Avvio L660 User manual

1
A LL R I G HT S RE SE R VE D
© 2015. All rights reserved! No replication allowed!
This handbook is for reference only. Software might upgrade
any time, and no further notifications will be announced.
SAFETY PRECAUTIONS
Please read the following safety guidelines before using the
device.
Do not use the phone while you are driving.
Do not place magnetic storage media near your
phone. Radiation from the phone may erase the
information stored on them.
Keep your phone and its accessories away from
children.
Cell phone can interfere with the functioning of
medical devices such as hearing aids or
pacemakers. Contacts having active medical
implants should keep their cell phone at least 15
cm away from the implant.
Permanent hearing loss may occur if you use
earphones or headphones at high volume.
Use a wireless hands-free system (headphone/
headset) with a low power Bluetooth emitter.
Make sure the cell phone has a low SAR.
Keep your calls short or send a text message
(SMS) instead. This advice applies specially to
children adolescents and pregnant women.
Use cell phone when the signal quality is good.

2
T A B LE O F C O N T E NT S
ALL RIGHTS RESERVED......................................1
TABLE OF CONTENTS .........................................2
1. UNDERSTANDING YOUR DEVICE....................3
1.1 DEVICE OVERVIEW .......................................................4
2. INSTALLING CARDS ........................................5
2.1 INSTALLING CARDS & BATTERY......................................5
2.2 POWERING ON/OFF THE DEVICE ...................................6
3. SYSTEM GUIDE ................................................7
3.1 MAIN SCREEN OPERATING ............................................7
3.2 USING YOUR PHONE.....................................................7
3.3 CALLING ......................................................................8
3.4 MESSAGING.................................................................8
3.5 CONTACTS ...................................................................8
4. HOME SCREEN...............................................10
4.1 CUSTOMIZING SCREEN ...............................................10
5. MULTIMEDIA ..................................................11
5.1 FILE MANAGER ..........................................................11
5.2 CAMERA....................................................................11
5.3 GALLERY....................................................................11
5.4 FM RADIO..................................................................11
5.5 BROWSER..................................................................11
6. APPLICATIONS & UTILITIES ..........................12
6.1 CALCULATOR .............................................................12
6.2 CLOCK .......................................................................12
7. SPECIFICATIONS ...........................................13
ENVIRONMENTAL CONCERN ............................14

3
1 . U N D ER S T A N D I N G Y O U R D E V I C E
AVVIO L660 is a smart phone, such as Android Version 5.1,
Wi-Fi, 1.0G Quad Core Processor, 8.0 MP Digital Camera, etc.

4
1. 1 DE V I CE OVERVIE W
Position of Keys
1. Earphone Jack
2. Earpiece
3. Volume Control Key
4. Touch Screen
5. Back Key
6. Home Key
7. Record Recent
8. Front Camera Lens
9. USB Port
10. Power Key
11. Flash
12. Battery Cover
13. Speaker
14. Camera Lens

5
2. I N S T AL L I N G C A R D S
2.1 IN STA LLI NG C ARD S & B AT TE RY
Please switch off your device before inserting or removing the
SIM card and memory card.
Installing SIM Card
In order to install battery and SIM card in the device, please
follow the steps mentioned below:
Switch off your device.
Remove the battery cover and battery of the device.
Insert the SIM cards.
Installing Memory Card
Your device supports T-Flash card, which is a multimedia
memory card used to multiply the memory of the device. The
T-flash card is small and should be pulled out and installed
carefully and prudently in order to avoid any kind of damage.
Please follow the steps mentioned below to install the
memory card in the device:
Switch off your device.
Remove the battery cover and battery of the device.
Insert the T-Flash memory card into the slot.
Charging the Battery
The device prompts a warning tone and message stating
insufficient battery when the battery power is low.

6
Please follow the instructions mentioned below to charge
your device:
Plug the connector of the charger into the jack of the
device.
Plug the charger into a standard AC wall outlet.
Charging……. Fully Charged…….
You should fully charge the battery before using the device
for the first time. It is recommended to charge the battery for
three hours before using the device for the first time.
2.2 PO WERING ON /OFF THE DEVI CE
Turning On the Device
After installing the SIM card/s and charging the battery, you
are now ready to turn on your device.
Long press and hold the Power Key to turn on the
device.
The first screen that appears is known as the
Home/idle Screen.
Drag up the unlock icon to release the screen.
If the screen turns off, then short press the Power
Key to turn on the display.
Turning Off the Device
Press and hold the Power Key.
A pop-up window appears, select Power off.

7
3 . S Y S T EM G U I D E
3.1 MA I N S CREE N OPERATI NG
Notification Panel
The table below lists various icons that might appear on the
Notification Panel of the device.
Network intensity of SIM card 1 or SIM
card 2
Battery level of the device
New short message
Missed call notification
Headset is plugged in
USB connected
Wi-Fi is connected
Bluetooth is activated
4G network is in use
3.2 US I NG YOUR PHONE
Enter main menu
In idle mode press the key to enter the main menu on
the desktop and press the (Home) key to return.
Enter sub menu
In the main menu click the icon to select the sub menu, press
the Back key to return to the previous menu ,and press the
Home key to return to the Home screen.
To view recently used APP
Touch the view the recent operation record.Drag the
horizontal to delete the record.

8
3.3 CALLI NG
To Make Calls
If the icon appears on the screen, then you can make or
receive calls.
To make a call, please follow the steps mentioned below:
Select phone.
Tap , enter the phone number using the
on-screen keyboard.
Tap to delete a wrong number. Tap and hold it
to erase the entire number.
After entering phone number, tap .
To end the call, tap .
3. 4 ME S S A GING
For using your device for sending and receiving of SMS (Short
Message Service) and MMS (Multimedia Message Service), go
to Main Menu and then select Messaging.
Creating a Message
Tap Compose new message.
In “Type name or number”field; enter the recipient’s
phone number.
Type message in the “Type text message”field.
Tap to Send.
Receiving and Managing Messages
When you send and receive messages to or from a contact,
these messages are grouped as a message thread. A message
thread looks like an exchanged conversation.
3.5 CONT A CTS
You can save information such as name, phone numbers, etc.
for each contact listed in your Contacts menu.
To add a Contact
Enter the Main Menu select Contacts.
Tap add to contacts .

9
Store the contact to SIM card or Phone contact.
You can fill out as many or as little fields as you’d like
for the contact.
Tap to save the contact.

10
4 . H O M E S C R E E N
4.1 CUST OMIZ ING SCREE N
The device features a touchscreen with idle displays and
access to utilities at just one-touch. So you can swipe right or
left to navigate through various screens accessing your
favorite features without entering the main menu. Each
screen can be customized by adding various widgets,
shortcuts and folders.
Shortcuts
In order to add a shortcut on the screen: Long press on the
desired application to add on the screen.
Widgets
Save time with live updates right on Home screen and get all
of your personalized updates at one place.
Setting the wallpaper
You can customize the wallpaper of your Home screen with
default wallpaper or with pictures taken from your device.
Long press the Home screen > WALLPAPERS.
Rotating Your Mobile Phone Screen
The orientation of most screens will change to
landscape or portrait view when you rotate your
phone sideways.
On the Home screen, tap > Settings > Display >
“When device is rotated”screen to disable this
function.
