USER MANUAL
AX2065A
acve vercal array loudspeaker
KEY FEATURES
• High output line array element • Transmission Line back loading for clean mid-bass reproducon
• Compact size, very good output-to-weight rao • Natural sound Transmission Line HF projecon wave-forming device
• High quality, low compression, low distoron HF driver • 96KHz / 40 bit floang point CORE processing with PRONET remote control
• Very stable horizontal coverage • Digitally controlled Class D amplifier module with SMPS
INTRODUCTION
The AX2065A Vercal Line Array element is designed for a wide range of sound reinforcement applicaons where a flexible and easy to use vercal
array systems is needed. The AX2065A has been designed both for rental live sound applicaons and for fixed installaons and has been engineered
for the simplest use possible but without sacrificing anything in sound quality and performance.
The high frequency range is reproduced by a low-distoron compression driver, equipped with very light-weight
Titanium diaphragms and a special new suspension design for
very natural sound. A transmission line wave-forming waveguide
has been used to load the HF driver, in order to provide a detailed
and natural sound and to achieve a long-distance HF projecng
capacity.
The two 6.5” woofers are back loaded by a short hybrid
transmission line that minimizes the effect of the box resonances
and eliminates the “boxy” mid-bass sound commonly obtained from regular bassreflex enclosures.
The AX2065A is processed by 40bit, 96kHz floang point CORE DSP and powered by DA SERIES digital
power modules, a new generaon of CLASS D power amplifier with digitally-controlled SMPS. The
DA module employed for powering the AX2065A delivers in an ultra-compact package a maximum
power of 2000W and each AX2065A is able to power an addional passive AX2065P module through
the available power output on the back panel. This feature will allows to assemble very compeve
hybrid soluons both for rental and installaon applicaons.
TECHNICAL SPECIFICATION
AcousƟcal Remote Controls PRONET control soware
System type
Line Array Element
Short Transmission Line LF Back Loading
Acousc Transmission Line HF Waveguide
Network protocol CANBUS
Amplifier Type Class D with Variable Switching Frequency
and SMPS
Low frequency transducer Two 6.5” (165 mm), 1.5” (38 mm) aluminium
voice coil, 16Ωeach, paralleled
Output Power 2x 1000 W
Mains Voltage Range (Vac) 230 V~ ±15% or 115 V~ ±15% 50/60 Hz
High frequency transducer
One 1.4” driver, 2.5” (64 mm) edgewound
voice coil, tanium diaphragm,
8Ωeach, paralleled
Mains Connector PowerCon® (NAC3MPA + NAC3MPB)
Consumpon* 700 W (nominal) 1700 W (max)
IN / OUT Connectors Neutrik XLR-M / XLR-F / Speakon NL4MP
Frequency response (±3 dB) 80 Hz – 18 kHz (Processed) IN / OUT Network Connectors ETHERCON® (NE8FAV)
Horizontal Coverage Angle 110° (-6 dB) Mechanical
Vercal Coverage Angle 12° (-6 dB) Width 583 mm (22.95”)
Maximum Peak SPL @ 1m 129 dB Height 244 mm (9.60”)
Electrical Depth 481 mm (18.93”)
Input Impedance 20 kΩbalanced Taper angle 5°
Input Sensivity +4 dBu / 1.25 V Construcon 15 mm, reinforced Phenolic Birch
Signal Processing CORE processing, 96kHz / 40bit floang
point SHARC DSP, 24 bit AD/DA converters
Paint High resistance, water based paint
Suspension system
Direct access Controls
4 Presets: Standard, Long Throw, Down Fill-
Single Box, User.
Network Terminaon, GND Link
Front Suspension Aluminium Fast Link structure with ¼ Fast Pin
Back Suspension High Strength Steel with ¼ Fast Pin
Net Weight 22.5 Kg (49.6 lbs.)
* Nominal consumpƟon is measured with pink noise with a crest factor of 12
dB, this can be considered a standard music program.
revision 2014-11-10

MECHANICAL DRAWING
OPTIONAL ACCESSORIES
AXCASE05 Carrying Case for 4 box unit + Flying Bar AX2065P Passive vercal array loudspeaker
AXCASE06 Carrying Case for 4 box unit USB2CAN PRONET network converter
NAC3FCA Neutrik Powercon® BLUE PLUG KPTSW215 Fly bar for Axiom AX2065 and SW215 Loudspeakers
NAC3FCB Neutrik Powercon® WHITE PLUG KPTAX2065 Fly bar for Axiom AX2065 only
NE8MCB Neutrik Ethercon PLUG AXFEETKIT Kit Of 6pcs BOARDACF01 M10 foot for stacked installaon
NC3MXXBAG Neutrik XLR-M KPAX265 Pole Adaptor
NC3FXXBAG Neutrik XLR-F KP010 0° to 10° lt adaptor
SW215A Acve Subwoofer DHSS10M20 Sub-Speaker ø35mm Pole with M20 screw
SW215FA Flyable Acve Subwoofer RAINCOV2065 Rain cover for input sockets
see hƩp://www.axiomproaudio.com/ for detailed descripƟon and other available accessories.
SPARE PARTS
NAC3MPA Neutrik Powercon® BLUE SOCKET 91DSPKT3 Input & DSP module with panel assembly
NAC3MPB Neutrik Powercon® WHITE SOCKET 98AXM6W16 6.5’’ woofer - 1.5” VC
94SPI2265 Locking Pin for AX2265 98DRI2065 1.4’’ - 2.5” compression driver
PLG716 Straight Shackle 16 mm for Fly bar 98MBN2065 tanium diaphragm for 1.4” driver
91AMD2065 Power amplifier module with mechanical assembly
48.1 cm
18.93"
58.3 cm
22.95"
24.4 cm
9.60"
5°
14.5 cm
5.70"
KPAX265
MAX 2x AX2065
1x SW215
KP010
DHSS10M20
AX2065 used as convenƟonal system

I/O AND CONTROL OPERATIONS
MAINS IN - Powercon® NAC3FCA power input connector (blue). To switch the amplifier on, insert the Powercon®
connector and turn it clockwise into the ON posion. To switch the amplifier off, pull back the switch on the connector
and turn it counter-clockwise into the POWER OFF posion.
WARNING! In the case of product failure or fuse replacement, disconnect the unit completely from the mains
power. The power cable must only be connected to a socket corresponding to the specificaƟons indicated on
the amplifier unit. The power supply must be protected by a suitably rated thermo-magneƟc breaker. Preferably
use a suitable switch to power on the whole audio system leaving the Powercon® always connected to each
speaker, this simple trick extend the life of the Powercon® connectors.
MAINS OUT - Powercon® NAC3FCB power output connector (grey). This is connected
in parallel with the MAINS ~ / IN. The maximum load applicable depends on the mains
voltage. With 230V~ we suggest to link a maximum of 4 AX2065A loudspeakers, with
120V~ we suggest to link a maximum of 2 AX2065A loudspeaker.
INPUT - Audio signal input with locking XLR connector. It has a fully electronically balanced
circuitry including AD conversion for the best S/N rao and input headroom.
LINK - A direct connecon from the input connector to link other speakers with same
audio signal.
ON - This LED indicates power on status.
PROT - This red LED lights when the amplifier module is in protect mode for an internal
fault and, consequently, the amplifier is muted.
SIGN/LIMIT - This LED lights in green to indicate
the presence of the signal and lights in red when an
internal limiter reduces the input level.
GND LIFT - This switch lithe ground of the balanced
audio inputs from the earth-ground of the amplifier
module.
PRESET BUTTON - This buon has two funcon:
1) Pressing it while powering on the unit:
ID ASSIGN the internal DSP assigns a new ID to the unit for the PRONET
remote control operaon. Each loudspeaker must have a unique
ID to be visible in the PRONET network. When you assign a new
ID, all the other loudspeakers with the ID already assigned must
be ON and connected to the network.
2) Pressing it with the unit ON you can select the DSP PRESET. The selected PRESET
is indicated by the corresponding LED:
STANDARD This PRESET is suitable for vercal flown arrays that may range
from 4 to 8 boxes or for the centre region of a bigger flown array.
It can be used also for stacked arrays.
LONG THROW This PRESET can be used in arrays bigger than 6 or 8 boxes and
loaded in the top 1 or 2 boxes in order to obtain a more even
distribuon of the sound pressure, especially if they point very far away or to the upper deck of a large theatre.
DOWN FILL / This PRESET, which features a much smoother high frequency response, can be loaded in the boom boxes (usually 1 or 2
SINGLE BOX boxes) of a large flown array, in order to reach conveniently the audience close to the stage. This preset could be very useful
also when the box is used just on its own as a Front Fill element in the front of very large stages.
USER This LED lights when the USER PRESET is loaded. This preset corresponds to USER MEMORY no. 1 of the
DSP and, as a factory seng, it’s the same to STANDARD. If you want to modify it, you have to connect
the unit to a PC, edit the parameters with PRONET soware and save the PRESET into USER MEMORY no.
1. Note: see also the PRONET example further on this manual.
NETWORK IN/OUT - These are a standard RJ45 CAT5 connectors (with oponal NEUTRIK NE8MC RJ45 cable connector carrier),
used for PRONET network transmission of remote control data over long distance or mulple unit applicaons.
TERMINATE - In a PRONET network the last loudspeaker device must be terminated (with an inner load resistance) especially
in a long run cabling: press this switch if you want to terminate the unit.
POWER OUT - AX2065A is able to power an addional passive AX2065P module through the available power output on the
back panel.
WARNING: connect a single AX2065P module only.

POWER AMPLIFIERS
The AX2065A is powered by DA SERIES digital power modules, a new generaon of CLASS D power amplifier with digitally-controlled SMPS.
The innovave technology used for these amplifiers (including also the use of a variable switching frequency) offers performances at the top of
the range, such as a superior sound definion at any audio frequency, very high dynamics also for low level signals and very low distoron even at
the maximum power The superior sound quality can be compared with top-of-the-range AB-class analog systems, while the DA modules feature
a higher dynamics, very compact size and light weight and efficiency above 90%. The DA module employed for powering the AX2065A deliver
in an ultra-compact package a maximum power of 2000W, 1000W are delivered to the internal speakers, the other 1000W are delivered to the
AX2065P connected in parallel using the POWER OUT speakon connector.
SIGNAL PROCESSING
The system processing is based on the CORE DSP plaorm, which has been designed by the PROEL R&D Laboratories using one of the most
advanced SHARC DSP for audio applicaon. It features 40bit, 96kHz floang point resoluon and high quality 24bit AD/DA converters, for a perfect
signal integrity, a dynamic range in excess of 110dB and a superior sonic performance. Thanks to its massive processing power, the CORE plaorm
is capable of providing the most sophiscated algorithms for speaker processing, together with remote control and networking capability.
The PRONET control soware, working on a solid and reliable CANBUS based network protocol, provides an intuive interface for the remote
control of the whole system, with the possibility of eqing, delaying, increasing the protecons and monitoring the status of the amplifier.
PRONET
PRONET soware has been developed in collaboraon with sound engineers and sound designers, in order to offer an “easy-to-use” tool to setup
and manage your audio system. With PRONET you can visualize signal levels, monitor internal status and edit all the parameters of each connected
device.
Download the PRONET app from the AXIOM website at hƩp://www.axiomproaudio.com/ clicking on downloads secƟon of the product.
The AXIOM acve loudspeaker devices
can be connected in a network and
controlled by the PRONET software.
For the network connecon the PROEL
USB2CAN converter oponal accessory
is needed. The first time you connect
a device with the USB2CAN converter,
Windows O.S. will ask you to install the
driver files, which you can find in the
Driver folder within the Pronet applicaon
folder (by default is C:\Program Files\
Proel\Pronet\Driver, or if you changed it
<your path>\Driver). Please refer also to
“Installaon” and “Drivers” paragraphs in
the Pronet documentaon.
The PRONET NETWORK is based on a
robust, reliable and fast communicaon
protocol called CANBUS. The devices
in a PRONET NETWORK are connected
together with a “linear bus topology”. The
USB2CAN converter must be connected
to the network input of the first device,
the network output of the first device is
connected to the input of the second and
so on. For the network connecons simple
RJ45 cat.5 or cat.6 ethernet cables can be
used (please don’t confuse a ethernet
network with a PRONET network these
are completely different and must be fully
separated also both use the same kind of cable).
The beginning and the end of a PRONET NETWORK must be terminated. One side is terminated by the USB2CAN converter, the other side must
be terminated pressing the TERMINATE switch on the last device. All devices between these two points must have the TERMINATE switch lied.
Assign the ID number
To work properly in a PRONET network each connected device must have a unique idenfier number, called ID. By default the USB2CAN PC
controller has ID=0 and there can be only one PC controller. Every other device connected must have its own unique ID equal or greater than 1:
in the network cannot exist two devices with the same ID.
An ID number is assigned automacally to each devices when they are turned on for the first me connected to a network.
In order to correctly assign a new available ID to each device for working properly in a Pronet network, follow these instrucons:
1. Switch offall the devices.
2. Connect them correctly to the network cables.
3. “TERMINATE” the latest device in the network connecon.
4. Switch on the first device keep pressed “PRESET” buon on the control panel.
5. Leaving the previous device switched on, repeat the previous operaon on the next device, unl the latest device is turned on.
not pressed
pressed
last device
network
network
AX2065A
USB2CAN
PC NOTEBOOK
USB 2.0 port
AX2065A
AX2065P
AX2065A
AX2065P
SW215A
STATUS
CONVERTER
USB2CAN
CODE: S/N: RATINGS: RoHS COMPLIANT MADE IN ITALY
USB2CAN 00001 5V --- 200mA
EXAMPLE OF PRONET NETWORK WITH AX2065A AND SW215A

The “Assign ID” procedure for a device makes the internal network controller to perform two operaons: reset the current ID; search the first free
ID in the network, starng from ID=1. If no other devices are connected (and powered on), the controller assume ID=1, that is the first free ID,
otherwise it searches the next one lefree.
These operaons ensure that every device has it’s own unique ID, if you need to add a new device to the network you simply repeat the operaon
of step 4. Every device maintains its ID also when it is turned-off, because the idenfier is stored in the internal memory and it is cleared only by
another “Assign ID” step, as explained above. This means that if your network is made always of the same devices the assigning ID procedure must
be executed only the first me the system is turned on.
For more detailed instrucƟon about PRONET see the PRONET USER’S MANUAL included with the soŌware.
Useful tools to set up properly a verƟcal array system
This is a list of tools that can be very useful to set properly a vercal array system.
CABLE TESTER
It is a good pracce to check all cables before each installaon, because even one faulty cable can compromise heavily the
system performance.
INCLINOMETER WITH LEVER
This tool can be used to verify the vercal array angle. It can be used at the top or at the boom of the array In this
case you have to sum all splay angles, so the maximum precision is needed for aiming the vercal array, parcularly
for long throw applicaons.
LASER DISTANCE METER
This instrument can be useful to measure the height of the vercal array and to know the distance between FOH-Subs and FOH-Array
for seng the delay me.
SMAART or similar acousƟc measurement system
These are useful to measure delays, phase and response of the system.
EXAMPLE OF INSTALLATION IN A THEATRE WITH BALCONY
Here below you can see an example of the use of different PRESETS in an AX2065 flown array installed in a big theatre with balcony. The TOP BOXES
of the array are aiming at the balcony while the DOWN FILL box is aiming at the audience close to the stage.
TOP BOXES: the power level at the end of
the balcony is lower, as well as the high
frequency level.
DOWN FILL BOXES: the power level in the
proximity of the stage is higher, as well as
the high frequency level.
PRESET USING EXAMPLE
In order to opmize the array performances for this specific applicaon, the
PRESETS should be used in the following way.
Load the STANDARD preset in the central boxes.
Load the LONG THROW preset in the TOP 1 or 2 boxes, in order to compensate
the loss of power level and high frequencies of the program sent the upper
deck of the theatre.
Load the DOWN FILL / SINGLE BOX preset in the BOTTOM box in order to
smooth the high frequency content of the program sent to the audience close
to the stage.
TOP BOX
DOWN FILL BOX
+15 dB
+10
+5
0
-5
-10
-15
-20
-25
-30
-35 20 50 100 200 500 1K 2K 5K 10K 20K Hz
LONG THROW
STANDARD
SINGLE/DOWNFILL
AX2065A - PRESET RESPONSE

PREDICTION: EASE Focus 2
To aim correctly a complete system we suggests to use always the Aiming Soware - EASE Focus 2:
The EASE Focus 2 Aiming Soware is a 3D Acousc Modelling Soware that serves for the configuraon
and modelling of Line Arrays and convenonal speakers close to reality. It only considers the direct
field, created by the complex addion of the sound contribuons of the individual loudspeakers or
array components.
The design of EASE Focus is targeted at the end user. It allows the easy and quick predicon of the array
performance in a given venue. The scienfic base of EASE Focus stems from EASE, the professional
electro- and room acousc simulaon soware developed by AFMG Technologies GmbH. It is based
on the EASE GLL loudspeaker data file required for its use: AXIOM_AX Series_v2_1.GLL, please note
that the version must be 2.0 or more. The GLL file contains the data that defines the Line Array with regard to its possible configuraons as well
as to its geometrical and acouscal properes.
Download the EASE Focus 2 app from the AXIOM website at hƩp://www.axiomproaudio.com/ clicking on downloads secƟon of the product.
Use the menu opon Edit / Import System DefiniƟon File to import the file AXIOM_AX Series_v2_1.gll from the installaon Data folder, the
detailed instrucons to use the program are located in the menu opon Help / User’s Guide.
Note: Some windows system can require the .NET Framework 4 that can be download from microsoŌwebsite at hƩp://www.microsoŌ.com/en-
us/download/default.aspx.
WARNING! CAREFULLY READ THE FOLLOWING INSTRUCTIONS AND CONDITION OF USE:
• This loudspeaker is designed exclusively for Professional audio applicaons. The product must be installed by qualified personal only.
• Proel strongly recommends that this loudspeaker cabinet be suspended taking into consideraon all current Naonal, Federal, State and
Local regulaons. Please contact the manufacturer for further informaon.
• Proel do not accept any liability for damage caused to third pares due to improper installaon, lack of maintenance, tampering or
improper use of this product, including disregard of acceptable and applicable safety standards.
• During assembly pay aenon to the possible risk of crushing. Wear suitable protecve clothing. Observe all instrucons given on the
rigging components and the loudspeaker cabinets. When chain hoists are in operaon ensure that there is nobody directly underneath or
in the vicinity of the load. Do not under any circumstances climb on the array.
AIMING and SUSPENDING INSTRUCTIONS
Fly Bar and accessories
The AX2065 Systems are built to allow the suspension of array with variable
shape and dimensions. Thanks to a suspension mechanism designed to be
funconal, flexible and safe, each system must be suspended or stacked using
the KPTSW215 or KPTAX2065 fly bar. The loudspeakers are linked together in
a column using a series of couplers integrated in the frame of each enclosure.
Each system is set up properly both acouscally and mechanically only using
the aiming soware.
Coupling system in the front does not require any adjustment: using two
locking pins, each loudspeaker box is fixed to the previous. The sloed bar in
the back is inserted in a U-shaped frame which features a series of numbered
holes. Sliding the sloed bar in the U-shaped frame of the next loudspeaker
and inserng a locking pin in one of the numbered holes, it is possible to
adjust the relave splay angle between two adjacent loudspeakers in the
array column.
KPTSW215 fly bar maximum capacity is 540 Kg (1190 lbs) with the
0° angle. It can support, with a safety factor of 10:1, up to:
• 8 AX2065A + 8 AX2065P (flybar from 0° to 10°)
• 12 AX2065A (flybar from 0 to 10°)
• 2 SW215AF + 4 AX2065A + 4 AX2065P (flybar at 0°)
• 2 SW215AF + 8 AX2065A (flybar at 0°)
• 6 SW215AF (flybar from 0° to 5°)
KPTSW215 can be used for stacked array, see further on this
manual.
KPTAX2065 fly bar maximum capacity is 200 Kg (441 lbs) with the
0° angle. It can support, with a safety factor of 10:1, up to:
• 6 AX2065 acƟve or passive (flybar from 0° to 10°)
KPTAX2065 can NOT be used for stacked array.
NOTE: The figures illustrate the KPTWS215 only, KPTAX2065 use is
similar with capacity limitaƟons.
1
1
2
2
3
4
5
KPTSW215 FLY BAR ASSEMBLY SEQUENCE
SUSPEND HOLES
SUSPEND HOLE
INDICATOR
REAR BOX
PIN ATTACHMENT
FRONT BOX
PIN ATTACHMENT
FRONT BOX
PIN ATTACHMENT
STRAIGHT SHACKLE 16mm
M10 FOOT FOR
STACKED INSTALLATION
(OPTIONAL)
IDENTIFICATION AND
DATA LABEL
KPTSW215 FLY BAR AND ACCESSORIES

Follow the sequence in the figure for fixing the fly bar at the first
box. Usually this is the first step before liing up the system. Be careful
to insert properly all the locking pins (1)(2) and (3)(4) then the shackle
(5) in the right holes as specified by the aiming soware.
When liing the system always proceed gradually step by step, paying
aenon to secure the fly bar to the box (and the box to the other boxes)
before pulling up the system: this makes easier to insert properly the
locking pins. Also when the system is released down, unlock gradually
the pins. During the liing be very careful to not let the cables enter the space between one enclosure and the other, as their compression could
cut them.
Fly bar suspension and angle setup (centre of gravity)
The figure at the top of this page shows where the normal
centre of gravity is with one box or several boxes arranged in
a line. Usually the boxes are arranged to make an arc for the
best coverage of the audience, so the center of gravity moves
backward. The aiming soware suggests the ideal suspension
pinpoint taking into account this behaviour: fix the straight shackle
in this posion.
Note that the ideal aiming angle oen doesn’t correspond to the
pinpoint: there is oen a lile difference between ideal aiming and
real aiming and its value is the Delta angle: posive delta angle
can be adjusted a lile using two ropes, negave delta angle are
self adjusted a lile because the cables weighs on the back of the
array. With some experience it’s possible to consider prevenvely
these required lile adjustments.
During the flown set up you can connect the elements of the array
to their cables. We suggest to discharge the weight of the cables
from the flying pinpoint by tying them with a texle fibre rope,
instead of leng them hang freely: in this way the posion of the
array will be much more similar to the simulaon produced by
the soware.
Pin locking and splay angles set up
The figure below shows how to insert correctly the locking pin and
how to set up the splay angle between loudspeakers.
Wind loads
When planning an open-air event it is essenal to obtain current weather and wind informaon. When
loudspeaker arrays are flown in an open-air environment, possible wind effects must be taken into account.
Wind load produces addional dynamic forces acng on the rigging components and the suspension, which
may lead to a dangerous situaon. If according to the forecast wind forces higher than 5 b(29-38 Km/h)
are possible, the following acons have to be taken:
- The actual on-site wind speed has to be monitored permanently. Be aware that wind speed typically
increases with height above ground.
- Suspension and securing points of the array should be designed to support double the stac load in order
to withstand any addional dynamic forces.
WARNING!
Flying loudspeakers overhead at wind forces higher than 6 bŌ(39-49 Km/h) is not recommended.
If the wind force exceeds 7 b(50-61 Km/h) there is a risk of mechanical damage to the components
which may lead to a dangerous situaon for persons in the vicinity of the flown array.
- Stop the event and make sure that no person remains in the vicinity of the array.
- Lower and secure the array.
95AXM014 LOCKING PIN
press and
insert
release and
lock
KPTSW215 FLY BAR FOR FLOWN ARRAY
CENTRE OF GRAVITY
HINGE BAR OF PREVIOUS BOX
LOUDSPEAKER SPLAY ANGLES SET UP
USE THIS HOLE TO LOCK THE
HINGE BAR WHEN THE
LOUDSPEAKER IS REST
LOCK THE PIN IN THE
HOLE TO OBTAIN THE
REQUIRED SPLAY
ANGLE.
SINGLE PINPOINT FOR
STRAIGHT SHACKLE
KPTSW215 FLOWN PINPOINT

LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If any defects are found
in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner should inform about these defects the
dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon. This warranty does not extend to damage resulng from
improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned units, and when the unit has been properly used and warranty is sll
valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible for any “direct damage” or “indirect damage” caused by product defecveness.
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately nofied to forwarder. Each complaint for package tampered with should be done within eight days from product
receipt.
SAFETY INSTRUCTIONS
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the product. Connect the
apparatus to a power supply using only power cord included making always sure it is in good condions.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon.
– Make sure that power supply mains line has a proper earth connecon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when leunused for a long period of me.
CE CONFORMITY
Proel products comply with direcve 2004/108/EC (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direcve 2006/95/CE (LVD), as stated in EN
60065 standard.
PROEL S.p.A. (World Headquarter) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY
Tel: [phone] Fax: [phone] www.axiomproaudio.com
Stacked installaƟon (KPTSW215 only)
WARNING!
• The ground where the KPTSW215 Fly bar serving as ground
support is placed needs to be absolutely stable and compact.
• Adjust the feet so to lie the bar perfectly horizontal.
• Always secure ground stacked setups against movement and
possible pping over.
• A maximum of 4 x AX2065 cabinets with the KPTSW215 Fly bar
serving as ground support are allowed to be set up as ground
stack.
In the stack configuration you have to use the three optional
BOARDACF01 feet and the fly bar must be mounted upside down on
the ground.
Coupling system in the front do not require any adjustment: using two
locking pins each loudspeaker box is fixed to the previous. The sloed
bar in the back is inserted in a U-shaped frame which features a series
of numbered holes. Sliding the sloed bar in the U-shaped frame of the
next loudspeaker and inserng a locking pin in one of the numbered
holes, it is possible to adjust the relave splay angle between two
adjacent loudspeakers in the array column.
The opmal splay angles can be simulated using the EASE Focus 2
soware.
KPTSW215 STACKED ARRAY
max splay angle 10°
max splay angle 10°
max splay angle 10°
max splay angle 10°
