STX88831 Series Quick Installation Guide
©Copyright 2009 AXIOMTEK Co., Ltd.
Version A1 February 2009
Printed in Taiwan
94188831000E
1
I. Checklist
STX88831 Board x 1
Quick Installation Guide x 1
Product Information CD-ROM x 1
Heatspreader x 1
Note: Please contact your local vendors if any damaged or missing items.
DO NOT apply power to the board if any damaged components.
II. Jumper Settings
Before applying the power to STX88831 Series, please make sure all
jumper settings are defaulted as the following table:
Description Function Jumper Setting
3.3V (Default) LVDS Voltage
Select (JP1)
5V
Normal (Default) CMOS Clear (JP2)
Clear CMOS
ATX Power
Mode (Default)
Auto Power Button
Mode Selection
(SW1)
Auto Power
Mode
Please refer to the STX88831 Series Product Information CD for the complete User’s Manual, drivers
and
utilities. User’s Manual and related documents are Acrobat PDF format.

STX88831 Series Quick Installation Guide
©Copyright 2009 AXIOMTEK Co., Ltd.
Version A1 February 2009
Printed in Taiwan
94188831000E
2
III. Connectors
Connectors Label
LVDS Connector FC1
SATA Connector SATA1
DDRⅡSO-DIMM DIMM1
STX Connector – P1 SP1
STX Connector – P2 SP2
IV. Board Layout
Please refer to the STX88831 Series Product Information CD for the complete User’s Manual, drivers
and
utilities. User’s Manual and related documents are Acrobat PDF format.
STX88831 Series Quick Installation Guide
©Copyright 2009 AXIOMTEK Co., Ltd.
Version A1 February 2009
Printed in Taiwan
94188831000E
3
V. Heatspread Installation
1. There is a protective plastic covering on the thermal pads. This
must be removed before the heatspreader can be mounted.
Each heatspreader is designed for a specific STX module. The
thermal pads on the heatspreader are designed to make contact
with the necessary components on the STX module. When
mounting the heatspreader you must make sure that the thermal
pads on the heatspreader make complete contact (no space
between thermal pad and component) with the corresponding
components on the STX module. This is especially critical for STX
modules that have higher CPU speeds (for example 1.0GHz or
more) to ensure that the heatspreader acts as a proper thermal
interface for cooling solutions.
2. The two long screws (M3x15) and two short screws (M3x12) are
used to mount the heatspreader and STX module assembly to the
baseboard. (see Figure 1)
3. If you have an additional thermal solution on the heatspreader,
please refer to the STX88831 thermal solution design guide (see
Figure 2) to design your thermal solution.
Figure 1: STX88831 Heatspreader Assembly Guide
Please refer to the STX88831 Series Product Information CD for the complete User’s Manual, drivers
and
utilities. User’s Manual and related documents are Acrobat PDF format.
