USER MANUAL
SW215P
passive subwoofer
KEY FEATURES
• Very High Output • Manifolded Transmission Line configuraon for very fast transient response
• Compact size for a very good output-to-weight rao
INTRODUCTION
The SW215P subwoofer is designed to deliver high quality low frequency reproducon where very
high output is a key requirement, together with well defined deep bass response and fast transient
response. Its compact size and light weight make it suitable for several different uses, ranging from
touring applicaons to fixed installaons and high-level dance clubs.
The SW215P is a very high quality powered subwoofer system featuring some of the most
advanced technologies for low frequency reproducon. Its unique and innovave design is based
on a configuraon that can be defined as Manifolded Transmission Line.
It uses manifolding of the front side of the cones to maximize the mutual coupling between the
two drivers, while loading the back of the cone with a large-size transmission line that has the
funcon to create a transmission path from the back of the transducers to the front.
The SW215P subwoofer system is equipped with two high power 15” (380mm) transducers
capable of long excursion (up to 33mm peak-to-peak), controlled by high sffness Double Silicon
Spider as centering suspension and by heavy duty surround. The motor structure features high
strength (BL²/Re) with opmized symmetry and excursion controlled by Aluminium Demodulang
Ring. The robust copper 75mm (3”) voice coil is wounded in two different layers both outside and
inside the coil support, then doubling the coil surface exposed to air cooling and consequently
improving the long term thermal capacity of the loudspeaker. Cones are made of very high-sffness
reinforced paper, featuring also invisible water repellent treatment.
TECHNICAL SPECIFICATION
AcousƟcal Connectors
System type Manifolded Band Pass Connector Type Neutrik® Speakon® NL4 x 2
Transducer
Two 15” (380 mm), 3” (75 mm) VC,
High sffness water repellent reinforced cone,
Flux Demodulang Ring VC,
Double Centering Spider Suspension
Input Wiring LF1 = Pin 1+/-; LF2 = Pin 2+/-)
Mechanical
Width 571 mm (22.48”)
Height 800 mm (31.50”)
Depth 582 mm (22.91”)
Frequency response (±3 dB) 39 Hz – 120 Hz (Processed) Depth Including Wheels 710 mm (27.95”)
Frequency range (±10 dB) 35 Hz – 300 Hz (Unprocessed) Construcon 15 mm, reinforced Phenolic Birch
Sensivity (1.41V @ 1m, 2Pi) 102dB (averaged from 40 to 100Hz) Paint High resistance, water based paint
Maximum Peak SPL @ 1m 139 dB Wheels 4 heavy-load 100 mm ø
Electrical Transport 4 handles
Nominal Impedance 8 Ω+ 8 ΩNet Weight 61 Kg (134.5 lb)
Minimum Impedance 6.1 Ω+ 6.1 Ω@ 41Hz
Power Handling Connuous* 700 W + 700 W
Power Handling Program 900 W + 900 W
Power Handling Peak 2100 W + 2100 W
Power Compression
@ -10 dB Power (180 W + 180 W) = 0.8 dB
@ -3 dB Power (900 W + 900 W) = 1.5 dB
@ 0 dB Power (1800 W + 1800 W) = 2.7 dB
* AES Pink Noise Power
revision 2014-12-5

MECHANICAL DRAWING
OPTIONAL ACCESSORIES
NL4FX Neutrik Speakon® PLUG
PC260 2 in 6 out digital loudspeaker processor
USB2CAN PRONET network converter
RAINCOV215 Rain cover for input sockets
DHSS10M20 Sub-Speaker ø35mm Pole with M20 screw
see hƩp://www.axiomproaudio.com/ for detailed descripƟon and other available accessories.
SPARE PARTS
AC103GS 100 mm Swivel castor without brake
AC115DN Black steel handle
98AXM215SW8 15’’ woofer - 3” VC - 8 ohm
NL4MP Neutrik Speakon® panel socket
80 cm
31.50"
57.1 cm
22.48"
58.2 cm
22.91"
71.0 cm
27.95"
P = M20 insert for DHSS10M20
pole adaptor for convenƟonal
SUB-SAT system.
P

REAR PANEL
INPUT - Power input for the external amplifier. The SW215P does not include a passive crossover for filtering the signal. The connecons are the
following:
INPUT - LINK
NL4 pin number internal connecƟon
1+ LF1+
1- LF1-
2+ LF2+
2- LF2-
LINK - Power output in parallel with the INPUT socket for connecng the unit to another speaker. The number of SW215P cabinets that can be
connected in parallel depends on the amplifier load capacity.

LIMITED WARRANTY
Proel warrants all materials, workmanship and proper operaon of this product for a period of two years from the original date of purchase. If any
defects are found in the materials or workmanship or if the product fails to funcon properly during the applicable warranty period, the owner
should inform about these defects the dealer or the distributor, providing receipt or invoice of date of purchase and defect detailed descripon.
This warranty does not extend to damage resulng from improper installaon, misuse, neglect or abuse. Proel S.p.A. will verify damage on returned
units, and when the unit has been properly used and warranty is sll valid, then the unit will be replaced or repaired. Proel S.p.A. is not responsible
for any “direct damage” or “indirect damage” caused by product defecveness.
• This unit package has been submied to ISTA 1A integrity tests. We suggest you control the unit condions immediately aer unpacking it.
• If any damage is found, immediately advise the dealer. Keep all unit packaging parts to allow inspecon.
• Proel is not responsible for any damage that occurs during shipment.
• Products are sold “delivered ex warehouse” and shipment is at charge and risk of the buyer.
• Possible damages to unit should be immediately nofied to forwarder. Each complaint for package tampered with should be done within eight
days from product receipt.
SAFETY INSTRUCTIONS
– To reduce the risk, close supervision is necessary when the product is used near children.
– Protect the apparatus from atmospheric agents and keep it away from water, rain and high humidity places.
– This product should be site away from heat sources such as radiators, lamps and any other device that generate heat.
– This product should be located so that its locaon or posion does not interfere with its proper venlaon and heang dissipaon.
– Care should be taken so that objects and liquids do not go inside the product.
– The product should be connected to a power supply mains line only of the type described on the operang instrucons or as marked on the
product. Connect the apparatus to a power supply using only power cord included making always sure it is in good condions.
– WARNING: The mains plug is used as disconnect device, the disconnect device shall remain readily operable.
– Do not cancel the safety feature assured by means of a polarized line plug (one blade wider than the other) or with a earth connecon.
– Make sure that power supply mains line has a proper earth connecon.
– Power supply cord should be unplugged from the outlet during strong thunderstorm or when leunused for a long period of me.
CE CONFORMITY
Proel products comply with direcve 2004/108/EC (EMC), as stated in EN 55103-1 and EN 55103-2 standards and with direcve 2006/95/CE (LVD), as stated in EN
60065 standard.
