Avalue Technology VMS-APL User manual

Part No. E2017HAI0A2R
VMS-APL
Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor
Fanless Vehicle Telematics System
Quick Reference Guide
3rd Ed –25 October 2018
Copyright Notice
Copyright 2018 Avalue Technology Inc., ALL RIGHTS RESERVED.

VMS-APL
2 VMS-APL Quick Reference Guide
FCC Statement
THIS DEVICE COMPLIES WITH PART 15 FCC RULES. OPERATION IS
SUBJECT TO THE FOLLOWING TWO CONDITIONS:
(1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE.
(2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED INCLUDING
INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION.
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS "A" DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND, IF NOT INSTATLLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS.
OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE
HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO
CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
A Message to the Customer
Avalue Customer Services
Each and every Avalue’s product is built to the most exacting specifications to ensure
reliable performance in the harsh and demanding conditions typical of industrial
environments. Whether your new Avalue device is destined for the laboratory or the factory
floor, you can be assured that your product will provide the reliability and ease of operation
for which the name Avalue has come to be known.
Your satisfaction is our primary concern. Here is a guide to Avalue’s customer services. To
ensure you get the full benefit of our services, please follow the instructions below carefully.
Technical Support
We want you to get the maximum performance from your products. So if you run into
technical difficulties, we are here to help. For the most frequently asked questions, you can
easily find answers in your product documentation. These answers are normally a lot more
detailed than the ones we can give over the phone. So please consult the user’s manual
first.
To receive the latest version of the user’s manual; please visit our Web site at:
http://www.avalue.com.tw/

Quick Reference Guide
VMS-APL Quick Reference Guide
3
Content
1. Getting Started............................................................................................................6
1.1 Safety Precautions ................................................................................................6
1.2 Packing List...........................................................................................................6
1.3 System Specifications ...........................................................................................7
1.4 System Overview.................................................................................................13
1.4.1 Front View.................................................................................................................................. 13
1.4.2 Rear View................................................................................................................................... 13
1.5 System Dimensions.............................................................................................15
2. Hardware Configuration...........................................................................................16
2.1 VMS-APL connector mapping .............................................................................17
2.1.1 Serial Port 1 connector (COM1)................................................................................................. 17
2.1.2 Serial Port 2 connector/CAN connector (COM2/CAN) .............................................................. 18
2.1.3 DC power-in connector (DC-in).................................................................................................. 19
2.1.4 DC power-out connector (DC-out)............................................................................................. 19
2.1.5 LVDS connector (LVDS)............................................................................................................ 19
2.1.6 General purpose I/O connector (GPIO)..................................................................................... 20
2.2 EBM-APLV Overviews.........................................................................................21
2.3EBM-APLV Jumper & Connector list...................................................................23
2.4 EBM-APLV Jumpers & Connectors settings........................................................25
2.4.1 Clear CMOS (JCMOS1)............................................................................................................. 25
2.4.2 COM 1/2 pin 9 signal selector (JRI1/2)...................................................................................... 25
2.4.3 Serial port 1/2 –RS232/422/485 mode select (JCOM_SEL1/2) ............................................... 26
2.4.4 Vehicle/Industrial PC power mode selector (JACC1) ................................................................ 26
2.4.5 Digital Input selector (JDI1)........................................................................................................ 27
2.4.6 Digital Output selector (JDO1)................................................................................................... 28
2.4.7 Multi-function select (SW1)........................................................................................................ 29
2.4.8 Power Input selector (SW2)....................................................................................................... 30
2.4.9 LCD backlight brightness adjustment (JVR1)............................................................................ 30
2.4.10 CAN/COM selector (JUART_SEL1/2)................................................................................... 31
2.4.11 LPC port connector (JLPC1) ................................................................................................. 31
2.4.12 LCD inverter connector (JBKL1)............................................................................................ 32
2.4.13 BIOS SPI connector (BIOS_SPI1)......................................................................................... 32
2.4.14 DC Output connector (DCOUT1)........................................................................................... 33
2.4.15 EC Debug connector (JEC_ROM2)....................................................................................... 33
2.4.16 On-board header for USB2.0 (JUSB2).................................................................................. 34

VMS-APL
4 VMS-APL Quick Reference Guide
2.4.17 General purpose I/O connector (DIO1) ................................................................................. 34
2.4.18 CAN Module slot (CAN1)....................................................................................................... 35
2.4.19 DC Input connector (JVIN1) .................................................................................................. 35
2.4.20 Battery connector 1 (BT1) ..................................................................................................... 36
2.4.21 Battery connector 2 (BT2) ..................................................................................................... 36
2.4.22 LVDS connector (JLVDS1).................................................................................................... 37
2.5 Installing Hard Disk & Memory, PCI devices .......................................................38
3.BIOS Setup....................................................................................................................39
3.1 Introduction..........................................................................................................40
3.2 Starting Setup......................................................................................................40
3.3 Using Setup.........................................................................................................41
3.4 Getting Help.........................................................................................................42
3.5 In Case of Problems............................................................................................42
3.6 BIOS setup..........................................................................................................43
3.6.1 Main Menu ................................................................................................................................. 43
3.6.1.1 System Language..........................................................................................................................44
3.6.1.2 System Date ..................................................................................................................................44
3.6.1.3 System Time..................................................................................................................................44
3.6.2 Advanced Menu......................................................................................................................... 44
3.6.2.1 Trusted Computing.........................................................................................................................45
3.6.2.2 ACPI Settings.................................................................................................................................45
3.6.2.3 IT8528 Super IO Configuration......................................................................................................46
3.6.2.3.1 Serial Port 1 Configuration.............................................................................................................47
3.6.2.3.2 Serial Port 2 Configuration.............................................................................................................47
3.6.2.4 EC 8528 H/W Monitor....................................................................................................................48
3.6.2.5 S5 RTC Wake Settings..................................................................................................................49
3.6.2.6 Serial Port Console Redirection.....................................................................................................50
3.6.2.6.1 Legacy Console Redirection Settings ............................................................................................50
3.6.2.7 CPU Configuration.........................................................................................................................51
3.6.2.7.1 Socket 0 CPU Information..............................................................................................................52
3.6.2.7.2 CPU Power Management Configuration........................................................................................52
3.6.2.8 Network Stack Configuration..........................................................................................................53
3.6.2.9 CSM Configuration.........................................................................................................................53
3.6.2.10 NVMe Configuration.......................................................................................................................54
3.6.2.11 USB Configuration .........................................................................................................................54
3.6.2.12 Security Configuration....................................................................................................................55
3.6.3 Chipset..................................................................................................................................... 56
3.6.3.1 North Bridge.................................................................................................................................56
3.6.3.2 South Bridge ................................................................................................................................57
3.6.3.3 Uncore Configuration ...................................................................................................................58

Quick Reference Guide
VMS-APL Quick Reference Guide
5
3.6.3.4 South Cluster Configuration .........................................................................................................59
3.6.3.4.1 HD-Audio Configuration ..................................................................................................................60
3.6.3.4.2 PCI Express Configuration..............................................................................................................60
3.6.3.4.2.1 PCI Express Root Port 3(i210/211)..............................................................................................61
3.6.3.4.2.2 PCI Express Root Port 4(i210/211)..............................................................................................62
3.6.3.4.2.3 PCI Express Root Port 5(Switch2-mPCIe)...................................................................................63
3.6.3.4.2.4 PCI Express Root Port 6(Switch1-IET).........................................................................................64
3.6.3.4.3 SATA Drives....................................................................................................................................65
3.6.3.4.4 SCC Configuration ..........................................................................................................................66
3.6.3.4.4 USB Configuration...........................................................................................................................66
3.6.4 Security .................................................................................................................................... 67
3.6.4.1 Secure Boot ...................................................................................................................................68
3.6.5 Boot.......................................................................................................................................... 69
3.6.6 Save and exit ........................................................................................................................... 70
3.6.6.1 Save Changes and Reset..............................................................................................................70
3.6.6.2 Discard Changes and Reset..........................................................................................................71
3.6.6.3 Restore Defaults ............................................................................................................................71
3.6.6.4 Launch EFI Shell from filesystem device .......................................................................................71
4. Drivers Installation.......................................................................................................72
4.1 Install Chipset Driver ...........................................................................................73
4.2 Install TXE Driver.................................................................................................74
4.3 Install VGA Driver................................................................................................75
4.4 Install Audio Driver (For Realtek ALC892)...........................................................76
4.5 Install Gigabit Driver............................................................................................77
4.6 Install Serial IO Driver..........................................................................................79

VMS-APL
6 VMS-APL Quick Reference Guide
1. Getting Started
1.1 0BSafety Precautions
Warning!
Always completely disconnect the power cord from your
chassis whenever you work with the hardware. Do not
make connections while the power is on. Sensitive
electronic components can be damaged by sudden power
surges. Only experienced electronics personnel should
open the PC chassis.
Caution!
Always ground yourself to remove any static charge before
touching the CPU card. Modern electronic devices are very
sensitive to static electric charges. As a safety precaution,
use a grounding wrist strap at all times. Place all electronic
components in a static-dissipative surface or static-shielded
bag when they are not in the chassis.
1.2 1BPacking List
1 x VMS-APL Intel® Pentium®/Celeron®/Atom™ SoC BGA Processor
Fanless Vehicle Telematics System
Other major components include the followings:
—1 x Accessory kit (Dust Covers, Rubber foot and Screws)
—1 x DP to VGA Converter

Quick Reference Guide
VMS-APL Quick Reference Guide
7
1.3 System Specifications
System
Mother Board
EBM-APLV (New Board for Vehicle)
CPU
Intel® Atom™ Processor E3950 4C 1.6 GHz
Intel® Atom™ Processor E3940 4C 1.6 GHz
Intel® Atom™ Processor E3930 2C 1.3 GHz
Intel® Pentium® Processor N4200 4C 1.1 GHz
Intel® Celeron® Processor N3350 2C 1.1 GHz
BIOS
AMI uEFI BIOS, 128Mbit SPI Flash ROM
Memory
One 204-pin SODIMM Socket Up to 8GB DDR3L 1866MHz SDRAM
I/O Chipset
ITE IT8528VG-I
TPM 2.0
Infineon SLB9665TT2.0 (Factory Option)
Watchdog
H/W Reset, 1sec. ~ 65535sec.
H/W Status
Monitor
Monitoring CPU & System Temperature and Voltage
Operation System
Win10(64 bit )/ Linux(64 bit)/ Android(64 bit)
Expansion
1 x Avalue 80-Pin IET Interface (1 x DP, 4 x PCIex1, 3 x USB2.0, 1 x LPC,
1 x Line-Out(R/L), 1 x SMBus)
1 x Mini-PCIe socket (PCIe + USB) for WLAN option
1 x Mini-PCIe socket (PCIe + USB) for WWAN option
1 x CAN
Storage
Combination
1 x 2.5” Drive Bay (SATA III)
1 x M.2 (SATAIII)
1 x SD (SD3.0)
Front Side External
I/O Connector
2 x USB 3.0 Host (included USB 2.0 signal)
1 x SD Slot w/ dust protection cover
2 x SIM Holder w/ dust protection cover
1 x Swappable 2.5” drive bay
1 x Push Button for Power on/off w/ LED
1 x Push Button for Reset in hiding
3 x LEDs for Storage, WLAN/ HSDPA
1 x Line-Out
1 x Mic-In
1 x 8-bit GPIO from EC

VMS-APL
8 VMS-APL Quick Reference Guide
Rear Side External
I/O Connector
1 x DC Power input connector
1 x 12V/6A DC output
1 x DP
2 x RS232/422/485 (Jumper+Dip switch), with +5V and +12V support on
Pin-9 via jumper+dip switch
1 x COM2 optional CAN support SAE J19399 or J1708 (Factory Option)
2 x RJ-45
2 x USB 3.0 Host (Included USB 2.0 signal)
1 x DB26 LVDS interface with 12V and USB2.0
LVDS Power input Voltage Selection in header
+5V in
+3.3V in
1 x Line-Out
1 x Mic-In
5 x Antenna Mounting w/ dust protection cover
Internal I/O
Connector
1 x 3-pin header for CMOS (JCMOS1)
2 x 2x3-pin header for COM1/ 2 pin 9 signal selection (+5, +12, Ring),
( JRI1/2)
1 x 3-pin header for LCD backlight brightness adjustment (JVR1)
1 x 3-pin header for Vehicle/Industrial PC power mode selector (JACC1)
1 x 2 x 4-pin header for Digital input selector (JDI1)
1 x 2 x 4-pin header for Digital output selector (JDO1)
1 x 16-pin DIP Switch for Serial Port 1/2 mode selector: power
mode(AT/ATX)、DDI0(DP)/1(IET)mode(SW1)、COM2(CAN) mode
1 x 4-pin DIP switch for power input selector (SW2)
1 x 2 x 7 header for LPC port connector (JLPC1)
1 x 5-pin lockable connector for LVDS inverter backlight control (JBKL1)
1 x 2 x 4-Pin header for SPI (SPI1)
1 x 6-Pin DC Output Connector (DCOUY_S1), 12V/6A for DC-Out and

Quick Reference Guide
VMS-APL Quick Reference Guide
9
Powered LAN IET Module.
1 x 2 x 5-pin header for EC debug connector (JEC_ROM1)
2 x 5-pin wafer for 2 x USB 2.0 reservation (JUSB1/2)
1 x 2 x 6 header for General purpose I/O connector (DIO1)
1 x 2 x 7 header for CAN module slot (CAN1)
1 x 2 x 20-pin lockable connector for 18/ 24-bit LVDS (JLVDS1)
1 x 7+15-pin SATA connector (SATA 3.1, 1.5/3.0/6.0)
1 x Buzzer
GPS
Chipset
u-blox NEO-M8N module supports GPS/ Gloness/ QZSS/ Galileo/ Beidou
Interface
UART/USB
PCIe Switch
Chipset
2 x PI7C9X2G404SL Port-4lane PCI Express Gen 2 Switch
Interface
4-Port/ 4-lane
Display
Chipset
Intel® Apollolake SoC integrated Graphics
3 Independent Display:
1st DP 1.2a for Edge connector on rear side
2nd DP reserved for IET Interface
3rd : LVDS
Resolution
DP 1.2a: 4096x2160@60Hz
LVDS: 1920x1200@60Hz, supports 2 channels 18/24-bit via Chrontel®
CH7511B (eDP to LVDS)
Ethernet
Chipset
2 x Intel® I211AT GbE controller
Ethernet Interface
10/100/1000 Base-Tx GbE compatible
LAN Port
2 x RJ-45
Audio
Chipset
Realtek ALC892 HD codec, supports 2 CH
Audio Interface
2 x Mic-In and 2 x Line-Out
Mechanical
Power Requirement
+9 ~ 36Vdc
Power Connector
Type
3-Pin Terminal Block
ACPI
Single power ATX Support S0, S3, S4, S5 and ACPI 5.0 Compliant
Dimension
9.4” x 7.3” x 2.44 (239mm x 186mm x 62mm)
Weight
2.7KG(4.85lbs)
Color
Compliant with the color plan of the new family look
Mounting Kit
Wall mount kit (Standard)

VMS-APL
10 VMS-APL Quick Reference Guide
Reliability
Certification
CE, FCC Class B w/ERP, IP50, e13 Mark, ISO 7637-2,
Dust and Rain Test
IP 50 Rating
Vibration (Random)
With SSD : 1.5g@5~500 Hz (in operation)
Vibration Test
Operating with SSD : MIL-STD-810G, Method 514.6, Category 4,
common carrier US highway truck vibration exposure
Storage with SSD/ : MIL-STD-810G, Method 514.6, Category 24,
minimum integrity test
Mechanical Shock
Test
Operating with SSD : MIL-STD-810G, Method 516.6, Procedure I,
functional shock=20g
Non-Operating with SSD: MIL-STD-810G, Method 516.6, Procedure V,
crash hazard shock test=75g
Drop Test
Package drop test
Reference ISTA 2A, Method : IEC-60068-2-32 Test:Ed
Test phase : One corner, three edges, six faces
Operating
Temperature
-20/40°C ~70°C (w/SSD, M.2) ambient w/ air flow
N4200 and N3350 are -20°C ~70°C
E3950, E3940 and E3930 are -40°C ~70°C
Operating Humidity
5% ~ 90% relative humidity, non-condensing
Storage
Temperature
-40°C ~ 85°C
Power Management
Definition
Vehicle Power Mode
BIOS sets up as Vehicle PC
ACC Function (JACC1) sets up as Enable
AT/ATX Jumper (SW1) sets up as AT
Industrial PC Power Mode
BIOS sets up as Industrial PC
ACC Function (JACC1) sets up as Disable
AT/ATX Jumper (SW1) sets up as AT or ATX
ACC Function (JACC1)
It is Vehicle PC power mode (Power on/off controlled by Ignition or Power
button) if ACC Function sets up as Enable.
It is Industrial PC power mode (Power on/off controlled by Power button) if
ACC Function sets up as Disable.
AT/ATX Jumper (SW1)
This function will be active if ACC Function (JACC1) sets up Disable
(Industrial PC power mode).
Power Input Selection (SW2)
To set up the DC input voltage is +12Vdc, +24Vdc or wide range from

Quick Reference Guide
VMS-APL Quick Reference Guide
11
+9~36Vdc.
Vin Work/Shutdown (BIOS)
To set up the startup/shutdown voltage in accordance with DC input
voltage as +12Vdc, +24Vdc or wide range from +9~36Vdc.
The following behaviors happen if ACC Function (JACC1) sets up as
Enable:
VMS-APL won’t power on if the DC Input voltage is lower than the startup
voltage.
VMS-APL will automatically power on, if the DC input voltage reaches the
startup voltage.
VMS-APL will automatically power on, if the DC input voltage reaches the
startup voltage and power on delay ends up (the power on delay is Enable
in BIOS).
VMS-APL will automatically power off, if the DC input voltage is lower than
shutdown voltage, and the time exceeds 60sec. If it still doesn’t power off
and the time exceeds 6min, VMS-APL will be forced power off
immediately.
Power on delay time is selectable by BIOS in following hierarchies
10sec / 30sec / 1min / 5min / 10 min / 15min / 30min / 1hr.
The delay time starts to count if ignition turns on.
User can skip the delay time to turn on VMS-APL if pressing power button.
VMS-APL will automatically power on if the delay time ends up.
Power off delay time is selectable by BIOS in following hierarchies
20sec / 1min / 5min / 10min / 30min / 1hr / 6hr / 18hr.
The delay time starts to count if ignition turns off.
User can skip the delay time to turn off VMS-APL if pressing power button.
VMS-APL will automatically power off, if the delay time ends up. If it still
doesn’t power off and the time exceeds 60sec, VMS-APL will be forced
power off immediately.
S3, S4 suspend mode
In the vehicle power mode, the S3/S4 is only able to resume from power
button.
The status of Ignition On/Off is detectable by SW

VMS-APL
12 VMS-APL Quick Reference Guide
The status of Low battery is detectable by SW
VMS will shut down automatically when internal temperature is reach the
setting (it is selectable by BIOS).
VMS-APL will cancel the delay function, and then continue to operate
normally, if the ignition is turned on again and the power off delay is in
process.
VMS-APL will shut down completely, and then power on again
automatically, if the ignition is turned on again and the power off delay
ended.
VMS-APL will cancel the delay and stayed in power off status, if the
ignition is turned off again and power on delay is in process.
VMS-APL is only 10mA if it is off.
IET modules
AUX-M01
4COM module/ 4COM+2USB
Functional Testing & Mechanical Checking
AUX-M02
4LAN bypass Module/ 4LAN+2USB
Functional Testing & Mechanical Checking
AUX-M03
4LAN Powered LAN 802.3af module/ 4LAN+2USB
Functional Testing & Mechanical Checking
AUX-M07
4COM Isolation module/ 4COM+2USB
Functional Testing & Mechanical Checking
EBM-CDVS DB-A
Display module/ DVI+2USB
Functional Testing & Mechanical Checking
EBM-BYTS DB-A
Display Module/ HDMI+2USB+2COM+2LAN
Functional Testing & Mechanical Checking
EBM-BYTV DB-A
COM, GPIO, CAN Isolation module
Functional Testing & Mechanical Checking
EBM-BYTV DB-B
Mini PCIe Module/ 2 Mini PCIe w/2SIM+DVI-D
Functional Testing & Mechanical Checking
Note: Specifications are subject to change without notice.

Quick Reference Guide
VMS-APL Quick Reference Guide
13
1.4 System Overview
1.4.1 Front View
1.4.2 Rear View
Connectors
Label
Function
Note
Power
Power on button
USB 3.0
4 x USB 3.0 connector
SIM card slot
2 x SIM card slot
SD card slot
SD card slot
2.5” Drive Bay
2.5” Driver Bay socket
GPIO
General purpose I/O connector
Line-out
Line-out jack
Mic-in
Mic-in audio jack
WWAN
WWAN Indicator
WLAN
WLAN Indicator
HDD
HDD Indicator

VMS-APL
14 VMS-APL Quick Reference Guide
RESET
Reset button
LAN
2 x RJ-45 Ethernet connector
DP
DP connector
COM1
Serial port 1 connector
COM2/CAN
Serial port 2 connector
CAN connector
LVDS
LVDS connector
DC-in
DC power-in connector
DC-out
DC power-out connector

Quick Reference Guide
VMS-APL Quick Reference Guide
15
1.5 System Dimensions
(Unit: mm)

VMS-APL
16 VMS-APL Quick Reference Guide
2.Hardware
Configuration
Jumper and Connector Setting, Driver and BIOS Installing
For advanced information, please refer to:
1- EBM-APLV included in this manual.
Note: If you need more information, please visit our website:
http://www.avalue.com.tw

Quick Reference Guide
VMS-APL Quick Reference Guide
17
2.1 VMS-APL connector mapping
2.1.1 Serial Port 1 connector (COM1)
In RS-232 Mode
Signal
PIN
PIN
Signal
NDCD#
1
6
NDSR#
NRXD
2
7
NRTS#
NTXD
3
8
NCTS#
NDTR#
4
9
NRI#
GND
5
In RS-422 Mode
Signal
PIN
PIN
Signal
TxD1-
1
6
NC
TxD1+
2
7
NC
RxD1+
3
8
NC
RxD1-
4
9
NC
GND
5
In RS-485 Mode
Signal
PIN
PIN
Signal
DATA1-
1
6
NC
DATA1+
2
7
NC
NC
3
8
NC
NC
4
9
NC
GND
5

VMS-APL
18 VMS-APL Quick Reference Guide
2.1.2 Serial Port 2 connector/CAN connector (COM2/CAN)
Note:
COM2/CAN Bus mode selected by SW1 pin8 &
JUART_SEL1/2.
CAN BUS
DB9/M
1708-
1
1708+
8
1939-
5
1939+
3
GND
2
In RS-232 Mode
Signal
PIN
PIN
Signal
NDCD#
1
6
NDSR#
NRXD
2
7
NRTS#
NTXD
3
8
NCTS#
NDTR#
4
9
NRI#
GND
5
In RS-422 Mode
Signal
PIN
PIN
Signal
TxD1-
1
6
NC
TxD1+
2
7
NC
RxD1+
3
8
NC
RxD1-
4
9
NC
GND
5
In RS-485 Mode
Signal
PIN
PIN
Signal
DATA1-
1
6
NC
DATA1+
2
7
NC
NC
3
8
NC
NC
4
9
NC
GND
5

Quick Reference Guide
VMS-APL Quick Reference Guide
19
2.1.3 DC power-in connector (DC-in)
Signal
PIN
VIN + (BAT+)
1
ACC (IGN)
2
VIN- (BAT-)
3
2.1.4 DC power-out connector (DC-out)
Signal
PIN
+12V
1
GND
2
2.1.5 LVDS connector (LVDS)
Note:
This connector included LVDS, USB, 12V and 5V
interfaces.
PIN
Signal
PIN
Signal
PIN
Signal
1
PS_ON
10
1+
19
12V
2
GND
11
1-
20
GND
3
3.3V
12
GND
21
Backlight_EN
4
5V
13
2+
22
VBRIGHT
5
GND
14
2-
23
USB_VCC
6
GND
15
3+
24
D-
7
0+
16
3-
25
D+
8
0-
17
CLK+
26
USB_GND
9
GND
18
CLK-

VMS-APL
20 VMS-APL Quick Reference Guide
2.1.6 General purpose I/O connector (GPIO)
PIN
Signal
PIN
Signal
PIN
Signal
1
DIO_GPO0
6
DIO_GPI2
11
GND
2
DIO_GPI0
7
DIO_GPO3
12
+3.3V
3
DIO_GPO1
8
DIO_GPI3
13
NC
4
DIO_GPI1
9
MBCLK
14
NC
5
DIO_GPO2
10
SMB_DATA
15
NC
