STX88810 STX Evaluation Platform Module Series User’s Manual
Introduction 1
C h a p t e r 1
Introduction
1.1 General Description
AXIOMTEK’s STX88810 is a STX form factor SoM (System On a
Module) which is with Intel®Pentium®M/Celeron™ M CPU equipped
processors, Fast Ethernet and audio interface. Designed with the
space-limited applications in mind. In addition of onboard features
which are integrated on STX88810, the STX standard interface
provides 4 PCI Masters and ISA output for expansion design purpose
applied on the related Baseboard.
With Axiomtek’s STX SoM, customers are capable of maintaining the
same hardware kernel and adapt various I/O combinations for
different application purposes.

STX88810 STX Evaluation Platform ModuleModule Series User’s Manual
Introduction
2
1.2 Specifications
zProcessor: Intel®Pentium®M 1.4GHz and Celeron®M
600M/1GHz (other frequency processors
are manufacture optional
zChipset: Intel®852GM + ICH*4
zBus Clock: 400MHz
zBIOS:
Phoenix-Award BIOS, Y2K compliant
4Mbit Flash, DMI, Plug and Play
SmartView for multiple LCD type selection, display mode
option and application extension features
RPL/PXE Ethernet Boot ROM
“Load Optimized Default” to backup customized Setting in
the BIOS flash chip to prevent from CMOS battery fail
zSystem Memory:
One 200-Pin DDR SODIMM socket
Maximum DDR of up to 1GB DDR266
zL2 Cache: integrated in CPU
zIDE Support:
2 channels up to 4 devices (IDE1 through STX interface
connector, IDE2 through AXIOMTEK 41Pin FPC connector )
PIO Mode 0-4, DMA Mode 0-2 and Ultra DMA/33/66/100
LS-120 & ZIP Bootable
zMulti I/O support:
One floppy port (STX interface connector) supporting up to
two devices (LS-120 & ZIP Bootable)
One SPP/EPP/ECP parallel port (STX interface connector), LS-
120 supported
Two 16550 UARTs compatible serial ports (STX interface
connector)
IrDA (STX interface connector) for wireless communcation
zKeyboard / Mouse support (STX interface connector)
zReal Time Clock: Integrate Intel®ICH*4 on STX88810

STX88810 STX Evaluation Platform Module Series User’s Manual
Introduction 3
zGraphics/Streaming:
Integrate Intel®852GM GMCH
Unified Memory Architecture shares system memory up to
32MB
Single display mode maximum resolutions:
CRT: 2048 x 1536@ 75Hz
LVDS LCD: 1600 x 1200
DualView display mode:
CRT: 2048 x 1536@ 75Hz
LVDS LCD: 1600 x 1200
Support 18 bit TFT LCD (STX interface connector) and
18/24/36/48bit LVDS [through AXIOMTEK 30Pin FPC connector
(FC4) either one
LCD backlight control supported
Optional DVOC (FC3)for Dual LVDS LCD ,DVI, TV singal
zEthernet:
RTL8100BL integrated on STX Module
Wake-On-LAN supported via ATX power supply
zUSB Interface: 4 USB ports with USB Spec. Rev. 2.0
zTemperture: C-M 600M/0KB and 1GHz/512KB supports
for fanless up to 55℃only and up to 60℃
with system fan.
zAudio Interface:
Support Standard AC’97 codec audio
zExpansion Bus:
Four PCI Bus Master
Standard ISA Bus
zPower Management: ACPI (Advanced Configuration and
Power Interface)
zDimensions: 96x90mm
NOTE: Specifications are subject to change without notice.

STX88810 STX Evaluation Platform ModuleModule Series User’s Manual
Introduction
4
1.3 Utilities Supported
zIntel Chipset Driver
zEthernet Utility and Drivers
zVGA Drivers
zAudio Driver

5
This page does not contain any information.

STX88810 STX Evaluation Platform Module Series User’s Manual
Jumpers and Connectors
6
C h a p t e r 2
Jumpers and Connectors
2.1 Board Dimensions
I/O Connectors may overhang in this area
(STX Baseboard componenl hight 4mm max.)
Component Side
The Limited Height of Component side is 30mm

STX88810 STX Evaluation Platform Module Series User’s Manual
Jumpers and Connectors
7
A
A
B
STX88810 Component Height : A-4.0mm & B-4.5mm
Solder Side
(TOP VIEW)

STX88810 STX Evaluation Platform Module Series User’s Manual
Jumpers and Connectors
8
2.2 Board Layout and Fixing Holes

STX88810 STX Evaluation Platform Module Series User’s Manual
Jumpers and Connectors 9
2.3 Jumper Settings
The jumpers on the STX88810 allow you to configure your CPU card
according to the needs of your applications. If you have doubts about
the best jumper configuration for your needs, contact your dealer or
sales representative. The following table lists the connectors on
STX88810 and their respective functions.
Jumper Description DefaultSetting
J1 CMOS Clear Jumper: default Short 1-2
LED Description
D1 +5VSB Power LED

10
This page does not contain any information.

STX88810 STX Evaluation Platform Module Series User’s Manual
Installation 11
C h a p t e r 3
Installation
This chapter describes the hardware installation procedures on the
STB86600 STX Evaluation Platform Base Board. The following is a list of
typical peripherals required to build a minimum system:
Power supply and passive STX Module
IBM™PC/AT keyboard
Display monitor
Floppy or hard disk with MS-DOS or Flash Disk emulator
3.1 Ultra DMA/66/100 Drive Installation
To accommodate the fast transfer rate of Ultra DMA/66/100, an 80-
conductor cable is necessary when installing Ultra DMA/66 drives.
The STX88810 Series, on this aspect, can support a total of 4 Ultra
DMA/66/100 drives (IDE2 from AXIOMTEK 41Pin connector). It is
through the Primary IDE Connectorand Secondary IDE Connector
where the cables are connected. The diagram below illustrates the
proper installation procedure, including color coding of connectors, of
the 80-conductor cable.
Red stripe
represents pin 1
of cable
Grey ATAS
TM
for Slave Drive
Black ATAS
TM
for Master Drive
80-pin Ultra DMA/66 cable
Blue ATAS
TM
for
system board's
40-pin IDE
connector
A
TA/66/100
Cable with
80 conductors
A
TA/33
Cable with
40 conductors

STX88810 STX Evaluation Platform Module Series User’s Manual
Installation
12
3.2 Completing Installation
To complete the installation, follow the steps listed below.
1. Make sure the power is OFF.
2. Set the configuration jumpers according to the jumper settings on
Chapter 2.
3. Install the STX Module into the STX Evaluation Platform base board.
4. Connect the I/O cables and peripherals, i.e. floppy disk, hard disk,
monitor, keyboard, power supply and etc. to the STB base board.
NOTE: The color of pin one is usually red or blue, while others are gray.
5. Turn ON the system power.
