Automatic Technology GDO-6v3 EasyRoller User manual

GDO-6v3 EasyRoller®
Roll Up Garage Door Opener
INSTALLATION INSTRUCTIONS | OWNERS COPY
Featuring TrioCode™Technology
Part # 13236 (Manual) v2.01

2GDO-6v3 EasyRoller®Owner Installation Instructions
WARNING: It is vital for the safety of people to follow all
instructions.Failuretocomplywiththeinstallationinstructions
and the safety warnings may result in serious personal injury
and/or property and opener damage. Please save these
instructions for future reference.
Automatic Technology (Australia) Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all
conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an
Automatic Technology (Australia) Pty Ltd Roll Up Door Opener. Automatic Technology (Australia) Pty Ltd hereby further
expressly excludes all or any liability for any injury, damage, cost, expense or claim whatsoever suffered by any person
as a result whether directly or indirectly from failure to install the Automatic Technology (Australia) Pty Ltd Roll Up Door
Opener in accordance with these installation instructions.

Owner Installation Instructions GDO-6v3 EasyRoller®3
Important Safety Instructions 4
Features 6
Operating Controls 8
Package Contents 10
Installation 11
Programming the Opener 15
Safety Obstruction Force 17
Coding Transmitters 19
Deleting Transmitter Codes 21
Accessories 22
Photo Electric Beam 22
Auto-Close 23
Final Setup 24
Setting of Courtesy Light Time 24
Setting the Pet Mode Position 24
Wall Transmitter Installation 24
Keyswitch Connection 24
Auxilary Output 25
Reset all Factory Defaults 25
SmartSolar™ Installation 26
Battery Backup Kit Installation 27
Parameters 28
Door Status Indicators 28
Button Functions 29
Default Settings & Specifications 30
Troubleshooting 31
Maintenance 32
Spare Parts 33
Warranty 35
GDO-6v3 EasyRoller®
Roll Up Garage Door Opener

4GDO-6v3 EasyRoller®Owner Installation Instructions
CAUTION: If your garage has no pedestrian entrance door, an emergency access device should be installed.
This accessory allows manual operation of the garage door from outside in case of power failure.
For ADDITIONAL SAFETY protection we STRONGLY recommend the fitting of a Photo Electric (PE)
Beam. In most countries, PE Beams are mandatory on all garage doors fitted with automatic openers.
For a small additional outlay, Automatic Technology recommends that Photo Electric Beams be
installed with the automatic opener ensuring additional safety and peace of mind.
DO NOT operate the opener unless the garage door is in full view and free from objects such
as cars and children/people. Make sure that the door has finished moving before entering or
leaving the garage.
DO NOT operate the opener when children/people are near the door. Children must be
supervised at all times when the EasyRoller® is in use. Serious personal injury and/or
property damage can result from failure to follow this warning.
DO NOT allow children to operate the EasyRoller®. Serious personal injury and/or
property damage can result from failure to follow this warning.
Photo Electric Beams must be installed where the closing force as measured
on the bottom of the door is more than 400N (40kgf).
Regularly check to make sure that the Safety Obstruction Force is working
correctly, and is tested and set as per page 17 of this manual. Failure to
follow these instructions could result in serious personal injury and/or
property damage. This test must be repeated at regular intervals and
the necessary adjustments made as required.
DO NOT disengage the door opener to manual operation with
children/people or any other objects including motor vehicles
within the doorway.
The door opener is not intended for use by young children
or infirm persons without adequate supervision. Children
should be supervised to ensure that they do not play
with the remote transmitters or the opener.
Keep hands and loose clothing clear of the door
and door opener at all times.
WARNING: It is vital for the safety of persons to follow all
instructions. Failure to comply with the following Safety
Instructions may result in serious personal injury and/or
property damage.
Important Safety Instructions

Owner Installation Instructions GDO-6v3 EasyRoller®5
The unit should be installed so that it is protected from the elements. It should not be exposed to water or rain.
It is not to be immersed in water or sprayed directly by a hose or other device.
The garage door must be well balanced. Sticking or binding doors must be repaired by a qualified garage
door installer prior to installation of the opener.
Frequently examine the installation, in particular cables, springs and mountings for signs of wear, damage
or imbalance. DO NOT use if repair or adjustment is needed since a fault in the installation or an
incorrectly balanced door may cause injury. DO NOT attempt to repair the door yourself as hardware
is under extreme tension.
Remove or disengage all garage door locks and mechanisms prior to installation of the opener.
Connect the opener to a properly earthed general purpose 220V mains power outlet installed
by a qualified electrical contractor.
Disconnect the power cord from mains power before making any repairs or removing
covers. Only experienced service personnel should remove covers from the opener.
When using Auto-Close mode, a photo electric beam must be fitted correctly and
tested for operation at regular intervals. Extreme caution is recommended when
using Auto-Close mode. All safety rules must be followed.
In order for the EasyRoller® to sense an object obstructing the door way,
some force must be exerted on the object. As a result the object, door and/
or person may suffer damage or injury.
If the power supply cord is damaged, it must be replaced by an
Automatic Technology service agent or suitably qualified person.
Make sure that the door is fully open before driving in or out of the
garage and fully closed before leaving the driveway.
Make sure that remote transmitters are kept out of reach of
children.
Install the (optional) wall switch or (optional) wall
mounted transmitter in a location where the garage
door is visible, but out of the reach of children at a
height of at least 1.5 metres from the floor.
Important Safety Instructions

6GDO-6v3 EasyRoller®Owner Installation Instructions
Operation
To open or close the door simply press a button on a TrioCode™ handheld
transmitter, a wall mounted transmitter, or optional wall switch for two seconds.
During open and close cycles the door can be stopped by pressing the button
again. The next actuation will move the door in the opposite direction.
TrioCode™ Code Hopping Technology
Every time a TrioCode™ transmitter is used, a new security code is randomly
generated from over 4.29 billion possibilities. This greatly enhances the security of
the system and makes “code grabbing” a thing of the past.
These transmitters also overcome interference issues by simultaneously sending a
signal over three slightly different frequencies. Even if two of the three signals are
jammed, the system will still work.
ALPS (Automatic Limits Positioning System)
ALPS does away with manual adjustment of the door’s limits position using mechanical
parts, such as cams and microswitches. During installation the handheld transmitter can be
programmed to set the door limits positions.
ISS (intelligent safety obstruction system)
While the door is performing a close cycle, should it hit an obstacle or be restricted in some manner, it
will automatically reverse. The amount of force the door should encounter before reversing is automatically
adjusted by the doors control system during the initial installation of the automatic door opener. The door will
also stop if restricted whilst opening. The Safety Obstruction Force should be checked monthly.
Auto courtesy light
The courtesy light comes on automatically for three minutes whenever the door is activated. The light can also
be operated independently of the door by coding a dedicated button on a transmitter.
Features
Thank you for purchasing the Automatic Technology
EasyRoller® Automatic Garage Door Opener.
Designed by our renowned engineers to suit Vertical
Operating Continuous Curtain Roll up doors, the
EasyRoller® will provide years of smart, simple
& secure convenience to your home.

Owner Installation Instructions GDO-6v3 EasyRoller®7
SmartSolar™ and Battery Backup Compatibility (optional)
The opener can be fitted with a SmartSolar™ or Battery Backup kit for operation in
the event of a power outage, or where mains power access is not available. NOTE: If
the door is the only entrance to the garage, and a battery backup kit is not fitted,
a keyed cable release should be fitted externally to the garage.
Vacation mode
A handheld transmitter can be programmed to lock and unlock all other
transmitters that have been programmed into the openers’ memory. The vacation
mode can be used when the door is left idle for long periods of time.
Pet/Pedestrian mode
The transmitter can be programmed to open the door to an adjustable partial height
so that the family pet can enter and exit the garage at any time. You may also wish to
open the door to a height suitable for pedestrian access.
Auto-Close mode
The opener can be programmed to automatically close after an open cycle. The Auto-Close
time is adjustable. It is compulsory to install a PE Beam if this mode is selected, otherwise the
door may cause personal injury or damage to property.
Photo Electric (PE) Beam (optional)
The opener has an input to connect a PE Beam for extra safety and use of the Auto-Close mode.
Manual operation
The opener is equipped with a unique manual disengaging device. If the power to the opener is disrupted,
the door can be put into manual mode by pulling down on the string handle on an angle towards the door.
This allows for manual operation of the door. To re-engage the opener, pull the string handle away from the
door.
Easy Access Transmitter
Inside the manual release handle is a transmitter designed to be in easy reach so that the garage door can
be operated without having to stretch to reach the operate button on the control panel.

8GDO-6v3 EasyRoller®Owner Installation Instructions
Operating Controls
TERMINAL BLOCK
24V (not filtered or regulated) PWR is used to power photo electric beam.
PE (Input) for photo electric beam.
PE (-) is used to power photo electric beam.
GND is used with OSC input or AUX output
O/S/C INPUT is used for the connection of a wired switch (momentary contact). This switch can
then be used to open, stop or close the door. Install the wall switch in a location where the switch
is out of reach of children and the garage door is visible.
AUX (output) can be used to control an alarm system.
LIGHT CODE button (White) is used for storing or erasing the transmitter button (code) you wish to use
to switch the courtesy light on the opener on or off.
CODING LED (Red) light flashes when a code is being stored or when a transmitter button is pressed.
DOOR CODE BUTTON (Blue) is used for storing or erasing transmitter buttons for door operation.
DOOR STATUS LED (Yellow)
CLOSE button (Red) is used during installation to help set the close limit position. Pressing and holding
this button will move the door in the close direction. Movement stops when the button is released.
NOTE: The safety obstruction detection is inoperable when the CLOSE button is used to move door.
CLOSE LIMIT LED (Red) the LED is very helpful during installation. It illuminates and flashes when the
door is closing and remains steady on when the close limit position has been reached.
AUTO CLOSE TIME button (White) is used to adjust the Auto-Close time. Pressing the open button
whilst pressing the Auto Close button increases length of operation. Each press will increase the time by 5
seconds. Pressing the close button will decrease the time.
FORCE MARGIN SET button. The obstruction force margin is set automatically during installation. The
margin can be adjusted manually using the Force Margin Set button (White). Holding the Force Margin
Set button and pressing OPEN or CLOSE buttons will increase or decrease the amount of force. The Force
Margin Set should only be used if environmental factors (wind, etc.) affect the door’s operation.
OPEN LIMIT LED (Green) the LED is very helpful during installation. It illuminates and flashes when the
door is opening and remains steady on when the open limit position has been reached.
OPEN button (Green) is used during installation to help set the open limit position. Pressing and holding
this button will move the door in the open direction, releasing stops the door.
NOTE: The safety obstruction detection is inoperable when the OPEN button is used to move door.
OPERATE button (Yellow) is used during installation to test the open, stop and close cycles for the
opener. The opener has to be initialised by the Reset button to make the O/S/C button operable.
SET button (Yellow) is used during the installation phase together with the Open and Close buttons to set
the door limit positions. The Set button is also used to re-initialize the Opener.
ENGAGE/DISENGAGEMENT CORD enables manual door operation, especially useful during
power failures. At the cord’s end is the EASY ACCESS TRANSMITTER; a wireless door controller.
01
02
03
04
05
06
07
08
09
10
11
12
14
13

Owner Installation Instructions GDO-6v3 EasyRoller®9
01
02
03
04
05
06 07 08
09
10
11
12
13
14
15
17
15
JP1 SOLAR CONNECTOR the shunt must be fitted for solar operation.
PROG INPUT is used to connect the Automatic Technology Handheld Programmer for editing control
and receiver functions, accessing diagnostic tools, and activating special features and operating modes.
SBY-3 CONNECTOR is used to connect both Battery Backup Kits and SmartSolar™ kits.
16
17
16
PWR
PE
PE-
GND
OSC
AUX

10 GDO-6v3 EasyRoller®Owner Installation Instructions
Package Contents
GDO-6v3 Easyroller® drive unit w/ Easy Access Transmitter 1
TrioCode™ keyring transmitters 2
Pan head screw M4x50mm (not included in some models) 2
Nilock Hex nut M4 (not included in some models) 2
Flat washer I.D. 3/16 x 1/2 (not included in some models) 2
Spring washer I.D. 5 (not included in some models) 2
Locking bar covers 2
Weight bar (not included in some models) 1
Installation Instructions 1
TrioCode™ Keyring Transmitter Pack
Weight Bar
Drive Unit
Locking Bar Covers

Owner Installation Instructions GDO-6v3 EasyRoller®11
Installation
Pre-Installation Requirements
IMPORTANT SAFETY INSTRUCTIONS FOR INSTALLATION
Warning: Incorrect installation can lead to severe injury.
Follow ALL installation instructions.
01
fig
02
fig
Door Operation
The door must be in good operating condition. The
maximum effort to move the door up or down, from
stationary, should not exceed 150 Newtons (15kg force) at
the bottom rail. The recommended force is 70N (7kg) for
manual operation.
Lift the door to about halfway. When released, the door
should stay in place supported entirely by its springs. Raise
and lower the door to check for binding or sticking.
The door may need to be serviced to meet these
requirements – refer to the door manufacturer’s servicing
instructions or contact an authorised dealer.
Unsuitable Door Types
The fitting of an opener to doors with removable mullions is
not recommended.
IMPORTANT NOTE - The opener should not be
installed on any door incorporating a wicket door.
Position
The opener can be installed on either the right- or left hand
side of the door (when viewed from inside the garage). The
opener is factory set for right hand side installation.
This opener must be installed in a dry position that is
protected from the weather. Moisture or corrosion damage
is not covered by the Warranty.
Power Supply
Properly earthed 3 pin single-phase power is required.
WARNING! A portable power generator is
not recommended. The opener may appear to
malfunction due to spikes, surges and fluctuations in
the generated voltage.
Sideroom
The minimum sideroom required from the edge of the door
curtain is 40mm to the inside of the door bracket, and 85mm
to the wall (Fig. 01). If a Battery Backup Kit is to be fitted, at
least 135mm to the bracket is required (Fig. 01a).
The recommended sideroom from the edge of the door
curtain is 95mm to the inside of the door bracket, and
135mm to the wall (Fig. 02).
NOTE: Door Axle Diameter must not exceed 35mm.
135
01a
fig

12 GDO-6v3 EasyRoller®Owner Installation Instructions
Installation
Step 1 - Preparation
Check the door’s operation:
The door must travel smoothly and be
easy to operate by hand.
Operating force on the bottom rail should
be approximately 70N (7kgs) force.
Adjust any tight or twisted guides/tracks
Clean the guides if there is any oil or wax
present using a suitable white spirit. The
only lubricant suitable for use on door
guides is silicon spray. DO NOT use WD-
40, RP-7, petroleum grease, or similar.
Install the locking bar covers if there are locking bar
holes in the guides. (Fig.03)
IMPORTANT NOTE - Do not lock your door
with the locking bars after installing the opener.
Remove or disable the lock using wire or cable
ties. Security is not affected as the opener has an
inbuilt locking facility.
Affix the warning labels supplied with this opener in
a prominent place where they are clearly visible.
Choose the side where the opener will be installed,
ensuring there is sufficient sideroom.
Step 2 - Fit the Weight Bar
The weight bar must be fitted to the bottom-centre for
proper operation of the opener.
If the door has a handle:
Remove the door handle
Fit the weight bar and refit the handle using the
new fasteners provided (Fig.04).
If the door does not have a handle:
Locate the centre of the door at the bottom rail
(Fig.05).
Place the weight bar at this point (there is a
centreline marked on the weight bar) and mark the
two positions where the fasteners will go.
Drill the two 4.5mm holes in the door and fit the
weight bar using the new fasteners provided.
(Fig.06).
Check that the door is still balanced and smooth to
operate. If it is not, then the door may require servicing
(refer to door manufacturer’s instructions).
WARNING! The door and its springs are under
significant tension. Adjustments should only
be carried out by experienced persons, as this
function can be dangerous if not performed under
strict safety procedures.
a.
i.
ii.
iii.
iv.
b.
c.
d.
a.
b.
a.
b.
c.
03
fig
06
fig
05
fig
04
fig

Owner Installation Instructions GDO-6v3 EasyRoller®13
Installation
07
fig
08
fig
Step 3 - Pin the Door Curtain
Pinning the door curtain to the door drum maintains
security when the opener closes and locks.
Fully close the door.
Mark drill holes at both ends of the drum (Fig. 07).
Drill holes using 3.2mm (1/8”) drill bit. Open the
door slightly for easier access, if necessary.
Fit a 10 x 32mm screw and washer to each end. This
screw should be positioned as low as possible, but
make sure that it does not alter the curtain’s normal
approach to the guide (lead-in angle).
NOTE: Make sure that the screws do not project into the
area where the internal gear will fit.
Step 4 - Fitting the opener
At the end opposite to where the opener will be
fitted, check that the U-bolt is tightened securely.
Open the door completely and tie safety ropes
around the door roll approximately 300mm from
each end. Do not tie the ropes too tight as damage
to the curtain may ensue.
At the end where the opener is to be fitted, support
the door with a ladder or suitable prop:
WARNING! Make sure the support is snug under
the door, stable and will not move.
At the end where the opener will be fitted, use
masking tape or pen to mark the position of the
U-bolt in the door bracket and the position of the
door bracket on the wall to assist in reassembling.
Remove the U-bolt (or bolts) and saddle from the
door bracket.
Remove the door bracket allowing the door to rest
on the support (Fig. 08).
NOTE - For minimum sideroom installations the
door may have to be taken down.
WARNING! The opener must not be used with a
door incorporating a wicket door.
a.
b.
c.
d.
a.
b.
d.
e.
f.
Door drum
U-bolt
Bracket
Pin Points

14 GDO-6v3 EasyRoller®Owner Installation Instructions
Step 5 - Mounting the Opener
If the internal gear does not rotate freely, switch the
opener to manual by pulling the disengagement
handle down (there will be a click), so that the ring
gear can be rotated by hand.
Slide the opener over the door axle and into the
drum of the door (Fig. 09).
Ensure the internal gear is pushed in as far as
possible (without interfering with the door curtain)
and that one of the door drum’s wheel spokes is
completely between the opener’s drive forks.
Re-attach the door bracket using your reference
marks as a guide and tighten the bolts. Ensure that
the slots in the mounting bracket of the opener
align with the slots in the door bracket, otherwise
the door bracket may have to be relocated (Fig.
10).
NOTE: If the bracket cannot be relocated, the opener
may be fitted onto the axle using the opener’s saddle
and U-bolt as follows:
Using your reference marks as a guide,
sit the opener on the door mounting
bracket and secure with the opener’s U-
bolt and saddle and tighten firmly.
Adjust the door position (if necessary)
on the brackets so that the door feeds
smoothly into the guides. Make sure that
the centre of the door doesn’t hit the
lintel and that the curtain is not pushed
forward hard into the guide.
Remove the support and safety ropes (Fig. 10).
IMPORTANT NOTE - If the manual release handle
is more than 1.8 metres from floor level when the
opener is installed, extend the handle to a height
less than 1.8 metres.
Connect the power cord to a suitable power point,
but DO NOT SWITCH ON.Secure the power cord
away from any moving object (e.g. the door) with
the cable clip supplied.
With the opener still disengaged, pull the door up
and down to make sure it runs freely.
a.
b.
c.
d.
i.
ii.
e.
f.
g.
09
fig
10
fig
Installation
PULL STRING HANDLE
IF GEAR IS NOT
TURNING FREELY
UNTIE ROPE
REMOVE PROP
REFIT RIGHT
BRACKET
TIGHTEN “U”
BOLT NUTS

Owner Installation Instructions GDO-6v3 EasyRoller®15
Programming the Opener
11
fig
12
fig
Step 6.1 - Setting Travel Limits
NOTE: If PE Beams are to be used they must be installed
before setting the travel limits.
WARNING! Use caution when operating the manual
release with the door open since it may fall rapidly
due to weak or broken springs, or an improperly
balanced door.
CAUTION! Do not disengage the opener to manual
operation with children, persons or any objects
including motor vehicles within the doorway.
NOTE: To access the console, remove the controls lid
cover and reattach when setup is completed.
Move the door to halfway open. If necessary,
disengage the opener by pulling the cord down (Fig.
11).
Re-engage the opener by pulling the cord down.
Turn on the power to the opener. The CLOSE LIMIT
LED will be flashing.
Press and hold the CLOSE button - the door should
start closing (Fig. 12).
If the door opens, release the CLOSE button and
press the OPERATE button once to change the
motor’s direction. Press the CLOSE button again to
close the door.
Release the CLOSE button when the door is near the
desired closed position. Single presses of the CLOSE
button will “inch” the door closed.
If the door overshoots, press the OPEN button to
move the door in the open direction.
When the door is at the desired close position, press
the SET button to record the close limit position. The
OPEN LIMIT LED will now flash.
Press and hold the OPEN button to open the door.
Release the OPEN button when the door is near the
desired open position. Single presses of the OPEN
button will “inch” the door open.
If the door overshoots, press the CLOSE button to
move the door in the close direction.
WARNING! Once the next step is performed, the
door will automatically close and open to calculate
force settings. Keep persons and objects clear of the
door until it stops and the opener sounds a beep.
Press the SET button to store the open limit. Please
read the above warning.
Step 6.2 - Resetting Travel Limits
To reset the limits, press and hold the CLOSE button for 6
seconds until the CLOSE LIMIT LED flashes quickly. If no
action is taken within 30 seconds, the opener will return
to normal operating mode and restore the original limit
settings.
a.
b.
c.
d.
e.
f.
g.
h.
i.
j.
k.
l.

16 GDO-6v3 EasyRoller®Owner Installation Instructions
Programming the Opener
13
fig
Setting Limits: via Transmitter
The GDO-6v3 has the alternate ability to set travel limits
using the transmitter, allowing free movement around the
garage to better assess the desired limit positions.
Step 7.1 - Code a Transmitter for Limit Setting
Ensure the opener is powered up.
Press and hold the DOOR CODE button (Fig. 13).
Press Button 1 on the transmitter for two seconds
(Fig. 14). Release and pause for two seconds.
Press the Button 1 again for two seconds.
Release the DOOR CODE button.
Step 7.2 - Setting Limits via Transmitter
Press and hold Button 4 on the transmitter to close
the door. When the door is approximately 2cm from
the ground, press and hold Button 3 for two seconds
and release (Fig. 14).
If the door opens, release the CLOSE button and
press the OPERATE button once to change the
motor’s direction, then repeat Step 7.2(a).
Each press of Button 4 will allow you to “inch” the
door closed. Keep doing this until the door reaches
the desired close limit position.
If the door is closed too far, press Button 1 to “inch”
the door towards open.
When happy with the close limit position, press
Button 2 to store this in memory.
Press Button 1 to open the door. When approximately
2cm from the desired open position, press and hold
Button 3 for two seconds then release.
Each press of Button 1 will allow you to “inch” the
door open. Keep doing this until the door reaches
the desired open limit position.
If the door is opened too far, press Button 4 to “inch”
the door towards closed.
IMPORTANT WARNING: The door will
automatically close, open and close again once
Step 7.2(i) is performed. Ensure that no persons
or objects are in the door’s path.
When happy with the open limit position, press
Button 2 on the transmitter to store into memory.
The door will now automatically close and open to
calculate the safety obstruction settings. After this, the
opener can be operated with the OPERATE button.
Step 7.3 - Resetting the Door Limit Positions
Limit positions can be deleted by the following steps:
Press and hold the MINUS (-) button for six (6)
seconds until you hear three beeps and the CLOSE
LIMIT LED starts to flash.
Release the CLOSE button.
Repeat Steps 7.2 to set new travel limit positions.
NOTE: There is no need to re-code the transmitter (Step
7.1) upon resetting travel limits. The transmitter will still
be stored in memory.
a.
b.
c.
d.
a.
b.
c.
d.
e.
f.
g.
h.
i.
j.
a.
b.
c.
Button 1
(Inch Open)
Button 4
(Inch Close)
Button 2
(Set)
14
fig

Owner Installation Instructions GDO-6v3 EasyRoller®17
Safety Obstruction Force
Wood (40mm high)
15
fig
WARNING! Take care when testing or adjusting
the Safety Obstruction Force. Excessive force
may cause SERIOUS PERSONAL INJURY and/or
PROPERTY DAMAGE.
WARNING! Photo Electric Beams must be
installed where the closing force as measured
on the bottom of the door is more than 400N
(40kgf)
Safety Obstruction Force Test
Step 8.1 - Testing Close Cycle
Press the OPERATE button to open the door (Fig.
15).
Place a piece of timber approximately 40mm high
on the floor directly under the door (Fig. 16).
Press the OPERATE button to close door. The door
should strike the object and start to re-open.
Step 8.2 - Testing Open Cycle
Press the OPERATE button to close the door (Fig.
15).
Press again to open the door. When the door
reaches the half open point, grab the bottom rail of
the door firmly and the door should stop.
If the door does not reverse readily when closing,
or stop when opening, the force may be excessive
and need adjusting, refer below.
DANGER! If the door fails these tests, put the
opener into manual mode, only operate the door
by hand and call for service.
a.
b.
c.
a.
b.
c.
16
fig

18 GDO-6v3 EasyRoller®Owner Installation Instructions
Adjusting Safety Obstruction Force
The Safety Obstruction Force is calculated automatically
during setup. Adjusting this is normally only necessitated
by environmental conditions such as windy or dusty areas,
and areas with extreme temperature changes.
Step 9.1 - To Increase Force Pressure
Hold down the FORCE MARGIN SET button (Fig.
17).
While holding the FORCE MARGIN SET button,
press the OPEN button. Each press increases the
force margin.
The OPEN LIMIT LED will flash each time the
OPEN button is pressed to indicate a force margin
increase.
NOTE: If the OPEN LIMIT LED is lit continuously
when pressing the OPEN button, this indicates that the
maximum setting has been reached.
Test the force again as per Steps 8.1 and 8.2
Step 9.2 - To Decrease Force Pressure
Hold down the FORCE MARGIN SET button (Fig.
17).
While holding the FORCE MARGIN SET button,
press the CLOSE button. Each press decreases the
force margin.
The CLOSE LIMIT LED will flash each time the
CLOSE button is pressed to indicate a force margin
decrease.
NOTE: If the CLOSE LIMIT LED is lit continuously
when pressing the CLOSE button, this indicates that the
minimum setting has been reached.
Test the force again as per Steps 8.1 and 8.2
Step 9.3 - To Recall Factory Set Force
While holding down the FORCE MARGIN SET
button, press the SET button for two (2) seconds.
(Fig. 18)
Release both buttons. The default setting should
now be recalled.
Step 9.4 - To Recalculate Force Margins
Press and hold the SET Button for two (2) seconds,
the beeper will sound once (Fig. 19).
The door will start to move and re-calculate force
margins. The door can move between the open and
close limit positions up to four (4) times (depending
on the position of the door and the power up
condition).
A single beep will be heard once the process is
complete.
Test the force again as per Steps 8.1 and 8.2.
a.
b.
c.
d.
a.
b.
c.
d.
a.
b.
a.
b.
c.
d.
Safety Obstruction Force
17
fig
18
fig
19
fig

Owner Installation Instructions GDO-6v3 EasyRoller®19
Step 10.1 - Code a Transmitter Button for
Door Operation
Press and hold the DOOR CODE button (Fig. 20).
Press one of the four buttons on the transmitter for
two (2) seconds, pause for two (2) seconds, then
press the same button again for two (2) seconds.
Release the DOOR CODE BUTTON.
Press the transmitter button to test.
Step 10.2 - Coding a Transmitter Button to
the Courtesy Light
The transmitter can be programmed to operate the
courtesy light on the opener independently of the door
moving.
Press and hold the LIGHT CODE button (Fig.
21).
Press one of the four buttons on the transmitter for
two (2) seconds, pause for two (2) seconds, then
press the same button again for two (2) seconds.
Release the LIGHT CODE button.
Press the transmitter button to test.
Step 10.3 - Code a Transmitter Button for Pet
(Pedestrian) Mode
Briefly press the DOOR CODE button three times,
then press it again and hold (will beep four times on
fourth press (Fig. 22)).
Press one of the four buttons on the transmitter for
two (2) seconds, pause for two (2) seconds, then
press the same button again for two (2) seconds.
Release the DOOR CODE button.
Press the transmitter button to test.
To change the default pet (pedestrian) door opening
position, refer to step 17.
Step 10.4 - Code a Transmitter Button to
Enable Vacation Mode
The opener can be programmed into a “Vacation
Mode” where the opener will not respond to any
transmitter except the button of the transmitter that was
programmed for vacation mode.
Briefly press the DOOR CODE button once, then
press it again and hold (will beep two times on
second press (Fig. 23)).
Press one of the four (4) buttons on the transmitter
for two (2) seconds, pause for two (2) seconds,
then press the same button again for two (2)
seconds.
Release DOOR CODE button.
Press and hold the transmitter button for six (6)
seconds to set Vacation Mode. The door code
LED will stay lit while Vacation Mode is active.
To reset Vacation Mode, press the same button
for two seconds.
a.
b.
c.
d.
a.
b.
c.
d.
a.
b.
c.
d.
e.
a.
b.
c.
d.
e.
Coding Transmitters
20
fig
21
fig
22
fig
23
fig

20 GDO-6v3 EasyRoller®Owner Installation Instructions
24
fig
Step 10.5 - Code a Transmitter Button to
Enable AUX OUTPUT
Briefly press the DOOR CODE button two (2)
times, then press it again and hold (will beep
three times on third press (Fig. 24)).
Press one of the four buttons on the transmitter
for two (2) seconds, pause for two (2) seconds,
then press the same button again for two (2)
seconds.
Release the DOOR CODE button.
Press the transmitter button to test.
Step 11 - Easy Access Transmitter (EAT)
Coding
Press and hold the DOOR CODE button (Fig. 24).
Press the EAT’s button for two (2) seconds, pause
for two (2) seconds, then press the button again
for two (2) seconds (Fig. 25).
Release the DOOR CODE button.
Press the transmitter button to test.
Step 12 - Remotely Coding Transmitters
Using this method, transmitters can be coded without
access to the opener’s control panel as long as a pre-
coded transmitter is available.
IMPORTANT NOTE: The door or courtesy light
must activate when the steps below are performed.
This indicates that the pre-coded transmitter is in
range of the opener, and the correct button has
been pressed.
Take any pre-coded transmitter. Press the button
for the function to be duplicated and release. If
the door is running, stop it by pressing the same
button again
Using a small needle, press and hold firmly for (2)
two seconds through the Coding Hole (Fig. 26).
WITHIN 10 SECONDS, take the additional
transmitter you wish to code. Decide which
button that you want to activate the function to
be duplicated (e.g. activate the door, or turn on
the courtesy light).
Hold the new transmitter’s button for two (2)
seconds, pause for two (2) seconds, hold again
for two (2) seconds and then release.
Wait for 10 seconds and then press the new
transmitter’s button to test.
a.
b.
c.
d.
a.
b.
c.
d.
a.
b.
c.
d.
e.
Coding Transmitters
25
fig
26
fig
