Awesomatix A12 User manual

INSTRUCTION MANUAL
A12
1/12-SCALE ELECTRICON-ROAD CAR

2
BEFOREYOUSTART
The A12car is the high-quality,innovative1/12-scale on-road car and should bebuilt only bypersons with previous experience
building R/C model racing cars.
This is not atoy and is not intended for use bychildren without direct supervision of a responsible, knowledgeable adult.
Read the instruction manual carefully and fully understand it before beginning assembly. If you have any problems or
questions please do not hesitate to contact the Awesomatixteam at [e-mail]. If,for any reason,you
decide that you do not want your A12car you must not begin assembly.
Your A12car cannot be returned to UAB Awesomatix for a refund or exchange if it has been fully or partially assembled.
This kit is a radio controlled model racing product and could cause harm and personal injury.
The A12car isdesigned for use on r/c car race tracks. It should not be used in general public areas.
UAB Awesomatix accept no responsibility for any injuries caused by making or using this kit.
Due to policy of continuous product development the exact specifications of the kit may vary.
UAB Awesomatix do reserve all rights to change any specifications without prior notice. All rights reserved.
INTRODUCTION
Congratulations on purchasing your Awesomatix car!
The A12car was produced by UAB Awesomatix company.
GENERALPRECAUTIONS
•Many of the items in this kit are small enough to be accidentally swallowed and are therefore potential choking hazards, making them potentially fatal.
Please ensure that when assembling the kit you do so out of the reach of small/young children.
•Take care when building, as some parts may have sharp edges.
•Please read this manual carefully to understand which ancillary items (tools, electrics, electronics etc) are used with this kit.
Awesomatix Innovations accept no responsibility for the operation of any such ancillary items.
Exercise care when using tools and sharp instruments.
• Follow the operating instructions for the radio equipment at all times.
•
• Never touch rotating parts of the car as this may cause injury.
Keepthewheelsofthemodeloffthegroundwhencheckingtheoperation of the radio equipment.
• To prevent any serious personal injury and/or damage to property, be responsible when operating all remote controlled models.
• The model car is not intended for use on roads or areas where its operation can conflict with or disrupt pedestrian or vehicular traffic.
•
• Do not run your car in poor light or if it goes out of sight. Any impairment to your vision may result in damage to your car or, worse, injury to others
or their property.
• As a radio controlled device, your car is subject to radio interference from things beyond your control. Any such interference may cause a loss of
control of your car so please consider this possibility at all times.
When not using RC model, always disconnect and remove battery.
• Insulate any exposed electrical wiring to prevent dangerous short circuits.
•
Take maximum care in wiring, connecting and insulating cables. Make sure cables are always connected securely.
Check connectors for if they become loose and if so reconnect them securely. Never use R/C models with damaged wires.
A damaged wire is extremely dangerous and can cause short-circuits resulting in fire.
ASSEMBLYNOTES
You can find the useful tips of A12assembling and the A12 editablesetupsheeton the Internet site:
http://site.petitrc.com/reglages/awesomatix/setupa12/
EQUIPMENT RECOMMENDED(NOT INCLUDED)
Radio Transmitter
• Radio Receiver
• Electronic Speed Control
• Steering Servo
•
• Servo Saver
•Electric Motor
Pinion Gear (64 or 48 Pitch)
•
Spur Gear (64 or 48 Pitch)
• 1SLi-Po Battery
•
• 1/12 scale Body Shell
1/12 scale Wheels and Tires
•
TOOLS RECOMMENDED(NOT INCLUDED)
1.5mm, 2.0mm, 2.5mm Hex Drivers
•
• 12mm Wrench
• Sewing Needle or Sharp Pin
• Callipers
Hobby Knife
• Ride Height Gauge
•
• ThinCA Glue
Thread Lock
•
• Double Side Tape
• Silicone Oil for Dampers
Joint Grease
•

3
SH1.5W
SF3X10
AM1206
STEP1
Note:SH1.5Wis 7.4x3x1.5mm alloyspacer.
C1204
C1205
SF3X10
SH1.5W
STEP2
SB3X5ALx2
AM1203
SB3X5ALx2
Note:
SB3X5ALis 3x5mm alloyscrew.

4
AM1205
STEP3
AM1205
SF3X6
SF3X6
AM1204
STEP4
SS3X4
OR125
OR125
SH1.5W
ST1205
ST1205
ST1209M
ST1209L
Note:SS3X4set screw tipsshouldjust
slightly touchAM1204chassissurface.
ST1205OR125(5x1.2mm o-ring)
Rear ball joint Front ball joint
SH1.5W
ST1209L
ST1205
ST1209L
OR125(5x1.2mm o-ring)
Note:Add small amount of a joint grease
between ST1205and ST1209M/L.
Use blue “soft” thread lock for SS3X4screw!

5
STEP5
STEP7
STEP6
Note:Add a bit of silicone oil into groove of ST1202.
OR153V(3x1.5mm o-ring)
ST1202
OR153V
Note: Lubricate OR153Vvia silicone oil.
Stretch OR153Vvia fingers and putit on ST1202 (to avoid the
damage of o-ring please don’t use a sharp edged tool for this!).
Note:Add ~0,3g of50 000...100 000 cst silicone oil
into cavity of ST1204 damper case.We recommend
100000 cst silicone oilas the base setup.
Keep ST1204 upright for several
minutes until all oil reaches
the bottom of the cavity.
ST1204
Note:Insert ST1202 damper rotor into ST1204damper case slowly.
After the lower face of the ST1202reaches the oil in the bottom of the cavity, the
ST1202will need an additional force to be pushed fully into the proper position. We
recommend using a rubber band or OR230o-ring as shown in the picture. The oil will
start to come up towards the top of the cavity of the ST1204as the ST1202is pushed
further into that cavity by the o-ring. When the OR153Vo-ring and the ST1204damper
are close to flush (almost fully inserted), please use a sewing needed or a sharp pin
along the recess of the ST1202to move the o-ring out of position and allow more oil to
be pushed out from the ST1204case. Using this needle or pin will allow the ST1202to
be fully seated and sit perfectly flush with the ST1204damper case.
ST1204
ST1202
OR230
or
rubber band
needle/pin
recess
on ST1202
M3screws
Note:It is very important to assemble
the damper without any air inside!
Thesiliconeoil has to occupy thegap
betweenthedamper’srotorand case
fully.Itcan take somepractice.

STEP9
6
STEP8
Repeat the STEPS 5,6,7 for other side of ST1204and check that both ST1202 rotors reached the desirable position
(flush with the ST1204face)
Note:These faces of ST1204
and ST1202should coincide.
SB3X5
SB3X5
SS3X10
Note: SS3X10 set screw is used for adjusting of the rear downstop.
An exact position of this SS3X10 screw will be set later during setup
of the car. Please use blue “soft’’ thread lock for this screw.

7
STEP10
STEP11
ST1201
ST1201
ST1201 3mm Ball Stud
ST1203
SF3X6x2
SF3X5x2
AM1202
AM1207
Note:ST1201 ball studs should be
placed into slotsof ST1202 rotors.

8
STEP12
AT1203
SS3X5
SS3X5
SB3X12
SB3X12
SH0.25...SH1.0
SH0.25
SH0.5
SH1.0
SH1.75
SH0.25
SH0.5
SH1.0
SH1.75
SH0.25...SH1.75
Note:Assortment of SHshimsisused for
settingofthe desired rear ride height.
Pressboth B168ZZ bearings into AT1203rear beam.
Use blue ”soft” thread lock for SS3X5screws!
STEP13
B168ZZ
OR15
Preparetwo B168ZZ bearings
with OR15o-rings.
Stretch OR151x5mm o-ring and
putit on B168ZZ ball bearing.
SS3X5
SS3X5
Short wheel base
Long (+1mm)wheel base
Shortand+1mm longer wheelbase
settings are possible.
Note position of SS3X5 screws.

9
STEP14
Note:ST1208steering block posts provide 4 deg caster.
Optional ST1208-C5posts provide 5 deg caster.
AT1206
AT1206
ST1208
1,5mm hexdriver
or optional
RHG4.2probe
SB3X5
SB3X5
SB3X6
SB3X6
1,5mm hexdriver
or optional
RHG4.2probe
Thetip of 1,5mm hexdriveror optional
RHG4.2probe isused for alignment of
the appropriate holes of ST1208
and C1205.
ST1208
Alignment of the appropriate holes of ST1208and C1205for camber settings.
0.75 deg camber 1.0 deg camber
1.25 deg camber 1.5 deg camber 1.75 deg camber

10
STEP16
STEP15
DT1202
AT1201
ST24
AT1204
SH1.0
SH0.1x 0..2
OR155SI x0..1
DT1202
AT1201
SH0.1x 0...2
ST1207
Noteorientation!
longerpartofST1207
shorterpartofST1207Note orientation of DT1202
SB3X5
SH12S-0.2x1..7
SH12S-0.2x1..7
SB3X5
SPR12FS
SPR12FS
SH12S-0.2x0..6
SH12S-0.2x0..6
Note orientation of DT1202
Top SH12S-0.2shims
Bottom SH12S0.2shims
Note:SPR12FSFront Soft Springs (Silver) and SPR12FMFront Medium Springs (Gold) come in the A12kit.
SH12S-0.20.2mm thickness shims are used to set the
front spring preload and the front ride height.
The front damping of the steering blocks
is adjusted via:
1) Number of the o-rings installed (0,1 or 2).
2) O-ring’s preload by SH0.1 6x8x0.1mm shims.
3) Lubricant for o-rings.
4) Amount and viscosity of the damping fluid
inside the steering blocks.
Oilfilled steeringblocksalso
need toaspace for exessive
oiltoberemoved,tobleed
thesteeringblock. Likethe
reardamper,use aneedle
tocreateagap between the
o-ringand the steeringblock
toallowexcess oiltobe
removed.
This cavity can be filled
with different oils or
greases.
OR155SI x0..1As initial setting we recommend to
use only one lower OR155SIoring
lubricated by joint grease without
preload by SH0.1 shims.
Another option is to use no orings
and only thick grease on the
ST1207 in the steering blocks,
depending on track conditions.
ST1207
Attention!When installing SH12S0.2 shims,make
sure they surround the ST1207but not below or
above the ST1207end faces.

11
STEP17
STEP18
STEP19
ST24-4.0x2
SB3X5AL
Servosaver (not included!)
C1201
SB3X5AL
SANWASRGservo (not included!)
Servosaver (not included!)
Miniservo(not included!)
Up to 35x30x15mm mini
servos can be installed.
ST24-4.0x2
SB3X5AL
C1201
SB3X5AL
AT1202
AT1202
SH1.0
SH1.0
SB3X6
SB3X6
SH0.25
SH0.25
Installation oftheSANWASRGservo.
Installation ofthestandard mini servo.
Installation oftheSANWASRGservo.Installation ofthe15mm thick mini servo.
SB3X5
SB3X5
SB3X8
SB3X8
SH1.0
SH1.0
SH1.0
SH1.0
SH0.5
SH0.5
P13-4 P1213
AT25-2
P13-4
P1213
AT25-2
Install both steeringlinks.
Left steeringlinkRight steeringlink
Note: ST24-4.0are 4.0mm ball studs. ST24-4.0fit P12134.0mm ball cups.
Note: P12134.0mm ball cups are used for the inner steeringjoints.

12
STEP20
STEP21
P06-1
ST1211
C1203
P06-1
Note:Press P06-1collars into C1203 from lower face
of C1203 and apply a drop of CA glue to set them.
CA glue (not included)
Rear body holdersassembling.
SPR12S0.5
Initial position of the side spring.
ST1211 spring retainer should
be screwed fully.
Snap the spring on the groove of ST1211
retainer and rotate the spring to find the mutual
angular position that provides a perfect
alignment of the spring and retainer.
Assemble the left body holder in the same manner as the
right body holder and install both body holders on the
chassis.
SB3X10x4
SH4.0(6x3x4mm spacer)x4
Note:Additional spacers can be used together with SH4.0to
change the side springs operational range.
Using the outer hole for ST1211 retainer
provides about a 50% increase in the
effective spring rate against side roll.
Use this hole for the side spring as the base setting.

13
STEP22
STEP23
SB3X10
SB3X10
SF3X10
SF3X10
P14-2
P14-2
P14-2
P14-2
P1215
Note:Usethin double
sided tape to secure
P1215foam bumper on
C1204bumper plate.
SH0.25
SH0.25
SB3X10 SB3X8
Motor (not included)
AT1215 OR91or OR915
Note:UseOR919x1mm o-ring with the thick
spur gears. UseOR9159x1.5mm o-ring with
the thinner spur gears (TC-style spur gears).
Note:Tighten AT1215 nut via12mm wrench.
Please don’t overtighten AT1215 nut!
STA1212
Spurgear(not included)
AT1215
with
OR91or
OR915
Note:The sum of the 64P spur+pinion teeth should be within 112-120 range
for short wheel base and within112-125 range for +1mm longer wheel base.

14
STEP24
Note:The second SC25X8 M2.5x8 screw is used for
perfect axial balancing of the left wheel hub.
SC25X8
SC25X8
AT1207
SH12R0.5
SH12R0.5
C1206
Note:Optional ST1212 steel axle can beused
instead ofC1206carbon axle.
SC25X8
AT1208
SB3X6
SB3X5AL x2
Spur gear (not included)
SB3X5AL x2
SB3X6
Note:TwoSB3X5ALM3x5 alloyscrew with one SB3X6M3x6 steel
screw are used for perfect axial balancing of the right wheel hub.
SH12R2.0
SH12R3.5
SH12R2.0
Note:The second SC25X8 M2.5x8 screw is used
for perfect axlebalancing of the left wheel hub.
SH12R3.5
Note:The set of SH12R*** spacers shown ensures
correct initial centering of the rear axle.
Carbon Spool set CS-1 (optional).

15
STEP25
STEP27
STEP26
B156
B156
SB3X5
SC3X5x3
or
SC3X6x3
SH12F0.5
Pinion gear
(not included)
Install:
Speed controller (not included),
Receiver (not included),
Battery (not included),
Transponder (not included).
Front 1/12 wheel
(not included)
Rear 1/12 wheel
(not included)
Note:Combination of SH12F0.5spacers
on both sides of the front wheel is used
for the front width adjustment.
Note:Use SC3X5or SC3X6depending of the rear rims chosen.
Some rims may need optional 3x8 mm screws (not included).
Note:The sum of the 64P spur+pinion teeth should
be within 112-120 range for short wheel base and
within 112-125 range for +1mm longer wheel base.

16
RHG4.2Ride Height Gauge (optional)
ST1215RHGSpacer
ST1214RHGProbe
AT1210 RHGIndicator
“+1” RHG Spacer position for ride height
measuring within 4.0 - 5.2 mm range.
“+1,5” RHG Spacer position for ride height
measuring within 4.5 - 5.7mm range.
RHG4.2gauge is designed for setting and measuring the ride height under rear damper of the
A12car (DRH-Damper Ride Height) and can bealso used for setting and measuring of the front
ride height (FRH) and the rear ride height (RRH).
RHG4.2gauge provides a 3.0- 4.2mm range for ride height measuring without ST1215 spacer.
With ST1215 spacer the gauge provides a 4.0- 5.2mm and 4.5- 5.7mm ranges (positions “+1”
and “+1.5”of ST1215 spacer).
TheDRH- ride height under rear damper measuring.
TheRRH- rear ride height measuring.TheFRH- front ride height measuring.

17
Setting oftheDRH-therideheightunder rear damper.
The ride height under rear damper (DRH)is set via preloadof two side coil springs SPR12Sin
conjunction withtheoptional additional preloadvia set screws in the two sidebeams AM1205.
These beams act as springs when the screws in them press on the AM1204chassis plate.
A12setupsheet includes two values forthe rear ride height. DRH1shows the ride height resulting
from side spring pressure only, without the use of AM1205side beams. DRHride height is the final
ride height of the car (which can be a combination of both side springs and side bars to reach this final
desired height). For example, DRH1 (damper ride height set with only side spring pressure) will equal
DRH when side beams are not being used, as there is no additional side beam pressure.
Setting oftheRear Droop.
AM1205 side beams act as an additional spring when these set screws are set to touch
the AM1204 outer plate. The rearmost position of the set screws provides the stiffest
vertical suspension rate, and the front most position the softest vertical suspension rate.
These side beams can also be used without any set screws for a small increase in the
cars overall vertical stiffness. Please use blue “Soft” thread lock on any set screws used.
Adjusting of SS3X10 set screw depth (DroopScrewDepth)
is used for setting of the rear suspension droop (RearDroop).
DroopScrewDepth can be measured via calipers or via
counting of the number of turns the screw is screwed into
damper’s case. Every turn of the thread is 0,5mm in depth.
So for example, 4full turns of SS3X10 screw starting
from position when the lower face of the screw
coincides with the lower face of the damper
corresponds to 2mm DroopScrewDepth.
Enter DroopScrewDepthvalue into the
A12editable setup sheet. The rear droop
value will be calculated automatically based
on the DRHand RRH data.
DroopScrewDepth
SS3X10
ST1204 damper case

18
When using big tires,youwill needto use shimsunder theC1205 to obtain the
desiredrideheight. Placing shimsunder thesteering block will not besufficient
to lower therideheightto proper heightwithlarger tire sizes,so please use this
additional methodofadding shimsunder theC1205
C1205
SH0.25...SH1.0 x7

NAME
COUNTRY
RACE
TRACK
DATE TEMPERATURE AIR / TRACK
/
TRACK CONDITION
TRACTION
TIRES
ADDITIVE TIME min min
MOTOR
SERVO BATTERY
SPUR PINION ROLLOUT
STEER.TRAVEL IN ° OUT °
BODY
F/R WEIGHT DISTRIBUTION %
RECEIVER
ESC RADIO
ESC SETTING
BEST LAPTIME QUALIF./ FINAL POSITION /
SETUP SHEET
TOTAL WEIGHT g
A12
FRONT REAR
BRAND
TYPE
DIAMETER
SERVOSAVER
TRACK WIDTH
FRONT mm
REAR mm
RIDE HEIGHT
FRONT (FRH) mm
UNDER DAMPER (DRH1)mm
UNDER DAMPER (DRH)mm
REAR (RRH) mm
FRONT DROOP mm
REARDROOP mm
SERVO POSITION LEFT RIGHT
BATTERY PLUGS FRONT BACK
ESC POSITION LEFT RIGHT
mm mm
STEERING HUB POSTS
ST1208
ST1208-C5
OTHER
SUSPENSION PLATE
C1205
C1205-ZT
C1205AL
C1205AL-ZT
OTHER
REAR AXLE
SSS SPOOL
CS-1 SPOOL
CARBON
STEEL
BALL DIFF
LOOSE
MEDIUM
TIGHT
TOE OUT °
OUTDOOR INDOOR CARPET
TECHNICAL MIXED FAST
LOW MEDIUM HIGH
ASPHALT
FOAM BUMPER
P1215
OTHER
GEAR DIFF
BRAND
OIL
g
g
g g
DAMPER OIL
SERVO PLATE
C1201
C1201-ZT
AM1205
YES
NO
BODY HOLDER SHIMS mm
WHEEL BASE
SHORT
LONG
BUMPSTEER SHIMS mm
STEERING BLOCKS
AT1204
AT1204-ZT
OTHER
RIDE HEIGHT SPACERS mm
SIDE BEAM
SCREWS
SIDE SRINGS
SPR12S-C0.5
SPR12S-C0.4
OTHER
FRONT HUBSSETUP
SPRING SPR12FS SPR12FM SPR12FH
TOPSHIMS mm pcs
BOTTOM SHIMS mm pcs
O-RING TYPE
GREASE
FLUID
O-RINGS 0pcs 1pcs 2pcs
CAMBER
0.75 deg
1.00 deg
1.25 deg
1.50 deg
1.75 deg
OTHER
COMMENTS:
VERSION 1.0
°C °C
FRONT REAR
TIME
BUMPY FLAT
mm
DROOP SCREW DEPTH
1.20
3.6
3.6
1
1
0.00
2

20
Parts # Description Parts # Description
AM1202 Motor Mount SPR12S0.5 Side Spring C0.5
AM1203 Battery Plate SPR05 Body Clip
AM1204 Chassis Plate B156 3/16x5/16x1/8 Flanged Bearing
AM1205 Side Beam B168 1/4x3/8x1/8 Flanged Bearing
AM1206 Front Nut SH12S-0.2 Spring Shim 0.2mm
AM1207 Left Bulkhead SH12F0.5 Front Axle Spacer 0.5mm
AT1201 Steering Block Nut SH12R0.5 Rear Axle Spacer 0.5mm
AT1202 Servo Post SH1.5W 7.4x3x1.5mm Spacer
AT1203 Rear Beam SH12R2.0 Rear Axle Spacer 2.0mm
AT1204 Steering Block SH12R3.5 Rear Axle Spacer 3.5mm
AT1206 Servo Plate Post SH0.1 6x8x0.1mm Shim
AT1207 Left Hub SH0.25 6x3x0.25mm Spacer
AT1215 Spur Nut SH0.5 6x3x0.5mm Spacer (Silver)
AT25-2 Turnbuckle39mm x 2 SH1.0 6x3x1.0mm Spacer (Gray)
DT1202 Steering Washer SH4.0 6x3x4.0mm Spacer
ST1201 3mm Ball Stud OR155SI 1.5x5mm O-Ring Silicone
ST1202 Damper Rotor OR230 2x30mm O-Ring
ST1203 Downstop Rod OR15 1x5mm O-Ring
ST1204 Damper Case OR125 1.2x5mm O-Ring
ST1205 Ball Cup OR153V 1.5x3mm O-Ring Viton
ST1207 Steering BlockTube OR91 9x1mm O-Ring
ST1208 Steering Block Post OR915 9x1.5mm O-Ring
ST1209-M Ball Stud SC25X8 M2.5x8 Cap Head Screw
ST1209-L Ball Stud Long SS3X4 M3x4 Set Screw
ST1211 Spring Retainer SS3X5 M3x5 Set Screw
ST24-4.0 4.0mm Ball Stud SS3X10 M3x10 Set Screw
ST24 4.8x6mm Ball Stud SC3X5 M3x5 Cap Head Screw
STA1212 Composite Axle SC3X6 M3x6 Cap Head Screw
P1215 Foam Bumper SB3X5 M3x5 Button Head Screw
P13-4 Ball Cup SB3X6 M3x6 Button Head Screw
P1213 Ball Cup 4.0 mm SB3X8 M3x8 Button Head Screw
P06-1 Insert SB3X10 M3x10 Button Head Screw
P14-2 Body post SB3X12 M3x12 Button Head Screw
C1201 Servo Plate SF3X5 M3x5 Flat Head Screw
C1203 Body Holder SF3X6 M3x6 Flat Head Screw
C1204 Bumper Plate SF3X10 M3x10 Flat Head Screw
C1205 Suspension Plate SB3X5AL M3x5 Alloy Screw
SPR12FS Front Spring Soft STS-A12 A12 Stickers Sheet
SPR12FM Front Spring Medium SIO100K 100k silicone oil
Parts # Description
RHG 4.2 Ride Height Gauge
CS-1 Carbon Spool set
AT1204-ZT Steering Block Zero Trail
AT1208 Right Hub
ST1208-C5 Steering Hub Post 5 Deg
ST1208-C6 Steering Hub Post 6 Deg
ST1216 Balance Weight 5 g
ST1212 Spring Steel Axle
C1205-ZT Suspension Plate Zero Trail
C1201-ZT Servo Plate Zero Trail
C1206 Carbon Axle
C1205AL Suspension Plate Alloy
OR155PU 1.5x3mm O-Ring PU
SPR12FH Front Spring Hard
SPR12S0.4 Side Spring C0.4
SH12R5.5 Rear Axle Spacer 5.5mm
SC25X7AL 2.5x7 Cap Head Screw Alloy
Optional parts
Spare parts
