AXISQ60-SPTZDomeNetworkCameras
Pressurized,stainlesssteelhigh-speedPTZdomes
AXISQ60-SPTZDomeNetworkCamerasaretop-of-the-line,high-speedsurveillancecameras
inapressurized,marine-gradestainlesssteelcasing.Providing360°coverageofwideareasand
greatdetailwhenzoomingin,thehighlydurable,outdoor-readycamerasareidealformarine,
mining,aswellasoilandgasenvironments.Theyarealsoapplicableindoorsinfood,medical
andcleanroommanufacturingfacilities.
Thankstothestainlesssteel(SAE316L)casing,
AXISQ60-Scamerashavehighresistancetocorrosion
andcanwithstandcleaningchemicalsandhigh-pres-
suresteam.Theyaredesignedtobelledwithnitrogen
toprovidebenetssuchaspreventinginternalconden-
sationandcreatinganonammableenvironment.
ThemodelscompriseAXISQ6042-S(ExtendedD1res-
olutionand36xopticalzoom),AXISQ6044-S(HDTV
720pand30xopticalzoom),andAXISQ6045-S(HDTV
1080pand20xopticalzoom).Therobustcameras,with
day/nightfunctionality,canbeautomaticallydirectedto
256presetpositionsusingguardtour.
AXISQ6042-SandAXISQ6044-Ssupportelectronic
imagestabilization,whichdeliversmoreusefulvideo
inwindyorvibratingconditions.AXISQ6044-Salso
supportsautomaticdefogforclearervideoinfog.All
AXISQ60-Scamerashaveenhancedcapacityforintel-
ligentvideo.
ThesuppliedmediaconverterswitchallowsAXISQ60-S
camerastobeconnectedinadaisychaintothenetwork
usingstandardnetworkorberopticcables.Themedia
converterswitchalsoenablesthecamerastoconnect
toexternaldevicesviainput/outputportsandto12V
power.
DATASHEET
>Marine-grade
stainlesssteel
>Casingfor
pressurized
nitrogen
>UptoHDTV1080p
withhighzoom
>SFPslotsforber,
RJ45connections
>I/Oforalarmin/out
Note:Mountingbracketsaresold
separately.

Highdurability
AXISQ60-Scameras,withmarine-grade(SAE316LorV4A)stainlesssteelandanyloncleardomecover,havehighre-
sistancetothecorrosiveeffectofseawaterandcleaningchemicals.Theycanwithstandhigh-pressuresteamcleaning.
Pressurizednitrogen,meanwhile,providesbenetssuchaspreventingexternalcontaminantsfromentering,preventing
internalcondensationandinternalcorrosion,andcreatinganonammableenvironment.Thecamerascanoperatein
-30°Cto50°C(-22°Fto122°F).TheyhaveMIL-STD-810G509.5,IP6K9K,IP66,IP67andNEMA4Xapprovals,ensuring
protectionagainstsaltfog,highpressureandsteamjetcleaning,dust,rain,snowandice.Supportforshockdetection
enablesthecamerastotriggeranalarmiftheyhavebeenhit.
AXISQ60-Scamerasaretobelledwithnitrogengasthroughtheinletvalve[1]andthepressureshouldbeabove0.2bar(3psi)forfullprotectionfrominternal
condensation.Thepressurereliefvalve[2]willopenwhenthepressureinsidethecamerareaches0.5bar(7psi).
Systemschematic
AnAXISQ60-SconnectstothesuppliedAXIST8605MediaConverter
SwitchusinganIP66-ratedmulti-connectorcable[1],whichattaches
tothecamerawithasimpleclick.Throughthemediaconverterswitch,
themulti-connectorcableenablesthecameratoreceivepower(power
supply[2]notincluded),andsendandreceivedatatoandfromexternal
alarmdevicesandthenetwork.TwoSFPslotsandtwoRJ45connectors
inthemediaconverterswitchgiveinstallerstheexibilitytonetworkthe
camerascost-effectivelyoverlongdistancesinadaisychainorinaring
topologyforincreasedreliabilityintheeventofasinglepointoffailure.
(IGMPlteringisnotsupportedandringtopologyrequiresaswitchsup-
portingIEEE802.1DSpanningTreeProtocol).TheRJ45connectorscan
alsobeusedforconnectiontocomplementarycamerassuchasathermal
cameraortemporarilytoalaptoptoservicethesystemlocally.

TechnicalSpecications-AXISQ60-SPTZDomeNetworkCameras
ModelsAXISQ6042-S50Hz,AXISQ6042-S60Hz
AXISQ6044-S50Hz,AXISQ6044-S60Hz
AXISQ6045-S50Hz,AXISQ6045-S60Hz
Camera
ImagesensorAXISQ6042-S:1/4”progressivescanCCD
AXISQ6044-S:1/3”progressivescanCCD
AXISQ6045-S:1/3”progressivescanCMOS
LensAXISQ6042-S:f=3.3–119mm,F1.4–4.2,autofocus
Horizontalangleofview:57.2°–1.7°
AXISQ6044-S:f=4.4–132mm,F1.4–4.6,autofocus
Horizontalangleofview:62.9°–2.2°
AXISQ6045-S:f=4.45–89mm,F1.6–2.9,autofocus
Horizontalangleofview:62.98°–3.49°
DayandnightAutomaticallyremovableinfrared-cutlter
Minimum
illuminationAXISQ6042-S:Color:0.5luxat30IREF1.4;B/W:0.008luxat
30IREF1.4
AXISQ6044-S:Color:0.2luxat30IREF1.4;B/W:0.04luxat
30IREF1.4
AXISQ6045-S:Color:0.6luxat30IREF1.6;B/W:0.04luxat
30IREF1.6
ShuttertimeAXISQ6042-S:1/30000sto1.5s(50Hz),1/30000sto
0.5s(60Hz)
AXISQ6044-S:1/10000sto1/4s
AXISQ6045-S:1/33000sto1/3s(50Hz),1/33000sto
1/4s(60Hz)
Pan/Tilt/ZoomE-ip,256presetpositions,Tourrecording,Guardtour,Control
queue,On-screendirectionalindicator
Pan:360°endless,0.05°–450°/s;Tilt:220°,0.05°–450°/s
AXISQ6042-S:36xopticalzoomand12xdigitalzoom,
total432xzoom
AXISQ6044-S:30xopticalzoomand12xdigitalzoom,
total360xzoom
AXISQ6045-S:20xopticalzoomand12xdigitalzoom,
total240xzoom
Video
Video
compressionH.264MainandBaselineProles(MPEG-4Part10/AVC)
MotionJPEG
ResolutionsAXISQ6042-S:ExtendedD1736x576to176x144(50Hz),
ExtendedD1752x480to176x120(60Hz)
AXISQ6044-S:1280x720(HDTV720p)to320x180
AXISQ6045-S:1920x1080(HDTV1080p)to320x180
FramerateH.264:Upto25/30fps(50/60Hz)inallresolutions
MotionJPEG:Upto25/30fps(50/60Hz)inallresolutions
VideostreamingMultiple,individuallycongurablestreamsinH.264and
MotionJPEG
Controllableframerateandbandwidth
VBR/CBRH.264
ImagesettingsWidedynamicrange(WDR),Manualshuttertime,Compression,
Color,Brightness,Sharpness,Whitebalance,Exposurecontrol,
Exposurezones,Backlightcompensation,Finetuningofbehavior
atlowlight,Rotation,Textandimageoverlay,32individual3D
privacymasks,ImagefreezeonPTZ
AXISQ6042-S:Electronicimagestabilization
AXISQ6044-S:Electronicimagestabilization,Automaticdefog
AXISQ6045-S:Highlightcompensation
Network
SecurityPasswordprotection,IPaddressltering,HTTPSaencryption,
IEEE802.1Xanetworkaccesscontrol,Digestauthentication,User
accesslog
Supported
protocolsIPv4/v6,HTTP,HTTPSa,SSL/TLSa,QoSLayer3DiffServ,FTP,
CIFS/SMB,SMTP,Bonjour,UPnPTM,SNMPv1/v2c/v3(MIB-II),
DNS,DynDNS,NTP,RTSP,RTP,TCP,UDP,IGMP,RTCP,ICMP,
DHCP,ARP,SOCKS,SSH
Systemintegration
Application
Programming
Interface
OpenAPIforsoftwareintegration,includingVAPIX®
andAXISCameraApplicationPlatform;specicationsat
www.axis.com
AXISVideoHostingSystem(AVHS)withOne-ClickCamera
Connection.
ONVIFProleS,specicationatwww.onvif.org
IntelligentvideoVideomotiondetection,Autotracking,ActiveGatekeeper,
AXISCameraApplicationPlatformenablinginstallationof
additionalapplications
AXISQ6044-S:Automaticdefog
AXISQ6045-S:Basicanalytics(nottobecomparedwith
third-partyanalytics):Objectremoved,Enter/exitdetector,Fence
detector,Objectcounter,Highlightcompensation
EventtriggersVideomotiondetection,Shockdetection,Fan,Heater,
Temperature,Manualtrigger,Autotracking,Moving,PTZpreset,
Edgestorageevents,AXISCameraApplicationPlatform
AXISQ6045-S:Enter/exit,Fencedetector,Objectremoved
EventactionsFileupload:FTP,HTTP,networkshareandemail
Notication:email,HTTPandTCP
PTZpreset,Guardtour,Autotracking,Day/nightmode,Video
recordingtoedgestorage,Pre-andpost-alarmvideobuffering
Built-in
installationaids
Pixelcounter
General
CasingIP6K9K-,IP66-,IP67-andNEMA4X-ratedstainlesssteelcasing
(V4A,SAE316L/UNSS31603/EN1.4432),nyloncleardome
Memory512MBRAM,128MBFlash
Power60WpoweredthroughAXIST8605MediaConverterSwitch
ConnectorsIP66-ratedmulti-connectorforDCpower,Ethernet
10BASE-T/100BASE-TX,inputandoutput,including7m(23ft)
cable
EdgestorageSD/SDHC/SDXCslotsupportingmemorycardupto
64GB(cardnotincluded);supportforrecordingtodedicated
network-attachedstorage(NAS)
Operating
conditions-30°Cto50°C(-22°Fto122°F)
Humidity10–100%RH(condensing)
Storage
conditions-40°Cto65°C(-40°Fto149°F)
ApprovalsEN55022ClassA,EN61000-3-2,EN61000-3-3,EN61000-6-1,
EN61000-6-2,EN55024,EN50121-4,IEC62236-4,
FCCPart15SubpartBClassA,ICES-003ClassA,VCCIClassA,
C-tickAS/NZSCISPR22ClassA,KCCKN22ClassA,
KN24,IEC/EN/UL60950-1,IEC/EN/UL60950-22,
IEC/EN60529IP66,IP67,IP6K9K,NEMA250Type4X,
IEC60068-2-1,IEC60068-2-2,IEC60068-2-78,
IEC60068-2-14,IEC60068-2-30,IEC60068-2-6,
IEC60068-2-27,IEC60068-2-60,MIL-STD810G509.5
Weight5.7kg(12.6lb)
Included
accessories
AXIST8605MediaConverterSwitch,IP66-ratedmulti-connector
cable,InstallationGuide,InstallationandManagementSoftware
CD,Windowsdecoder1-userlicense
Video
management
software
AXISCameraCompanion(included),AXISCameraStation
andvideomanagementsoftwarefromAxis’Application
DevelopmentPartners(notincluded).Formoreinformation,see
www.axis.com/products/video/software
WarrantyAxis3-yearwarrantyandAXISExtendedWarrantyoption,see
www.axis.com/warranty
a.ThisproductincludessoftwaredevelopedbytheOpenSSLProjectforuseinthe
OpenSSLToolkit.(www.openssl.org),andcryptographicsoftwarewrittenbyEric
Young([email protected]).
Moreinformationisavailableatwww.axis.com

Dimensions
1.Without
sunshield
2.Withsunshield
(soldseparately)
256 mm (10.1”)
89 mm (3.5”)
154 mm (6.1”)
51 mm (2”)
51 mm (2”)
224 mm (8.8”)
164 mm (6.5”)
250 mm (9.8”)
12
Includedaccessories
1.AXIST8605
2.BracketMount
DINClip
3.IP66-rated
multi-connector
cable,7m(23ft)
Optionalaccessories
1.AXIST91C61WallMount
2.AXIST94S01DPendantKit
3.AXIST91C67PoleMount
4.AXISQ60-SSunshield
5.AXIST8008PS12
6.AXIST98A-VESurveillanceCabinet
7.AXIST8310VideoSurveillanceControl
Board
AXIST8605MediaConverterSwitch
DatarateRJ45:10/100Mbps;SFP:100/1000MbpsOperating
conditions-40°Cto75°C(-40°Fto167°F)
NetworkcablesShieldedcategory5orhigher;berStorageconditions-40°Cto75°C(-40°Fto167°F)
Connectors2xRJ45connectors[1]
2xSFPslots(e.g.forSFPopticalbermodules)
[2]
2congurablealarminput/outputports[3]
Multi-connectorcable[4]
Groundscrew[5]
1xpower[6]
Approvals
EMC:
EN55022ClassA,EN55024,VCCI,
FCCPart15ClassAwithSTPcabling,KCC
Safety:
IEC/EN/UL60950-1,IEC/EN/UL60950-22
Power12–13VDC,min.60W(powerinfrompower
supply)
InstallationBracketMountDINClip(included)fora
35mmDINrail
Display&indicatorsPower
5xNetwork
ComplianceRoHS,REACH,WEEE,CE,EN50022,IEC60715,
AS2756
Dimensions150x100x30mm(5.9”x3.9”x1.2”)
AXIST8008PS12(Optionalaccessory)
Operating
conditions-40°Cto75°C(-40°Fto167°F)
Powerin90–264VAC(operating)
115–230VAC(nominal)
47–63Hz
Storage
conditions-40°Cto75°C(-40°Fto167°F)
Powerout12.5VDC+/-0.2VDC,85W
ApprovalsEMIClassB,EN61000Immunity,
IEC68-2-27,IEC68-2-6/IEC721-3-2,
UL+CSA60950-12ndEdition,
UL+CSA60601-12ndEdition,CBScheme60950-1,
EN61347-1/-2-13,IP64
Dimensions178x102x38mm(7”x4”x1.2”)
