VI. Installing the Memory Module
Step 1 Turn off the system, and unplug the power cord. Turn the system
upside down to locate screws at the Bottom, loosen screws.
Remove the bottom cover to locate the Memory Heatsink screws.
Step 2 Loosen screws of heatsink, and Remove Memory heatsink
Step 3 Take out the thermal pad, remove transparent plastic mylar, and
stick it onto motherboard. Locate the memory module, insert the
gold colored contact into the socket, and push the module down
until it is firmly seated by locking two latches on the sides.
Step 4 Take 2nd thermal pad, remove the transparent plastic mylar and
stick it onto memory. Put grease onto the memory bracket.
Step 5 Assembly the memory bracket and fasten all screws. Assembly the
Top Cover back and fasten all screws.
eBOX660-872-FL Quick Installation Guide
©Copyright 2015Axiomtek Co., Ltd.
Version A2 March 2015
Printed in Taiwan
9416K660020E
1
I. Packing List
eBOX660‐872‐FLSystemUnitx1CDx1(forDriver&Manual)
QuickInstallationGuidex1ScrewsPackx1
Pre‐installIntelProcessorPre‐installFootPadx4
OptionalWall‐mountBracketOptionalDDR3SODIMM
OptionalAntennaOptionalMiniCardmodule
Optional2.5”StorageOptionalCFast™Card
Do not try to apply power to the system if any damaged components.
II. Dimensions
eBOX660-872-FL Robust Din-rail Fanless Embedded System

©Copyright 2015Axiomtek Co., Ltd.
Version A2 March 2015
Printed in Taiwan
9416K660020E
2
III. I/O Outlets
The following figures show you I/O outlets on front and rear panels of the
eBOX660-872-FL Series.
Front View
Rear View
©Copyright 2015Axiomtek Co., Ltd.
Version A2 March 2015
Printed in Taiwan
9416K660020E
3
IV. Installing the HDD
Step 1 Turn off the system, and unplug the power cable.
Step 2 Turn the system to the side with HDD Bracket. Locale the 2.5” HDD
Bracket, loose two thumb nail screws, and then pull out the HDD
Bracket smoothly
Step 3 Assemble the HDD bracket together with the 2.5” SATA device
Step 4 Slide HDD/SSD bracket module into position to connect SATA
signal and power to SATA device, and then fasten screws of HDD
bracket
V. Installing the CFast Card
Step 1 Turn off the system, unplug the power cable, turn the system to the
side with CFast cover.
Step 2 Loosen screws to remove the CFast cover, slide CFast card into
CFast slot with caution.
Step 3 Close the cover to the chassis, and fasten all screws.
