Avaya S9RM Setup guide

Avaya S9RM Uninterruptible Power Systems
Site Preparation,
Installation and Operator’s Manual
www.powerware.com/avaya

Avaya S9RM Uninterruptible Power Systems
Site Preparation,
Installation and Operator’s Manual
www.powerware.com/avaya

US Patent 6,160,722
Requesting a Declaration of Conformity
Units that are labeled with a CE mark comply with the following harmonized standards and EU directives:
SHarmonized Standards: EN 62040-1-1 and EN 50091-2; IEC 60950-1
SEU Directives: 73/23/EEC, Council Directive on equipment designed for use within certain voltage limits
93/68/EEC, Amending Directive 73/23/EEC
89/336/EEC, Council Directive relating to electromagnetic compatibility
92/31/EEC, Amending Directive 89/336/EEC relating to EMC
The EC Declaration of Conformity is available upon request for products with a CE mark. For copies of the EC
Declaration of Conformity, contact:
Eaton Power Quality Oy
Koskelontie 13
FIN-02920 Espoo
Finland
Phone: [phone]
Fax: [phone]
Avaya and the Avaya logo are trademarks of Avaya Inc. and may be registered in certain jurisdictions. Powerware
and ABM are registered trademarks and ConnectUPS is a trademark of Eaton Electrical Inc. HyperTerminal is a
registered trademark of Hilgraeve.
ECopyright 2001–2006 Avaya Inc. All rights reserved. No part of this document may be reproduced in any way
without the express written approval of Avaya Inc.

Class B EMC Statements
FCC Part 15
NOTE This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the following measures:
SReorient or relocate the receiving antenna.
SIncrease the separation between the equipment and the receiver.
SConnect the equipment into an outlet on a circuit different from that to which the receiver is connected.
SConsult the dealer or an experienced radio/TV technician for help.
ICES-003
This Class B Interference Causing Equipment meets all requirements of the Canadian Interference Causing
Equipment Regulations ICES-003.
Cet appareil numérique de la classe B respecte toutes les exigences du Reglement sur le matériel brouilleur du
Canada.
VCCI Notice

Special Symbols
The following are examples of symbols used on the UPS or accessories to alert you to important
information:
RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the
associated warning should be observed.
CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for
additional information, such as important operating and maintenance
instructions.
RJ-45 RECEPTACLE - For 230V models only: this receptacle provides network
interface connections. Do not plug telephone or telecommunications equipment
into this receptacle.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. This product contains sealed, lead-acid batteries and must be
disposed of properly. For more information, contact your local recycling/reuse or
hazardous waste center.
This symbol indicates that you should not discard waste electrical or electronic
equipment (WEEE) in the trash. For proper disposal, contact your local
recycling/reuse or hazardous waste center.

AvayatS9RM UPS Site Preparation, Installation and Operator’s Manual S05147387 Rev C i
Table of Contents
1 Introduction 1.........................................................
2 Safety Warnings 3.....................................................
3 Installation 19..........................................................
Inspecting the Equipment 19................................................................
Connecting the UPS Internal Battery 19........................................................
UPS Setup 20..........................................................................
Rack-Mount Setup 21..................................................................
Tower Setup 22......................................................................
Installing the UPS 25.....................................................................
Remote Emergency Power-off Installation 27....................................................
UPS Rear Panels 29......................................................................
4 Operation 31...........................................................
Turning the UPS On 31....................................................................
Starting the UPS on Battery 31..............................................................
Turning the UPS Off 32....................................................................
Initiating the Self-Test 32..................................................................
Operating Modes 33.....................................................................
Normal Mode 34.....................................................................
Battery Mode 35.....................................................................
Bypass Mode 36......................................................................
Standby Mode 36.....................................................................
5 Configuration 37........................................................
Configuration Mode 37....................................................................
Installing ERM Configurator with a ConnectUPS-X Web/SNMP Card 40.................................
Placing the Card into Serial Pass-Through Mode 40.............................................
Exiting Serial Pass-Through Mode 42.......................................................
6 Additional UPS Features 43...............................................
ConnectUPS-X Web/SNMP Card 43...........................................................
The Alarm Adapter 44....................................................................
Network Transient Protector 46..............................................................
Load Segments 47.......................................................................

TABLE OF CONTENTS
AvayatS9RM UPS Site Preparation, Installation and Operator’s Manual S05147387 Rev C
ii
7 UPS Maintenance 49....................................................
UPS and Battery Care 49..................................................................
Storing the UPS and Batteries 49............................................................
When to Replace Batteries 50...............................................................
Replacing Batteries 50....................................................................
How to Replace Internal Batteries 51.......................................................
How to Replace Extended Battery Modules 52................................................
Testing New Batteries 54..................................................................
Recycling the Used Battery or UPS 54.........................................................
8 Specifications 55.......................................................
9 Troubleshooting 59......................................................
Audible Alarms and UPS Conditions 59........................................................
Silencing an Audible Alarm 59............................................................
Obtaining Service 62.....................................................................

AvayatS9RM UPS Site Preparation, Installation and Operator’s Manual S05147387 Rev C 1
Chapter 1 Introduction
The AvayatS9RM uninterruptible power system (UPS) protects
your sensitive electronic equipment from the most common power
problems including power failures, power sags, power surges,
brownouts, line noise, high voltage spikes, frequency variations,
switching transients, and harmonic distortion.
Power outages can occur when you least expect it and power
quality can be erratic. These power problems have the potential to
corrupt critical data, destroy unsaved work sessions, and damage
hardware — causing hours of lost productivity and expensive repairs.
With the Avaya S9RM, you can safely eliminate the effects of power
disturbances and guard the integrity of your equipment. Figure 1 shows
the Avaya S9RM UPS with an optional Extended Battery Module (EBM).
Figure 1. The Avaya S9RM UPS with Optional EBM
Providing outstanding performance and reliability, the Avaya S9RM’s
unique benefits include the following:
SOnline UPS design with pure sine wave output. The UPS filters and
regulates incoming AC power and provides consistent power to your
equipment without draining the battery.
S2U rack height that conserves valuable rack space.
STwo-in-one form factor for using the UPS in a rack-mount
configuration or as a standalone cabinet.
SABM®technology that uses advanced battery management to
increase battery service life, optimize recharge time, and provide a
warning before the end of useful battery life.
SHours of extended runtime with up to four EBMs or with up to three
Extended Battery Cabinets (EBC48s).

INTRODUCTION
AvayatS9RM UPS Site Preparation, Installation and Operator’s Manual S05147387 Rev C
2
SStart-on-battery capability for powering up the UPS even if utility
power is not available.
SHot-swappable batteries that simplify maintenance by allowing you to
replace batteries safely without powering down the critical load.
SEmergency shutdown control through the remote emergency
power-off (REPO) port.
SNetwork power management with the ConnectUPS -X Web/SNMP
Card, providing SNMP and HTTP capabilities, monitoring through a
Web browser interface, and connection to a twisted-pair Ethernet
(10/100BaseT) network.
SNetwork transient protector that guards your network
communications equipment from surges. Low voltage models can
also protect modems, fax machines, or other telecommunications
equipment.
SAdvanced power management with the Software Suite CD for
graceful shutdowns and power monitoring.
SSequential shutdown and load management through separate
receptacle groups, called load segments.
SBacked by worldwide agency approvals.
