Avaya 1600 Series Service manual

Avaya 1600 Series IP Deskphones
Administrator Guide
Release 1.3.6
16-601438
Issue 6
August 2014

Issue 6 August 2014 1
© 2014 Avaya Inc.
All Rights Reserved.
Notice
While reasonable efforts were made to ensure that the information in this document was complete and accurate at the time of printing,Avaya Inc. can assume no
liability for any errors. Changes and corrections to the information in this document may be incorporated in future releases.
For full legal page information, please see the complete document, Avaya Legal Page for Hardware Documentation, Document number 03-600759.
To locate this document on our Web site, simply go to http://www.avaya.com/support and search for the document number in the search box.
Documentation disclaimer
Avaya Inc. is not responsible for any modifications, additions, or deletions to the original published version of this documentation unless such modifications,
additions, or deletions were performed byAvaya. Customer and/or End User agree to indemnify and hold harmlessAvaya, Avaya's agents, servants and employees
against all claims, lawsuits, demands and judgments arising out of, or in connection with, subsequent modifications, additions or deletions to this documentation to
the extent made by the Customer or End User.
Link disclaimer
Avaya Inc. is not responsible for the contents or reliability of any linked Web sites referenced elsewhere within this documentation, and Avaya does not necessarily
endorse the products, services, or information described or offered within them. We cannot guarantee that these links will work all of the time and we have no control
over the availability of the linked pages.
Warranty
Avaya Inc. provides a limited warranty on this product. Refer to your sales agreement to establish the terms of the limited warranty. In addition,Avaya’s standard
warranty language, as well as information regarding support for this product, while under warranty, is available through the following Web site:
http://www.avaya.com/support
Copyright
Except where expressly stated otherwise, the Product is protected by copyright and other laws respecting proprietary rights. Unauthorized reproduction, transfer,
and or use can be a criminal, as well as a civil, offense under the applicable law.
Avaya support
Avaya provides a deskphone number for you to use to report problems or to ask questions about your product. The support deskphone number is 1-800-242-2121
in the United States. For additional support deskphone numbers, see the Avaya Web site:
http://www.avaya.com/support
Software License
USE OR INSTALLATION OF THE PRODUCT INDICATES THE END USER’S ACCEPTANCE OF THE TERMS SET FORTH HEREIN AND THE GENERAL
LICENSE TERMSAVAILABLE ON THEAVAYA WEBSITE AT http://support.avaya.com/LicenseInfo/ (“GENERAL LICENSE TERMS”). IF YOU DO NOT WISH TO
BE BOUND BY THESE TERMS, YOU MUST RETURN THE PRODUCT(S) TO THE POINT OF PURCHASE WITHIN TEN (10) DAYS OF DELIVERY FORA
REFUND OR CREDIT.
Avaya grants End User a license within the scope of the license types described below. The applicable number of licenses and units of capacity for which the license
is granted will be one (1), unless a different number of licenses or units of capacity is specified in the Documentation or other materials available to End User.
“Designated Processor” means a single stand-alone computing device. “Server” means a Designated Processor that hosts a software application to be accessed by
multiple users. “Software” means the computer programs in object code, originally licensed by Avaya and ultimately utilized by End User, whether as stand-alone
Products or pre-installed on Hardware. “Hardware” means the standard hardware Products, originally sold by Avaya and ultimately utilized by End User.
License Type(s):
Designated System(s) License (DS). End User may install and use each copy of the Software on only one Designated Processor, unless a different number of
Designated Processors is indicated in the Documentation or other materials available to End User. Avaya may require the Designated Processor(s) to be identified
by type, serial number, feature key, location or other specific designation, or to be provided by End User to Avaya through electronic means established by Avaya
specifically for this purpose.
Third-party Components
Certain software programs or portions thereof included in the Product may contain software distributed under third party agreements (“Third Party Components”),
which may contain terms that expand or limit rights to use certain portions of the Product (“Third Party Terms”). Information identifying Third Party Components and
the Third Party Terms that apply to them is available on Avaya’s Web site at:
http://support.avaya.com/ThirdPartyLicense/
Interference
Using a cell, mobile, or GSM deskphone, or a two-way radio in close proximity to an Avaya IP Deskphone might cause interference.
Security
See http://support.avaya.com/security to locate and/or report known vulnerabilities in Avaya products. See http://support.avaya.com to locate the latest software
patches and upgrades. For information about secure configuration of equipment and mitigation of toll fraud threats, see theAvayaToll Fraud and Security Handbook
at http://support.avaya.com.

2 1600 Series IP Deskphone Administrator Guide

Issue 6 August 2014 1
Chapter 1: Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
About This Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
New in this release. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Document Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Other Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 2: Administration Overview and Requirements . . . . . . . . . 11
1600 Series IP Deskphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Parameter Data Precedence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
The Administrative Process. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Administrative Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Deskphone Initialization Process. . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 1: Deskphone to Network . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Step 2: DHCP Server to Deskphone . . . . . . . . . . . . . . . . . . . . . . . 18
Step 3: Deskphone and File Server. . . . . . . . . . . . . . . . . . . . . . . . 18
Step 4: Deskphone and the Call Server . . . . . . . . . . . . . . . . . . . . . 18
Error Conditions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 3: Network Requirements . . . . . . . . . . . . . . . . . . . . . 21
Network Assessment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Hardware Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Server Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
HTTP/HTTPS Server . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Required Network Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Other Network Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
SNMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Reliability and Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
IEEE 802.1P and 802.1Q . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Network Audio Quality Display on 1600 Series IP Deskphones . . . . . . . . 26
IP Address Lists and Station Number Portability . . . . . . . . . . . . . . . . 26
TCP/UDP Port Utilization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Security. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Registration and Authentication . . . . . . . . . . . . . . . . . . . . . . . 30
Chapter 4: Avaya Aura Communication Manager Administration . . . . 31
Call Server Requirements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Contents

Contents
2 1600 Series IP Deskphone Administrator Guide
Switch Compatibility and Aliasing IP Deskphones . . . . . . . . . . . . . . . 31
Media Server (Switch) Administration . . . . . . . . . . . . . . . . . . . . . . . . 33
IP Interface and Addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
UDP Port Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
RSVP and RTCP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
QoS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
IEEE 802.1P and 802.1Q . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
NAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
DIFFSERV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Voice Mail Integration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
1600 Series IP Deskphones with Avaya Aura Communication Manager 5.2 Native Support
36
1600 Series IP Deskphones Aliased as 4600 Series IP Deskphones. . . . . . 36
Deskphone Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
System-Wide Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Feature-Related System Parameters . . . . . . . . . . . . . . . . . . . . . . . 37
Administering Stations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Aliasing 1600 Series IP Deskphones . . . . . . . . . . . . . . . . . . . . . . . 39
Administering Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Feature Buttons and Call Appearances . . . . . . . . . . . . . . . . . . . . . . . 40
For the 1603/1603SW/1603-I/1603SW-I and 1608/1608-I IP Deskphones . . . . 40
For the 1616/1616-I IP Deskphones. . . . . . . . . . . . . . . . . . . . . . . . 40
Conference Details Screen for Ad-Hoc Conferences . . . . . . . . . . . . . . 41
Shuffling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Printing Button Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Chapter 5: Server Administration . . . . . . . . . . . . . . . . . . . . . 43
Software Checklist. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
DHCP and File Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
DHCP Server Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
DHCP Generic Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Windows NT 4.0 DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Verifying the Installation of the DHCP Server . . . . . . . . . . . . . . . . 48
Creating a DHCP Scope for the IP Deskphones . . . . . . . . . . . . . . . 49
Editing Custom Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Adding the DHCP Option . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Activating the Leases . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Verifying Your Configuration . . . . . . . . . . . . . . . . . . . . . . . . . 51
Windows 2000 DHCP Server . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Contents
Issue 6 August 2014 3
Verifying the Installation of the DHCP Server . . . . . . . . . . . . . . . . 52
Adding DHCP Options. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Activating the New Scope. . . . . . . . . . . . . . . . . . . . . . . . . . . 55
HTTP Generic Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
HTTP Configuration for Backup/Restore. . . . . . . . . . . . . . . . . . . . . . . 56
For IIS Web Servers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Web Configuration Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Chapter 6: Deskphone Software and Application Files. . . . . . . . . . 61
General Download Process . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
1600 Series IP Deskphone Scripts and Application Files. . . . . . . . . . . . . . 62
Choosing the Right Application File and Upgrade Script File . . . . . . . . . 62
Upgrade Script File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Settings File . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Contents of the Settings File . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
The GROUP System Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Call Center Administration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Chapter 7: Administering Deskphone Options . . . . . . . . . . . . . . 69
Administering Options for the 1600 Series IP Deskphones . . . . . . . . . . . . 69
VLAN Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
VLAN Tagging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
VLAN Default Value and Priority Tagging . . . . . . . . . . . . . . . . . . . . 76
VLAN Separation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
DNS Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
IEEE 802.1X . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
802.1X Pass-Through and Proxy Logoff . . . . . . . . . . . . . . . . . . . . . 80
802.1X Supplicant Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Link Layer Discovery Protocol (LLDP) . . . . . . . . . . . . . . . . . . . . . . . . 82
Local Administrative Options Using the Deskphone Dialpad . . . . . . . . . . . 87
Clear Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Disabling or enabling the Debug mode . . . . . . . . . . . . . . . . . . . . . 88
Group Identifier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Reset System Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Restart the Deskphone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Interface Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
The View Local Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Static Addressing Installation . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Contents
4 1600 Series IP Deskphone Administrator Guide
Disable/Enable Event Logging . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Logoff. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Self-Test Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Language Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
1600 Series Global Deskphones . . . . . . . . . . . . . . . . . . . . . . . . . 104
1600 Series International Deskphones . . . . . . . . . . . . . . . . . . . . . . 106
Enhanced Local Dialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Backup/Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Backup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Restore . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Chapter 8: Administering Applications and Options . . . . . . . . . . . 115
Customizing 1600 Series IP Deskphone Applications and Options . . . . . . . . 115
The Application Status Flag (APPSTAT) . . . . . . . . . . . . . . . . . . . . . 118
Appendix A: Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . 121
Appendix B: Related Documentation . . . . . . . . . . . . . . . . . . . 123
IETF Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
ITU Documents. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
ISO/IEC, ANSI/IEEE Documents . . . . . . . . . . . . . . . . . . . . . . . . . 125
Appendix C: Sample Administration Forms . . . . . . . . . . . . . . . . 127
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

Issue 6 August 2014 1
Chapter 1: Introduction
About This Guide
This guide is for personnel who administer AvayaAura™ Communication Manager, Avaya Aura
Communication Manager Branch (formerly known as Avaya Distributed Office), DHCP, HTTP/HTTPS
servers for Avaya 1600 Series IP Deskphones, a Local Area Network (LAN), or a Web server.
The 1600 Series IP Deskphones use Internet Protocol (IP) technology with Ethernet line interfaces and
support the H.323 protocol only. The 1600 Series IP Deskphones provide support for DHCP, HTTP, and
HTTPS over IPv4, which enhances the administration and servicing of the deskphones. These
deskphones use DHCP to obtain dynamic IP Addresses, and HTTPS or HTTP to download new
versions of software or customized settings for the deskphones.
!CAUTION:
CAUTION: Avaya does not support many of the products mentioned in this document. Take care to
ensure that there is adequate technical support available for servers used with any 1600
Series IP Deskphone system. If the servers are not functioning correctly, the 1600 Series
IP Deskphones might not operate correctly.
New in this release
Release 1.3.5 has the following new enhancements:
●Supported on the 1603, 1603-I, 1603SW, 1603SW-I, 1608, 1608-I, 1616, and 1616-I IP
Deskphones only. This package will not load or operate on any other models.
●Avaya recommends that all the customers upgrade both new and installed 1600 Series IP
Deskphones to this version at their earliest convenience.

Introduction
2 1600 Series IP Deskphone Administrator Guide
Document Organization
The guide contains the following sections:
Chapter 1: Introduction Provides an overview of this document.
Chapter 2: Administration
Overview and Requirements Provides an overview of the administrative process and describes general hardware, software, and operational
requirements.
Chapter 3: Network
Requirements Describes administrative requirements for your Local Area Network.
Chapter 4: AvayaAura
Communication Manager
Administration
Describes how to administer AvayaAura Communication
Manager to operate with 1600 Series IP Deskphones.
Chapter 5: Server
Administration Describes DHCP, HTTP, and HTTPS administration for the 1600 Series IP Deskphones.
Chapter 6: Deskphone
Software and Application Files Describes deskphone software, covers application software downloads, and provides information about the configuration
file.
Chapter 7: Administering
Deskphone Options Describes how to use file parameters and options to administer 1600 Series IP Deskphones. Covers backup and
restoration of deskphone data. Also describes how to use
local procedures to customize a single deskphone from the
dialpad.
Chapter 8: Administering
Applications and Options Provides a table of customizable application-specific parameters, to provide administrative control of deskphone
functions and options.
Appendix A: Glossary of
Terms Provides a glossary of terms used in this document or which can be applicable to 1600 Series IP Deskphones.
Appendix B: Related
Documentation Provides references to external documents that relate to telephony in general, which can provide additional
information about specific aspects of the deskphones.
Appendix C: Sample
Administration Forms Provides examples of AvayaAura Communication Manager forms related to system-wide and individual deskphone
administration.

Other Documentation
Issue 6 August 2014 3
Other Documentation
See the Avaya support site at http://www.avaya.com/support for 1600 Series IP Deskphone technical
and end user documentation.
The following documents are available for the 1600 Series IP Deskphones:
●Avaya 1600 Series IP Deskphones Installation and Maintenance Guide, Document Number
16-601438.
●Avaya one-X™ Deskphone Value Edition 1600 Series IP Deskphone Pre-Installation Checklist,
Document Number 16-601439.
●Avaya one-X™ Deskphone Value Edition 1600 Series IP Deskphone Safety Instructions,
Document Number 16-601440.
●Avaya one-X™ Deskphone Value Edition 1600 Series IP Deskphones BM32 Button Module
Installation and Safety Instructions, Document Number 16-601441.
●Avaya one-X™ 9600 Series IP Deskphone Application Programmer Interface (API) Guide,
Document Number 16-601442.
●Avaya 1600 Series IP Deskphones Administrator Guide, Document Number 16-601443.
●Avaya 1603/1603SW/1603-I/1603SW-I IP Deskphone User Guide, Document Number
16-601444.
●Avaya 1608/1608-I IP Deskphone User Guide, Document Number 16-601446.
●Avaya 1616/1616-I IP Deskphone User Guide, Document Number 16-601448.
●Avaya one-X™ Deskphone Value Edition 1600 Series IP Deskphones BM32 Button Module User
Guide, Document Number 16-601450
●Avaya one-X™ Deskphone Value Edition 1600 Series IP Deskphone Wall Mount Instructions,
Document Number 16-601453.
●Avaya one-X™ Deskphone Value Edition 1600 Series IP Deskphone Stand Instructions,
Document Number 16-601451.
●Avaya 1603/1603SW/1603-I/1603SW-I IP Deskphone Quick Reference,
Document Number 16-601445.
●Avaya 1608/1608-I IP Deskphone Quick Reference, Document Number 16-601447.
●Avaya 616/1616-I IP Deskphone Quick Reference, Document Number 16-601449.
See Appendix B: Related Documentation for a list of non-Avaya documents, such as those published
by the Internet Engineering Task Force (IETF) and the International Telecommunication Union (ITU).

Introduction
4 1600 Series IP Deskphone Administrator Guide

Issue 6 August 2014 5
Chapter 2: Administration Overview and
Requirements
1600 Series IP Deskphones
The 1600 Series IP Deskphones currently support the H.323 signaling protocol.
The H.323 standard provides for real time audio, video, and data communications transmission over a
packet network. An H.323 deskphone protocol stack comprises several protocols:
●H.225 for registration, admission, status (RAS), and call signaling,
●H.245 for control signaling,
●Real Time Transfer Protocol (RTP), and
●Real Time Control Protocol (RTCP)
The parameters under which the 1600 Series IP Deskphones need to operate are summarized as
follows:
●Deskphone and System Administration on the Avaya Media Server, as covered in
Chapter 4: AvayaAura Communication Manager Administration.
●IP address management for the deskphone, as covered in DHCP and File Servers on page 37 for
dynamic addressing. For static addressing, see the Avaya 1600 Series IP Deskphones Installation
and Maintenance Guide.
●Tagging Control and VLAN administration for the deskphone, if appropriate, as covered in Chapter
7: Administering Deskphone Options.
●Quality of Service (QoS) administration for the deskphone, if appropriate. QoS is covered in
QoS on page 19 and QoS on page 28.
●Interface administration for the deskphone, as appropriate. Administer the deskphone to LAN
interface using the PHY1 parameter described in Chapter 3: Network Requirements. Administer
the deskphone to PC interface using the PHY2 parameter described in “Local Procedures” in the
Avaya 1600 Series IP Deskphones Installation and Maintenance Guide.
●Application-specific deskphone administration, if appropriate, as described in Chapter
8: Administering Applications and Options. An example of application-specific data is specifying
the extent to which users can add/edit/delete data for Contacts entries.
●Protocol administration, for example, Simple Network Management Protocol (SNMP) and Link
Layer Discovery Protocol (LLDP).

Administration Overview and Requirements
6 1600 Series IP Deskphone Administrator Guide
Table 1 indicates that you can administer system parameters in a variety of ways and use a variety of
delivery mechanisms like:
●Maintaining the information on the call server.
●Manually entering the information by means of the deskphone dialpad.
●Administering the DHCP server.
●Editing the configuration file on the applicable HTTP or HTTPS file server.
●User modification of certain parameters, when given administrative permission to do so.
Note:
Note: Not all parameters can be administered on all delivery mechanisms.
Table 1: Administration Alternatives and Options for 1600 Series IP
Deskphones
Parameter(s) Administrative
Mechanisms For More Information See:
Deskphone
Administration Avaya call server Chapter 4: AvayaAura Communication Manager
Administration, Chapter 5: Server Administration,
and Appendix B: Related Documentation.
IP Addresses DHCP
(strongly
recommended)
DHCP and File Servers on page 37, and especially
DHCP Server Administration on page 38.
Configuration file Chapter 6: Deskphone Software and Application
Files and Chapter 7: Administering Deskphone
Options.
Manual administration
at the deskphone “Static Addressing Installation” in the Avaya 1600 Series IP Deskphones Installation and
Maintenance Guide.
LLDP Link Layer Discovery Protocol (LLDP) on page 78.
Tagging and
VLAN LLDP Link Layer Discovery Protocol (LLDP) on page 78.
DHCP DHCP Server Administration on page 38, and
Chapter 7: Administering Deskphone Options.
Configuration file
(strongly
recommended)
DHCP and File Servers on page 37 and Chapter
7: Administering Deskphone Options.
1 of 3

1600 Series IP Deskphones
Issue 6 August 2014 7
Manual administration
at the deskphone “Static Addressing Installation” in the Avaya 1600 Series IP Deskphones Installation and
Maintenance Guide.
Avaya call server Use the change ip-network-map command to
configure the VLAN ID.
Table 1: Administration Alternatives and Options for 1600 Series IP
Deskphones (continued)
Parameter(s) Administrative
Mechanisms For More Information See:
2 of 3

Administration Overview and Requirements
8 1600 Series IP Deskphone Administrator Guide
General information about administering DHCP servers is covered in DHCP and File Servers on
page 37, and more specifically, DHCP Server Administration on page 38. General information about
administering HTTP servers is covered in DHCP and File Servers, and more specifically, HTTP Generic
Setup. Once you are familiar with that material, you can administer deskphone options as described in
Chapter 7: Administering Deskphone Options.
Quality of
Service Avaya call server
(strongly
recommended)
UDP Port Selection on page 28 and
Appendix B: Related Documentation.
DHCP DHCP and File Servers on page 37, and Chapter
7: Administering Deskphone Options.
Configuration file DHCP and File Servers on page 37, and Chapter
7: Administering Deskphone Options.
Interface DHCP DHCP and File Servers on page 37, and Chapter
6: Deskphone Software and Application Files.
Configuration file
(strongly
recommended)
DHCP and File Servers on page 37, and Chapter
6: Deskphone Software and Application Files.
Manual administration
at the deskphone “Ethernet (Hub) Interface Enable/Disable” in the Avaya 1600 Series IP Deskphones Installation and
Maintenance Guide.
LLDP Link Layer Discovery Protocol (LLDP) on page 78.
Application -
specific
parameters
DHCP DHCP and File Servers on page 37, and especially
DHCP Server Administration on page 38.
Also, Chapter 8: Administering Applications and
Options.
Configuration file
(strongly
recommended)
DHCP and File Servers on page 37, and especially
HTTP Generic Setup on page 49. Also,
Chapter 8: Administering Applications and Options.
Table 1: Administration Alternatives and Options for 1600 Series IP
Deskphones (continued)
Parameter(s) Administrative
Mechanisms For More Information See:
3 of 3

Parameter Data Precedence
Issue 6 August 2014 9
Parameter Data Precedence
If a given parameter is administered in multiple places, the last server to provide the parameter has
precedence. The precedence, from lowest to highest, is:
1. LLDP,
2. Manual administration, with the two exceptions described for the system parameter STATIC on
page 71,
3. DHCP,
4. HTTP/HTTPS script file,
5. theAvaya Media Server, and finally,
6. Backup files, if administered and if permitted.
Settings the IP deskphone receives from backup files or the media server overwrite any previous
settings, including manual settings. The only exception to this sequence is in the case of VLAN IDs. In
the case of VLAN IDs, LLDP settings of VLAN IDs are the absolute authority. Then the usual sequence
applies through HTTP/HTTPS.
Note:
Note: For the L2QVLAN and L2Q system values, LLDP settings of VLAN IDs are the absolute
authority only if the LLDP task receives the VLAN IDs before DHCP and HTTP, and the
DHCP client of the deskphone is activated at all. If the LLDP task receives the VLAN IDs
after DHCP negotiation, several criteria must be successful before the deskphone
accepts VLAN IDs from LLDP. For more information, see Link Layer Discovery Protocol
(LLDP).
The Administrative Process
The following list depicts administration for a typical 1600 Series IP Deskphone network. Your own
configuration might differ depending on the servers and system you have in place.
1. LAN and applicable servers administered to accept the deskphones.
2. Deskphone software downloaded from theAvaya support site.
3. 46xxsettings file updated with site-specific information, as applicable.
4. 1600 Series Deskphones installed. For more information, see the Avaya 1600 Series IP
Deskphones Installation and Maintenance Guide.
5. Individual 1600 Series IP Deskphones updated using local procedures, as applicable. For more
information, see “Local Administrative Procedures” in the Avaya 1600 Series IP Deskphones
Installation and Maintenance Guide.

Administration Overview and Requirements
10 1600 Series IP Deskphone Administrator Guide
Administrative Checklist
Use the following checklist as a guide to system and LAN administrator responsibilities. This high-level
list helps ensure that all deskphone system prerequisites and requirements are met prior to deskphone
installation.
Note:
Note: One person might function as both the system administrator and the LAN administrator
in some environments.
Table 2: Administrative Checklist
Task Description For More Information See:
Network Requirements
Assessment Determine that network hardware is in place and can
handle deskphone system
requirements.
Chapter 3: Network
Requirements.
Administer the call
server Verify that the call server is licensed and is administered for
Voice over IP (VoIP).
Verify the individual
deskphones are administered
as desired.
Chapter 4: AvayaAura
Communication Manager
Administration.
Chapter 4: AvayaAura
Communication Manager
Administration.
DHCP server
installation Install a DHCP application on at least one new or existing PC on
the LAN.
Vendor-provided instructions.
Administer DHCP
application Add IP deskphone administration to DHCP
application.
DHCP Server Administration in
Chapter 5: Server
Administration.
HTTP/HTTPS server
installation Install an HTTP/HTTPS application on at least one new
or existing PC on the LAN.
Vendor-provided instructions.
Application file(s), script
file, and settings file
installation on HTTP/
HTTPS server
Download the files from the
Avaya support site. http://www.avaya.com/support
Chapter6: Deskphone Software
and Application Files.
Modify settings file as
desired Edit the settings file as desired, using your own tools or the
[Avaya] Web configuration tool.
Chapter6: Deskphone Software
and Application Files and Web
Configuration Tool on page 52.
1 of 2

Deskphone Initialization Process
Issue 6 August 2014 11
Note:
Note: The 1608/1608-I and 1616/1616-I deskphones support the Top Line Text and Audio
Push types (but not the WML Push type).
Deskphone Initialization Process
These steps offer a high-level description of the information exchanged when the deskphone initializes
and registers. This description assumes that all equipment is properly administered ahead of time.This
description can help you understand how the 1600 Series IP Deskphones relate to the routers and
servers in your network.
Step 1: Deskphone to Network
The deskphone is appropriately installed and powered. After a short initialization process, the
deskphone identifies the LAN speed and sends a message out into the network, identifying itself and
requesting further information. A router on the network receives and relays this message to the
appropriate DHCP server if the phone IP address is 0.0.0.0.
Administer deskphones
locally as applicable As a Group: The GROUP System Value on
page 61 and the Avaya 1600
Series IP Deskphones
Installation and Maintenance
Guide.
Individually: The applicable Local
Procedures in the Avaya 1600
Series IP Deskphones
Installation and Maintenance
Guide.
Installation of
deskphones in the
network
Avaya 1600 Series IP
Deskphones Installation and
Maintenance Guide.
Allow user to modify
Options, if applicable OPSTATon page 68 and the
respective User Guide for the
specific deskphone model.
Table 2: Administrative Checklist (continued)
Task Description For More Information See:
2 of 2

Administration Overview and Requirements
12 1600 Series IP Deskphone Administrator Guide
Step 2: DHCP Server to Deskphone
The DHCP file server provides information to the deskphone, as described in DHCP and File
Servers on page 37. Among other data passed to the deskphone is the IP address of the HTTP or
HTTPS server.
Step 3: Deskphone and File Server
The 1600 Series IP Deskphones can download script files and settings files from either an HTTP or
HTTPS server. These deskphones can also download the application files from the HTTP server. The
deskphone queries the file server, which transmits a script file to the deskphone. This script file, at a
minimum, tells the deskphone which application file the deskphone must use. The application file is the
software that has the telephony functionality.
The deskphone uses the script file to determine if it has the proper application file. If the deskphone
determines the proper application file is missing, the deskphone requests an application file download
from the HTTP server. The deskphone then downloads the file and conducts some checks to ensure
that the file was downloaded properly. If the deskphone determines it already has the proper file, the
deskphone proceeds as described in the next paragraph without downloading the application file again.
The deskphone checks and loads the application file, then uses the script file to look for a settings file,
if appropriate. The optional settings file can contain settings you have administered for any or all of the
1600 Series IP Deskphones in your network. For more information about this download process and
settings file, see Chapter 6: Deskphone Software and Application Files.
Step 4: Deskphone and the Call Server
The call server referred to in this step is the Avaya Media Server.
In this step, the deskphone might prompt the user for an extension and password. The deskphone uses
that information to exchange a series of messages with the call server. For a new installation and for full
service, the user can enter the deskphone extension and password. For a restart of an existing
installation, this information is already stored on the deskphone, but the user might have to confirm the
information. The deskphone and the call server exchange more messaging. The expected result is that
the deskphone is appropriately registered and call server data such as feature button assignments are
downloaded.

Error Conditions
Issue 6 August 2014 13
The 1600 Series IP Deskphones support a feature called Unnamed Registration. Unnamed
Registration allows a deskphone to register with the Avaya Media Server without an extension,
assuming theAvaya Media Server also supports this feature. To invoke Unnamed Registration, take no
action. Allow the Extension... prompt to display for 60 seconds without making an entry. The
deskphone automatically attempts to register by means of Unnamed Registration. A deskphone
registered with Unnamed Registration has the following characteristics:
●only one call appearance,
●no administrable features,
●can make only outgoing calls, subject to call server Class of Restriction/Class of Service
limitations, and
●can be converted to normal “named” registration by the user entering a valid extension and
password (that is, logging in).
Note:
Note: Unnamed Registration requires administration on the AvayaAura Communication
Manager system.
You can also administer the deskphone to avoid unnamed registration and remain unregistered if no
extension and password are provided. For more information, see UNNAMEDSTAT in Table 9.
For more information about the installation process, see the Avaya 1600 Series IP Deskphones
Installation and Maintenance Guide.
Error Conditions
Assuming proper administration, most of the problems reported by deskphone users are likely to be
LAN-based. Quality of Service, server administration, and other issues can impact user perception of
IP deskphone performance.
The Avaya 1600 Series IP Deskphones Installation and Maintenance Guide covers possible
operational problems that might be encountered after successful 1600 Series IP Deskphone
installation. The following User Guides also contain guidance for users having problems with specific IP
deskphone applications:
●Avaya 1603/1603SW/1603-I/1603SW-I IP Deskphone User Guide,
Document Number 16-601444.
●Avaya 1608/1608-I IP Deskphone User Guide, Document Number 16-601446.
●Avaya 1616/1616-I IP Deskphone User Guide, Document Number 16-601448.
●Avaya one-X™ Deskphone Value Edition 1600 Series IP Deskphones BM32 Button Module User
Guide, Document Number 16-601450.
