Avalue Technology EPC-SKLU-39-C2-1R User manual

Part No. E2017CAG0A5R
EPC-SKLU
Intel® Core® SoC Processor Fanless Box PC
Quick Reference Guide
6th Ed –17 January 2023
Copyright Notice
Copyright 2023 Avalue Technology Inc., ALL RIGHTS RESERVED.

EPC-SKLU
2EPC-SKLU Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
EPC-SKLU Quick Reference Guide
3
Content
1. Getting Started............................................................................................................4
1.1 Safety Precautions ................................................................................................4
1.2 Packing List...........................................................................................................4
1.3 System Specifications ...........................................................................................5
1.4 System Overview...................................................................................................7
1.4.1 Front View................................................................................................................................ 7
1.4.2 Rear View................................................................................................................................ 7
1.5 System Dimensions...............................................................................................9
1.5.1 Front & Top View..................................................................................................................... 9
2. Hardware Configuration...........................................................................................10
2.1 EPC-SKLU connector mapping...........................................................................11
2.1.1 Serial Port 1 connector (COM1) ............................................................................................ 11
2.1.2 Serial Port 2 connector (COM2) ............................................................................................ 11
2.2 Installing Hard Disk & Memory (EPC-SKLU).......................................................12
2.3 Installing M.2 card & MPCIE devices (EPC-SKLU) .............................................15
2.4 Installing Mounting Brackets (EPC-SKLU) ..........................................................16
2.5 Installing Din Rail Mounting (EPC-SKLU)............................................................17
2.6 Installing Stand (EPC-SKLU)...............................................................................18

EPC-SKLU
4EPC-SKLU Quick Reference Guide
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not make
connections while the power is on. Sensitive electronic
components can be damaged by sudden power surges.
Only experienced electronics personnel should open the PC
chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
Risk of Explosion if Battery is replaced by an Incorrect Type.
Dispose of Used Batteries According to the Instructions.
Français:
Attention!
Débranchez le câble d'alimentation de votre châssis chaque
fois que vous travaillez avec le matériel. Ne faites pas de
connexion lorsque le système est allumé. Les composants
électroniques sensibles peuvent être endommagés par les
surtensions soudaines. Seule les personnels expérimentés
de l'électronique peuvent ouvrir le châssis du PC.
Précaution!
Il faut toujours mettre à la masse pour éliminer l’électricité
statique avant de toucher la carte CPU. Les appareils
électroniques modernes sont très sensibles aux électricité
statique. Pour des raisons de sécurité, utilisez un bracelet
électrostatique. Placez tous les composants électroniques
sur une surface antistatique ou dans un sac antistatique
quand ils ne sont pas dans le châssis.
Risque d'explosion si la batterie est remplacée par un type
incorrect. Jetez les piles usagées selon les instructions
1.2 Packing List
1 x EPC-SKLU Intel® Core® SoC Processor Fanless Box PC
Other major components include the followings:
—Screw kit/Adapter/EPC-SKLU Stand

Quick Reference Guide
EPC-SKLU Quick Reference Guide
5
1.3 System Specifications
System
CPU
Intel® Core™ i7-6600U Processor (4M Cache, up to 3.40 GHz)
Intel® Core™ i5-6300U Processor (3M Cache, up to 3.00 GHz)
Intel® Core™ i3-6100U Processor (3M Cache, 2.30 GHz)
Intel® Celeron® Processor 3955U (2M Cache, 2.00 GHz)
BIOS
AMI uEFI BIOS,128 Mbit SPI Flash ROM
iAMT supported
I/O Chipset
EC ITE IT8528E
System Memory
1 x 260-Pin DDR4 2133MTs SO-DIMM
(support non-ECC only)
Watchdog Timer
H/W Reset, 1sec. ~ 65535sec.
H/W Status
Monitor
Monitoring CPU Temperature, Voltage with Auto Throttling Control
Expansion
1 x Full Size Mini PCIe (mSATA)
1 x M.2 (2242,B-KEY)
Storage
Combination
1 x 2.5" Drive Bay (7mm)
1 x M.2 (2242,B-KEY)
1 x mSATA
Front I/O
Power Switch
1 x Power Switch w/ LED indicator
Rear I/O
Serial Port
1 x RS-232
1 x RS-232/422/485 (Cable & BIOS)
USB Port
4 x USB 3.0, 2 x USB 2.0
Others
2 x Knockouts for Antenna Mounting
Display
Chipset
Processor Graphics
Intel® HD Graphics 520 for i7-6600U, i-5-6300U, i3-6100U
Intel® HD Graphics 510 for Celeron 3955
Resolution
2 x HDMI: Max. Resolution 4096x2160 @ 24Hz
Multiple Display
Dual display
Ethernet
Chipset
1 x Intel I210AT
1 x Intel I219LM
Ethernet Interface
10/100/1000 Base-Tx Gigabit Ethernet Compatible

EPC-SKLU
6EPC-SKLU Quick Reference Guide
Lan Port
2 x RJ45 w/LED
Audio
Chipset
Realtek ALC888S
Mechanical & Environmental
Power Connector
Lockable DC Jack
Power Requirement
+12V ~ +26V
Power Type
AT/ATX (ATX is default)
ACPI
Single power ATX Support S0,S3, S4, S5
ACPI 5.0 Compliant
Dimension
177 x 123 x 50 mm
Weight
2.65lbs(1.2KG)
Color
Black & Blue
Mounting Kit
Stand (Default)
VESA Mount kit (Factory Option)
Din Rail kit (Factory Option)
Reliability
Vibration Test
With SSD: 5Grms, IEC 60068-2-64, Random, 10 ~ 500Hz, 30min/axis
With HDD : 0.5Grms, IEC 60068-2-64, Random, 10 ~ 500Hz, 1hr/axis
Mechanical Shock
Test
With SSD : 50G, IEC 60068-2-27, Half Sine, 11ms
With HDD : 10G, IEC 60068-2-27, Half Sine, 11ms
Drop Test
Avalue Standard Test Criteria
Operating
Temperature
With extended temperature peripherals: -10°C ~ 60°C (14°F ~ 140°F) with
0.5m/air flow
With extended temperature peripherals: -10°C ~ 50°C (14°F ~ 122°F)
0.2m/air flow
With 2.5” hard drive: 0°C ~ 40°C (32°F ~ 113°F) with 0.5m/s air flow
Operating Humidity
0% ~ 90% relative humidity, non-condensing
Storage
Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Certification
CE, FCC Class B
OS Supported
Win10/8.1/7/Linux
Note: Specifications are subject to change without notice.

Quick Reference Guide
EPC-SKLU Quick Reference Guide
7
1.4 System Overview
1.4.1 Front View
1.4.2 Rear View
Connectors
Label
Function
Note
POWER
Power on button
COM1/2
Serial port 1/2 connector
D-sub 9-pin, male
HDD
HDD indicator
PWR
System power indicator
LAN1/2
RJ-45 Ethernet 1/2
USB2.0
USB 2.0 connector x 2
USB3.0
USB 3.0 connector x 4
HDMI
HDMI connector x 2
DC-IN
DC Power-in connector

EPC-SKLU
8EPC-SKLU Quick Reference Guide
Note:
UL Certified Cables are required & purchased from the distributors.
Français:
Il est nécssaire que vous achetez des câbles certifiés par UL auprès des distributers.

Quick Reference Guide
EPC-SKLU Quick Reference Guide
9
1.5 System Dimensions
1.5.1 Front & Top View
(Unit: mm)

EPC-SKLU
10 EPC-SKLU Quick Reference Guide
2.Hardware
Configuration
For advanced information, please refer to:
1- ECM-SKLU User’s Manual
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

Quick Reference Guide
EPC-SKLU Quick Reference Guide
11
2.1 EPC-SKLU connector mapping
2.1.1 Serial Port 1 connector (COM1)
Signal
PIN
PIN
Signal
DCD#
1
6
DSR#
RXD
2
7
RTS#
TXD
3
8
CTS#
DTR#
4
9
RI#
GND
5
2.1.2 Serial Port 2 connector (COM2)
RS-485
Signal
PIN
PIN
Signal
485_Tx-
1
6
NC
485_Tx+
2
7
NC
NC
3
8
NC
NC
4
9
NC
GND
5
RS-232
Signal
PIN
PIN
Signal
DCD#
1
6
DSR#
RXD
2
7
RTS#
TXD
3
8
CTS#
DTR#
4
9
RI#
GND
5
RS-422
Signal
PIN
PIN
Signal
422_Tx-
1
6
NC
422_Tx+
2
7
NC
422_Rx+
3
8
NC
422_Rx-
4
9
NC
GND
5

EPC-SKLU
12 EPC-SKLU Quick Reference Guide
2.2 Installing Hard Disk & Memory (EPC-SKLU)
Step1. For HDD installation, remove four screws from bottom cover.
Step2. Evert the bottom cover.
Step3. Install HDD/SSD.

Quick Reference Guide
EPC-SKLU Quick Reference Guide
13
Step4. Fix HDD/SSD with four M3*4L screws.
Step5. Put the bottom back and fix with four M3*5L screws.

EPC-SKLU
14 EPC-SKLU Quick Reference Guide
Step2. For Memory installation, properly install the memory module and press until properly
seated.

Quick Reference Guide
EPC-SKLU Quick Reference Guide
15
2.3 Installing M.2 card & MPCIE devices (EPC-SKLU)
Step1. Fix M.2 card using the screw in the Accessory Kit.
Step2. Insert MPCIE cards into designated locations and fasten with the screw to complete
MPCIE installation.

EPC-SKLU
16 EPC-SKLU Quick Reference Guide
2.4 Installing Mounting Brackets (EPC-SKLU)
Step1. Remove 4 screws from the side.
Step2. Insert and fasten screw on each side of the system to secure Mounting brackets.

Quick Reference Guide
EPC-SKLU Quick Reference Guide
17
2.5 Installing Din Rail Mounting (EPC-SKLU)
Step1. Position brackets on both sides, matching the holes on the system.
Step2. Insert and fasten screws on each side of the system to secure Mounting bracket.

EPC-SKLU
18 EPC-SKLU Quick Reference Guide
2.6 Installing Stand (EPC-SKLU)
Step1. Remove 2 screws from the side.
Step2. Fasten 2 screws on the side of the system to secure Stand.
