CEB94022 COM ExpressTM Type 6 with MXM Application Board
Introduction 1
Chapter 1
Introduction
The CEB94022 is a new COM ExpressTM Type 6 Application Board for embedded COM
ExpressTM Type 6 with MXM slot which fully compliant with the PCI Industrial Computer
Manufactures PICMG COM ExpressTM standard. In addition to the standard output signals for
converting, CEB94022 provides six display interfaces which include one HDMI port (from COM
ExpressTM module), one DP port (from COM ExpressTM module) and four DP port (from MXM
module). Besides of multiple display interface, CEB94022 also provide two full-size
PCI-Express Mini Card sockets for expansion purposes.
This board supports various I/O features: display interfaces including one VGA (box header)
and LVDS (connector), two Gigabit/Fast Ethernet, HD audio codec, one SATA-600 interface,
two USB 3.0, two USB 2.0, eight GPIO and four serial ports (three RS-232/422/485 and one
RS-232).
With CEB94022, customers can implement it in their own applications devices and accelerate
time-to-market for multiple display or high graphic computing demand applications e.g. Retail
or computer vision.

CEB94022 COM ExpressTM Type 6 with MXM Application Board
2 Introduction
1.1 Features
1 HDMI and 1 DP ports (default from COM ExpressTM module)
4 DP ports (from MXM module)
MXM Type A support
2 Gigabit LAN ports
SATA and mSATA
LVDS/VGA
2 USB 3.0 ports (depend on CEM module)
4 USB 2.0 ports
4 COM ports (RS-232/422/485 x3 / RS-232 x1)
8 GPIO
2 full-size PCI-Express Mini Cards
1.2 Specifications
CPU
COM ExpressTM Type 6 module.
System Chipset
On the COM ExpressTM module.
BIOS
On the COM ExpressTM module.
System Memory
On the COM ExpressTM module.
MXM
Standard MXM slot.
Support MXM Type A max TDP 50W.
Onboard Multi I/O
Three RS-232/422/485 in wafer connector.
One RS-232 in wafer connector.
Serial ATA
One SATA-600 connector.
One mSATA (mini PCI-Express socket).
Ethernet
Two RJ-45 interfaces for 1000/100/10Mbps.
Audio
HD audio with line-out/line-in/MIC-in.
USB Interface
Two USB ports comply with USB Spec. Rev. 3.0 (depend on CEM Module).
Four USB ports comply with USB Spec. Rev. 2.0.
SMBUS
Supported.
I2C
Supported.

CEB94022 COM ExpressTM Type 6 with MXM Application Board
Introduction 3
Digital I/O
Four inputs and four outputs in wafer connector.
Display
One 2x20-pin connector for 18/24-bit single/dual channel LVDS and one 8-pin
inverter connector. LVDS resolution is up to 1920x1200 in 24-bit dual channels.
One 16-pin wafer connector as VGA interface.
Five DP connectors (one DP from COM ExpressTM , four DP from MXM).
One HDMI connector (from COM ExpressTM)
Expansion Interface
Two full-size PCI-Express Mini Card sockets which comply with PCI-Express Mini
Card Spec. V1.2.
Power Input
DC 19V~24V.
Battery
Lithium 3V/220mAH.
Size
245 x 190mm.
Board Thickness
1.6mm.
Operation Temperature
-20°C ~ +65°C (-68°F ~ 149°F).
Operation Humidity
10% ~ 95% relative humidity, non-condensing.
Note
All specifications and images are subject to change without notice.
Before using the COM ExpressTM baseboard, check with your supplier if the
BIOS on COM ExpressTM module supports this baseboard.
1.3 Utilities Supported
Audio driver
Intel®Ethernet driver

CEB94022 COM ExpressTM Type 6 with MXM Application Board
4 Introduction
This page is intentionally left blank.

CEB94022 COM ExpressTM Type 6 with MXM Application Board
Board and Pin Assignments 5
Chapter 2
Board and Pin Assignments
2.1 Board Dimensions and Fixing Holes
Top View

CEB94022 COM ExpressTM Type 6 with MXM Application Board
6 Board and Pin Assignments
Bottom View
Side View

CEB94022 COM ExpressTM Type 6 with MXM Application Board
Board and Pin Assignments 7
2.2 Board Layout
Top View

CEB94022 COM ExpressTM Type 6 with MXM Application Board
8 Board and Pin Assignments
2.3 Assembly Drawing
The CEB94022 has some assembly holes for installation. Align and firmly install the basic size
CEM ExpressTM module on CEB94022 as indicated in image below.

CEB94022 COM ExpressTM Type 6 with MXM Application Board
Board and Pin Assignments 9
2.4 Jumper Settings
Jumper is a small component consisting of jumper clip and jumper pins. Install jumper clip on 2
jumper pins to close. And remove jumper clip from 2 jumper pins to open. Below illustration
shows how to set up jumper.
Properly configure jumper settings on the CEB94022 to meet your application purpose. Below
you can find a summary table of all jumpers and onboard default settings.
Note
Once the default jumper setting needs to be changed, please do it under power-off
condition.
Jumper
Description
Setting
JP1
LVDS Voltage Selection
Default: +3.3V
1-2 Close
JP2
Restore BIOS Optimal Defaults
Default: Normal Operation
1-2 Close
JP5
Boot BIOS Selection
Default: Boot from Module BIOS
1-3, 2-4 Close
JP6
Auto Power On
Default: Disable
2-3 Close

CEB94022 COM ExpressTM Type 6 with MXM Application Board
10 Board and Pin Assignments
2.4.1 LVDS Voltage Selection (JP1)
The board supports voltage selection for flat panel displays. Use this jumper to set LVDS
connector (CN16) pin 1~6 VCCM to +3.3V, +5V or +12V. To prevent hardware damage,
before connecting please make sure that the input voltage of flat panel is correct.
2.4.2 Restore BIOS Optimal Defaults (JP2)
Put jumper clip to pin 2-3 for a few seconds then move it back to pin 1-2. Doing this
procedure can restore BIOS optimal defaults. Use SPI select to determine which BIOS
to restore; BIOS on COM ExpressTM module or BIOS on baseboard (see section 2.4.3).
2.4.3 Boot BIOS Selection (JP5)
Use JP5 to select system to boot from module BIOS or baseboard BIOS.
2.4.4 Auto Power On (JP6)
If JP6 is enabled for power input, the system will be automatically power on without
pressing soft power button. If JP6 is disabled for power input, it is necessary to manually
press soft power button to power on the system.
Function
Setting
+3.3V level (Default)
1-2 close
+5V level
2-4 close
+12V level
5-6 close
Function
Setting
Normal operation (Default)
1-2 close
Restore BIOS optimal defaults
2-3 close
Function
Setting
Module BIOS (Default)
1-3, 2-4 close
Baseboard BIOS
1-3, 4-6 close
Function
Setting
Enable auto power on
1-2 close
Disable auto power on (Default)
2-3 close

CEB94022 COM ExpressTM Type 6 with MXM Application Board
Board and Pin Assignments 11
2.5 Connectors
Signals go to other parts of the system through connectors. Loose or improper connection
might cause problems, please make sure all connectors are properly and firmly connected.
Here is a summary table which shows all connectors on the hardware.
Connector
Description
CN1
I2C Connector
CN2
USB 2.0 Wafer Connector
CN3
Front Panel Connector
CN4
Digital I/O Connector
CN5~CN8
COM3~COM6 Connectors
CN9
Audio Connector
CN10
SMBus Connector
CN11
VGA Wafer Connector
CN12, CN15
PCI-Express Mini Card Connectors
CN13
Inverter Connector
CN14
SATA Power Connector
CN16
LVDS Connector
CN17
SATA Connector
CN19
LAN and USB 3.0 Port
CN20
LAN and USB 2.0 Port
CN22
DisplayPort (Upper) and HDMI (Lower) Connector
CN23
DC Jack Power Connector
DP1~DP2
DisplayPort Combo Connectors
FAN1, FAN3
Fan Connectors
MXM1
MXM Type A Connector
RECS1~ RECS2
COM ExpressTM Connectors

CEB94022 COM ExpressTM Type 6 with MXM Application Board
12 Board and Pin Assignments
2.5.1 I2C Connector (CN1)
This is a 3-pin (pitch=2.0mm) connector. The I2C interface is a simple bus for the
purpose of lightweight communication.
1
2.5.2 USB 2.0 Wafer Connector (CN2)
The CN2 (for USB port 4 and 5) is a 2x5-pin (pitch=2.0mm) connector commonly used
for installing USB 2.0 compliant peripherals such as keyboard, mouse, scanner, etc. This
connector is designed with +5V level standby power which can provide power when
system is in suspend mode.
Pin
Signal
1
I2C_CLK
2
I2C_DATA
3
GND
Pin
Signal
Pin
Signal
1
USB VCC (+5V level
standby power)
2
USB VCC (+5V level
standby power)
3
USB DX-
4
USB DY-
5
USB DX+
6
USB DY+
7
GND
8
GND
9
GND
10
GND

CEB94022 COM ExpressTM Type 6 with MXM Application Board
Board and Pin Assignments 13
2.5.3 Front Panel Connector (CN3)
This is a 2x4-pin (pitch=2.54mm) connector for front panel interface.
Power On/Off Button
Pin 1 and 2 connect the power button on front panel to CPU board, which allows users to
turn on or off power supply.
System Reset Switch
Pin 3 and 4 connect the case-mounted reset switch that reboots your computer without
turning off the power switch. It is a better way to reboot your system for a longer life of
system power supply.
Power LED
Pin 6 connects anode (+) of LED and pin 5 connects cathode(-) of LED. The power LED
lights up when the system is powered on.
HDD Activity LED
This connection is linked to hard drive activity LED on the control panel. LED flashes
when HDD is being accessed. Pin 7 and 8 connect the hard disk drive to the front panel
HDD LED, pin 9 is assigned as cathode(-) and pin 10 is assigned as anode(+).
2.5.4 Digital I/O Connector (CN4)
These are Molex 78046-102, 2x5-pin (pitch=2.0mm) box header. The board is equipped
with 8-channel (4 inputs and 4 outputs) digital I/O that meets requirements for a system
customary automation control. They are suitable for controlling cash drawers and sense
warning signals from an Uninterrupted Power System (UPS), or performing store
security control. You can use software programming or BIOS Setup utility to control
these digital signals.
Pin
Signal
Pin
Signal
1
PWRSW-
2
PWRSW+-
3
HW RST-
4
HW RST+
5
PWRLED-
6
PWRLED+
7
HDDLED-
8
HDDLED+
Pin
Signal
Pin
Signal
1
Digital Input 1
2
Digital Output 5
3
Digital Input 2
4
Digital Output 6
5
Digital Input 3
6
Digital Output 7
7
Digital Input 4
8
Digital Output 8
9
+5V level
10
GND

CEB94022 COM ExpressTM Type 6 with MXM Application Board
14 Board and Pin Assignments
2.5.5 COM Connectors (CN5~CN8)
These are Molex 78046-102, 2x5-pin (pitch=2.0mm) box headers for serial port
interfaces. The COM3~COM5 support RS-232/422/485 communication mode, while the
COM6 supports RS-232 only. The related pin assignments are given in table below. You
can change the communication mode in BIOS Setup utility.
2.5.6 Audio Connector (CN9)
This is a 2x5-pin (pitch=2.0mm) audio connector for convenient connection and control
of audio devices.
2.5.7 SMBus Connector (CN10)
The CN10 is a 5-pin (pitch=2.0mm) connector for SMBus interface. The SMBus (System
Management Bus) is a simple bus for the purpose of lightweight communication.
Pin
RS-232
RS-422
RS-485
1
DCD
TX-
Data-
2
DSR
No use
No use
3
RXD
TX+
Data+
4
RTS
No use
No use
5
TXD
RX+
No use
6
CTS
No use
No use
7
DTR
RX-
No use
8
RI
No use
No use
9
GND
No use
No use
10
No use
No use
No use
Pin
Signal
Pin
Signal
1
MIC_IN
2
GND
3
LINE_IN_L
4
GND
5
LINE_IN_R
6
GND
7
AUDIO_OUT_L
8
GND
9
AUDIO_OUT_R
10
GND
Pin
Signal
1
+3.3V
2
SMB_CLK_S
3
SMB_DATA_S
4
SMB_ALERT
5
GND
