With SwitchView SC, you can safely switch between as many as eight classified and
unclassified computers, all from one keyboard, monitor and mouse. The SwitchView
SC design makes it impossible to transfer data between the connected computers ---
an important factor for a user who may access secure and non-secure networks from
one point of contact. The Cybex SwitchView SC from Avocent is the only KVM switch
evaluated to NIAP Common Criteria EAL 4 security requirements.
Available in 4-port and 8-port models, the SwitchView SC puts secure access and
control at your fingertips. Plus, the 8-port model doubles as a monitor stand, leaving
zero footprint on the desktop.
When combined with Avocent's LongView extension technology, critical computers
and other related assets can be located in secure (locked) areas, providing controlled
access with the SwitchView SC.
SwitchView SC
Enhanced Secure KVM Switching
Switch between multiple computers without compromising
network security.
FEATURES AND BENEFITS
•Agency Approval. Evaluated to NIAP
Common Criteria EAL 4 security
requirements.
•Controlled KVM Switching. Separate
I/O processors for control KVM switching
and access to computers.
•Cable Management. Avocent’s locking
cables provide secure connections and
reduce cable volume.
•Custom-Designed Firmware. Custom-
designed encrypted internal firmware
made in the U.S.
•Standard PS/2 Protocol. Standard
PS/2 protocol is maintained to avoid the
possibility of any external device detecting
the presence of the SwitchView SC.
•Clears Buffer. Automatically clears the
keyboard buffer immediately after data
is transmitted through the switch, so no
data is ever left in the switch.
•Reliable Performance. 8-port model
uses an internal power supply for
optimal processing performance.
•Space Saving. Compact 4-port model
saves space on the desktop and 8-port
model doubles as monitor stand for zero
footprint on the desktop.
SwitchView provides secure access and control to classified and unclassified computers, all
from one switch.
The Power of Being There ®

ENVIRONMENTAL / POWER / HARDWARE
10040-SC (4-port)
•Operating Temperature - 41° (5°C) to 104° (40°C)
•Storage - -4° (-20°C) to 122° (50°C)
•Power - 6 VDC @ 700 mA (optional)
•Computer - IBM PC/AT, PS/2 and 100% compatible
•Video Modes - VGA and SVGA, maximum resolution
1600x1200 @ 75 Hz
•Peripherals - PS/2 keyboard, PS/2 mouse, Microsoft
IntelliMouse (PS/2 only)
10080SC-AM (8-port)
•Operating Temperature - 41° (5°C) to 104° (40°C)
•Storage --4° (-20°C) to 122° (50°C)
•Power - Input Power: 8.0 W; Operating Voltage: 100 - 230 VAC;
Power Frequency: 50 - 60 Hz
•Computer - IBM PC/AT, PS/2 and 100% compatible
•Video Modes - VGA, SVGA, (XGA, XGA-II with adaptor),
maximum resolution 1280x1024 @ 60 Hz
•Peripherals - PS/2 keyboard, PS/2 mouse, Microsoft
IntelliMouse (PS/2 only)
SWITCHVIEW SC SPECIFICATIONS
MECHANICAL
10040-SC (4-port)
•Height - 1.9˝ (4.83 cm)
•Depth - 11˝ (27.94 cm)
•Width - 8.1˝ (20.6 cm)
•Weight - 0.9 lbs. (0.4 kg)
•Style - Desktop
4991 Corporate Drive, Huntsville, AL 35805
TEL [phone] FAX [phone]
www.avocent.com
Avocent, the Avocent logo, The Power of Being There and SwitchView are trademarks
of Avocent Corporation. All other marks are the property of their respective owners.
Copyright © 2003. Avocent Corporation.
0403-SVSC-TP-02
SwitchView SC security features let you switch safely
between secured and non-secured networks
10080SC-AM (8-port)
•Height - 1.7˝ (4.5 cm)
•Depth - 8.5˝ (21.6 cm)
•Width - 17.2˝ (43.7 cm)
•Weight - 6.3 lbs. (2.9 kg)
•Style - Desktop or rack mount
STANDARDS
•Approved Agency
10040-SC (4-port)
UL 1950, CSA C22.2 No. 950, EN60950
FCC part 15B, EN55022, EN50082
10080SC-AM (8-port)
UL, cUL, FCC, IC and CE
•NSA Requirements
NIAP Commm Criteria Tested to EAL 4
ORDERING DETAILS
10040-SC Single user, 4-port
10080SC-AM Single user, 8-port
•Cable Assemblies
10040-SC (4-port)
CPS2-6A - 6 feet color-coded VGA, PS/2 keyboard and mouse
10080SC-AM (8-port)
CIFCA-4 - 4 feet single sheath VGA, PS/2 keyboard and mouse
CIFCA-8 - 8 feet single sheath VGA, PS/2 keyboard and mouse
CIFCA-15 - 15 feet single sheath VGA, PS/2 keyboard and mouse
CIFCA-30 - 30 feet single sheath VGA, PS/2 keyboard and mouse
RMK-39 - 19 inch rack mount kit
WARRANTY
•Two Year
GSA NUMBER
• GS-35F0264K
TCP/IP
TCP/IP
TCP/IP
Non-Secured
Networks
SwitchView SC
Secured
Networks
Security User
TCP/IP
