Pulse Output
The pulse outputs can be set to generate pulses to
represent kWh/kVarh
Pulse constant: 0.001/0.01/0.1/1/10/100/1000 kWh or
kVarh per Pulse
Pulse width: 200/100/60 Ms.
The pulse output is passive type, complies with
IEC62053-31 Class A.
Uimp
R
OUTPUT
P+ Com
ATTENTION: Pulse output must be fed as shown in
the wiring diagram below. Scrupulously respect
polarties and the connection mode. Opto-coupler with
potential-free SPST-No Contact.
Contact range: 5~27VDC Max. current Input: 27mADC
Pulse
This option allows you to configure the pulse output. The output can be set to
provide a pulse for a defined amount of energy active or reactive.
This option sets the pulse output type, pulse rate, duration
time.
From the Set-up menu, Use and to select the
Pulse option.
And long press for confirmation
Pulse rate
Pulse rate options: 0.001 , 0.01 , 0.1 , 1, 10, 100, 1000 kWh /
kVarh per Pulse. Default : 0.01 kWh (100imp/kWh)
Use and to select Pulse Rate option.
Long press the setting will flash.
Use and to choose Options.
Long press for confirmation.
Password Entry
Setting-up mode is password protected, so you must enter
the correct password.
By firmly pressing the button for 3 seconds, the
password screen appears.
The default password is 1000.
If an incorrect password is entered, the display shows ERR.
Programming the meter
When you receive the meter there will be at least one value that you must
programme into the meter. This is the current transformer ratio.
If the meter has been purchased with the intention of using the RS 485
Modbus output then you will have to program the Modbus parameters you
require. See reverse Communication. (RS 485 Modbus)
HT-1095 METER
From the main Set-up menu, Use and to select the
CT option.
And long press for confirmation
C.T. (Current Transformer)
C.T. Rate (Current Transformer)
To set the primary current ratio in the meter you must
program the divider into the meter. e.g. to set 200/5 amp
input “0040” (Divide the primary by 5) 5 amp being the
secondary of the c.t. See table below.
Options: 1~2000
Default CT rate 1. ( New Ratio Must Be Programmed Into
The Meter)
Long press to enter the CT Rate routine.
Press for 3s, the CT rate setting will flash.
Use and to choose CT rate with 1~2000.
And long press for confirmation
C.T.2 (Current Transformer)
Set C.T.2 secondary current input.
Options: 5A or 1A
Default CT2: 5A
Long press to enter the CT2 routine.
Press for 3s, the CT2 setting will flash.
Use and to choose CT2 with 5A or 1A.
And long press for confirmation
P
PF Hz
MD
P
PF Hz
MD
P
PF Hz
MD
P
PF Hz
MD
P
PF Hz
MD
P
P
PF Hz
MD
E
E
E
E
E
E
E
E
E
E
E
Quick setup guide
Example of meter set at 200/5 amp
Example of how
the display should
look for a meter
programmed to
200/5 amp.
See table for
more settings.
Number to program
into the meter
0020
0030
0040
0050
0060
0080
0100
0120
0160
C.T Primary
100/5
150/5
200/5
250/5
300/5
400/5
500/5
600/5
800/5
C.T Primary
100/1
150/1
200/1
250/1
300/1
400/1
500/1
600/1
800/1
Number to program
into the meter
0100
0150
0200
0250
0300
0400
0500
0600
0800
Example of meter set at 200/1 amp
Example of how
the display should
look for a meter
programmed to
200/1 amp.
See table for
more settings.
To check the settings which have been progammed into the
meter.
Long press Modbus Address.
Short press to scroll through the other settings:
Baud Rate
Parity
Primary current transformer ratio ( c. .t 1)
Secondary current transformer ratio ( c.t. 2)
Meter serial number, 7 day program time
Date and Time
Tariff 1-8
Full test icons on display
IMPORTANT NOTICE
The HT-1095 is a MID approved panel meter, once you have altered any of the
parameters e.g. Current transformer ratio or voltage ratio and you have come
out of the programming mode you cannot alter them again.
This rule does not apply to the Modbus settings.
Meter programming check
PF Hz
MD

Terminal covers supplied
must be fitted and sealed to
comply to MID specifications.
Pulse Duration time option 200, 100, 60mS
Default : 100mS
Use and to enter Pulse duration routine.
Long press , the setting will flash. Use and to
choose Options.
And long press for confirmation.
Press to return the Pulse Duration set up menu.
Pulse Duration
Baud rate
Baud rate options: 2400 4800 9600 19200 38400 (bps).
Default: 9600bps
From the Set-up menu, Use and to select the Baud
rate options.
Long press to enter the selection routine.
The Baud Rate setting will flash. Use and to choose
Baud Rate.
And long press for confirmation
Parity
Parity Options: NONE, EVEN, ODD.
Default Parity : EVEN
Note that if parity is set to ODD or EVEN, Stop Bits will be set
to 1 and cannot be changed.
From the Set-up menu, Use and to select the
Parity options.
Long Press to enter the selection routine.
The Parity setting will flash. Use and to choose
Parity.
Example shows:
Set Parity: EVEN
And long press for confirmation.
Press to return the main set up menu.
Address
An RS485 network can accommodate up to 255 different
devices, each identified by an individual address.
The Modbus address range on the HT-1095 is between
001~247
Default setting from Autometers is 001
Long press to enter the selection routine.
The address setting will flash. Use and to
increment or reduce the number.
Long press for confirmation.
Product development is continuous and Autometers Systems Limited reserves the
right to make alterations and manufacture without notice. Products as delivered may
therefor differ from the descriptions and illustrations in this publication
Autometers Systems Ltd.
4B Albany Road, Chorlton-cum-Hardy
Manchester M21 0AW
Email: [email protected]
Phone: [phone]
www.autometers.co.uk
Mains
Load
Neutral
L1
L2
L3
Direction of Current
P2
P2
P2
1 Amp
Fast Blow
Fuses S2 S1 S2 S1 S2 S1
L3 L2 L1
C.T. INPUTS
P1+ COM P2+
PULSE OUTPUT
TX+ TX- SHIELD
MODBUS OUTPUT
Voltage Outputs
N V3 V2 V1
Voltage Inputs
NV3V2V1
S1
S2
S1
S2
S1
S2
3 phase 4 wire
Communication (RS 485 Modbus)
The RS485 port can be used for communications using
Modbus RTU protocol. Parameters such as Address, Baud
rate, Parity, Stop bit can be selected.
Long press to enter the Address option.
Communication status
Indication only
Electrician
The HT-1095 panel meter should only be installed by a fully qualified electrician who
has knowledge of electricity meters connected with current transformers.
It is the installer who is fully responsible for the safe installation of this meter. It must
be installed to meet the current electrical regulations concerning installation of panel
meters.
EMC Installation Requirements
Please see full installation brochure for details - visit autometers.co.uk
Wiring Information
Power Supply
The HT-1095 receives it power from any one of the voltage connections and Neutral.
Wiring
Electrical and communication connections are made directly to the back of the
meter.
The electrical connections of voltage, current and Pulse output are made directly to
the back of the meter. The RS 485 Modbus connections are at the top on the side of
the meter.
All terminals are green in colour and can be unplugged, The current terminals are
screwed in but can be unplugged if the screws are removed
Electrical Connections
2.5mm flexible stranded cable is recommended for all main electrical connections.
For the low voltage communication connections we recommend a twisted shielded
cable Belden 9841 2 wire or 9842 4 wire or equivalent.
Phasing and polarity of the AC current and voltage inputs and their relationship is
critical to the correct operation.
Dimensions
The meter is a 96 x 96 mm panel mounted meter with a depth of 70mm
The cut out hole for the panel meter is 92 x 92 mm.
For full installation brochure please visit autometers.co.uk
