Autel Robotics EVO II Series User manual

For EVO II Series
USER GUIDE
BATTERY CHARGING HUB

Thank you for purchasing the EVO IITM Battery Charging Hub (hereinafter
referred to as “Product”). Read this disclaimer carefully before using this
Product. By using this Product, you hereby agree to this disclaimer and signify
that you have read it fully. Please use the Product in strict accordance with the
manual and be sure to pay attention to the Warnings. SHENZHEN AUTEL
ROBOTICS CO., LTD. (hereinafter referred to as “AUTEL ROBOTICS”)
assumes no liability for damage(s) or injuries incurred directly or indirectly from
improper use of this Product. Misuse includes, but is not limited to, using
unapproved chargers, charging unapproved batteries, short-circuiting,
overheating, introducing foreign materials into the Product, or touching the
terminals with skin or metal. Refer to the Safety Guidelines and Disclaimer,
Intelligent Flight Battery Quick Start Guide and User Manual for applicable
information not herein contained.
This Product and manual are copyrighted by AUTEL ROBOTICS with all rights
reserved. No part of this Product and manual shall be reproduced in any form
without the prior written consent or authorization of AULTEL ROBOTICS.
This disclaimer is produced in various languages. In the event of divergence
among different versions, the Simplified Chinese version shall prevail when the
Product in question is purchased in China, and English version shall prevail
when the Product in question is purchased in any other region.
Disclaimer
Warning
• The Charging Hub is only compatible with the designed Battery
Charger. DO NOT attempt to use the Charging Hub with any other
battery charger.
• The Charging Hub is only compatible with the EVO II Intelligent Flight
Battery. DO NOT attempt to use the Charging Hub with other battery
models.
• Place the Charging Hub on a flat and stable surface when in use. Ensure
the device is properly insulated to prevent fire hazards.
• DO NOT attempt to touch the metal terminals on the Charging Hub with
skin or other material.
• Clean the metal terminals with a clean, dry cloth if there is any
noticeable buildup.

The EVO II Battery Charging Hub is designed for use with the EVO II Intelligent
Fight Battery. When used with the EVO II Battery Charger, it can charge up
to four Intelligent Flight Batteries.
1. Connecting to a Power Source
Connect the EVO II Battery Charger to a power outlet (100-240V), then
connect the Battery Charger to the Charging Hub. The LED indicator lights
up.
Introduction
Using the Charging Hub
2. Connecting Batteries
Insert the Intelligent Flight Batteries into the
battery port to begin charging. Indicator
light becomes slowly pulsing when the
batteries are being charged and solid on
after fully charged. DO NOT cover the
Charging Hub during charging.
Status LED
Indicator
Batton
Battery Port
Micro USB Slot
Power Port
Power Outlet Charger Charging Hub

• Charging Management
There are 2 charging mode for charging the Intelligent flight batteries:
1. Parallel-charging mode: The charging progress started from the lowest
battery, when the power level are the same, the batteries are charged
simultaneously.
2. Sequential-charging mode: The batteries will be charged in sequence
according to their power levels, from high to low.
Refer to “Status LED Indicator Description” section for more information
about the Status of LED indictor’s blinking patterns. Unplug the batteries
when they are fully charged.
Note: Inserting a battery may interrupt the ones being charged.
• Exceptions Alert
When exceptions occur (communication error, abnormal charging
voltage, abnormal temperature, etc.), the Charging Hub will keep the red
light on to alert user.
Status LED Indicator Description
1. Solid Blue: All batteries are full charged in parallel-charging mode.
2. Slow Pulsing Blue: Charging in parallel-charging mode.
3. Solid Green: All batteries are fully charged in sequential-charging mode.
4. Slow Pulsing Blue: Charging in sequential -charging mode.
5. Solid Red: Charging error. Check components.
6. Solid Yellow: Firmware updating.
Product Features
Specifications
©2020-2021 Autel Robotics Co., Ltd. All Rights Reserved
www.autelrobotics.com
Operating Voltage
Operating Temperature
Charge Time (4 batteries)
13.2 V
41~104ºF (5º~45ºC )
6 hr 30 min
