Overview for the Avaya G450 Media
Gateway
03-602058
Issue 1
January 2008

© 2008 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts were made to ensure that the information in this
document was complete and accurate at the time of printing, Avaya Inc. can
assume no liability for any errors. Changes and corrections to the information
in this document may be incorporated in future releases.
For full legal page information, please see the complete document, Avaya
Legal Page for Software Documentation, Document number 03-600758.
To locate this document on the website, simply go to
http://www.avaya.com/support and search for the document number in
the search box.
Documentation disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to
the original published version of this documentation unless such modifications,
additions, or deletions were performed by Avaya. Customer and/or End User
agree to indemnify and hold harmless Avaya, Avaya's agents, servants and
employees against all claims, lawsuits, demands and judgments arising out of,
or in connection with, subsequent modifications, additions or deletions to this
documentation to the extent made by the Customer or End User.
Link disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked web
sites referenced elsewhere within this documentation, and Avaya does not
necessarily endorse the products, services, or information described or offered
within them. We cannot guarantee that these links will work all of the time and
we have no control over the availability of the linked pages.
Warranty
Avaya Inc. provides a limited warranty on this product. Refer to your sales
agreement to establish the terms of the limited warranty. In addition, Avaya’s
standard warranty language, as well as information regarding support for this
product, while under warranty, is available through the following web site:
http://www.avaya.com/support
Copyright
Except where expressly stated otherwise, the Product is protected by copyright
and other laws respecting proprietary rights. Unauthorized reproduction,
transfer, and or use can be a criminal, as well as a civil, offense under the
applicable law.
Avaya support
Avaya provides a telephone number for you to use to report problems or to ask
questions about your product. The support telephone number
is 1-800-242-2121 in the United States. For additional support telephone
numbers, see the Avaya web site:
http://www.avaya.com/support

Issue 1 January 2008 3
About this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Audience . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Downloading this book and updates from the web . . . . . . . . . . . . . . . . . 5
Downloading this book . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Related resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Within the US. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
International . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Sending us comments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
G450 physical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 2: Optional components. . . . . . . . . . . . . . . . . . . . . . 15
Supported media modules in the G450 . . . . . . . . . . . . . . . . . . . . . . . 15
S8300 server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Telephony media modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
WAN media modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Media module slot configurations in the G450 . . . . . . . . . . . . . . . . . . . 23
Permitted slots. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
G450 media module capacity . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Chapter 3: Summary of services . . . . . . . . . . . . . . . . . . . . . . 25
Media gateway services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Voice over IP (VoIP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Physical media — G450 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Media Gateway Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Additional features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
LAN services. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Physical media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
VLANs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Rapid Spanning Tree Protocol (RSTP) . . . . . . . . . . . . . . . . . . . . . . 32
Port mirroring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Port redundancy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Link Layer Discovery Protocol (LLDP) . . . . . . . . . . . . . . . . . . . . . . 32
WAN services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Physical media. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
WAN features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Contents

Contents
4 Administration for the Avaya G450 Media Gateway
Routing features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Chapter 4: Management, Security, Alarms and Troubleshooting . . . . 37
Management applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Avaya G450 Command Line Interface (CLI) . . . . . . . . . . . . . . . . . . . 37
Avaya G450 Manager and Embedded Web Manager . . . . . . . . . . . . . . 37
Avaya Integrated Management . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Management access security features. . . . . . . . . . . . . . . . . . . . . . . . 38
Network security features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Alarms and troubleshooting features . . . . . . . . . . . . . . . . . . . . . . . . 39
Front panel LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Automatic error detection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Packet sniffing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
VoIP debugging using RTP-MIB . . . . . . . . . . . . . . . . . . . . . . . . . 40
Converged Network Analyzer (CNA) test plug. . . . . . . . . . . . . . . . . . 40
Chapter 5: Documentation . . . . . . . . . . . . . . . . . . . . . . . . . 41
Appendix A: G450 capacities . . . . . . . . . . . . . . . . . . . . . . . . 43
G450 maximum media gateway capacities . . . . . . . . . . . . . . . . . . . . . 43
S8300 maximum capacities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Appendix B: Supported Avaya telephones . . . . . . . . . . . . . . . . 47
Appendix C: G450 technical specifications . . . . . . . . . . . . . . . . 49
G450 specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
G450 power cord specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
G450 media module specifications. . . . . . . . . . . . . . . . . . . . . . . . . . 50
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Issue 1 January 2008 5
About this book
This guide contains information that you need to consider before implementing the Avaya G450
Media Gateway. Use this guide to learn what the G450 can do and to plan how you will deploy a
G450 in your environment.
Audience
The information in this book is intended for use by Avaya technicians, provisioning specialists,
Business Partners, and customers.
Downloading this book and updates from the web
You can download the latest version of Overview for the Avaya G450 Media Gateway from the
Avaya web site. You must have access to the Internet, and a copy of Acrobat Reader must be
installed on your personal computer.
Avaya makes every effort to ensure that the information in this book is complete and accurate.
However, information can change after we publish this book. Therefore, the Avaya web site
might also contain new product information and updates to the information in this book. You can
also download these updates from the Avaya web site.
Downloading this book
1. Access the Avaya web site at http://www.avaya.com/support.
2. Click FIND DOCUMENTATION and TECHNICAL INFORMATION by PRODUCT NAME.
3. Type this book’s document number (03-602058) in the Search box.
4. Click GO.
The search results appear.
5. Locate the latest version of the book.
6. Click the book title. Your browser downloads the book.

About this book
6 Administration for the Avaya G450 Media Gateway
Related resources
Technical assistance
Avaya provides resources for technical assistance within the US and internationally.
Within the US
For help with:
●Feature administration and system applications, call the Avaya Technical Consulting
Support System at 1-800-225-7585
●Maintenance and repair, call the Avaya National Customer Care Support Line at
1-800-242-2121
●Toll fraud, call Avaya Toll Fraud Intervention at 1-800-643-2353
International
For all international resources, contact your local Avaya authorized dealer.
Title Number
Quick Start for Hardware Installation for the Avaya G450 Media
Gateway 03-602053
Installing and Upgrading the Avaya G450 Media Gateway 03-602054
Administration for the Avaya G450 Media Gateway 03-602055
Avaya G450 CLI Reference 03-602056
Maintenance Alarms for Avaya Communication Manager,
Media Gateways and Servers 03-300430
Maintenance Commands for Avaya Communication Manager,
Media Gateways and Servers 03-300431
Maintenance Procedures for Avaya Communication Manager,
Media Gateways and Servers 03-300432

Sending us comments
Issue 1 January 2008 7
Sending us comments
Avaya welcomes your comments about this book. To reach us by:
●Mail, send your comments to:
Avaya Inc.
Product Documentation Group
Room B3-H13
1300 W. 120th Ave.
Westminster, CO 80234 USA
●E-mail, send your comments to:
[email protected]
●Fax, send your comments to:
1-303-538-1741
Ensure that you mention the name and number of this book, Overview for the Avaya G450
Media Gateway, 03-602058.

About this book
8 Administration for the Avaya G450 Media Gateway

Issue 1 January 2008 9
Chapter 1: Introduction
The Avaya G450 Media Gateway is a multipurpose media gateway that can be deployed in
medium to large sized branch locations or in wiring-closets servicing buildings and floors, in a
campus environment. It works in conjunction with Avaya Communication Manager IP telephony
software running on Avaya S8XXX Servers to help deliver intelligent communications to
enterprises of all sizes.
The G450 combines telephone exchange and data networking, by providing PSTN toll bypass
and routing data and VoIP traffic over the WAN. The G450 features a VoIP engine, an optional
WAN router, and Ethernet LAN connectivity. The G450 provides full support for Avaya IP and
digital telephones, as well as analog devices such as modems, fax machines, and telephones.
The G450 can support up to 450 users when deployed as a branch gateway in a mid to large
branch office of a large enterprise or a call center, and can serve up to 2400 users when
deployed as a campus gateway. Both configurations require Avaya Communication Manager IP
telephony software running on one or more Avaya S8XXX Servers. The 450 user capacity is
reached when the Avaya S8300 server is used and the 2400 user capacity is reached when the
Avaya S8500 Server is used.
Telephone services on a G450 are controlled by an Avaya S8XXX Server operating either as an
External Call Controller (ECC) or as an Internal Call Controller (ICC). The G450 supports the
Avaya S8300 Server as an ICC, or as an ECC when the S8300 is installed in another media
gateway. The G450 also supports the Avaya S8710, S8720, S8730, S8500, and S8400 Servers
as ECCs.
An ICC can be used in addition to an ECC with the ICC installed as a Local Survivable
Processor (LSP) designed to take over call control in the event that the ECC fails or the WAN
link between the branch office and main location breaks. The LSP provides full featured
telephone service survivability for the branch office. The G450 itself also features Standard
Local Survivability (SLS), which provides basic telephone services in the event that the
connection with the primary ECC is lost.
The G450 is a scalable device with a basic configuration consisting of 1 power supply unit
(PSU), 256 MB RAM, and a single DSP childboard supporting either 20 or 80 VoIP channels.
This configuration can be enhanced by adding a redundant PSU, up to two RAM modules of
1 GB each, and up to three additional DSP childboards, increasing the number of VoIP
channels to 240 channels.
