Autonomous smart office ErgoChair Core User manual

ErgoChair Core
Assembly Instructions

OVERALL SIZE
ErgoChair Core
Front view
25.8”
20”
18”- 21.7”
24.4”- 28”
Side view
24
47.6”- 51.2”
26.4”
16.3”
18.5”
27.6”

Base x 1
Casters x 5
Gas lift x 1
Seat x 1
Armrest x 1
Leg rest x 1
Mechanism x 1
A
B
C
D
E
F
G
Backrest x 1
Headrest x 1
Speed Wrench x 1
Washers large (M8x22x2) x 3
Washers small (M6x15 x1.5) x 10
Spring washers M8 x 3
H
I
J
K
L
M
NSpring washers M6 x 10
Machine screws (M8x55) x 3
Machine screws (M6x55) x 2
Machine screws (M6x40) x 8
Machine screws (M6x8) x 2
Screws M5 x 2
O
P
Q
R
S
Screwdriver x 1 (with Gas lift)
T
A
J K L M
NOP Q
R S
B C
D E F
G H I
PART LIST
COMPONENTS
HARDWARE/ TOOLS
T
(Optional)
(Optional)
ErgoChair Core • [phone] • www.autonomous.ai • [email protected]

Step 1
Step 3 Step 4
Step 2
C
Q
D
F
E
L
N
For full-option ErgoChair Core, please follow Step 4 and Step 5 to install the leg rest
before tightening the mechanism to the seat. Otherwise, please skip these two steps if
you own a basic ErgoChair Core.
Screws pre-installed on the leg rest.
Insert 5 Wheels to the holes on each
prong of chair Base.
ErgoChair Core • [phone] • www.autonomous.ai • [email protected]
A
B

Step 5
Step 7 Step 8
Step 6
P
L
N
H
O
M
K
Prepare the combo of P + N + L.
Tighten another two screws remaining
in the metal bar.
The R screws are ready on the leg rest.
Slot the base of the leg rest through the
support bracket, and tighten the screws
into place.
R
G
Q
L
N
Prepare the combo of Q + N + L.
Tighten the combo into the metal bar and
the seat bottom.
Prepare the combo of O + M + K.
Tighten three O screws, connect the
metal bar with the base of the backrest.
ErgoChair Core • [phone] • www.autonomous.ai • [email protected]

S
T
I
Step 9 Step 10
For full-option ErgoChair Core, please
follow Step 9 to install the headrest to
backrest.
Congratulations! You’ve done the assembly. Enjoy your ErgoChair Core now.
From the top, lift down slightly the seat
into the base, connect by the center
hole.
The screws are ready
on the headrest.
Tighten the screws
when it is in position.
Function
Right side.
Pull the handle
up to adjust the
seat height.
Left side.
This handle controls
the backrest’s angle.
Pull up: release
Push down: lock
ErgoChair Core • [phone] • www.autonomous.ai • [email protected]

Function
Rotate the leg rest
clockwise before use.
Pull the leg rest out.
3” up and down
3” up and down
25 degrees
adjustment
ErgoChair Core • [phone] • www.autonomous.ai • [email protected]

FAILURE TO FOLLOW THESE INSTRUCTIONS
MAY RESULT IN INJURY.
WARNING
1. This product is designed for seating only, do not stand on
this product. Do not use it as a step ladder.
2. Do not use this product unless all bolts and parts are firmly
tightened.
3. If any parts are missing, damaged or worn, stop using this
product. Repair the product with the replacement parts from
manufacturer.
4. Do not sit on the armest of this product.
5. This product is designed for one person sitting at a time.
6. Keep out of reach of children under the age of 10 unless
assistance from an adult is provided.
ErgoChair Core • [phone] • www.autonomous.ai • [email protected]
