Axiom SW2100P User manual

SW2100P
Passive Subwoofer
USER MANUAL
revision 2023-08-04

2
Watch for these symbols:
The lightning ash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure, that may be of sucient magnitude to constute a risk of electric shock to
persons.
The exclamaon point within an equilateral triangle is intended to alert the user to the presence of important operang and
maintenance (servicing) instrucons in the literature accompanying the appliance.
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instrucons.
2. Keep these instrucons.
3. Heed all warnings.
4. Follow all instrucons.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any venlaon openings. Install in accordance with the manufacturer’s instrucons.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including ampliers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than
the other. A grounding-type plug has two blades and a third grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not t into your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched, parcularly at plugs, convenience receptacles, and the point where
they exit from the apparatus.
11. Only use aachments/accessories specied by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specied by the manufacturer, or sold with the apparatus. When a cart
is used, use cauon when moving the cart/apparatus combinaon to avoid injury from p-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of me.
14. Refer all servicing to qualied service personnel. Servicing is required when the apparatus has been damaged in any way, such
as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate normally, or has been dropped.
15. Warning: to reduce the risk of re or electric shock, do not expose this apparatus to rain or moisture.
16. Do not expose this equipment to dripping or splashing and ensure that no objects lled with liquids, such as vases, are placed
on the equipment.
17. To completely disconnect this apparatus from the ac mains, disconnect the power supply cord plug from the ac receptacle.
18. The mains plug of the power supply cord shall remain readily operable.
19. This apparatus contains potenally lethal voltages. To prevent electric shock or hazard, do not remove the chassis, input
module or ac input covers. No user serviceable parts inside. Refer servicing to qualied service personnel.
20. The loudspeakers covered by this manual are not intended for high moisture outdoor environments. Moisture can damage
the speaker cone and surround and cause corrosion of electrical contacts and metal parts. Avoid exposing the speakers to
direct moisture.
21. Keep loudspeakers out of extended or intense direct sunlight. The driver suspension will prematurely dry out and nished
surfaces may be degraded by long-term exposure to intense ultra-violet (UV) light.
22. The loudspeakers can generate considerable energy. When placed on a slippery surface such as polished wood or linoleum,
the speaker may move due to its acouscal energy output.
23. Precauons should be taken to assure that the speaker does not fall o a stage or table on which it is placed.
24. The loudspeakers are easily capable of generang sound pressure levels (SPL) sucient to cause permanent hearing damage
to performers, producon crew and audience members. Cauon should be taken to avoid prolonged exposure to SPL in excess
of 90 dB.
This marking shown on the product or its literature, indicates that it should not be disposed with other household wastes at the end
of its working life. To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate
this from other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources. Household users
should contact either the retailer where they purchased this product, or their local government oce, for details of where and
how they can take this item for environmentally safe recycling. Business users should contact their supplier and check the terms
and condions of the purchase contract. This product should not be mixed with other commercial wastes for disposal.

3
LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If any
defects are found in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner
should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon.
This warranty does not extend to damage resulng from improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned
units, and when the unit has been properly used and warranty is sll valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible
for any “direct damage” or “indirect damage” caused by product defecveness.
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately noed to forwarder. Each complaint for package tampered with should be done within eight
days from product receipt.
CONDITIONS OF USE
Proel do not accept any liability for damage caused to third pares due to improper installaon, use of non-original spare parts, lack of
maintenance, tampering or improper use of this product, including disregard of acceptable and applicable safety standards. Proel strongly
recommends that this loudspeaker cabinet be suspended taking into consideraon all current Naonal, Federal, State and Local regulaons. The
product must be installed be qualied personal. Please contact the manufacturer for further informaon.
DECLARATION OF CONFORMITY
The product is in compliance with:
RoHS Direcve 2011/65/EU and 2015/863/EU, WEEE Direcve 2012/19/EU.
The product is in compliance with:
S.I. 2012/3032 The Restricon of the Use of Certain Hazardous Substances in Electrical and
Electronic Equipment Regulaons 2012.

4
INTRODUCTION
The SW2100P is a very compact Band-Pass/Bass-Reex subwoofer providing high output and extended low frequency response. It
is equipped with a single 21” neodymium transducer with a 4” ISV voice coil, large displacement suspension system, and composite
reinforced, water repellent cone, able to provide clean and undistorted LF reproducon at very high SPL.
The loudspeaker is designed with a unique motor featuring a high grade neodymium magnet assembly in a structure opmized for
thermal and magnec eciency. Its features include a large displacement suspension system which, in conjuncon with a composite
reinforced, straight ribbed cone and the proprietary Double Silicon Spider (DSS) technology, allows an ultra-linear piston acon and
provides full mechanical control across the enre working range. The 100mm (4 in) state-of-the-art voice-coil ulizing Interleaved
Sandwich Voice coil (ISV) technology, provides high levels of thermal stability and durability. The ISV technology achieves a balanced
linear motor unit exerng an exceponally high force factor.
The phenolic birch plywood cabinet is equipped with pole mount socket, stacking feet, ush handles, and heavy duty wheels to
enable easy handling and transportaon.
It will deliver high level and extended low bass performance from a very compact cabinet, and thanks to the integral pole mount
socket partners well with any of the ED point source and AXIOM line array loudspeakers in any audio applicaons, while its small
size enables it to be easily ed into ght venue spaces.
TECHNICAL SPECIFICATION
SYSTEM POWER HANDLING
System’s Acousc Principle Band-pass / bass-reex Power Handling Connuous* 1600 W
Frequency response (-6 dB) 34 Hz - 180 Hz (Processed) Power Handling Program 3200 W
Nominal Impedance 4 Ω Power Handling Peak 7200 W
Minimum Impedance 3 Ω @ 30 Hz
Power Compression
@ -10 dB Power (320 W) = 0.62 dB
@ -3 dB Power (1600 W) = 2.18 dB
@ 0 dB Power (3200 W) = 3.57 dB
Sensivity (1.41V @ 1m, 2Pi) 94 dB
Maximum Peak SPL @ 1m 138 dB
TRANSDUCERS ENCLOSURE & CONSTRUCTION
Type 21” Neodymium magnet woofer, 4”
(100mm) VC Dimensions (W x H x D) 760 mm (29.9”) x 511 mm (20.1”) x 770
mm (30.3”)
Cone High stiffness (Complex Composite),
water repellent
Depth Including Wheels 881 mm (34.6”)
Enclosure Material 18mm, reinforced phenolic birch
Voice Coil Type Interleaved Sandwich Voice coil (ISV) Paint Black High resistance, water based paint
Suspension Triple-roll Transport 4 x heavy duty 100mm (4”) castors,
8 handles
INPUT CONNECTIONS
Connector Type Neutrik® Speakon® NL4 x 2 Net Weight 56 Kg (123.5 lbs)
60 Kg (132.3 lbs) including wheels
Input Wiring Pin 1+/1-; (Pin 2+/2- pass thru)
* AES Pink Noise Power
INDEX
INTRODUCTION ...........................4
TECHNICAL SPECIFICATION ..................4
MECHANICAL DRAWING ....................5
OPTIONAL ACCESSORIES ....................5
SPARE PARTS ..............................5
REAR PANEL ..............................6
INPUT ...................................6
LINK .....................................6

5
MECHANICAL DRAWING
OPTIONAL ACCESSORIES
NL4FXX-W-L Neutrik Speakon® PLUG for OD 10-16mm
DHSS10M20 Sub-Speaker ø35mm 1-1.7m Pole with Handle and M20 screw
KP210S Sub-Speaker ø35mm 0.7-1.2m Pole with M20 screw
COVERSW2100 Cover for SW2100A
see hp://www.axiomproaudio.com/ for detailed descripon and other available accessories.
SPARE PARTS
AC103GS 100 mm Swivel castor without brake
98SW2100WZ4 21’’ woofer - 4” VC - 4 ohm
NL4MP Neutrik Speakon® panel socket
51 cm
20.1"
76 cm
29.9"
77 cm
30.3"
88 cm
34.7"
M20 Pole Adaptor

6
REAR PANEL
INPUT
Power input for the external amplier. The SW2100P does not include a passive crossover for ltering the signal. The connecons
are the following:
INPUT - LINK
NL4 pin
number
internal
connecon
1+ LF+
1- LF-
2+ + pass thru
2- - pass thru
LINK
Power output in parallel with the INPUT socket for connecng the unit to another speaker. The number of SW2100P cabinets that
can be connected in parallel depends on the amplier load capacity.

7

PROEL S.p.A. (World Headquarters) - Via alla Ruenia 37/43 - 64027 Sant’Omero (Te) - ITALY
Tel: [phone] Fax: [phone] www.axiomproaudio.com
