Axis NETWORK CAMERA 2100 User manual

■Built-in Web Server and network connection
■Place a camera wherever you want it —
No PC required for operation
■View live ima es from any network-connected PC
■Monitor your house or office over the Internet
■Audio functionality available in combination
with the AXIS 2191 Audio Module
Crisp, quality ima es and streamin video from
anywhere on your network.
The AXIS 2100 Network Camera is a digital camera with
direct network attach! No PC required the camera
operates stand-alone and can be placed wherever there is
a LAN connection or an available modem. It even
contains a high performance web server, so you can put
the camera directly on the internet!
Live web images unleashed
AXIS 2100
Network Camera
MY GOLDIE
FAVOURITE
FOOD
WATER
TEMPERATURE
FAMILY TREE
NICE PICTURES
POSTCARD
Network

General
•Built-in Web Server and network interface. No
PC needed for operation.
•Linux-based operating s stem.
Installation
•Quick and eas installation – connect to our
network, assign an IP address, it’s completed in
less than a minute. The included null modem
cable enables set up without a network.
Camera
•Digital, 24-bit color.
Image sensor
•1/4 inch Son progressive scan RGB CCD.
•HxV: 659x494.
•Resolution (pixels): 640x480
Exposure
•Backlight compensation.
•Automatic AGC.
•White Balance: Automatic and Preset: Fixed
Indoor, Fixed Fluorescent, Fixed Outdoor, Hold.
•Exposure times: 1-1/30,000s.
Sensitivity
•Maximum Illumination: 10,000 Lux.
•Minimum Illumination: 3 Lux.
Lens
•Replaceable standard CS mount lens.
•Focus 0.5 mm to infinit .
•4.0 mm lens, equivalent to 35 mm on a
standard camera with aperture F 2.0.
•Image frame rate: up to 10 frames/second.
•JPEG still images and Motion-JPEG video.
•High-speed hardware-based image compression,
generating high qualit JPEG images.
•5 levels of compression available. The file size
of a JPEG compressed image depends on the
actual content of the image. Images containing
much detail will generate larger files. Image
qualit is controlled through the level of
compression. High compression ields small
files while low compression maintains higher
image qualit at the expense of larger files. The
table below contains average file size in Kb tes,
derived from real life tests.
•10 frames/second t picall requires 1 MBps
(maximum bandwidth limit can be set to
prevent network saturation).
Light Condition Adaptive Frame Rate
General I/O
•Input/Output connector to trigger the camera
on external events, e.g., a door sensor with a
solenoid.
•Accepts Dial-in and Dial-out access via
external modem (modem not included)
•Event triggered remote image storage via
e-mail and FTP.
System Requirements
•Compatible with operating s stems such as
Windows 98, Windows 2000, Windows XP,
Windows NT, Windows ME, Linux, Mac OS
and Mac OS X.
•Internet Explorer 4.x, 5.x, 6.x or Netscape
Navigator 4.x.
•Non-network, i.e. modem installation requires
Windows PC with Dial-up networking.
Supported Protocols
•TCP/IP, HTTP, FTP, SMTP, ARP, BOOTP, PPP,
CHAP, PAP and more
Security
•Can be password protected, or open to the
entire world.
ardware
•ARTPEC-1 compression chip.
•ETRAX 100, 32 bit RISC, 100 MIPS CPU.
•8 Mb te RAM.
•2 Mb te FLASH PROM.
Firmware Updates
•Flash memor for simple upgrades.
Connections
•RJ 45 Twisted Pair cable, 10/100 MBit Ethernet
network connection
•Modem connection RS-232 modem connector
for dial-up use. Supports most V90 modems.
•Input/Output connector to trigger the camera
on external events.
Power Supply
•External power suppl 12V AC (included).
Consumption max 7W.
Operating Environment
•Indoor onl .
•Operating temperature: 40–105° F (5–40° C).
•Humidit : 20–80% RHG, non-condensing.
•Warning: Never aim the camera at the sun or
other extremel bright light sources! Whether the
camera is in use or not, exposure to extremel
bright objects will harm the CCD image sensor.
Dimensions / Weight
•Height: 1.6 in (4.1 cm)
•Width: 4.0 in (10.2 cm)
•Length: 5.8 in (14.7 cm)
•Weight: 0.5 lb (0.24 kg)
(excluding power suppl and mini-tripod.)
Approvals
•EMC : FCC Class A, Part 15 subpart B
•CE : EN 55022 Class B, EN55024
•Safet : EN 60950, UL, CSA
Accessories Included
•Camera mini-tripod, using standard 1/4" nut.
•Null modem cable for modem installation.
•Power cord extension cable.
•Power suppl : 12V AC, 9.6 VA.
•I/O connector.
©2002, Axis Communications AB. The Axis logo is a registered trademark of Axis Communications AB. All other
compan names and products are trademarks or registered trademarks of their respective companies. We reserve the
right to introduce modifications without notice.
Technical Specification - AXIS 2100 Network Camera
19139/EN/R2/0202
www.axis.com
For more information visit our website:
3
10
640x480 20 Kb
8 Kb
13 Kb
5 Kb
8 Kb
3 Kb
320x240
Low
250 Kb
70 Kb
Lowest Medium High
Resolution Compression level
