Avalue Technology EMS-SKLU User manual

Part No. E2017AAG0A1R
EMS-SKLU/
EMS-SKLU-Marine
6th Gen Intel® Core™ Processor i7/i5/i3/Celeron Fanless
Rugged Embedded System
Quick Reference Guide
1st Ed –01 March 2017
Copyright Notice
Copyright 2017 Avalue Technology Inc., ALL RIGHTS RESERVED.

EMS-SKLU/EMS-SKLU-Marine
2 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
3
Content
1. Getting Started..............................................................................................................7
1.1 Safety Precautions ................................................................................................7
1.2 Packing List...........................................................................................................7
1.3 System Specifications ...........................................................................................8
1.4 System Overview.................................................................................................11
1.4.1 Front View.................................................................................................................................. 11
1.4.2 Rear View................................................................................................................................... 12
1.5 System Dimensions.............................................................................................13
1.5.1 EMS-SKLU Front & Top view .................................................................................................... 13
1.5.2 EMS-SKLU-Marine Front & Top view........................................................................................ 14
2. Hardware Configuration..............................................................................................15
2.1 EMS-SKLU connector mapping...........................................................................16
2.1.1 Serial port connector 1 (COM1)................................................................................................. 16
2.1.2 Serial port connector 3/4/5/6 (COM3/4/5/6)............................................................................... 16
2.1.3 Multi-Function Port combined COM2, 2 PS/2, Audio, GPIO and SMBus (Multi-function port) . 17
2.1.3.1 GPIO+SMBUS....................................................................................................................... 18
2.1.3.2 COM2 .................................................................................................................................... 18
2.2 EBM-SKLUS, AUX-M01, AUX-M02, AUX-M03, AUX-M04, AUX-M07, EBM-BYTS
DB-A and EBM-CDVS DB-A Overviews.........................................................................19
2.2.1 EBM-SKLUS .............................................................................................................................. 19
2.2.2 AUX-M01.................................................................................................................................... 20
2.2.3 AUX-M02.................................................................................................................................... 20
2.2.4 AUX-M03.................................................................................................................................... 21
2.2.5 AUX-M04.................................................................................................................................... 22
2.2.6 AUX-M07.................................................................................................................................... 22
2.2.7 EBM-BYTS DB-A....................................................................................................................... 23
2.2.8 EBM-CDVS DB-A ...................................................................................................................... 23
2.2.9 EBM-CDVS DB-B ...................................................................................................................... 24
2.3 EBM-SKLUS Jumper & Connector list.................................................................25
2.4 EBM-SKLUS Jumpers & Connectors settings.....................................................27
2.4.1 Multi-function select (SW1)........................................................................................................ 27
2.4.2 COM 1/2 pin 9 signal select (JRI1/2)......................................................................................... 28
2.4.3 Serial port 1/2 RS-232/422/485 mode select (JCOM_SEL1/2) ................................................. 28
2.4.4 Clear CMOS (JCMOS1)............................................................................................................. 29
2.4.5 LPC port connector (JLPC1)...................................................................................................... 29

EMS-SKLU/EMS-SKLU-Marine
4 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
2.4.6 SPI connector (JSPI1) ............................................................................................................... 30
2.4.7 Front Panel Connector (CN5).................................................................................................... 30
2.4.8 DC Output connector (DCOUT1)............................................................................................... 31
2.4.9 DC Input connector (JVIN1)....................................................................................................... 31
2.4.10 EC Debug connector (JEC_ROM1)....................................................................................... 32
2.4.11 On-board header for USB2.0 (USB2).................................................................................... 32
2.4.12 Power ON/OFF connector (PWRBTN1)................................................................................ 33
2.5 AUX-M01, AUX-M02, AUX-M03, AUX-M04, AUX-M07, EBM-BYTS DB-A ,
EBM-CDVS DB-A and EBM-CDVS DB-B Jumper & Connector list ...............................34
2.6 AUX-M01 Jumpers & Connectors settings ..........................................................37
2.6.1 COM 3/4/5/6 pin 9 signal select (JRI3/4/5/6)............................................................................. 37
2.6.2 USB connector (USB3).............................................................................................................. 37
2.6.3 USB connector (JUSB3)............................................................................................................ 38
2.6.4 SMBUS of TCA9555 address setting (PJP1) ............................................................................ 38
2.7 AUX-M02 Connectors settings ............................................................................39
2.7.1 LAN ACT/LNK/SPD LED (JLANLED)........................................................................................ 39
2.7.2 Normal/Bypass mode LED (JLANMODE) ................................................................................. 39
2.8 AUX-M03 Connectors settings ............................................................................40
2.8.1 System reset (WCN1)................................................................................................................ 40
2.8.2 LPT Port (WJPRT1)................................................................................................................... 40
2.9 AUX-M04 Jumpers & Connectors settings ..........................................................41
2.9.1 Operating Modes select (ZJP1)................................................................................................. 41
2.9.2 Power connector (ZPWR1)........................................................................................................ 41
2.9.3 LAN ACT/LNK/SPD LED (Z_JLANLED).................................................................................... 42
2.10 AUX-M07 Connector settings..............................................................................43
2.10.1 SMBUS of TCA9555 address setting (SJP2)........................................................................ 43
2.11 EBM-BYTS DB-A Jumpers & Connectors settings..............................................44
2.11.1 COM 3/4 pin 9 signal select (OJRI3/4).................................................................................. 44
2.11.2 Serial port 1/ 2 –RS485 mode select (OJP485) ................................................................... 44
2.11.3 SMBUS of TCA9555 address setting (OJP1)........................................................................ 45
2.12 EBM-CDVS DB-A Connector settings.................................................................46
2.12.1 Front Panel Connector 1 (CN1)............................................................................................. 46
2.13 EBM-CDVS DB-B Connector settings.................................................................47
2.13.1 DC Input connector (DC-IN1)................................................................................................ 47
2.13.2 DC Output connector (DC-OUT1) ......................................................................................... 47
2.14 Installing Hard Disk & Memory, PCI devices (EMS-SKLU)..................................48
2.15 Installing Mounting Brackets (EMS-SKLU)..........................................................49
3.BIOS Setup.....................................................................................................................50
3.1 Introduction..........................................................................................................51
3.2 Starting Setup......................................................................................................51

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
5
3.3 Using Setup.........................................................................................................52
3.4 Getting Help.........................................................................................................53
3.5 In Case of Problems............................................................................................53
3.6 BIOS setup..........................................................................................................54
3.6.1 Main Menu ................................................................................................................................. 54
3.6.1.1 System Language............................................................................................................................55
3.6.1.2 System Date....................................................................................................................................55
3.6.1.3 System Time....................................................................................................................................55
3.6.2 Advanced Menu......................................................................................................................... 55
3.6.2.1 Trusted Computing ..........................................................................................................................56
3.6.2.2 ACPI Settings ..................................................................................................................................57
3.6.2.3 AMT Configuration...........................................................................................................................58
3.6.2.4 PCH-FW Configuration....................................................................................................................59
3.6.2.4.1 Firmware Update Configuration.......................................................................................................59
3.6.2.5 IT8528 Super IO Configuration........................................................................................................60
3.6.2.5.1 Serial Port 1 Configuration...............................................................................................................60
3.6.2.5.2 Serial Port 2 Configuration...............................................................................................................61
3.6.2.6 EC 8528 H/W Monitor......................................................................................................................61
3.6.2.7 S5 RTC Wake Settings....................................................................................................................62
3.6.2.8 Serial Port Console Redirection.......................................................................................................62
3.6.2.8.1 Legacy Console Redirection Settings..............................................................................................63
3.6.2.9 CPU Configuration...........................................................................................................................64
3.6.2.10 Intel TXT Information .......................................................................................................................64
3.6.2.11 SATA Configuration.........................................................................................................................65
3.6.2.12 Network Stack Configuration ...........................................................................................................66
3.6.2.13 CSM Configuration...........................................................................................................................66
3.6.2.14 USB Configuration...........................................................................................................................67
3.6.3 Chipset..................................................................................................................................... 68
3.6.3.1 System Agent (SA) Configuration....................................................................................................68
3.6.3.1.1 Graphics Configuration....................................................................................................................69
3.6.3.1.2 Memory Configuration......................................................................................................................69
3.6.3.2 PCH-IO Configuration......................................................................................................................70
3.6.3.2.1 PCI Express Configuration...............................................................................................................70
3.6.3.2.1.1 PCI Express Root Port2 (mPCIe)............................................................................................71
3.6.3.2.1.2 PCI Express Root Port3 (I210/211).........................................................................................72
3.6.3.2.1.3 PCI Express Root Port5 (IET)..................................................................................................73
3.6.3.2.1.4 PCI Express Root Port6 (IET)..................................................................................................74
3.6.3.2.1.5 PCI Express Root Port7 (IET)..................................................................................................75
3.6.3.2.1.6 PCI Express Root Port8 (IET)..................................................................................................76
3.6.3.2.1.7 PCI Express Root Port12 (M.2)...............................................................................................77

EMS-SKLU/EMS-SKLU-Marine
6 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
3.6.3.2.2 USB Configuration...........................................................................................................................78
3.6.3.2.3 HD Audio Configuration...................................................................................................................79
3.6.4 Security .................................................................................................................................... 79
3.6.4.1 Secure Boot menu...........................................................................................................................80
3.6.4.1.1 Key Management.............................................................................................................................81
3.6.5 Boot.......................................................................................................................................... 82
3.6.6 Save and exit ........................................................................................................................... 83
3.6.6.1 Save Changes and Reset................................................................................................................83
3.6.6.2 Discard Changes and Reset............................................................................................................84
3.6.6.3 Restore Defaults..............................................................................................................................84
3.6.6.4 Launch EFI Shell from filesystem device.........................................................................................84
4. Drivers Installation .........................................................................................................85
4.1 Install Chipset Driver ...........................................................................................86
4.2 Install ME Driver..................................................................................................87
4.3 Install VGA Driver................................................................................................88
4.4 Install Audio Driver (For Realtek ALC892)...........................................................89
4.5 Install Ethernet Driver..........................................................................................90

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
7
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x EMS-SKLU/EMS-SKLU-Marine 6th Gen Intel® Core™ Processor
i7/i5/i3/Celeron Fanless Rugged Embedded System
1 x DVD-ROM contains the followings:
—QRG in PDF file
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
Other major components include the followings:
—44 Pin Multi I/O Cable
—Wall Mount Kit
—Terminal Block to Lockable DC Jack cable
—DP to VGA Converter

EMS-SKLU/EMS-SKLU-Marine
8 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
1.3 System Specifications
System
Board
EBM-SKLUS, AUX-M01, AUX-M02, AUX-M03, AUX-M04, AUX-M07,
EBM-BYTS DB-A and EBM-CDVS DB-A (EMS-SKLU)
EBM-SKLUS, EBM-CDVS DB-B, AUX-M07 (EMS-SKLU-Marine)
CPU
Intel® Core™ i7-6600U Processor (4M Cache, up to 3.40 GHz)
Intel® Core™ i5-6300U Processor (3M Cache, up to 3.00 GHz)
Intel® Core™ i3-6100U Processor (3M Cache, 2.30 GHz)
Intel® Celeron® Processor 3955U (2M Cache, 2.00 GHz)
BIOS
AMI uEFO BIOS 128 Mbit SPI Flash ROM
I/O Chip
EC ITE IT8528E
System Memory
One 260-pin SODIMM Socket Up to 16GB DDR4 2133MHz SDRAM
Watchdog Timer
H/W Reset, 1sec. ~ 65535sec.
H/W Status
Monitor
CPU & system temperature monitoring and Voltages monitoring
Battery
Horizontal battery socket
Supports no RTC battery mode
Expansion
IET interface (1 x DP, 4 x PCIex1, 3 x USB, 1 x LPC, 1 x Line-Out(R/L), 1
x SMBus)
1 x mini-PCIe Socket, supports PCIe, USB 2.0 and SIM Card slot
1 x M.2, supports B-Key 2242/3042 and SIM Card slot (SSD & 3G/4G)
Storage
Combination
1 x 2.5” Drive Bay
1 x M.2 B-Key 2242/3042
External I/O
Front Side External
I/O Connector
1 x Dual deck USB connector for two USB 3.0 ports (USB 2.0 signal
included)
2 x USB 3.0
1 x Swappable 2.5” drive bay (SATA III, 2A, 12mm)
2 x SIM Card Slot (Mini PCIe, M.2)
1 x Push Button for Power on/off (Sunk type)
1 x Push Button for Reset (Hidden Type)
1 x 2-Pin Terminal Block for wire-control power on/off
1 x Power LED (Green)
1 x Storage LED (Green)
Rear Side External
I/O Connector
1 x 3-Pin Terminal Block for DC-Input
2 x USB 3.0
2 x USB 2.0 (EMS-SKLU-Marine)

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
9
1 x DP+ (DP to VGA converter is the standard accessory, and optional DP
to DVI, DP to HDMI converters)
1 x DB-9 male connector for COM1, RS 232/ 422/ 485(4-wire) selectable
by Jumper; RS 485 supports Auto Flow
2 x RJ-45 for GbE
1 x Dual deck USB connector for two USB 3.0 ports (USB 2.0 signal
included)
1 x DB-44 male connector for multi-I/O output.
-COM2 with COM1, RS 232/ 422/ 485(4-wire) selectable by Jumper;
RS 485 supports Auto Flow
-2 x PS/2 keyboard and mouse
-SMBus
-12-bit DIO; 6-bits for input and 6-bits for output
-Line-In, Line-Out and Mic-In with plug-in detection
6 x COM Port (4 support Isolation) (EMS-SKLU-Marine)
2 x Antenna mounting w/ cover
Internal I/O
Connector
1 x 7+15-pin SATAIII connector (2A)
1 x 4-pin wafer connector for +5V, +12V and GND output.
1 x 6-Pin wafer connector for DC-OUT
1 x 3-pin header for CMOS (protect*Clear)
2 x 2 x 3-pin header for COM1/ 2 pin 9 signal selection (+5, +12, Ring)
1 x 2 x 7-pin header for LPC
1 x 2 x 3-Pin header for SPI
1 x 3-pin DIP Switch for Power mode (AT/ATX)
1 x Buzzer
1 x 1 x 5-Pin header for 1 x USB 2.0 reservation
1 x 3-pin for EC
Display
Chipset
Intel® Skylake Processor integrated Graphics
Resolution
1 x DP+
One Panel Display max. 4096 x 2304@60Hz
DP to VGA will be the standard accessory
DP to DVI-I and DP to HDMI will be the optional accessory
Ethernet
Chipset
1 x Intel I211AT GbE controller
1 x Intel I219LM Gigabit Ethernet PHY
Ethernet Interface
10/100/1000 Base-Tx GbE compatible
Audio
Chipset
Realtek ALC892 HD codec
Audio Interface
Mic-In, Line-In and Line-Out

EMS-SKLU/EMS-SKLU-Marine
10 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
Mechanical & Environmental
Power Requirement
Typical 12/24Vdc (9 ~ 32Vdc) (EMS-SKLU)
Typical 12/24Vdc (9 ~ 36Vdc) (EMS-SKLU-Marine)
TVS component for surge protection
Reverse current/voltage protection
ACPI
Single power ATX Supports S0, S3, S4, S5
Compliant with ACPI 5.0
Power Connector
Type
3-Pin Terminal Block (V+, V-, Ground)
Power Mode
AT/ATX (ATX is the default setting)
Dimension
9.45" x 5.96" x 1.77" (240mm x 151.5mm x 45mm) (EMS-SKLU)
9.45" x 5.96" x 2.95" (240mm x 151.5mm x 75mm) (EMS-SKLU-Marine)
Weight
4.4 lbs (2 Kg)
Color
Black
Mounting Kit
Wall mount kit (Standard)
Din Rail mount kit (Optional)
Reliability
EMI Test
CE & FCC Class A w/ERP
Safety
Avalue Standard Test Criteria
Dust and Rain Test
IP50
Vibration Test
With SSD : 5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 1hr/axis
Mechanical Shock
Test
With SSD : 50Grms, IEC 60068-2-27, Half Sine, 11ms
Drop Test
Avalue Standard Test Criteria
Operating
Temperature
-20°C ~ 60°C (w/SSD) ambient w/ air flow
0°C ~ 40°C (w/HDD) ambient w/ air flow
Operating Humidity
5% ~ 90% relative humidity, non-condensing
Storage
Temperature
-40°C ~ 85°C
Note: Specifications are subject to change without notice.

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
11
1.4 System Overview
1.4.1 Front View EMS-SKLU
EMS-SKLU-Marine

EMS-SKLU/EMS-SKLU-Marine
12 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
1.4.2 Rear View EMS-SKLU
EMS-SKLU-Marine
Connectors
Label
Function
Note
PWR
System power indicator
HDD
HDD indicator
RESET
Reset button
USB3.0
4 x USB3.0 connector
USB
2 x USB2.0 connector (EMS-SKLU-Marine)
Ext. ON/OFF
Power on button
DP
DP connector
LAN1/2
RJ-45 Ethernet 1/2
COM1
Serial port connector 1
Multi-function
port
Multi-Function Port combined COM2,
2 PS/2, Audio, GPIO and SMBus
COM3/4/5/6
Serial port connector 3/4/5/6 (EMS-SKLU-Marine)
support Isolation
DC-IN
DC power-in connector

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
13
1.5 System Dimensions
1.5.1 EMS-SKLU Front & Top view
(Unit: mm)

EMS-SKLU/EMS-SKLU-Marine
14 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
1.5.2 EMS-SKLU-Marine Front & Top view
(Unit: mm)

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
15
2.Hardware
Configuration
Jumper and Connector Setting, Driver and BIOS Installing
For advanced information, please refer to:
1- EBM-SKLUS, AUX-M01, AUX-M02, AUX-M03, AUX-M04, AUX-M07,
EBM-BYTS DB-A, EBM-CDVS DB-A and EBM-CDVS DB-B included in
this manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

EMS-SKLU/EMS-SKLU-Marine
16 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
2.1 EMS-SKLU connector mapping
2.1.1 Serial port connector 1 (COM1)
Pin
RS-232
RS-485
RS-422
1
DCD
TXD-/RXD-
TXD-
2
RXD
TXD+/RXD+
TXD+
3
TXD
RXD+
4
DTR
RXD-
5
GND
GND
GND
6
DSR
7
RTS
8
CTS
9
RI
2.1.2 Serial port connector 3/4/5/6 (COM3/4/5/6)
Pin
RS-232
RS-485
RS-422
1
DCD
TXD-/RXD-
TXD-
2
RXD
TXD+/RXD+
TXD+
3
TXD
RXD+
4
DTR
RXD-
5
GND
GND
GND
6
DSR
7
RTS
8
CTS
9
RI

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
17
2.1.3 Multi-Function Port combined COM2, 2 PS/2, Audio, GPIO and SMBus
(Multi-function port)
PIN
Signal
PIN
Signal
PIN
Signal
1
LINE1_JD
16
FRONT_JD
31
LINE1_RIN
2
MIC1_JD
17
LINEOUT_R
32
GND
3
MIC_RIN
18
GND
33
LINE1_LIN
4
GND
19
LINEOUT_L
34
+5V
5
MIC_LIN
20
GND
35
DO3
6
DO5
21
DO4
36
DO0
7
DO2
22
DO1
37
DI3
8
DI5
23
DI4
38
DI0
9
DI2
24
DI1
39
SMB_CLK
10
MSCK
25
SMB_DATA
40
NRIB#
11
GND
26
GND
41
NRTSB#
12
MSDA
27
NCTSB#
42
COM2_GND
13
KBDA
28
NDSRB#
43
NTXDB_485RXP
14
VCC_PS2
29
NDTRB#_485RXN
44
NDCDB#_485TXN
15
KBCK
30
NRXDB_485TXP

EMS-SKLU/EMS-SKLU-Marine
18 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
2.1.3.1 GPIO+SMBUS
Signal
PIN
PIN
Signal
25
13
24
12
23
11
22
10
SMBUS_DATA
21
9
SMBUS_CLK
20
8
GND
GPI-D5
19
7
5V
GPI-D4
18
6
GPO-D5
GPI-D3
17
5
GPO-D4
GPI-D2
16
4
GPO-D3
GPI-D1
15
3
GPO-D2
GPI-D0
14
2
GPO-D1
1
GPO-D0
2.1.3.2 COM2
Pin
RS-232
RS-485
RS-422
1
DCD
TXD-/RXD-
TXD-
2
RXD
TXD+/RXD+
TXD+
3
TXD
RXD+
4
DTR
RXD-
5
GND
GND
GND
6
DSR
7
RTS
8
CTS
9
RI

Quick Reference Guide
EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
19
2.2 EBM-SKLUS, AUX-M01, AUX-M02, AUX-M03, AUX-M04, AUX-M07,
EBM-BYTS DB-A and EBM-CDVS DB-A Overviews
2.2.1 EBM-SKLUS

EMS-SKLU/EMS-SKLU-Marine
20 EMS-SKLU/EMS-SKLU-Marine Quick Reference Guide
2.2.2 AUX-M01
2.2.3 AUX-M02
