AVA WEIGH 334MSD600 User manual

05/2020
334MSD600
600 lb.
Digital BMI Physician Scale
w/ Height Rod
USER MANUAL

• This is a Digital Physician Weighing Scale with Body Mass Index (BMI) readout.
• It is an accurate electronic device with advanced design and stable performance.
• It is designed to measure the weight of a person and compute the BMI index once the
known height of a person is entered via the Indicator
• Do not dismantle the weighing machine without following the necessary instructions.
• Do not jump while standing on the platform. This may damage the sensor inside.
• Do not move the weighing machine violently and abruptly. It is recommended to move
and put down the weighing machine gently.
• It is suggested to wipe the stains with soft cloth soaked with detergent and to wipe
later with soft cloth too. Do not use organic solutions and boiled water to wipe the
stains. Do not use water for cleaning.
• Keep the weighing machine in a dry and clean environment. Do not expose it outdoor
or use it in locations near fire, under direct sunshine or with high temperature.
• When lifting the height meter, it is suggested to pull it straight along the pipe without
using excessive force.
GENERAL INFORMATION
SAFETY INFORMATION
TABLE OF CONTENTS
1.
General & Safety Informaon.................................................................................1
Specicaons..............................................................................................................2
Unpacking & Setup....................................................................................................3
• Packing List.........................................................................................................................................................................3
• Tools Required ..................................................................................................................................................................3
• Installation Procedure ..................................................................................................................................................3
Display & Keypad.......................................................................................................5
• Indicator Display..............................................................................................................................................................5
• Controls & Functions.....................................................................................................................................................5
• Function Keys....................................................................................................................................................................6
Operaon & Sengs ................................................................................................7
Calibraon...................................................................................................................8
User Parameters.........................................................................................................9
RS232 Communicaons...........................................................................................9
Error Messages........................................................................................................ 10

SPECIFICATIONS
2.
334MSD600
MAXIMUM CAPACITY 600 lb. / 300kg
MINIMUM WEIGHT 2 lb. / 1 kg
SCALE DIVISION 0.1 lb. / 0.05kg
WEIGHING UNITS lb. / kg
HEIGHT RANGE 24" - 83" (60cm - 212cm)
DIVISION OF HEIGHT MEASUREMENT Entry via keypad (0.5" / 1 cm)
DISPLAY LED Display
INTERFACE RS232
SIZE OF PLATFORM (L X W) 10.83" x 14.76" (291mm x 375mm)
TOWER HEIGHT 51.5" (1308mm)
OVERALL DIMENSIONS (LXWXH) 11.46" x 24.29" x 51.54"
(291mm x 617mm x 1309mm)
NET WEIGHT 31 lb. / 14kg
TEMPERATURE FOR USE 41 - 104°F (5 - 40°C)
HUMIDITY FOR USE <85% RH
POWER 12vDC 500mA adapter
BATTERY Internal, re-chargeable 6V 4Ah baery

5. Place the cable (4) into the tube
support (6) on the scale base.
6. Insert the pillar (3) into the
tube support (6).
7. Rotate the pillar to position
the indicator (1) in the direction
desired, and then secure using
the (2) screws (5) into the fixing
tube (6).
1. Locate the 4 screws (2).
2. Place the cable (4) through the pillar (3).
3. Insert the 4 screws (2) through the holes on
the pillar bracket and secure the bracket to
the indicator (1).
4. Make sure the screws are securely tightened.
• Indicator
• Height Rod
• Manual
• Pillar
• 12V 500mA Adapter
• Philips Head Screwdriver (Not Supplied)
• Small Hex Allen Wrench (Included)
• Large Hex Allen Wrench (Included)
UNPACKING & SETUP
3.
PACKING LIST
TOOLS REQUIRED
INSTALLATION PROCEDURE

8. Locate the load cell cable (13)
ready for connection.
9. Place the indicator cable (4) and
the load cell cable (13) together
near the hole on the base (16).
10.Plug the two connectors (15)
together.
11.Position the connector inside the
base (16).
12.The cables should be fixed to the
base using the clip (14) provided.
4.
13.Locate the fixing bolt & washer
(10) used to secure the height
rod to the scale base (11).
14.Locate the height rod (7) onto
the fixing points (9) of the upper
& lower brackets (8) & (12).
13.Secure the bolt & washer (10) to
the bracket on the base.
14.Tighten the bolt (9) on the upper
bracket.

INDICATOR DISPLAY
CONTROLS & FUNCTIONS
5.
kg lb Hold CH AC
NET
Zero
BMI
334MSD600
TARE
UNIT
HOLD
PRINT
600lb x 2lb / 300kg x 0.1kg
KEY FUNCTIONS
POWER To turn the scale on or o.
To zero the scale if the display dris from zero.
TARE To tare the scale, if necessary.
Accept sengs as required.
UNIT Toggle weight unit between Lb. & kg and to select the BMI funcon.
Move acve digit to the right when required.
HOLD/PRINT
Locks the reading even if the person to be weighed is moving.
Prints via the RS232 interface.
Increase value or sengs when required.
DISPLAY FUNCTIONS
Kg Indicates when the scale is weighing in Kilograms.
Lb Indicates when the scale is weighing in Pounds.
Hold
Indicates when the scale has held the weight reading shown on the display.
It will ash unl it locks into the stable reading when it will then remain on for
a preset me when it has held the displayed reading.
BMI Indicates when the scale is displaying the Body Mass Index value.
CH The charge light will be on when the baery is recharging.
AC This indicates when the scale is being used with the AC adapter.
Zero This indicator will be displayed in the le corner when the scale reaches zero.
NET The Net weight is displayed, Tare weight is at zero.

6.
DISPLAY CHARACTERS
SYMBOL DIGIT SYMBOL DIGIT SYMBOL DIGIT
0 A N
1 B O
2 C P
3 D Q
4 E R
5 F S
6 G T
7 H U
8 I V
9 J W
K X
L Y
M Z

1. Position the Physician Scale on an even floor and press the ON/OFF key.
2. The instrument performs a self-test after which it is ready for operation.
3. Press the ON/OFF key and the machine switches off.
4. The person to be weighed can sit on to the chair once the scale shows 0.0 on the display.
The weight will be display in Kg. or lb. depending on the units chosen by the user.
5. If the weighing value is to be tared press the tare key to remove the weight value from the display.
6. Press the UNIT key for changing the weighing unit to kg or lb. The LED will indicate the
chosen weighing unit.
7. Overload display: When “FULL” appears on the display, it shows that the load on the chair
is over the maximum capacity. Under these circumstances, it is necessary to reduce the load
otherwise the sensor or the chair will be damaged.
8. Hold Function: To lock the weighing result, press the PRINT/HOLD key. The LED will flash
until a stable reading has been obtained and then it will light up constantly. The weight will
be displayed until the hold time has expired (see Sec 6.0) or to manually release the function,
press the PRINT/HOLD key again.
9. Print Function: To send the weighing result to a printer or computer press the
PRINT/HOLD key when the PRINT/HOLD key has been set up in the parameter section to
work as print function.
1. While measuring the height, it is necessary to pull up the measuring board at a right angle
with the inside tube.
2. When the tube is pulled out straight, it is sufficient to measure the height from
24"-45.5" / 60-115cm. The number can be obtained upon the conjoint place where the upper
part of middle tube screw meets with the inside tube scale.
3. Further, if the middle tube is pulled out straight, it is possible to measure the height from
45.5"- 83" / 115-212cm. The reading can be obtained at the conjoint place where the upper
part of outside tube screw meets with the middle tube scale.
1. Once the height has been determined it is possible to enter the height reading into the display
ready for the scale to compute the BMI.
2. Press and hold the UNIT/BMI key to enter the BMI mode. The display will show the last height
value used, or depending on which weighing unit you are currently using.
3. The height entry unit (in. or cm) will be flashing to show you which unit you are currently in, use
the Up arrow key to change the height entry unit between in. to cm as required
4. Enter your height using the arrow keys, the PRINT/HOLD will increment the flashing digit, the
right arrow, the UNIT/BMI key, will move the flashing digit to the adjacent digit.
5. Press the TARE key to confirm the value.
6. The display will now show the BMI based on the current weight on the scale and the height entered.
7. Press the UNIT/BMI key to exit the BMI mode and return to normal weighing.
8. The Hold function will work as described above whilst in the BMI mode.
OPERATIONS & SETTINGS
7.
WEIGHING
MEASURING HEIGHT
MEASURING BMI (BODY MASS INDEX)

Before calibrating the scale, you should ensure that you have a suitable known weight for calibration.
CALIBRATION
8.
1. When in normal weighing mode with the scale at zero press and hold down TARE and ON/OFF
keys to enter the calibration mode.
2. If the calibration switch is in the off position on the main PCB inside the scale, the indicator will
show and then exit this mode. If the indicator shows , the scale is ready
for calibration.
3. When the indicator shows , press the TARE key to confirm and go to next step, or
press the ON/OFF key to exit the calibration mode.
4. When is displayed the scale will begin to calibrate the scale’s zero-point. Ensure that
there is no load or weight on the scale’s chair. Press the TARE key to confirm, or press the ON/
OFF key to exit this mode.
5. A few seconds after the TARE key has been pressed in step 4 the scale will show and
the kg LED, or and the lb LED depending on which unit you chosen, this is the
default calibration weight from the factory. Press the UNIT key to select the calibration weight
unit that you want to calibrate in. Press the ON/OFF key to exit the calibration mode at this
point or press the PRINT/HOLD key to choose a different calibration weight value (50kg,
100kg, 150kg, 200kg, 250kg, 300kg or 100lb, 200lb, 300lb, 400lb, 500lb, 600lb); Then put on
the weight that you selected and press the TARE key to confirm the chosen standard weight
that was selected earlier. The displayed data will flash on the display and if the scale accepts
the calibration data it will calculate and store the information into the EEPROM. If an error has
occurred, the scale will display and return back to step 4 for re-calibration. If the
loaded weight is not within the range of 95% to 105% of the weight value you selected, the
scale will not calibrate but display and return back to step 4 for re-calibration.)
6. Check the calibration by putting the weight that you calibrated at back on the scale, if it is off
repeat the calibration process again.

7.
1. When the scale is in normal weighing mode, press and hold down the ON/OFF key and the
UNIT key for 3 seconds until ‘Setup’ is shown on the display.
2. When in the SETUP mode, press the PRINT/HOLD key to change the flashing digits, and TARE
key to confirm the flashing digits and move to the next parameter setting. Press the ON/OFF
key to exit the set up mode.
3. Parameters setting summary:
• RS-232 output of weighing data
• ASCII code
• 9600 Baud rate (fixed)
• 1 start bit, 8 data bits,1 stop bit
• No Parity
• Connector: 9 pin d-subminiature socket
• Pin 2: Output
• Pin 3: Input
• Pin 5: Signal Ground
This indicator has 4 parameter settings that can be selected.
PARAMETER X/XY FACTORY SET SETTING
AUTO-OFF TIME
00-15 05
00 = No AUTO-OFF
01-15 Minutes before AUTO-OFF
PRINT/HOLD
FUNCTIONS
0, 1, 2 1
0 = Only PRINT Funcon
1 = Only HOLD Funcon
2 = Both HOLD & PRINT Funcon
(<3 Seconds = PRINT, >3 Seconds = HOLD)
HOLD TIME
0-4 0
0 = No Time Limit
1 = 10 Seconds
2 = 30 Seconds
3 = 60 Seconds
4 = 120 Seconds
RS232
FUNCTIONS
0-3 0
0 = No RS232 Funcon
1 = Connuously outputs display data
2 = Output display data when PRINT pressed
3 = Bi-direconal communicaon
(the scale receives & executes commands
from the HOST device)
USER PARAMETERS
RS232 COMMUNICATIONS
INTERFACE
PARAMETERS
CONNECTION
DETAILS

8.
1. RS-232 connection between the Scale and the Host:
DB9 Female
RXD Pin 3
TXD Pin 2
GND Pin 5
NOTE: Pins 1,4,6,7,8 & 9 are not connected.
NOTE: The RS232 function will not operate if PH has been set to 0 or 2.
(See User Parameters on Page 7.)
2. RS232 Function Parameter Settings (See User Parameters on Page 7)
0 No RS232 function. It will not transmit or receive any data although the scale is equipped with
RS232. The RS232 function can be only activated when scale is in normal weighing mode.
1 Continuous output of the current displayed reading and unit, and it does not receive any data.
The output format is one of the below:
<LF>< reading, minus, decimal point, weight unit>GR<CR><EXT>
<LF>< reading, minus, decimal point, weight unit>NT<CR><EXT>
2 Manually outputs display data when PRINT is pressed. The output format is one of the below:
<LF>< reading, minus, decimal point, weight unit>GR<CR><EXT>
<LF>< reading, minus, decimal point, weight unit>NT<CR><EXT>
3 The baud rate and data format are fixed with responses to serial commands being within 300
milliseconds. One second should be adequate for use as a time-out value by remote device.
3. Weight Field
The length of the weight field will be 7 digit weight data, one for minus sign, one for decimal
point, two for measure unit (e.g. “lb”, “kg”). Units of measure abbreviations are always lower case.
If the weight is overcapacity, the scale will return nine ‘^’ characters (the field of minus sign,
decimal point, weight data is filled by ‘^’).
If the weight is under capacity, it will return nine ‘-’ characters (the field of minus sign, decimal
point, and weight data is filled by ‘_’).
If the zero point has an error, it will return nine ‘-’ characters.
The character will be ‘-’ for negative weight or a space character for positive weight. Minus sign
follows after the first digit.
Useless leading zeroes before digits are suppressed.
4. Key to Symbols Used
<LF> Line Feed character (hex 0AH)
<CR> Carriage Return character (hex 0DH)
<ETX> End of Text character (hex 03)
<SP> Space (hex 20H)
H1H2H3 Three status bytes. Refer to Status Byte Table on page 9.
<p> Polarity character including minus sign for negative weight and a space character
for positive weight
W1-W7 Weight data
<dp> Decimal point
U1U2 Measure units, kg, lb

9.
5. Commands and Response
Command: W<CR> (57h 0dh)
Response:
<LF>^^^^^^u1u2<CR><LF>H1H2H3<CR><ETX>---over capacity
<LF>______u1u2<CR><LF> H1H2H3 <CR><ETX>---under capacity
<LF>---------u1u2<CR><LF> H1H2H3<CR><ETX>---zero-point error
< L F > < p > w 1 w 2 w 3 w 4 w 5 w 6 < d p > w 7 u 1 u 2 < C R > < L F > H 1 H 2 H 3 < C R >
<ETX> ---Scale is stable, and the current weight unit is kg or lb. With or without decimal point
and the position is as per the P9 setting and current unit.
Command: S<CR> (53h 0dh)
Response: <LF> H1H2H3<CR><ETX>
Command: Z<CR> (5ah 0dh)
Response: Zero function is activated and it returns to current scale status, just like pressing
ZERO/ON/OFF key:
<LF> H1H2H3<CR><ETX>
If ZERO function cannot be activated, it will return to current scale status.
Command: T<CR> (54h 0dh)
Response: TARE function is activated, and then returns scale status, just like pressing TARE key:
<LF> H1H2H3<CR><ETX>
If TARE function cannot be activated, it will return to current scale status.
Command: U<CR> (55h 0dh)
Response: Changes units of measure and return scale status with new units, just like pressing
UNIT key. The new measure unit should be allowed to use as per P11 setting.
<LF>u1u2<CR><LF> H1H2H3<CR><ETX>
Command: X<CR> (58h 0dh)
Response: power off the scale, just like pressing the ON/OFF key to turn off the scale.
Command: all others
Response: Unrecognized command <LF>?<CR><ETX>
BIT BYTE 1 (H1) BYTE 2 (H2) BYTE 3 (H3)
0
0 = Stable 0 = Not Under Capacity 01 = Normal Work Mode
1 = Not Stable 1 = Under Capacity 10 = Hold Work Mode
10 = Not at Zero Point 0 = Not Over Capacity 00 = Not Dene
1 = At Zero Point 1 = Over Capacity 11 = Not Dene
2Always 0 Always 0 0 = Gross Weight
1 = Net Weight
30 = eeprom OK Always 0 Always 0
1 = eeprom Error
4Always 1 Always 1 Always 1
5Always 1 Always 1 Always 1
6Always 0 Always 1 Always 0
7Parity Parity Parity

10.
ERROR MESSAGES
ERROR CAUSE
Zero Point is over the seng range
Zero Point is below the seng range
ADC is over maximum range
ADC is below minimum range
EEPROM Error
Calibraon Error
The capacity will be displayed
Baery voltage or input power is below 5.6V
The capacity has been exceeded by the person standing on the scale
