Automatic Technology PA1000V1 User manual

www.bnd.com.au
Part Number #40020
Model: PA1000V1
October 2011
FOR RESIDENTIAL USE ONLY
Instruction Manual
(Notice D’exploitation)
PA1000 - Overhead Garage Door Operator

WARNING: It is vital for the safety of persons
to follow all instructions. Failure to comply
with the installation instructions and the safety
warnings may result in serious personal injury
and/or property and remote control opener
damage. Please save these instructions for
future reference.
AVERTISSEMENT: pour la sécurité des usagers,
il est essentiel de suivre toutes les instructions.
Le non- respect des instructions d’installation et
des avertissements de sécurité peut causer de
graves blessures et/ou endommager l’appareil
et la télécommande. Veuillez conserver ces
instructions pour future référence.
To reduce the risk of electric shock, this
equipment has a grounding type plug that has a
third (grounding) pin. This plug will only fit into
a grounding type outlet. If the plug does not fit
into the outlet, contact a qualified electrician
to install the proper outlet. Do not change the
plug in any way.
Pour reduire les risques de choc electrique, cet
appareil est quipe d’une fiche avec mise a la
terre comportant une troisieme broche (broche
deterre). Cette fiche ne peut etre branche que
dans une prise avec mise a la terre. S’il n’est
pas possible de la brancher dans la prise, faire
poser une prise appropriee par un electricien
qualifie. Ne pas modifier la fiche.

Safety Rules 05
System Specications 06
Default Settings and Technical Specication 06
About Your Operator 07
Operating Controls 08
Kit Contents 10
Installation
Knockdown C-Rail Assembly 12
C-Rail Assembly 13
Mounting Operator for Track Type Door 14
Mounting Door Bracket & Arms 15
Safety Beam Installation 15
Setting Speed and Limits
Setting Speed Mode 17
Setting Limits Position 18
Testing Safety Obstruction Force 19
Setting Safety Obstruction Force 20
Coding Transmitters
Door 21
Courtesy Light 21
Vacation Mode 22
Auxiliary Output 22
Pet Mode 23
Erasing Transmitter Codes 23
Mounting Wall Transmitter 23
Accessories
Terminal Block 24
Remote Aerial 24
Wired Wall Switch / Key Switch 24
Battery Back Up Installation 25
CONTENTS
PA1000V1 Overhead Garage Door Operator
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
3PA1000 Instruction Manual (Instructions d’installation)

How to Use Your Operator
Remote Control Transmitter 26
In-Build Locking 27
Manual Door Operation 27
Power Failure 27
Removing Transmitter Battery 27
Safety Beam Option 28
Auto-Close Option 28
Courtesy Light 28
Auxiliary Output 28
Vacation Mode 28
Pet Mode 28
Service 28
Maintenance 29
Troubleshooting Guide 30
Parameters 31
Spare Parts List 32
Warranty 34
Optional Accessories 36
CONTENTS
PA1000V1 Overhead Garage Door Operator
PA1000 Instruction Manual (Instructions d’installation)4

Safety Rules
(Les règles de la sécurité)
Please read these important safety rules
These safety alert symbols indicate a personal safety or property damage
instruction exists. READ THESE INSTRUCTIONS CAREFULLY.
This automatic garage door operator is designed and tested to offer safe service
provided it is installed and operated in strict accordance with the following
safety rules. Failure to comply with the installation instructions and the safety
warnings may result in death, serious personal injury and/or property damage.
CAUTION: If your garage has no pedestrian entrance
door, an emergency access device should be installed.
This accessory allows manual operation of the garage
door from outside in case of power failure.
Position the Garage Door Operator so that the power plug
is accessible when inserted into the power outlet.
This opener should be installed in accordance with relevant
US and Canada Standards.
Do not allow children to play with door controls.
Keep transmitters away from children.
Watch the moving door and keep people away until the
door is completely opened or closed.
Activate the operator only when the garage door is in full
view, free of obstructions and with the opener properly
adjusted.
Keep the garage door balanced. Sticking or binding doors
must be repaired. Garage doors, door springs, brackets
and their hardware are under extreme tension and can
cause serious personal injury. Do not attempt any garage door
adjustment. Do not use if repair or adjustment is needed. Call
for professional garage door service.
Install the wall transmitter in a location where the garage
door is visible, but out of the reach of children at a height
of at least 5 feet (1.53m).
Disconnect electric power to the garage door operator
before removing covers.
Door must have Safety Beams tted.
Do not wear rings, watches or loose clothing while
installing or servicing a garage door operator.
This operator is not suitable for commercial, industrial
or common entry applications.
To avoid serious personal injury from entanglement,
remove all unnecessary ropes or chains and disable
any equipment such as locks which are not needed
for powered operation.
Installation and wiring must be in compliance with
your local building and electrical codes. Connect
the power cord only to properly earthed mains. If
an extension lead must be used, make sure it is a 3-core
lead and approved to 7 amp capacity.
To reduce the risk of electric shock, this equipment
has a earthing type plug that has a third (earthing)
pin. This plug will only t into a earthing type outlet.
If the plug does not t into outlet, contact a qualied
electrician to install the proper outlet. Do not change the
plug in any way.
If the power cord is damaged, it must be replaced
by the manufacturer, its service agent or a similarly
qualied person in order to avoid a hazard.
This operator is a plug in domestic appliance and is
designed for indoor use only. It must be installed in a
dry position that is protected from the weather.
The opener is not intended for use by young children
or inrm persons without supervision.
WARNING! It is vital for the safety of
persons to follow all instructions. Save
these instructions.
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
5PA1000 Instruction Manual (Instructions d’installation)

System Specifications
Factory Default Settings
Default Step Maximum
Maximum motor run time 30 Secs. - -
Courtesy light time 3 Mins. approx. - -
Obstruction force margin 2 1 14
Auto close time 30 Secs - -
Technical Specifications
Input Voltage 120Vac / 60Hz
Fuse (primary) 1.3A (slow blow)
Input power (max) 200 Watts
Standby power, less than 2 Watts
Transformer secondary output Voltage 24Vac
Motor type 24Vdc geared motor with permanent magnet
Shuttle travel distance in the C-Rail 9.19ft (2.8m) approximately (standard)
Maximum shuttle travel distance in the C-Rail 16.4ft (5m) (with extended C-Rail)
Maximum door area 177sq.ft (16.5 m2)
Maximum door hanging weight 441lbs (200kg)
Receiver type UHF Multifrequency FM-Receiver
Receiver code storage capacity 14 X 4 button transmitter codes
Transmitter frequency 433.47MHz; 433.92MHz; 434.37MHz
Coding type TrioCode™
Number of code combinations Over 4.29 billion random codes
Code generation Nonlinear encryption algorithm
Remote control battery CR2032 3 Volts
Courtesy light 2 LED Modules
Controller fuse 10A (slow blow)
NOTE: Intermittent operations may occur in areas which experience very strong winds. The strong wind puts extra
pressure on the door and tracks which may in turn trigger the safety obstruction detection system intermittently.
PA1000 Instruction Manual (Instructions d’installation)6

Thank you for choosing a PA1000 automatic garage door
operator.
The technically advanced construction of this operator
ensures you enjoy the following benets:
Warranty
xxx (x) years / xxxx cycles full parts and labour warranty
on motor, electronics and mechanical components of the
operator when installed by a garage door professional
(conditions such as annual garage door servicing apply).
TrioCode™ Frequency Hopping Technology
Every time a transmitter is used, it simultaneously sends a
signal over three different frequencies, reducing the chance
of interference from other radio frequency sources.
Code Hopping Technology
Every time a transmitter is used a new security code
is generated from over 4.29 billion possible code
combinations. This greatly enhances the security of the
system and makes “code grabbing” a thing of the past!
Multi-Channel Transmitter
Multi-channel transmitters allow you to operate other
devices such as an adjoining garage door or automated
gate from the same handy unit.
Warranty Expired Indicator
The operator will indicate that the number of cycles
covered by the warranty has been reached by ashing the
courtesy light 10 times after each operation. This ashing
will continue for 20 cycles unless it is reset by pressing the
SET button while the courtesy light is ashing.
S-ALPS (Semi Automatic Limits Positioning
System)
The S-ALPS system does away with manual adjustment of
the door’s limits position using mechanical parts, such as
cams and microswitches.
Safety Reversing System
The automatic safety reverse system signicantly reduces
the risk of death or serious injury if trapped by a closing door.
The safety reverse force can be adjusted for environmental
conditions such as windy areas.
Safety Infra-Red Beam Protection
The Safety Beam is the infrared (IR) invisible light beam
system which shall protect the doorway. The door stops
and reverse to the full position if anything passes through
the beam.
Soft Start/Soft Stop
The operator eases into and out of an operating cycle.
This makes operation smoother and quieter and
most importantly reduces wear and tear on the door
and operator.
Courtesy Light
The courtesy light automatically switches on for
approximately three (3) minutes when operating the
door. This can also be programmed to turn on and off
from a transmitter.
Memory Retention
In case of a power failure, the operator does not lose
the transmitter codes or limit settings.
Soft Start/Soft Stop
The opener eases into and out of each cycle making
for smoother and quieter operation, as well as reducing
wear and tear on the door and operator.
Manual Release
The manual release handle allows the door to be
operated by hand in the event of a power failure.
Self Locking
There is no need to manually lock your garage door, as
the operator ‘positively’ locks the door when closed.
Periodic Maintenance Indicator
The SERVICE LED will illuminate to indicate that
periodic maintenance is required. Contact your garage
door professional for service.
Service Fault Indicator
Flashing LEDs on the control panel easily identify
operational problems or service requirements.
Dynamic Door Proling
Changing door characteristics are automatically
compensated for and “learnt” with each operation of
the door.
External Aerial
An external aerial can be connected for sites where
radio reception is a problem.
Vacation Mode
A transmitter can be programmed to disable the
garage door operator radio receiver. This is ideal if the
door is to be left idle for prolonged periods.
Pet (Pedestrian) Mode
A transmitter can be programmed to open the door
partially to allow pets access to the garage. The door
opening height is adjustable via a handheld programmer.
Auxiliary Output
You can program a spare button on your transmitter to
operate this output, which can control items that use a
momentary close switching mechanism.
About Your Operator
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
7PA1000 Instruction Manual (Instructions d’installation)

Operating controls
Terminal is used to connect Vac to the control board.
10 Amps fuse to protect the electronic circuit board.
This connector is used to connect Battery Charger
SBC02 to the opener.
DC 24V motor connects to this connector.
Operate (blue) Button is used during installation to test
the open, stop and close cycles for the opener. The
opener has to be initialised by the Limit set button before
the Operate Button becomes operable.
Plus (+) Green Button is used during installation to
help set the open limit position. Pressing and holding
this button will move the door in the open direction.
Movement stops when the button is released.
Prog input is used to connect a PG-3 Programmer for
editing functions, diagnostic purposes and accessing
special features.
Open Limit (Green) LED illuminates and ashes when
the door is opening and remains steady on when the
open limit position has been reached.
Force Margin Set The obstruction force pressure is set
automatically by the opener during installation. The
pressure can be adjusted manually using the Force
Margin Set Button. Holding the Force Margin Set Button
and pressing the Plus (+) or Minus (-) Button will increase
or decrease the amount of force. The force margin set
is only ever used if other environmental factors (wind,
etc..) Affect the operations of the door/opener.
Close Limit Red LED illuminates and ashes when the
door is closing and remains steady on when the close
limit position has been reached.
Minus (-) Red Code Set Button is used during installation
to help set the close limit position. Pressing and holding
this button will move the door in the close direction.
Movement stops when the button is released.
Code Set LED light ashes when a code is being stored
or when a transmitter button is pressed.
Limit set Button is used during the installation phase
together with the open and close buttons to set the door
limit positions. The Limit set button is also used to re-
initialise the opener.
Service LED (yellow) indicates when the opener requires
service or repairs.
Courtesy LED Light Module Connectors are used to
connect +24V LED light modules.
Terminal Block (J4):
V+ (+35V/+24V) is used to power Accessories such
as external receiver (200mA max).
EB1 (mandatory) input is used to connect to Safety
Beam.
0V is a 0 volt connection for Safety Beam.
EB2 input is used to connect to Safety Beam.
0V is a 0 volt connection for Safety Beam.
OSC (Operate) is used for the connection of a wired
switch (momentary contact). This switch can then
be used to open, stop or close the door. Install the
wall switch in a location where the switch is out of
reach of children and the garage door is visible.
AUX allows the opener to operate other devices
such as an alarm system.
01.
02.
03.
04.
05.
06.
07.
08.
09.
10.
11.
12.
13.
14.
15.
16.
PA1000 Instruction Manual (Instructions d’installation)8

24V power input connector.
10Amp fuse.
SBC02 Battery Backup Connector
Motor connector
OPERATE (Blue) button
Plus (+) (Green) button
PG-3 Programmer connector
Open Limit LED
Operating controls
01
02
03
04
16
15
14
13
12
05
06
07
08
09
10
11
01.
02.
03.
04.
05.
06.
07.
08.
Fig.01
FORCE MARGIN SET Button
Close Limit LED
Minus (-) (Red) CODE SET button
Code Set LED
LIMIT SET Button
Service LED
Courtesy light module Connectors
Accessories (J4) Connector
09.
10.
11.
12.
13.
14.
15.
16.
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
9PA1000 Instruction Manual (Instructions d’installation)

Kit contents:
Powerhead Drive Unit Kit (Fig.02).
1 X PA1000 drive unit;
1 X Handheld Transmitter with battery;
1 X Wall mount Transmitter with battery;
2 X Door attachment arms;
1 X Accessory and hardware pack.
PLUS
Single Piece Track With Pre-Assembled Chain
(Fig.03)
NOTE: Chain in one piece rail has been tensioned by the
factory. Do not adjust the tension of the chain.
IMPORTANT NOTE: If modication to the track length
required, adjustment must be made only from power head
End.
OR
Single Piece Track With Pre-Assembled
Timing Belt (Fig.04)
NOTE: Timing belt in one piece rail has been tensioned by
the factory. Do not adjust the tension of the timing belt.
IMPORTANT NOTE: If modication to the track length
required, adjustment must be made only from power head
End.
Fig.02
Fig.04
Fig.03
PA1000 Instruction Manual (Instructions d’installation)10

OR
Multi-Piece Knockdown Track with
Pre-Assembled Chain (Fig.05)
IMPORTANT NOTE: If modication to the track length
required, adjustment must be made only from power head
End.
OR
Multi-Piece Knockdown Track With
Pre-Assembled Timing Belt (Fig.06)
IMPORTANT NOTE: If modication to the track length
required, adjustment must be made only from power head
End.
Kit contents:
Fig.05
Fig.06
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
11PA1000 Instruction Manual (Instructions d’installation)

Knockdown C-Rail Assembly
Step 1
Unpack and assemble
the C-Rail as shown
above in Fig.07.
Fig.07
PA1000 Instruction Manual (Instructions d’installation)12

C-Rail Assembly
Step 2
Locate and insert the shaft of drive unit into sprocket as
shown in Fig.08.
Step 3
Fix the two track brackets with four screws supplied in
accessory pack as shown in Fig.09.
Locate shaft into sprocket
Shaft
4 Taptite screws ‘S’ M4 X 10
2 Track brackets VP1
Fig.09
Fig.08
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
13PA1000 Instruction Manual (Instructions d’installation)

Mounting Operator for a Track Type
Door
Step 4 - Determine Bracket Position
Open the door and nd the highest point of travel of the
top door panel. Using a level, transfer this height to the wall
above the door (Fig 10) and mark a line 0.197” (60mm)
above it.
Determine the centre point on the wall above and on top of
the door. Then draw two lines 0.0705” (21.5mm) on each
side of the centre point (Fig.11).
Step 5 - Mounting the Wall Bracket
The wall bracket should be mounted 0.197” (60mm) above
highest point of the doors travel, 0.0705” (21.5mm) from
the centre point (Fig.11).
If the wall bracket is mounted onto concrete or brick wall,
use 8mm or 5/6 loxins or dynabolts. If mounting onto
wooden lintel or beam, use wood screw #20 or equivalent
(minimum 1.97” (50mm) long).
WARNING: Make sure concrete, brick wall or timber lintels
are solid and sound so as to form a secure mounting
platform.
Step 6 - Attach the C-Rail to the Wall Bracket
When the wall bracket is rmly secured in its proper
position, attach the C-Rail support assembly to wall bracket
with 0.295” (90mm) long clevis pin and secure with
supplied snap pin (Fig.12).
Leave the drive unit in its packing box for protection during
installation.
Step 7 - Securing the Powerhead to the
Ceiling
Raise the drive unit from the packing box and support it
in a horizontal position with a step ladder, then open the
garage door. Rest the operator on the open door and use a
scrap piece of wood to bring it to horizontal level. Line up
the track perpendicular to the wall.
Secure the perforated angle (not supplied) to the ceiling
above where drive unit mounting holes will be once fully
installed (Fig.13).
Connect angle and drive unit with two at perforated strips
of angle (not supplied) with M8 x 20mm screws, and nuts.
Strips should not extend more than 0.059” (18mm) below
centre of drive unit mounting holes (Fig 13).
For an alternative mounting option go to Step 8 Page 15.
43
21.5
21.5
SNAP PIN
PIN
WALL BRACKET
PLACE OPENER ON TOP OF
FABRIC CLOTH OR CARDBOARD BOX
TO AVOID SCRATCHES
Track
Level
Door
Drilled holes
Structural member
Fig.13
Fig.12
Fig.11
Fig.10
WARNING: The operator must be securely
fastened to a structural support of the garage.
Failure to fasten the operator correctly may
lead to operator failure causing serious
personal injury and/or property damage.
PA1000 Instruction Manual (Instructions d’installation)14

Mounting Door Bracket and Arms
Step 8 - Alternative Mounting Option
The operator can be fastened to the roof by drilling a hole
in the centre of the C-Rail and driving a bolt through it into
structural timber support. The height of bolt head must not
exceed 0.24” (6mm) (Fig.14).
Mounting door bracket and arms
Step 9 - Mounting Door Bracket
The door bracket comes in two parts. The bottom plate with
two mounting holes is used on its own for any one piece
doors. The top plate is placed over the bottom plate and
uses 4 mounting holes for extra strength. This is used on
sectional doors (Fig.15).
Mount the door bracket to the centre line of the door, 1/3
panel down (Fig.15) using M6 or equivalent screws (not
supplied) alternatively it can be welded on steel doors.
NOTE: As various types of doors exist, if in doubt about the
strength of the door, reinforcement may need to be added
to the frame of the door panel where necessary. Damage
to the door panel may occur if the bracket is installed
incorrectly on a panel with insufcient strength. The door
operator warranty does not cover damage caused by the
operator to the door and/or door panel.
Step 14 - Attaching the Arms
Assemble bent and straight arms (as shown in Fig.16) with
bolts and nuts supplied in accessory pack. Then connect
assembled arm to the door bracket and the trolley by clevis
pin and snap pin. Trolley must be in disengage position.
Always use both the bent and straight arm.
The angle “A“ must not be less than 10 degrees (See Fig.
16).
Ceiling
Aluminium rail
Shuttle VP2 assembly
Drill hole at centre of
track (recommended
bolt size M6 or M8)
The height
of bolt head
must not
exceed 6 mm
Fig.14
Fig.15
Fig.16
WARNING: connecting the bent arm other
way around may damage the door.
IMPORTANT NOTE: If the manual release
handle is more than 5.91ft (1.8 meters) from
oor level when the operator is installed,
extend the handle to a height less than 5.91ft
(1.8 meters).
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
15PA1000 Instruction Manual (Instructions d’installation)

Fig.17
WARNING: When the Safety Beam is tted,
the doorway must be clear of all obstructions
and persons at all times. The location of the
beams and manner in which it is installed
might not give safety protection at all
times. Check to make sure that the height
of the beam and type used give maximum
protection possible.
IMPORTANT NOTE: The Safety Beam must
be installed and connected before the travel
limits are set.
Step 15 - Safety Infra-Red Beam
A Safety Beam extends across the door opening. This Safety
Beam is designed to detect an obstruction while the door is
closing and to send a signal to the door operator to reverse or
stop the door movement.
Step 15.1 - Fitting the Safety Beam
Attach the mounting bracket (4) to the adjustmenta.
bracket (3) with the pan head screw (5) (supplied).
(Fig. 17).
Attach the bracket (2) to the Safety Beam transmitterb.
(PE3-V1-TX) (1) with four taptite screws (6) (M3x5) and
attach the other side to the adjustment bracket (3) with
the pan head screw (5) (supplied).
Repeat steps “a” and “b” to assemble the Safety Beamc.
(PE3-V1-RX) receiver.
Locate the Safety Beam in a strategic location in thed.
door opening. We recommends that the sensor is placed
no higher than 6” and no lower than 5”above the oor
level. Connect as per the wiring diagram (Fig. 19).
Step 15.2 - Alignment
Power up the PA1000 with the Safety Beam connected.a.
The green LED of the transmitter should be ON to
indicate that power is present.
If the receiver is connected properly and the red LED isb.
ashing while the green LED of the transmitter is ON,
the transmitter and/or receiver are not aligned.
Make horizontal and/or vertical adjustment c. (Fig. 18) on
the transmitter and/or receiver until the red LED of the
receiver turns steady on, indicating alignment.
12
3
4
5
5
Fig.18
Fig.19
WARNING: Install the Safety Beam as per
diagram in Fig. 19. Tampering with the Safety
Beam could result in serious personal injury
and/or property damage and will void the
warranty.
Safety Beam Installation
6
RED
BLACK
RED
BLACK
RED
BLACK
BLACK
EB1
0V
J4 TERMINAL BLOCK
(DCB08 CONTROL BOARD)
PA1000 Instruction Manual (Instructions d’installation)16

Setting Speed and Limits
Step 16 - Setting Speed Mode
The default speed of the operator has been set to suit the
majority of applications. However, there are 3 speed modes
available if required:
SLOW - suits one piece door without tracks.1.
MEDIUM (default) - suits majority of applications.2.
FAST - suits some special applications.3.
The speed settings can only be changed before setting the
travel limits. If the operator speed needs to be changed,
please complete the following steps below. If medium
(default) mode is appropriate skip straight to Step 17.1
(Setting Travel Limits). Pressing the OPERATE button will
cycle through all three speed modes. To change the speed
setting, use the following steps:
Engage the C-Rail’s trolley (attached to the door via thea.
arms) with the chain index by moving the door.
If the trolley does not “click” rmly onto the chain b.
index, ensure that the manual release cord is not in the
disengaged position by pulling it backwards.
Turn on the power to the operator. Thec. Close Limit
LED will be ashing.
Remove the buttons cover with a blade screwdriverd.
(Fig. 20).
Press thee. OPERATE button once, twice or three time
to select SLOW, MEDIUM or FAST speed mode.
Fig.20
Door Opener
Speed Mode
Open LED
(green)
status
Open LED
(red)
status
Beeper
Medium (Default) ON ON ON
Fast ON OFF ON
Slow OFF ON OFF
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
17PA1000 Instruction Manual (Instructions d’installation)

Setting Speed and Limits
Step 17 - Setting Travel Limits
NOTE: The door and shuttle must be engaged
into the chain/belt index. The door should be
open approximately half way.
Remove the controls cover (Fig.20) to access the controls
panel and place it back when nish programming.
17.1 - Setting Limits Positions (Fig.21)
1. Press red Minus (-) Button and hold it, the door will start
closing. Release the button once when the door has reached
your desired closed limit position.
2. Press the limit set button. This action will store into
memory the closed limit position.
3. Press the green Plus (+) Button and hold it, the door will
start opening. Release the button once when the door has
reached your desired open limit position.
4. Read the WARNING below.
IMPORTANT WARNING: Please be aware that
the garage door will start closing automatically
once Step 4 is performed. The door will also
automatically re-open after fully closing with a
small pause between the cycles.
5. Press the Limit set button. This action will store into memory
the door limit position. The door will now automatically close
to its limit position then fully open to calculate the safety
obstruction forces. Please be aware of the above warning.
The door operator can now be operated via the OPERATE
button.
17.2 Resetting Door Limit Positions (Fig.22)
The door travel limit positions can be deleted for new
positions by the following steps below:
1. Press and hold Limit set button for six (6) seconds until
you hear three beeps and the red Close Limit LED starts
to ash.
2. Release the button.
3. Follow Step 17.1 to set new travel limit positions.
Fig.22
Fig.21
IMPORTANT NOTE: The operate button will
not function until the open and close limits
positions are set.
PA1000 Instruction Manual (Instructions d’installation)18

Testing Safety Obstruction Force
18.1 - Testing the Close Cycle
Press the OPERATE button to open the door1.
(Fig.23).
Place an object approximately 1-1/2”(38mm) high2.
(or a 2”x 4” board laid at) on the oor under center
of garage door opening (Fig.24).
Press the OPERATE button to close the door.3.
When door contacts the object, the door must stop4.
(within 2 seconds) and reverse to open position.
If the door does not properly reverse.
Check the “close” limit position. It should not have•
reached its “close” limit before hitting board.
If the door STOPS but does not reverse, decrease•
FORCE (refer to Step 18.4).
18.2 - Testing the Open Cycle
Press the OPERATE button to close the door (1. Fig.23).
Press again to open the door. When the door is2.
reaching half of the opening distance, grab the bottom
rail of the door rmly, the door should stop.
If the door does not stop when opening, the force may be
excessive and need adjusting, refer to Step 18.4.
Fig.24
Fig.23
IMPORTANT WARNING: If the door is
closing and is unable to re-open when
obstructed, discontinue use. Do not use a
door with faulty obstruction sensing. Repair
fault and re-test before using.
CAUTION: Please take care when testing the
safety obstruction force. Excessive force may
cause serious personal injury and/or property
damage can result from failure to follow this
warning.
2”x 4” board
Diamond PD Power Drive : Instruction Manual
© Copyright 2011
19PA1000 Instruction Manual (Instructions d’installation)

Adjusting Safety Obstruction Force
The safety obstruction force is calculated automatically and
set in memory on the operator. It is usually not necessary
to adjust the safety obstruction force. The only time the
force may need to be increased is due to environmental
conditions, for example, windy or dusty areas, and areas
with extreme temperature changes.
WARNING: Safety Beam must be installed if
the closing force as measured at the bottom
edge of the door exceed 200N (20kg).
18.3 To Increase Force Pressure (Fig.25)
Press and hold the FORCE MARGIN SET button.1.
While holding down the FORCE MARGIN SET button,2.
press the Plus (+) button. Each press increases the
force margin.
The Open Limit LED will ash each time the plus 3.
button is pressed to indicate an increase in force.
If the Open Limit LED ashes continuously when the 4.
plus button is being pressed, this indicates that the
maximum force pressure setting has been reached.
Test the force again as per5. Step 17.1 and 17.2
above.
18.4 To Decrease Force Pressure (Fig.26)
Press and hold the FORCE MARGIN SET button.1.
While holding down the FORCE MARGIN SET button,2.
press the Minus (-) Button. Each press decreases
the force margin. The Close Limit LED will ash
each time the minus button is pressed.
If the Close Limit LED ashes continuously when 3.
the minus button is being pressed, this indicates
that the minimum force pressure setting has been
reached.
Test the force again as per4. Step 18.1 and 18.2
above.
18.5 To Recall Factory Set Force
While holding down the1. FORCE MARGIN SET button,
press the LIMIT SET button (Fig.27)for two seconds.
Release both buttons. The default setting should now2.
be recalled.
Fig.25
Setting Safety Obstruction Force
Fig.26
Fig.27
PA1000 Instruction Manual (Instructions d’installation)20
