Autel MaxiPRO MP808TS User manual

i
Trademarks
Autel®, MaxiSys®, MaxiDAS®, MaxiScan®, MaxiTPMS®, MaxiRecorder®, and
MaxiCheck®are trademarks of Autel Intelligent Technology Corp., Ltd.,
registered in China, the United States and other countries. All other marks
are trademarks or registered trademarks of their respective holders.
Copyright Information
No part of this manual may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise without the prior written permission of
Autel.
Disclaimer of Warranties and Limitation of Liabilities
All information, specifications and illustrations in this manual are based on
the latest information available at the time of printing.
Autel reserves the right to make changes at any time without notice. While
information of this manual has been carefully checked for accuracy, no
guarantee is given for the completeness and correctness of the contents,
including but not limited to the product specifications, functions, and
illustrations.
Autel will not be liable for any direct, special, incidental, indirect damages or
any economic consequential damages (including the loss of profits).
IMPORTANT
Before operating or maintaining this unit, please read this manual carefully,
paying extra attention to the safety warnings and precautions.
For Services and Support
pro.autel.com
www.autel.com
www.maxitpms.com
1-855-288-3587/1-855-AUTELUS (North America)
0086-755-22672493/86532091 (China)
[e-mail]
For technical assistance in all other markets, please contact your local selling
agent.

ii
Safety Information
For your own safety and the safety of others, and to prevent damage to the
device and vehicles upon which it is used, it is important that the safety
instructions presented throughout this manual be read and understood by all
persons operating or coming into contact with the device.
There are various procedures, techniques, tools, and parts for servicing
vehicles, as well as in the skill of the person doing the work. Because of the
vast number of test applications and variations in the products that can be
tested with this equipment, we cannot possibly anticipate or provide advice
or safety messages to cover every circumstance. It is the automotive
technician’s responsibility to be knowledgeable of the system being tested. It
is crucial to use proper service methods and test procedures. It is essential
to perform tests in an appropriate and acceptable manner that does not
endanger your safety, the safety of others in the work area, the device being
used, or the vehicle being tested.
Before using the device, always refer to and follow the safety messages and
applicable test procedures provided by the manufacturer of the vehicle or
equipment being tested. Use the device only as described in this manual.
Read, understand, and follow all safety messages and instructions in this
manual.
Safety Messages
Safety messages areprovided to help prevent personal injury and equipment
damage. All safety messages are introduced by a signal word indicating the
hazard level.
DANGER
Indicates an imminently hazardous situation that, if not avoided, will result in
death or serious injury to the operator or to bystanders.
WARNING
Indicates a potentially hazardous situation that, if not avoided, could result in
death or serious injury to the operator or to bystanders.

iii
Safety Instructions
The safety messages herein cover situations Autel is aware of. Autel cannot
know, evaluate or advise you as to all of the possible hazards. You must be
certain that any condition or service procedure encountered does not
jeopardize your personal safety.
DANGER
When an engine is operating, keep the service area WELL VENTILATED or
attach a building exhaust removal system to the engine exhaust system.
Engines produce carbon monoxide, an odorless, poisonous gas that causes
slower reaction time and can lead to serious personal injury or loss of life.
SAFETY WARNINGS
Always perform automotive testing in a safe environment.
Wear safety eye protection that meetsANSI standards.
Keep clothing, hair, hands, tools, test equipment away from all moving or
hot engine parts.
Operatethe vehicle in a well-ventilated work area, for exhaust gases are
poisonous.
Put the transmission in PARK (for automatic transmission) or NEUTRAL
(for manual transmission) and make sure the parking brake is engaged.
Put blocks in front of the drive wheels and never leave the vehicle
unattended while testing.
Be extra cautious when working around the ignition coil, distributor cap,
ignition wires and spark plugs. These components create hazardous
voltages when the engine is running.
Keep a fire extinguisher suitable for gasoline, chemical, and electrical
fires nearby.
Do not connect or disconnect any test equipment while the ignition is on
or the engine is running.
Keep the test equipment dry, clean, free from oil, water or grease. Use a
mild detergent on a clean cloth to clean the outside of the equipment as
necessary.
Do not drivethe vehicle andoperate thetest equipment at thesame time.
Any distraction may cause an accident.

iv
Refer to the service manual for the vehicle being serviced and adhere to
all diagnostic procedures and precautions. Failure to do so may result in
personal injury or damage to the test equipment.
To avoid damaging the test equipment or generating false data, make
sure the vehicle battery is fully charged and the connection to the vehicle
DLC is clean and secure.
Do not place the test equipment on the distributor of the vehicle. Strong
electro-magnetic interference can damage the equipment.

v
CONTENTS
1USING THIS MANUAL............................................................................. 1
CONVENTIONS ........................................................................................... 1
2GENERAL INTRODUCTION.................................................................... 3
MAXIPRO MP808TSDISPLAY TABLET ......................................................... 4
VCI –VEHICLE COMMUNICATION INTERFACE .................................................. 7
OTHER ACCESSORIES ................................................................................10
3GETTING STARTED ..............................................................................11
POWERING UP..........................................................................................11
POWERING DOWN......................................................................................15
4DIAGNOSTICS.......................................................................................16
GETTING STARTED ....................................................................................16
VEHICLE IDENTIFICATION.............................................................................17
NAVIGATION..............................................................................................23
MAIN MENU ..............................................................................................26
DIAGNOSIS ...............................................................................................27
HOT FUNCTIONS........................................................................................41
GENERIC OBDII OPERATIONS ....................................................................43
EXITING DIAGNOSTICS................................................................................47
5TPMS.....................................................................................................49
GETTING STARTED ....................................................................................49
VEHICLE SELECTION ..................................................................................51
TPMS CHECK ..........................................................................................54
TPMS DIAGNOSIS.....................................................................................56
SENSOR PROGRAMMING.............................................................................62
TPMS RELEARN .......................................................................................68
TPMS BY OEMPART NO...........................................................................72
6SERVICE ...............................................................................................77
OIL RESET SERVICE...................................................................................77
ELECTRIC PARKING BRAKE (EPB) SERVICE...................................................80
BATTERY MANAGEMENT SYSTEM (BMS) SERVICE..........................................83

vi
STEERING ANGLE SENSOR (SAS) SERVICE...................................................89
DIESEL PARTICLE FILTER (DPF) SERVICE .....................................................92
IMMOBILIZER (IMMO) SERVICE....................................................................99
7MAXIFIX...............................................................................................102
NAVIGATION............................................................................................102
OPERATIONS ..........................................................................................105
8SHOP MANAGER.................................................................................111
VEHICLE HISTORY....................................................................................112
WORKSHOP INFORMATION ........................................................................114
CUSTOMER MANAGER ..............................................................................115
9DATA MANAGER.................................................................................118
OPERATIONS ..........................................................................................118
10 SETTINGS ...........................................................................................123
UNIT......................................................................................................123
LANGUAGE .............................................................................................124
PRINTING SETTING...................................................................................125
NOTIFICATION CENTER .............................................................................126
AUTO UPDATE.........................................................................................127
SYSTEM SETTINGS...................................................................................129
ABOUT...................................................................................................130
11 UPDATE...............................................................................................131
DISPLAY TABLET UPDATE .........................................................................131
MAXIVCIMINI UPDATE.............................................................................133
12 VCI MANAGER.....................................................................................135
BT PAIRING............................................................................................136
UPDATE .................................................................................................136
13 SUPPORT............................................................................................137
PRODUCT REGISTRATION..........................................................................137
SUPPORT SCREEN LAYOUT .......................................................................138
MY ACCOUNT .........................................................................................138
USER COMPLAINT....................................................................................139

vii
DATA LOGGING .......................................................................................141
COMMUNITIES .........................................................................................142
TRAINING CHANNELS................................................................................144
FAQ DATABASE ......................................................................................144
14 ACADEMY............................................................................................145
15 REMOTE DESK....................................................................................146
OPERATIONS ..........................................................................................146
16 QUICK LINK.........................................................................................148
17 FUNCTION VIEWER ............................................................................149
18 MAINTENANCE AND SERVICE............................................................151
MAINTENANCE INSTRUCTIONS....................................................................151
TROUBLESHOOTING CHECKLIST .................................................................152
ABOUT BATTERY USAGE...........................................................................152
SERVICE PROCEDURES ............................................................................153
19 COMPLIANCE INFORMATION.............................................................156
20 WARRANTY.........................................................................................159
LIMITED ONE YEAR WARRANTY .................................................................159

1
1 Using This Manual
This manual contains device usage instructions.
Some illustrations shown in this manual may contain modules and optional
equipment that are not included in your system. Contact your sales
representative for availability of other modules and optional tools or
accessories.
Conventions
The following conventions are used.
Bold Text
Bold text is used to highlight selectable items such as buttons and menu
options.
Tap OK.
Notes and Important Messages
Notes
A NOTE provides helpful information such as additional explanations, tips,
and comments.
NOTE
New batteries reach full capacity after approximately 3 to 5 charging and
discharging cycles.
Important
IMPORTANT indicates a situation that, if not avoided, may result in damage
to the test equipment or vehicle.

2
IMPORTANT
Keep the cable away from heat, oil, sharp edges and moving parts. Replace
damaged cables immediately.
Hyperlink
Hyperlinks or links that take you to other related articles, procedures, and
illustrations are active in electronic documents. Blue italic text indicates a
selectable hyperlink and blue underlined text indicates a website link or an
email address link.
Illustrations
Illustrations used in this manual are samples, the actual testing screen may
vary for each vehicle being tested. Observe the menu titles and on-screen
instructions to make correct option selection.

3
2 General Introduction
When it comes to ultra-portability, MaxiPRO MP808TS (hereinafter referred
to as MP808TS) is your perfect companion. Featuring a fast quad-core
processor, MP808TS offers maximum convenience and swift diagnosis. The
intuitive user interface makes using the device effortless through a 7-inch
LCD touch screen that displays at 1024 x 600quality. Together withthe ability
to quickly read and clear Original EquipmentManufacturers (OEM) enhanced
codes for TPMS module of the majority of the makes and models on the
market, MP808TS provides you with superior special functions for TPMS
services with ease.
There are two main components of the MP808TS system:
MP808TS Display Tablet –the central processor and monitor for the
system.
MaxiVCI Mini (Vehicle Communication Interface) –the device for
accessing vehicle data.
Thismanual describesthe construction andoperationof both the devices and
how they work together to deliver diagnostic solutions.
