Avaya S9RM Setup guide

Avaya S9RM 3000 VA, 120V Uninterruptible Power Systems
Site Preparation,
Installation and Operator’s Manual
Material Code 700285596
www.avayaups.com

Avaya S9RM 3000 VA, 120V Uninterruptible Power Systems
Site Preparation,
Installation and Operator’s Manual
Material Code 700285596
Issue 1
Copyright 2003 Avaya Inc.
All Rights Reserved

Class A EMC Statements
FCC Part 15
NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
ICES-003
This Class A Interference Causing Equipment meets all requirements of the Canadian Interference Causing Equipment
Regulations ICES-003.
Cet appareil numérique de la classe A respecte toutes les exigences du Reglement sur le matériel brouilleur du Canada.
Special Symbols
The following are examples of symbols used on the UPS to alert you to important information:
RISK OF ELECTRIC SHOCK - Indicates that a risk of electric shock is present and the
associated warning should be observed.
CAUTION: REFER TO OPERATOR’S MANUAL - Refer to your operator’s manual for
additional information, such as important operating and maintenance
instructions.
This symbol indicates that you should not discard the UPS or the UPS batteries
in the trash. The UPS may contain sealed, lead-acid batteries. Batteries must be
recycled.
Avaya and the Avaya logo are trademarks of Avaya Inc. and may be registered in certain jurisdictions. PowerPass and
ABM are registered trademarks and ConnectUPS is a trademark of Powerware Corporation. Microsoft is a registered
trademark of Microsoft Corporation. Netscape is a trademark of Netscape Communications Corporation.
. Copyright 2003 Avaya Inc. All rights reserved. No part of this document may be reproduced in any way without the
express written approval of Avaya Inc.

i
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
TABLE OF CONTENTS
1 Avaya S9RM – The Ultimate Online UPS! 1.............................
2 Safety Warnings 3.................................................
3 Installation 17.....................................................
Inspecting the Equipment 17........................................................
UPS Setup 17..................................................................
Rack-Mount Setup 18..........................................................
Tower Setup 19..............................................................
EBM Installation 23..............................................................
Power Connections 25............................................................
Remote Emergency Power-Off 27....................................................
UPS Rear Panel 28...............................................................
4 Operation 29......................................................
Turning the UPS On 29............................................................
Starting the UPS on Battery 29....................................................
Turning the UPS Off 29...........................................................
Initiating the Self-Test 30..........................................................
Operating Modes 30.............................................................
Normal Mode 31.............................................................
Battery Mode 32.............................................................
Bypass Mode 33..............................................................
Standby Mode 33.............................................................
Sleep Mode 33...............................................................
5 Configuration 35...................................................
Configuration Mode 35...........................................................
6 Additional UPS Features 39..........................................
The ConnectUPS-X Web/SNMP Card 39...............................................
Network Transient Protector 40.....................................................
Load Segments 41...............................................................
7 UPS Maintenance 43...............................................
UPS and Battery Care 43..........................................................
Storing the UPS and Batteries 43..................................................
When to Replace Batteries 43......................................................

Table of Contents
ii Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
Replacing Batteries 44............................................................
How to Replace Extended Battery Modules 44.........................................
How to Replace Internal Batteries 46...............................................
Testing New Batteries 47..........................................................
Recycling the Used Battery 48......................................................
Using the PDM 48...............................................................
8 Specifications 51..................................................
9 Troubleshooting 55.................................................
Audible Alarms and UPS Conditions 55................................................
Silencing an Audible Alarm 55....................................................
Obtaining Service 58.............................................................
Parts List 58...................................................................

1
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
CHAPTER 1
AVAYA S9RM – THE ULTIMATE ONLINE UPS!
The AvayaZS9RM uninterruptible power system (UPS) protects your
sensitive electronic equipment from the most common power problems
including power failures, power sags, power surges, brownouts, line
noise, high voltage spikes, frequency variations, switching transients,
and harmonic distortion.
Power outages can occur when you least expect it and power quality can
be erratic. These power problems have the potential to corrupt critical
data, destroy unsaved work sessions, and damage hardware — causing
hours of lost productivity and expensive repairs.
With the Avaya S9RM, you can safely eliminate the effects of power
disturbances and guard the integrity of your equipment. Figure 1 shows
the Avaya S9RM UPS with an optional Extended Battery Module (EBM).
Figure 1. The Avaya S9RM
Providing outstanding performance and reliability, the Avaya S9RM’s
unique benefits include the following:
:True online design with pure sine wave output. The UPS filters and
regulates incoming AC power and provides consistent power to your
equipment without draining the battery.
:Hours of extended run time with up to four EBMs or with up to three
Extended Battery Cabinets (EBC72s).
:2U rack height conserves valuable rack space.
:Advanced Battery Management (ABM
9
) technology doubles battery
service life, optimizes recharge time, and provides a warning before
the end of useful battery life.

Avaya S9RM – THEULTIMATEONLINEUPS!
2Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
:With the two-in-one form factor, you can use the UPS in a
rack-mount configuration or as a standalone cabinet.
:Advanced power management with the Software Suite CD for graceful
shutdowns and power monitoring.
:Network power managment with the ConnectUPS -X Web/SNMP
Card. This internal card has SNMP and HTTP capabilities as well as
monitoring through a Web browser interface; connects to a
twisted-pair Ethernet (10/100BaseT) network.
:Sequential shutdown and load management through separate
receptacle groups, called load segments.
:Hot-swappable batteries simplify maintenance by allowing you to
replace batteries safely without powering down the critical load.
:Network Transient Protector guards your network communications
equipment from surges, as well as modems, fax machines, or other
telecommunications equipment.
:Emergency shutdown control through the Remote Emergency
Power-Off (REPO) port.
:Start-on-battery capability allows you to power up the UPS even if
utility power is not available.
:Flash memory provides easy upgrades or reconfiguration capability
without requiring a service call.
:The Avaya S9RM is backed by worldwide agency approvals.
Z

3
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
CHAPTER 2
SAFETY WARNINGS
Read the following precautions before you install the UPS.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
This manual contains important instructions that you should follow during installation
and maintenance of the UPS and batteries. Please read all instructions before
operating the equipment and save this manual for future reference.
DANGER
This UPS contains LETHAL VOLTAGES. All repairs and service should be performed
by AUTHORIZED SERVICE PERSONNEL ONLY. There are NO USER
SERVICEABLE PARTS inside the UPS.
WARNING
:This UPS contains its own energy source (batteries). The output receptacles may
carry live voltage even when the UPS is not connected to an AC supply.
:Do not remove or unplug the input cord when the UPS is turned on. This removes
the safety ground from the UPS and the equipment connected to the UPS.
:To reduce the risk of fire or electric shock, install this UPS in a temperature and
humidity controlled, indoor environment, free of conductive contaminants. Ambient
temperature must not exceed 40C (104F). Do not operate near water or
excessive humidity (95% max).
:To comply with international standards and wiring regulations, the total equipment
connected to the output of this UPS must not have an earth leakage current
greater than 1.5 milliamperes.

Safety Warnings
4Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
CAUTION
:Batteries can present a risk of electrical shock or burn from high short-circuit
current. Observe proper precautions. Servicing should be performed by qualified
service personnel knowledgeable of batteries and required precautions. Keep
unauthorized personnel away from batteries.
:Proper disposal of batteries is required. Refer to your local codes for disposal
requirements.
:Never dispose of batteries in a fire. Batteries may explode when exposed to flame.
Sikkerhedsanvisninger
VIGTIGE SIKKERHEDSANVISNINGER
GEM DISSE ANVISNINGER
DENNE BRUGERVEJLEDNING INDEHOLDER VIGTIGE
SIKKERHEDSANVISNINGER
FARE
Denne UPS indeholder LIVSFARLIG HØJSPÆNDING. Alle reparationer og
vedligeholdelse bør kun udføres af en AUTORISERET SERVICETEKNIKER. Ingen af
UPS’ens indvendige dele kan repareres af brugeren.
ADVARSEL!
:Denne UPS indeholder egen energiforsyning (batterier). Udgangsnetstikkene kan
lede strøm, selv når UPS’en ikke er tilsat en AC-energikilde.
:Netledningen må ikke fjernes og stikket må ikke trækkes ud, mens UPS’en er
tændt. Dette fjerner sikkerhedsjorden fra UPS’en og fra det udstyr, der er sat til.
:Installér denne UPS i et temperatur- og fugtighedskontrolleret indendørsmiljø, frit
for ledende forureningsstoffer for at formindske risikoen for brand og elektrisk
stød. Rumtemperaturen må ikke overstige 40C. UPS’en bør ikke betjenes nær
vand eller høj fugtighed (maksimalt 95%).
:I overensstemmelse med internationale normer og bestemmelser for el-installation
må det udstyr, der er forbundet til udgangen af denne UPS, tilsammen ikke
overskride en jordafdelingsspænding på mere end 1,5 milliampere.

Safety Warnings
5
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
ADVARSEL
:Batterier kan udgøre en fare for elektrisk stød eller forbrændinger forårsaget af høj
kortslutningsspænding. De korrekte forholdsregler bør overholdes.
:Korrekt bortskaffelse af batterier er påkrævet. Overhold gældende lokale regler for
bortskaffelsesprocedurer.
:Skaf dig aldrig af med batterierne ved at brænde dem. Batterierne kan eksplodere
ved åben ild.
Belangrijke Veiligheidsinstructies
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
BEWAAR DEZE INSTRUCTIES
DEZE HANDLEIDING BEVAT BELANGRIJKE
VEILIGHEIDSINSTRUCTIES
GEVAAR
Deze UPS bevat LEVENSGEVAARLIJKE ELEKTRISCHE SPANNING. Alle reparaties en
onderhoud dienen UITSLUITEND DOOR ERKEND SERVICEPERSONEEL te worden
uitgevoerd. Er bevinden zich GEEN ONDERDELEN in de UPS die DOOR DE GEBRUIKER
kunnen worden GEREPAREERD.
WAARSCHUWING
:Deze UPS bevat zijn eigen energiebron (batterijen). De uitgangsaansluitingen
kunnen onder spanning staan wanneer de UPS niet op een wisselstroom voeding is
aangesloten.
:Verwijder de ingangsnoer niet of haal de stekker van de ingangsnoer er niet uit
terwijl de UPS aan staat. Hierdoor zou de UPS en uw aangesloten apparatuur geen
aardebeveiliging meer hebben.
:Teneinde de kans op brand of elektrische schok te verminderen dient deze UPS in
een gebouw met temperatuur- en vochtigheidregeling te worden geïnstalleerd,
waar geen geleidende verontreinigingen aanwezig zijn. De omgevingstemperatuur
mag 40C niet overschrijden. Niet gebruiken in de buurt van water of bij zeer hoge
vochtigheid (max. 95%).
:Om aan de internationale normen en bedradingsvoorschriften te voldoen mag de
gehele apparatuur die op de uitgang van deze UPS is aangesloten, geen
aardlekstroom van meer dan 1,5 milliampère hebben.

Safety Warnings
6Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
OPGELET
:Batterijen kunnen gevaar voor elektrische schok of brandwonden veroorzaken als
gevolg van un hoge kortsluitstroom. Volg de desbetreffende aanwijzingen op.
:De batterijen moeten op de juiste wijze worden opgeruimd. Raadpleeg hiervoor uw
plaatselijke voorschriften.
:Nooit batterijen in het vuur gooien. De batterijen kunnen ontploffen.
Tarkeita Turvaohjeita
TÄRKEITÄ TURVAOHJEITA - SUOMI
SÄILYTÄ NÄMÄ OHJEET
TÄMÄ OPAS SISÄLTÄÄ TÄRKEITÄ TURVAOHJEITA
VAARA
Tämä UPS sisältää HENGENVAARALLISIA JÄNNITTEITÄ. Kaikki korjaukset ja huollot
on jätettävä VAIN VALTUUTETUN HUOLTOHENKILÖN TOIMEKSI. UPS ei sisällä
MITÄÄN KÄYTTÄJÄN HUOLLETTAVIA OSIA.
VAROITUS
:Tämä UPS sisältää oman energialähteen (akuston). Ulostuloliittimissä voi olla
jännite, kun UPS ei ole liitettynä verkkojännitteeseen.
:Älä poista tai irrota sisääntulojohtoa, kun UPS on kytkettynä. Tämä poistaa
turvamaadoituksen UPS-laitteesta ja siihen liitetystä laitteistosta.
:Vähentääksesi tulipalon ja sähköiskun vaaraa asenna tämä UPS sisätiloihin,
joissa lämpötila ja kosteus on säädettävissä ja joissa ei ole virtaa johtavia
epäpuhtauksia. Ympäristön lämpötila ei saa ylittää 40 C. Älä käytä lähellä vettä
ja vältä kosteita tiloja (95 % maksimi).
:Kansainväliset normit ja johdotusmääräykset vaativat, että kaikkien tämän
UPS-laitteen ulostulokytkentöjen yhteinen maavuotovirta ei ylitä
1,5 milliampeeria (mA).

Safety Warnings
7
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
VARO
:Akusto saattaa aiheuttaa sähköiskun tai syttyä tuleen, jos akusto kytketään
oikosulkuun. Noudata asianmukaisia ohjeita.
:Akusto täytyy hävittää säädösten mukaisella tavalla. Noudata paikallisia
määräyksiä.
:Älä koskaan heitä akkuja tuleen. Ne voivat räjähtää.
Consignes de sécurité
CONSIGNES DE SÉCURITÉ IMPORTANTES
CONSERVER CES INSTRUCTIONS
CE MANUEL CONTIENT DES CONSIGNES DE SÉCURITÉ
IMPORTANTES
DANGER!
Cet onduleur contient des TENSIONS MORTELLES. Toute opération d’entretien et de
réparation doit être EXCLUSIVEMENT CONFIÉE A UN PERSONNEL QUALIFIÉ AGRÉÉ.
AUCUNE PIÈCE RÉPARABLE PAR L’UTILISATEUR ne se trouve dans l’onduleur.
AVERTISSEMENT!
:Cet onduleur renferme sa propre source d’énergie (batteries). Les prises de sortie
peuvent être sous tension même lorsque l’onduleur n’est pas branché sur le
secteur.
:Ne pas retirer le cordon d’alimentation lorsque l’onduleur est sous tension sous
peine de supprimer la mise à la terre de l’onduleur et du matériel connecté.
:Pour réduire les risques d’incendie et de décharge électrique, installer l’onduleur
uniquement à l’intérieur, dans un lieu dépourvu de matériaux conducteurs, où la
température et l’humidité ambiantes sont contrôlées. La température ambiante ne
doit pas dépasser 40 C. Ne pas utiliser à proximité d’eau ou dans une atmosphère
excessivement humide (95 % maximum).
:Afin d’être conforme aux normes et règlements internationaux de câblage, le
courant de fuite à la terre de la totalité du matériel branché sur la sortie de
l’onduleur ne doit pas dépasser 1,5 mA.

Safety Warnings
8Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
ATTENTION!
:Les batteries peuvent présenter un risque de décharge électrique ou de brûlure par
des courts-circuits de haute intensité. Prendre les précautions nécessaires.
:Une mise au rebut réglementaire des batteries est obligatoire. Consulter les
règlements en vigueur dans votre localité.
:Ne jamais jeter les batteries au feu. L’exposition aux flammes risque de les faire
exploser.
Sicherheitswarnungen
WICHTIGE SICHERHEITSANWEISUNGEN AUFBEWAHREN.
DIESES HANDBUCH ENTHÄLT WICHTIGE
SICHERHEITSANWEISUNGEN.
WARNUNG
Die USV führt lebensgefährliche Spannungen. Alle Reparatur- und Wartungsarbeiten
sollten nur von Kundendienstfachleuten durchgeführt werden. Die USV enthält keine
vom Benutzer zu wartenden Komponente.
ACHTUNG
:Diese USV ist mit einer eigenen Energiequelle (Batterie) ausgestattet. An den
Ausgangssteckdosen kann auch dann Spannung anliegen, wenn die USV nicht an
einer Wechselspannungsquelle angeschlossen ist.
:Das Eingangskabel nicht entfernen oder abziehen, während die USV eingeschaltet
ist, weil hierdurch die Sicherheitserdung von der USV und den daran
angeschlossenen Geräten entfernt wird.
:Um die Brand- oder Elektroschockgefahr zu verringern, diese USV nur in Gebäuden
mit kontrollierter Temperatur und Luftfeuchtigkeit installieren, in denen keine
leitenden Schmutzstoffen vorhanden sind. Die Umgebungstemperatur darf 40C
nicht übersteigen. Die USV nicht in der Nähe von Wasser oder in extrem hoher
Luftfeuchtigkeit (max. 95 %) betreiben.
:Um internationale Normen und Verdrahtungsvorschriften zu erfüllen, dürfen die an
den Ausgang dieser USV angeschlossenen Geräte zusammen einen
Erdschlußstrom von insgesamt 1,5 Milliampere nicht überschreiten.

Safety Warnings
9
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
VORSICHT!
:Batterien können aufgrund des hohen Kurzschlußstroms Elektroschocks oder
Verbrennungen verursachen. Die entsprechenden Vorsichtsmaßnahmen sind
unbedingt zu beachten.
:Die Batterien müssen ordnungsgemäß entsorgt werden. Hierbei sind die örtlichen
Bestimmungen zu beachten.
:Batterien niemals verbrennen, da sie explodieren können.
ÐñïåéäïðïéÞóåéò ÁóöÜëåéáò
ÓÇÌÁÍÔÉÊÅÓ ÏÄÇÃÉÅÓ ÁÓÖÁËÅÉÁÓ
ÖÕËÁÎÔÅ ÁÕÔÅÓ ÔÉÓ ÏÄÇÃÉÅÓ
ÔÏ ÐÁÑÏÍ ÅÃ×ÅÉÑÉÄÉÏ ÐÅÑÉÅ×ÅÉ ÓÇÌÁÍÔÉÊÅÓ
ÏÄÇÃÉÅÓ ÁÓÖÁËÅÉÁÓ
ÊÉÍÄÕÍÏÓ
Áõôü ôï UPS ðåñéÝ÷åé ÈÁÍÁÔÇÖÏÑÁ ÔÁÓÇ. ¼ëåò ïé åðéóêåõÝò êáé ïé
óõíôçñÞóåéò ðñÝðåé íá ßíïíôáé ÌÏÍÏ ÁÐÏ ÅÎÏÕÓÉÏÄÏÔÇÌÅÍÏ ÃÉÁ
ÔÇ ÓÕÍÔÇÑÇÓÇ ÐÑÏÓÙÐÉÊÏ. Ôï UPS ÄÅÍ ÐÅÑÉÅ×ÅÉ ÊÁÍÅÍÁ
ÅÎÁÑÔÇÌÁ ÐÏÕ ÍÁ ÌÐÏÑÅÉ ÍÁ ÅÐÉÓÊÅÕÁÓÔÅÉ ÁÐÏ ÔÏ ×ÑÇÓÔÇ.
ÐÑÏÅÉÄÏÐÏÉÇÓÇÊ
: Ôï óõ êåêñéìÝíï UPS ðåñéÝ÷åé ôç äéêÞ ôïõ ðç Þ åíÝñ åéáò
(óõóóùñåõôÝò). Ïé ñåõìáôïäüôåò åîüäïõ ìðïñåß íá Ý÷ïõí åíåñ ü ôÜóç
áêüìç êáé üôáí ôï UPS äåí åßíáé óõíäåäåìÝíï óå ðç Þ
åíáëëáóóüìåíïõ ñåýìáôïò (AC).
: Ìçí â Üæåôå áðü ôçí ðñßæá ôï êáëþäéï ôñïöïäïóßáò üôáí ôï UPS åßíáé
áíïé÷ôü. Ì áõôü ôïí ôñüðï áöáéñåßôå ôç åßùóç áóöáëåßáò áðü ôï
UPS êáé áðü ôïí åîïðëéóìü ðïõ åßíáé óõíäåäåìÝíïò ìå ôï UPS.
: Ãéá íá ìåéþóåôå ôïí êßíäõíï ðõñêá éÜò Þ çëåêôñïðëçîßáò,
å êáôáóôÞóôå ôï óõ êåêñéìÝíï UPS óå åóùôåñéêü ÷þñï ìå
åëå ÷üìåíç èåñìïêñáóßá êáé õ ñáóßá, ï ïðïßïò íá ìçí ðåñéÝ÷åé
á þ éìá õëéêÜ. Ç èåñìïêñáóßá ðåñéâÜëëïíôïò äåí ðñÝðåé íá
îåðåñíÜåé ôïõò 40
 C. Ìç ÷ñçóéìïðïéåßôå ôï UPS êïíôÜ óå íåñü Þ
õðåñâïëéêÞ õ ñáóßá (ìÝ éóôç ôéìÞ: 95%).

Safety Warnings
10 Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
: Ãéá íá óõìöùíåß ìå ôá äéåèíÞ ðñüôõðá êáé ôïõò êáíïíéóìïýò
êáëùäßùóçò, ôï ñåýìá äéáññïÞò ðñïò ôç ç ïëüêëçñïõ ôïõ åîïðëéóìïý,
ðïõ åßíáé óõíäåäåìÝíïò ìå ôçí Ýîïäï ôïõ óõ êåêñéìÝíïõ UPS, äåí
ðñÝðåé íá åßíáé ìå áëýôåñï áðü 1,5 mA.
ÐÑÏÓÏ×Ç
: Ïé óõóóùñåõôÝò ìðïñåß íá ðñïêáëÝóïõí çëåêôñïðëçîßá Þ Ý êáõìá
áðü õøçëü ñåýìá âñá÷õêõêëþìáôïò. ËáìâÜíåôå ôéò êáôÜëëçëåò
ðñïöõëÜîåéò.
: Áðáéôåßôáé óùóôÞ äéÜèåóç ôùí óõóóùñåõôþí. Äåßôå ôïõò ôïðéêïýò
êáíïíéóìïýò ðïõ áöïñïýí ôéò áðáéôÞóåéò äéÜèåóÞò ôïõò.
: ÐïôÝ ìçí ðåôÜôå ôïõò óõóóùñåõôÝò óôç öùôéÜ, éáôß ìðïñåß íá
åêñá ïýí.
Avvisi di sicurezza
IMPORTANTI ISTRUZIONI DI SICUREZZA
CONSERVARE QUESTE ISTRUZIONI
QUESTO MANUALE CONTIENE IMPORTANTI ISTRUZIONI DI
SICUREZZA
PERICOLO
la TENSIONE contenuta in questo gruppo statico di continuità è LETALE. Tutte le
operazioni di riparazione e di manutenzione devono essere effettuate
ESCLUSIVAMENTE DA PERSONALE TECNICO AUTORIZZATO. All’interno del gruppo
statico di continuità NON vi sono PARTI RIPARABILI DALL’UTENTE.
AVVERTENZA
:Questo gruppo statico di continuità contiene una fonte di energia autonoma (le
batterie). Le prese di uscita possono condurre tensione energizzata quando il
gruppo statico di continuità non è collegato con una fonte di alimentazione a
corrente alternata.
:Non rimuovere nè scollegare il cavo di ingresso quando il gruppo statico di
continuità è acceso poichè in tal modo si disattiverebbe il collegamento a terra di
sicurezza del gruppo statico di continuità e dell’apparecchiatura ad esso collegata.

Safety Warnings
11
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
:Per ridurre il rischio di incendio o di scossa elettrica, installare il gruppo statico di
continuità in un ambiente interno a temperatura ed umidità controllata, privo di
agenti contaminanti conduttivi. La temperatura ambiente non deve superare i
40C. Non utilizzare l’unità in prossimità di acqua o in presenza di umidità
eccessiva (95% max).
:Per conformità con gli standard internazionali e con le norme in merito al
cablaggio, tutta l’apparecchiatura collegata con l’uscita del gruppo statico di
continuità non deve avere una corrente di dispersione di terra superiore a
1,5 milliampere.
ATTENZIONE
:Le batterie possono presentare rischio di scossa elettrica o di ustioni provocate da
alta corrente dovuta a corto circuito. Osservare le apposite istruzioni.
:Le batterie devono essere smaltite in modo corretto. Per i requisiti di smaltimento
fare riferimento alle disposizioni locali.
:Non gettare mai le batterie nel fuoco poichè potrebbero esplodere se esposte alle
fiamme.
Viktig Sikkerhetsinformasion
FARLIG
Denne UPS’en inneholder LIVSFARLIGE SPENNINGER. All reparasjon og service må
kun utføres av AUTORISERT SERVICEPERSONALE. BRUKERE KAN IKKE UTFØRE
SERVICE PÅ NOEN AV DELENE i UPS’en.
FARLIG
:Denne UPS’en har en egen energikilde (batterier). Stikkontaktene kan være
strømførende selv om UPS’en ikke er tilsluttet en vekselstrømforsyning.
:Strømforsyningskabelen må ikke fjernes eller trekkes ut når UPS’en er på, slik at
ikke sikkerhetsjordingen fjernes fra UPS’en og det utstyret som er forbundet
med den.
:For å redusere fare for brann eller elektriske støt, bør denne UPS’en installeres i et
innendørs miljø med kontrollert temperatur og luftfuktighet som er fritt for
ledende, forurensende stoffer. Romtemperaturen må ikke overskride 40C. Den må
ikke brukes i nærheten av vann eller ved meget høy luftfuktighet (95% maks.).

Safety Warnings
12 Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
:Alt utstyr som er forbundet med utgangen av denne UPS’en må ikke ha en sterkere
total lekkasjestrøm enn 1,5 milliampere for å være i overensstemmelse med
internasjonale standarder og forkablingsbestemmelser.
FORSIKTIG
:Batterier kan forårsake elektriske støt eller forbrenning på grunn av høy
kortslutningsstrøm. Følg instruksene.
:Batterier må fjernes på korrekt måte. Se lokale forskrifter vedrørende krav om
fjerning av batterier.
:Kast aldri batterier i flammer, da de kan eksplodere, hvis de utsettes for åpen ild.
Regulamentos de Segurança
INSTRUÇÕES DE SEGURANÇA IMPORTANTES
GUARDE ESTAS INSTRUÇÕES
ESTE MANUAL CONTÉM INSTRUÇÕES DE SEGURANÇA
IMPORTANTES
CUIDADO
A UPS contém VOLTAGEM MORTAL. Todos os reparos e assistência técnica devem ser
executados SOMENTE POR PESSOAL DA ASSISTÊNCIA TÉCNICA AUTORIZADO. Não
há nenhuma PEÇA QUE POSSA SER REPARADA PELO USUÁRIO dentro da UPS.
ADVERTÊNCIA
:Esta UPS contém sua própria fonte de energia (baterias). Os receptáculos de saída
podem conter voltagem ativa quando a UPS não se encontra conectada a uma
fonte de alimentação de corrente alternada.
:Não remova ou desconecte o cabo de entrada quando a UPS estiver ligada. Isto
removerá o aterramento de segurança da UPS e do equipamento conectado.
:Para reduzir o risco de incêndios ou choques elétricos, instale a UPS em ambiente
interno com temperatura e umidade controladas e livres de contaminadores
condutíveis. A temperatura ambiente não deve exceder 40C. Não opere próximo a
água ou em umidade excessiva (máx: 95%).
:Para estar de acordo com os padrões internacionais e os regulamentos de fiação, o
equipamento total conectado à saída desta UPS não deve ter uma corrente de fuga
à terra maior que 1,5 miliampères.

Safety Warnings
13
Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
PERIGO
:As baterias podem apresentar o risco de choque elétrico, ou queimaduras
provenientes de alta corrente de curto-circuito. Observe as instruções adequadas.
:Siga as instruções apropriadas ao desfazer-se das baterias. Consulte os códigos do
local para maiores informações sobre os regulamentos de descarte de produtos.
:Nunca jogue as baterias no fogo, porque há risco de explosão.
Предупреждения по мерам безопасности
ВАЖНЫЕ УКАЗАНИЯ ПО МЕРАМ ЕЗОПАСНОСТИ
СОХРАНИТЕ ЭТИ УКАЗАНИЯ
ДАННОЕ РУКОВОДСТВО СОДЕРЖИТ ВАЖНЫЕ
УКАЗАНИЯ ПО МЕРАМ ЕЗОПАСНОСТИ
ОПАСНО
В данном ИБП имеются СМЕРТЕЛЬНО ОПАСНЫЕ НАПРЯЖЕНИЯ.
Все работы о ремонту и обслуживанию должны вы олняться ТОЛЬКО
УПОЛНОМОЧЕННЫМ ОБСЛУЖИВАЮЩИМ ПЕРСОНАЛОМ.
Внутри ИБП нет узлов, ОБСЛУЖИВАЕМЫХ ПОЛЬЗОВАТЕЛЕМ.
ПРЕДУПРЕЖДЕНИЕ
:Данный ИБП содержит собственные источники энергии
(аккумуляторы). На выходных розетках может иметься на ряжение,
даже когда ИБП не одключен к сети еременного тока.
:Не отсоединяйте сетевой шнур и не извлекайте его вилку из розетки
ри включенном ИБП. При этом защитное заземление отключается
от ИБП и от оборудования, одключенного к ИПБ.
:Для снижения о асности ожара или оражения электрическим
током устанавливайте ИБП в закрытом омещении с
контролируемыми тем ературой и влажностью, в котором
отсутствуют роводящие загрязняющие вещества. Тем ература
окружающего воздуха не должна ревышать 40С. Не
экс луатируйте устройство около воды или в местах с овышенной
влажностью (макс. 95%).

Safety Warnings
14 Avaya S9RM 3000 VA, 120V UPS Site Preparation, Installation and Operator’s Manual :700285596 Issue 1
:Для обес ечения соблюдения требований международных
стандартов и требований к разводке электрических це ей,
суммарная величина тока утечки на землю всего оборудования,
одключенного к выходу ИБП, не должна ревышать
1,5 миллиам ера.
ОСТОРОЖНО
:Аккумуляторы могут вызвать о асность оражения электрическим
током или ожога от тока короткого замыкания. Соблюдайте
соответствующие меры редосторожности.
:Необходимо соблюдать равила утилизации аккумуляторов.
Обратитесь к местным нормативным актам за информацией о
требованиях к утилизации.
:Никогда не бросайте аккумуляторы в огонь. Аккумуляторы могут
взорваться од воздействием огня.
Advertencias de Seguridad
INSTRUCCIONES DE SEGURIDAD IMPORTANTES
GUARDE ESTAS INSTRUCCIONES
ESTE MANUAL CONTIENE INSTRUCCIONES DE SEGURIDAD
IMPORTANTES
PELIGRO
Este SIE contiene VOLTAJES MORTALES. Todas las reparaciones y el servicio técnico
deben ser efectuados SOLAMENTE POR PERSONAL DE SERVICIO TÉCNICO
AUTORIZADO. No hay NINGUNA PARTE QUE EL USUARIO PUEDA REPARAR dentro
del SIE.
ADVERTENCIA
:Este SIE contiene su propia fuente de energía (las baterías). Los receptáculos de
salida pueden transmitir corriente eléctrica aun cuando el SIE no esté conectado a
un suministro de corriente alterna (c.a.).
:No retire o desenchufe el cable de entrada mientras el SIE se encuentre
encendido. Esto suprime la descarga a tierra de seguridad del SIE y de los equipos
conectados al SIE.
