Hib Groove 50 User manual

Thank you for purchasing this HiB product.

Please read through these instructions carefully and refer back to them during installation to ensure that

your product is tted safely and that it retains its high quality nish.

Please retain this leaet for future reference.

Before drilling, ensure there are no hidden cables or pipes in the wall. Ensure the domestic electrical mains

supply to which the cabinet is being connected is turned o.

Please Note You may need to remove the door / doors to aid installation.

This can be done by unclipping the hinges (there is a release catch at the

back of the hinge) and disconnecting wire connectors. DO NOT FIT SHELVES AT THIS STAGE

FI#02 014 R161024 - Ver No. 1.0 Jan 2017

Bluetoothtm Cabinets

Groove 50

Art No. 48400

Groove 60 & 80

Art No. 48500 & 48600

Angle Adjustment

Claw In/Out

Adjustment

Claw In/Out

Adjustment

Fixing Preparation (Fig A)

Fixing Brackets (Fig B)

Hanger Adjustment (Fig C)

Mounting Points

Location of internal

xing hole (SINGLE DOOR)

REAR VIEW

Location of internal

xing hole (DOUBLE DOOR)

Wall Hung Installation

Ensure the domestic electrical mains supply to which

the cabinet is being connected is turned o.

1. Position the cabinet in a suitable location

(according to the zonal diagram (Fig 1) on the

back page) ensuring that the mains supply cable is

within reach of the cable connection point of the

cabinet. Carefully mark the desired position of the

cabinet using a soft pencil, ensuring it is level.

2. Remove the cabinet from the wall and using a

spirit level, mark a horizontal line below the pencil

mark, taking into account the location of the

mounting points (Fig. A). Place brackets on the

line paying attention to the distance between the

hangers on the cabinet. Carefully mark the position

of the holes using a soft pencil. (Fig. B).

3. Before drilling, ensure there are no hidden cables

or pipes behind the mounting point. Using a

suitable drill bit, drill holes in the marked positions

to a suitable depth.

4. Insert wall plugs level with the surface of the wall.

If tting to a tiled surface, wall plugs should be

inserted below the tile surface to avoid cracking.

NB. For plasterboard walls, specialist xings should be

purchased from any DIY or hardware store.

5. Fix the brackets to the wall using the screws

provided.

6. Carefully remove the small screws along the top

front edge of the cabinet to gain access to the

internal panel(s). (Fig. C) Keep screws in a safe

place.

7. Temporarily hang the cabinet ensuring the claws

on the hangers are securely located on the wall

brackets. Using a spirit level adjust the cabinet via

the screws on the hangers. (Fig. C).

8. Mark the position of the internal xing hole and

remove the cabinet. Using a suitable drill bit, drill a

hole and insert a wall plug as per stage 4 above.

9. Connect the cable at the rear of the cabinet to the

mains supply cable using a suitable terminal block

(not supplied) according to the wiring diagram (Fig.

2) on the back page.

10. Rehang the cabinet in position, tighten the screws

on the hangers (Fig. C) and secure the base of the

cabinet with the supplied screw(s) and screw cap(s).

11. Switch the mains supply back on.

Door Adjustment (Fig D)

Move door(s) up/down

Move door away/towards

the cabinet

Move door(s) left/right

Move door(s) up/down

Move door away/towards

the cabinet

Move door(s) left/right

Operation Instructions

To turn illumination on, touch the sensor once (Fig.E).

To change the colour temperature, touch and hold the

sensor until desired colour is obtained. The colour temp

is then set until changed again.

Heated Pad is only on when cabinet is illuminated.

Move door(s) up/down

Move door away/towards

the cabinet

Move door(s) left/right

Move door(s) up/down

Move door away/towards

the cabinet

Move door(s) left/right

hib.co.uk 3

Pairing Device To the Cabinet

• To activate the BluetoothTM, turn on cabinet by the

touch sensor located on the front of the cabinet (see

gure E). The cabinet will give out a tone to conrm

it is ready for pairing.

• Activate the BluetoothTM on your device* (see gure

F). Refer to the devices instructions for details.

• Search for“HiB001” if prompted for a connection

code, use “0000”. The cabinet will give out a tone to

conrm successful connection.

• You can now play music or other media through the

BluetoothTM cabinet (see g. G).

• When the cabinet is turned o the connection to the

BluetoothTM will be lost. When the cabinet is turned

on again it will automatically reconnect to the last

connected device.

• Refer to your device manual for operating controls.

• Music will stop playing when a phone call comes

into the BluetoothTM device, and will automatically

reconnect when nished.

*Only compatible Smart Phones & BluetoothTM Devices.

Care Instructions

To preserve the high quality nish of your HiB product,

please ensure you regard the following care and

cleaning recommendations:

Do not use abrasives or solvents when cleaning this

product.

Wipe o all water spillages as soon as possible using a

soft cloth.

Trouble Shooting Guide

Symptoms

Possible

Problem Solution

Device not

paired

BluetoothTM not

activated

Check BluetoothTM is

activated on compatible

device & cabinets turned

Device not

connecting

Only one

device can be

connected to the

cabinet at any

one time

Disconnect all devices and

reconnect only one device

No volume

Volume is

controlled from

device

Increase volume on device

connection Out of range

Range is within 8 metres,

move device closer to

cabinet

Turn Mirror On Fig. E

Activate BluetoothTM Fig. F Connect Fig. G

(Fig 1)

This product is suitable for installation in zones: 2 &Outside Zone

All installations must comply with guidelines which are based on a zonal concept. The diagram above

illustrates this concept and must be followed to ensure the safe installation of electrical appliances in the

bathroom. These regulations apply to domestic installations only. Installations must be made in accordance

with the current IEE wiring regulations and relevant building regulations. HiB recommends that all electrical

bathroom products should only be tted by a suitably qualied, Part P registered electrician.
