IP Office 6400 Quick Reference Guide
Programmable Buttons
The programmable buttons enable you to access a range of IP Office system features. Some of these
features are available by default, other can only be programmed by your system administrator. Contact your
system administrator for more information.
Admin and ProgA are two functions that enable you to program the most frequently used functions against
DSS keys. The programmable features that are available via Admin and ProgA are:
Admin Name Description Admin Name Description
Acct Account Code Entry Park Call Park to Other Extension
AD Abbreviated Dial Prog Abbreviate Dial Program
Admin Self-Administer SAC Send All Calls
AutCB Automatic Callback Spres AD Suppress
CFrwd Call Forwarding All Timer Timer
CPark Call Park TmDay Time of Day
CPkUp Call Pickup ProgA Name Description
Dir Directory Park Park
DPkUp Directed Call Pickup <User> User
GrpPg Group Paging <Group> Group
HfAns Internal Auto-Answer <Number> Dial Preset Number
HGNS+ Set Hunt Group Night Service
Default Feature Codes
You can access a variety of system features by dialling short codes. The following table shows the default
feature codes. For a full list of your phone’s default feature codes, see the IP Office 6400 Series User Guide.
Replace N, where shown, with an appropriate number. For example, *07*N#, where Nis the extension to
which you want your calls forwarded to, when you have forwarding switched on.
Short Code Description Short Code Description
*01 Forward Unconditional On *15 Call Waiting On
*02 Forward Unconditional Off *16 Call Waiting Off
*03 Forward On Busy On *17 Voicemail Collect
*04 Forward On Busy Off *18 Voicemail On
*05 Forward On No Answer On *19 Voicemail Off
*06 Forward On No Answer Off *26 Clear Call Waiting
*07*N# Forward to Number *27*N# Hold Call Waiting
*08 Do Not Disturb On *30 Call Pick Up Any
*09 Do Not Disturb Off *31 Call Pick Up Group
*10*N# Do Not Disturb Exception Add *32*N# Call Pick Up Extension
*11*N# Do Not Disturb Exception Delete *33*N# Call Queue
*12*N# Follow Me Here *48 Voicemail Ringback On
*13*N# Follow Me Here Cancel *49 Voicemail Ringback Off
*14*N# Follow Me To *57*N# Forward On Busy Number
Further information about Avaya IP Office is available from www.avaya.com/support and also from
http://www.avaya.com/ipoffice/knowledgebase.
Reference: 15-601106
Issue 1 (1 June 2006)
IP Office 6400 Quick Reference Guide
This guide covers the basic functionality of your IP Office 6400 series phone.
For more information on your phone settings and features, see the IP Office 6400 Series User Guide.
The diagram below shows the main phone features:
1 Softkey/Display 8 Message Indicator
2 Exit Exit 9 Volume
3 Prev/Next Page Left/Right 10 Dialling Pad
4 Hold Hold 11 Redial Redial
5 Conf Conference 12 Spkr Speaker
6 Trnsfr Transfer 13 Mute Mute
7 Feature Buttons 14 Menu Menu*
•Not available on the TransTalk MDW 9040
TelephoneMagic.com

IP Office 6400 Quick Reference Guide
Answering Incoming Calls
•Pick up the handset and begin talking.
•When in headset mode, press associated with the alerting call.
Making a Call
1. Pick up the handset or (without picking up the handset) press Spkr.
2. Dial the number, including any outside line digits and/or area codes.
Retrieving Voicemail
•To retrieve your voicemail, dial *17.
Hold
•To place a call on hold, press Hold. An His displayed.
•To retrieve a held call, press corresponding to the held call.
Transferring a Call
1. With the call active, press Trnsfr. The call is placed on hold.
2. Dial the number you want to transfer the call to:
•If the extension is busy or does not answer, press corresponding to the held call.
•If the extension answers and accepts the transfer, press Trnsfr again.
•To transfer without announcing the call (if the line is free), hang up.
Conference
1. During an existing call or conference, press Conf. When you hear a dial tone, dial the other party.
2. If there is no answer, press Hold and then press Conf.
or
If answered, press Conf again. Any call that was put on hold is now put into the conference.
Note: The short codes documented in this guide refer to the use of default short codes only.
IP Office 6400 Quick Reference Guide
Do Not Disturb
•To switch Do Not Disturb on, dial *08. An N is displayed. To switch it off, dial *09.
Mute
•To prevent the other person on the line from hearing you, press Mute.
•To reinstate two-way conversation, press Mute again.
Redial
1. To redial a number dialed, press Redial. The display shows numbers that you have recently dialed.
2. Press
and to move through the stored numbers.
3. Press the key below the number to redial it or, to exit the display without making a call, press Exit.
Diverting Calls
•To divert calls at another extension, dial *12*N# (where Nis your extension number). All calls to your
extension will be diverted to the extension you are using.
To re-direct your calls back to your own extension, dial *13*N#.
•To divert calls at your own extension, dial *14*N# (where Nis the extension to which you want your
calls diverted).
To cancel divert calls from your own extension, dial *14*#.
Call Forwarding
•To set the number to which your calls are forwarded, dial *07*201# (forwarding to 201 in this example).
•To switch Forward Unconditional On, dial *01. A Dis displayed. To switch it off, dial *02.
•To switch Forward On Busy On, dial *03. To switch it off, dial *04.
•To switch Forward On No Answer On, dial *05. To switch it off, dial *06.
