Autonomous SmartDesk Core Duo User manual

M
M
1a. Loosen 4 x (M) Screws of Support Beam (I) using 4mm Allen Wrench, then fully extended the
beam.
2. Attach 2 x Connection Beams (B) to the legs as shown. Place 8 x (Z1) Gaskets on 8 x (V)
Screws, then use them to secure the 2 x Connection Beams (B) in place with the 5mm Allen
Wrench.
1b. Place Support Beam (I) over Legs (A1 + A2). Attach with 8 x (W) Screws. Repeat this step with
the other support beam.
Heads up
The 4(M) are
already
attached into
the beam
Make sure
connectors
are facing the
same side.
Assemble other
Support Beam
following the
same steps.
SmartDesk Core Duo

M
3a. Attach Power Tray (C) to Support Beams (I) using 8 x (X) Screws and the 5mm Allen Wrench.
4. Attach 1 x Cable Trays (L) to each Support Beam (I) using 4 x Screws (M) with a Z2 and Z1
Gasket on each screw, as shown. Do not fully tighten screws.
5a. Flip the frame upright. Place the Power Beam Covers on Power Tray.
5b. Attach 4 x Screen Clips (E) to each
Connection Beam using 8 x Screws (X) and
5mm Allen Wrench.
3b. Attach Plastic Lids (J) to both
Connection Beams (I)
6a. Attach 2 x Brackets (D) to each Support Beam (I) using 4 x Screws (W) and 4mm Allen Wrench.
6b. Place 4 x Support Pads (Z) on each
Bracket (D) and 2 x Support Pads (Z) on
each Support Beam (I) as shown.
7a. Connect the Control Box (F) to corresponding
Control Switch (H), and Legs cable. Repeat process
with the Desk on other side.
7b. Plug the Power Cable (K) into Control Box (F)
and then into a power outlet. Repeat process with
the Desk on other side.
8a. Carefully place both Desk Tops (G)
onto the desk frame. Attach Tops using 4
x (Y) Screws for each Bracket (D).
8b. Fix each central Support Beam (I)
into place using 2 x (Y) Screws.

9a. Find the pre-drilled holes on the edge of each Desk Top (G) as shown, then attach Control
Switches (H) using 2 x (Y1) Screws.
9b. Attach Control Box (F) beneath Desk Top using 2 (Y), Repeat process
with the Desk on the other side. Or you can place each Control Box (F)
onto the corresponding Cable Tray (L).
10. Plug each Control Box (F) into its corresponding Power Tray (C) outlet.
Then plug the Power Tray (C) cord into your power outlet.
