AVLink H3S-01W User manual

HDMI to 3G-SDIs
Conversion Box
H3S-01W
USER MANUAL V1.0
H3S-01W
Package Contents-
1 H3S-01W Unit
1 User manual
1 Power adapter DC 12V
2 Screws
4 foot pads
1 SDI cable for Balden 1694A 1.2m
Any thing missed, please contact with your vendor.
Introduction
The H3S-01W Converter connect computer with HDMI
connector to 3G-SDI monitor or projector. The converter
changes your HDMI signal to 3G-SDI graphic signal.
Features
Use Panel Link digital technology.
Compliant with the specification of HDMI
Support high-resolution display up to 1080P@60Hz
(25-165MHz).
Inter-locked power plug for DC supply stably.
Only supports PCM audio. No supports compressed
audio.
Specifications
Function H3S-01W
Input Connector 1x HDMI (Female)
Output Connector 1x BNC(Female)
75ΩInterlocking Socket
Input HDMI support 1080P@60Hz(Max.)
Output 3G-SDI support
[email protected], 625i@50,
720p@50/59.94/60,
1080i@50/59.94/60,
[email protected]/24/25/29.97/30,
1080p@50/59.94/60
SDI Standards SD-SDI , HD-SDI & 3G-SDI
HDMI Cable Distance
(Single end) 10 m (Max.)
Power Adapter (Min.) DC 12V
Housing Metal
Weight 333g
Dimensions (LxWxH) 150x92x25mm
Note:
Different cable qualify might effect upon the maximum
resolution and cable distance.
-1-
Technical Specifications Output Signal
Pin # Signal Pin # Signal
1 TMDS Data 2+ 11 TMDS Clock Shield
2 TMDS Data 2 Shield 12 TMDS Clock -
3 TMDS Data 2- 13 CEC
4 TMDS Data 1+ 14 Reserved
(N.C. on device)
5 TMDS Data 1 Shield 15 SCL
6 TMDS Data 1- 16 SDA
7 TMDS Data 0+ 17 DDC/CEC Ground
8 TMDS Data 0 Shield 18 +5 Power
9 TMDS Data 0- 19 Hot Plug Detect
10 TMDS Clock+
FRONT VIEW
1. “HDMI In” Port
2. Control DIP Switch
3. Audio ON LED
4. Video Support LED
5. Power LED
6. Input Power Jack
REAR VIEW
1. “3G-SDI out” Port
-2-

Installation
1. Connect the H3S-01W video input HDMI connector with
HDMI cable from different video equipment.
2. Connect the BNC extension cable between the monitor
and the “3G-SDI Out” port of H3S-01W.
3. Connect the power cord and turn on the H3S-01W.
4. Turn on the HDMI video source device.
Support Vedio Mode
Analog Resolution Frequency(Hz)
525i(NTSC) 1440x480 59.94
625i(PAL) 1440x576 50
720p 1280x720 50/59.94/60
1080i 1920x1080 50/59.94/60
1080p 1920x1080 23.98/24/25/29.97/30
1080p 1920x1080 50/59.94/60
DIP Switch Settings
1 OFF HDMI AUDIO OFF ON HDMI AUDIO ON
2 OFF GROUP 1-2,1-8CH ON GROUP 3-4,9-16CH
OFF,OFF Group1, 1-2 CH_Group3, 9-10 CH
OFF,ON Group1, 3-4 CH_Group3, 11-12 CH
ON ,OFF Group2, 5-6 CH_Group4, 13-14 CH
3,4
ON ,ON Group2, 7-8 CH_Group4, 15-16 CH
5 Reserved
*Note1.
Only transmits 2 channel audio from HDMI to SDI at once,
even with multi-channel HDMI PCM audio.
© C&C TECHNIC TAIWAN CO., LTD. All rights reserved.
Trademarks:
All the companies, brand names, and product names
referred to this manual are the trademarks or
registered trademarks belonging to their respective
companies.
-3-
