyifthe ‘SUBTITLE’button is not pressed again
within3 seconds.
*Some DVDsonlyallowaccess to thisfunctionthroughtheDVD
menu
SubtitleScreenDisplay
SUBTITLE0102 /
b.Pressing‘DISPLAY’repeatedlywill provide the followingsequen-
tial options below:
TITLE ELAPSED: Theelapsed time ofthe title
TITLEREMAIN :The remainingtime of the title
CHAPTER ELAPSED: The elapsed time ofthe chapter
CHAPTERREMAIN: The remainingtime ofthe chapter
DISPLAYOFF: TheDVD’stimeiInformationisremovedfromview.
TITLEELAPSED
TITLEREMAIN
CHAPTERELAPSED
CHAPTERREMAIN
DISPLAYOFF

13
Audio Language
Zoom
3. AUDIO
During playback press ‘AUDIO’toselect the audiolanguage you
desire*, with thecurrent AudioChannelNumber(1) and the total
numberof AudioChannels(2)displayed. PressAUDIO againto se-
lect anotheraudiolanguage. Theaudio displaywilldisappear auto-
matically ifthe ‘AUDIO’button is notpressed withinfor 3 seconds.
*SomeDVDsonly allow accessto this functionthrough theDVD menu.
4.ZOOM
Duringplaybackpress ‘ZOOM’to enlarge the picture by2X, 3X ,4X ,
1/2X,1/3Xor1/4X.
(1) Press ZOOM”one time, the picture will be enlarged 2X.
(2) Press ZOOM”a second time, the picture will be enlarged 3X.
(3) Press ZOOM”a 3rd time, the picture willbe enlarged 4X.
(4) Press ZOOM”a 4th time, the picture will be enlarged 1/2X
(5) Press ZOOM”a 5th time, the picture will be enlarged 1/3X
(6) Press ZOOM”a 6th time, the picture will be enlarged 1/4X
(7) Press ZOOM”a 7th time, the picture will return tonormal size.

14
5. A-B REPEAT
a. Duringplaybackpress ‘A-B’to once to set the StartingPointA.
b.Press ‘A-B’asecond time to set the EndingPoint Band the
player will repeatedly playthe partbetween PointAand
Point B.
c.PressA-B athirdtime to cancelA-B repeat and resume
normalplayback.
A-B Repeat Starting Point
A-BRepeatEnding Point
A-B RepeatOff
REPEATOFF

15
L. Playing Audio CDs
When playinganaudio CDpress the DISPLAYbutton repeatedlyon
theremote to viewplaytime information. The options beloware
displayed in following sequence.
CD Display Mode
Chapter Repeat
6.1/ALLREPEAT
a.Duringplayback press‘1/ALLREPEAT’repeatedly tocycle through
therepeat modes.
CHAPTER: Repeat the current chapter
TITLE: Repeat the current title
ALL: Repeat all chapters and titles
REPEATOFF:Resumenormal playback
The ‘Chapter’repeat displayis shown below:
Single Elapsed When Playing Audio CDs
SINGLEELAPSED
Single Elapsed
SingleRemain
TotalElapsed
TotalRemain
Display Off

16
A-B RepeatOff
TOTALELAPSED:The current trackplayingand the totaltime that
the CD has been playing.
TOTALREMAIN:The current track playingand the amountoftime
remaining on theCD.
DISPLAY OFF:The CD time Information will not be displayed.
1. A-B REPEAT
a. Duringplaybackpress ‘A-B’to once to set the StartingPointA.
b.Press ‘A-B’asecond time to set the EndingPoint Band the
player will repeatedly playthe partbetween PointAand
Point B.
c.PressA-B athirdtime to cancelA-B repeat and resume
normalplayback.
A-B Repeat Starting Point
A-BRepeatEnding Point
REPEATOFF

17
TrackRepeat
2.1/ALLREPEAT
a.Duringplayback press‘1/ALLREPEAT’repeatedly tocycle through
therepeat modes.
TRACKCHAPTER: Repeat the current track
ALL: Repeat all tracks
REPEATOFF:Resumenormal playback
The ‘Chapter’repeat displayis shown below:
M. PlayingMP3 Discs
MP3isa format for storingdigital audio.AnaudioCD-quality songis
compressed into theMP3 format with very littleloss ofaudio quality
whiletaking up much less disc space.CD-R/RWdiscs that have
beenencoded in MP3formatare compatible with this system.
1.Open the disc tray by slidingtheOPENswitch inthe direction
of the arrow and place adisc into the tray with thelabelside
facing up.
2. Close the trayby pressingthe area marked PRESS”on the
disc door.
3.Usingthe LEFT buttonhighlight theAUDIO icon in the main
menu page.
4.PressOKbutton to automaticallyplay the first song.The
audiotracksare displayedon theleftside ofthescreen. Artist
information is displayed on the right ofthescreenwhen
available. Use the UP or DOWNbuttons to select the desired
trackthen pressthe OKbuttontoplay.

18
USINGTHEREPEATFEATURE
Thedefault modefor the Repeat feature isOFF. Pressing REPEAT
consecutively changes the repeat options:
•Repeat One (repeat playback ofa song)
•Repeat All(repeat playbackofall the songs)
•RepeatOff (normal playback)
As you toggle throughthe options, the repeat mode changes. The
selected repeat mode loops repeatedly until you turn it off.
N. Playing SD/MMC/MSCard /USB disc
1). Insert the SD/MMC/MSCard/USBdiscinto SD/MMC/MScard
slot/USB slot.
2). Press the SD/DVD Button on the Remote Control to access the
SDMenu.
3).Usingthe cursor buttonsmove the selection box to Photo”.
Press ENTER button to access the Slide Showmode.The
photoswill automaticallydisplay one after another.
4).PressENTER again to access the Pause. The player will display
asingle image. You can use thePREV.andNEXT button to
select a photo.
5). Press ENTER three times to enter Digest mode.Thumbnail
imagesofthephotos appearina table. Use theLeftandRight
buttonto navigatethrough thethumbnails.

19
Audio
6). Using theLEFT buttonhighlighttheAUDIO iconinthe main
menu page.
7).Press OK button to automatically playthe first song.And the
audiotracksare displayedon theleftside ofthescreen. Artist
information is displayed on the right ofthescreenwhen
available. Use the UP or DOWNbuttons to select the desired
trackthen pressthe OKbuttontoplay.
O. Using AnUSB MemoryDevice
1).Connect the USB memorydevice totheUSB Adapter
Cable female connector.
2).Connect theUSB Adapter Cablemale connector tothe DVD
player.
3).UponconnectingtheUSB Adapter cable, themainmenupage is
displayed. When the PHOTO categoryis selected, ifthe USB
memory device contains image files, the images will be
displayed. Refer tosteps 3,4, and5above. When theAUDIO
categoryis selected, if the USB memorydevice contains audio
files, the files will be displayedas tracksand played.

20
Press ‘MENU’ontheDVDplayerorto display the Main Menu onthe
screen.
1. GeneralSetup Page
1)RemovetheDVD disc fromthe player. Use the cursorbuttons move
theselectionboxto SETTINGandpressthe ENTERbutton.
2) Press the ENTER button again to accessthe sub menu.
3) Press the or button to select the the sub menu.
4) Press to enter the sub menu.
5) Press the or button to select the submenu and pressEN-
TER to confirm your selection.
6) Repeat steps 3-5 for other menus.
NOTE: Press to return the previous menu.
P. SETUP
a).TVDISPLAY
The submenuconsistsof Normal/PS (panandscan), Normal/LB
(4:3 aspect ratio) and Wide (16:9 Wide Screen).
b).SCREEN SAVER
ON: Enables screensaver
OFF: Disables screensaver
NOTE: The DVD player will enter the Screen Saver mode after
approximatelyfive minutes ifthe same image remainson the
screen.
c). LASTMEMORY
Thelast positionmemoryfunction is onlyactivated when the disc
trayis opened and the last memoryfunctionis set to ON.
ON: The unit will return to the last position on the disc.
OFF: The unit will not return to the last position on the disc.
