Avalue Technology EPS-AT270 User manual

Part No. E20173822A0R
EPS-AT270
Fanless Intel® 945GSE Micro PC
Quick Reference Guide
1st Ed –17 September 2009

EPS-AT270
2 EPS-AT270 Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
Avalue Customer Services
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation; please consult the user’s manual first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw
Copyright Notice
Copyright 2009 Avalue Technology Inc., ALL RIGHTS RESERVED.

Quick Reference Guide
EPS-AT270 Quick Reference Guide 3
1. Getting Started
1.1 Safety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 Packing List
1 x EPS-AT270 Fanless Intel® 945GSE Micro PC (with EPI-945GSE
inside)
1 x Quick Reference Guide
1 x DVD-ROM contains the followings:
—User’s Manual (this manual in PDF file)
—Ethernet driver and utilities
—VGA drivers and utilities
—Audio drivers and utilities
Other major components include the followings:
—1 x AC to DC adapter (12V/ 5A,60W)

EPS-AT270
4 EPS-AT270 Quick Reference Guide
1.3 System Specifications
Model EPS-AT270
CPU Onboard Intel® N270 Atom processor 1.6GHz, (2.5W)
BIOS Award 8Mbit Flash BIOS
System Chipset Intel® 945GSE/ICH7-M
I/O Chipset ITE 8712F/KX + Fintek F81216DG
System Memory One 200-pin SODIMM socket, up to 2 GB DDR2 400/533MHz SDRAM
SSD One Compact Flash Type I / II Socket with Ejector
Watchdog Timer Reset: 1 sec.~255 min. and 1 sec. or 1 min./step
Display Intel® 945GSE Integrated
Audio Realtek ALC655 supports 5.1-CH Audio
Ethernet Dual Realtek 8111C GigaLAN
Expansion 1x Express Card/34mm Slot
HDD Support 1x 2.5” HDD
COM Port 5xRS-232, 1x RS-232/422/485
Ethernet Port 2 x RJ-45
VGA / LCD / DVI Port 1 x VGA
Audio Port 1x Audio Jack (Mic-in, Line-out)
USB Port 6 x USB 2.0
SATA Port 2 x SATA
Mouse & KB 1 x PS/2 mini DIN (Optional)
Power Input 9~32V
Power Output Power Adapter: AC to DC, DC12V/5A, 60W
Operating Temperature -15°C ~60°C (5~140°F) (With CF or SSD)
Storage Temperature -20°C to +75°C (-4~167°F)
Relative Humidity 5 to 90% @ 40°C (104°F), relative humidity, non-condensing
Dimension (W x D x H) 220mm x 160mm x 80mm
Weight 4.4 lbs
Mounting Wall Mount Kit
Vibration 5 Grms, random, 5~500MHz, 1hr/axis (With CF)
1 Grms, random, 5~500MHz, 1hr/axis (With Automobile HDD)
Shock 50G, 11ms duration (With CF)
20G, 11ms duration (With Automobile HDD)

Quick Reference Guide
EPS-AT270 Quick Reference Guide 5
1.4 System Overview
1.4.1 Front & Rear View

EPS-AT270
6 EPS-AT270 Quick Reference Guide
1.4.2 Rear View
Connectors
Label Function Note
COM1~6 Serial port connector1~6
Compact Flash
CompactFlash card connector Type I/II x 1
DC-IN DC power-in connector (Screw Type)
Express Card Express card slot 1x Express Card/34mm Slot
HDD HDD Indicator
PWR Power Indicator
LAN1 RJ-45 Ethernet 1
LAN2 RJ-45 Ethernet 2
LINE OUT Line-out audio jack
MIC IN Microphone-in audio jack
Power System power switch
USB USB connector
VGA VGA connector

Quick Reference Guide
EPS-AT270 Quick Reference Guide 7
2. Hardware
Configuration
2.1 Jumper and Connector Setting, Driver and BIOS
Installing
Please refer to EPI-945GSE Quick Installation Guide or User’s Manual for
advanced information.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

EPS-AT270
8 EPS-AT270 Quick Reference Guide
2.2 Installing Hard Disk & Memory
Step 1. Unfasten 2 screws from bottom and rear side.
Step 2. Remove the chassis cover.
Step 3. Removing 4 fixing screws of bottom.
Step 4. Insert DDR2 SODIMM into memory socket.
Step 5. Insert the drive into position, and secure it with 4 screws.
Step 6. Place back the cover and fasten 2 screws back as the original.
