Autonomous SmartDesk Home Edition User manual

Please go to www.autonomous.ai/assembly to
watch our assembly video. We recommend you
watch it before assembling your SmartDesk, since
it will walk you through the steps and help you
understand the instructions.
2
3
4
6
7
1
5
8
9
10 11 12 1413 15 16
2
16 8Noise Dampener
Pad
Parts & Tools List

Step 1
Step 2
Lay the top face down on the oor and place the frame
at upside down on it.
DO NOT ATTACH THE FRAME TO THE TOP YET, THIS STEP IS
FOR MEASUREMENT ONLY
Line up the frame to the two pre-drilled pilot holes on the
table top.

Step 3
Step 4
M6*10 8PCS
M8*10 8PCS
Hand tighten M6x10 Machine hex screws to the frame.
NOTE: Do not over tighten the screws since you may
need further adjustment later.
Firmly attach both lifting columns (legs) to the frame
using 8 M8x10 Machine hex screws (4 for each side).

Step 5
Step 6
M8 x 16
8PCS
Foot Pad 4PCS
Upside Down
Firmly attach both feet to the bottom of the lifting
columns using 8 M8x16 Machine hex screws
( 4 for each side).
Turn the table over to upright position.

Step 7
M6*10 4PCS
Attach the brackets to both ends of the frame
using 4 M6x10 Machine hex screws ( 2 for each side).

Step 8
Step 9
Turn the LEFT NUT counterclockwise to remove
it from the DRIVESHAFT. Keep the PLASTIC GROMMET
inside the LEFT NUT.
Insert the LEFT NUT and PLASTIC GROMMET into the
LEFT COLUMN. Pay attention to the insert direction.

Step 10
Step 11
Insert the DRIVESHAFT into the LEFT COLUMN. Push the
DRIVESHAFT all the way in.
Turn the LEFT NUT clockwise to rmly lock the
DRIVESHAFT in place. Leave a small gap (about 0.2in)
between the LEFT NUT and the LEFT COLUMN so they
won’t block the DRIVESHAFT when it turns.

Step 12
Step 13
0.2in
Slightly loosen the RIGHT NUT by turning it once around.
DO NOT REMOVE THE RIGHT NUT.
Pull the CENTER ROD out and insert it into the RIGHT
COLUMN

Step 14
Step 15
0.2in
Push the CENTER ROD all the way in. Then leave a small
gap (about 0.2 in) between CENTER ROD and RIGHT
COLUMN FAR WALL.
Turn the RIGHT NUT to lock the DRIVESHAFT in place.
Do not let the RIGHT NUT touch the RIGHT COLUMN.

Step 16
Step 17
Use the wrench to tighten both LEFT NUT and RIGHT NUT.
Connect the CONTROL BOX and SMART KEYPAD to your
SmartDesk

Step 18
Almost done. Turn on your SmartDesk by holding both
the UP and DOWN buttons for 20 seconds until you hear
a BEEP sound.

Check 1
Check 2
0.2in
Press UP to raise your SmartDesk up. Press Down to lower
your SmartDesk. Repeat it a few times.
There is a still small gap (about 0.2 in) between the LEFT
NUT and the LEFT COLUMN. If not, adjust the LEFT NUT
location. Tighten it with the wrench.

Check 3
Check 4
0.2in
There is still a small gap (0.2 in) between the CENTER ROD
and the wall of the RIGHT COLUMN. If not, adjust the
RIGHT NUT and CENTER ROD. Tighten the RIGHT NUT with
the wrench.
There is a gap between the RIGHT NUT and the RIGHT
COLUMN. If not, adjust the RIGHT NUT. Tighten it with
the wrench.

Step 19
M4.8 x 19
8 PCS
Insert the noise dampener on to the holes on the desk top.
CONGRATULATIONS!
You’re now a driveshaft
installation expert!

Step 20
Step 21
M4.8 x 19
8 PCS
Readjust the frame length if needed, then tighten 8 M6x10
Hex screws from step 3. Attach the frame to the top using
8 M4 x 19 Wood screws (3 for each side and 2 in the middle).
Attach the control box, control pad to the bottom of the
table top using 2 M4.8 x 19 and 2 M3.5 x 19 wood screws.
Plug the cables from the driving motor and the control
pad into the control box, then the power cord.

v1.1
