AXISQ60PTZNetworkCameraSeries
RepaintingInstructions

AXISQ60PTZNetworkCameraSeries
Impactonwarranty
Impactonwarranty
ThisproductisapprovedforrepaintbyAxis,providedthatyoufollowtheinstructionsinthisdocumentandat
www.axis.com/warranty-implication-when-repainting
Riskswithrepainting
ThereareseveralriskswhendisassemblingorassemblinganAxisproduct.Thereisalwaysacertainyieldlossduringassembly.Training
ofoperatorsandtheuseofcorrecttoolsmediatessomeoftheproblemsbuttheycanneverbefullyavoided.Someoftherisksinclude:
ESDDamage-AlwayshandletheproductinanESDsafeenvironment.EvenifprecautionsaretakenthereisalwaysariskofESD
damage.Thedamagecanremainundetectedandcauseproblemsduringthelifetimeoftheeuipment.
Dustcontamination-Openingacameramayexposethelensandsensortodustorpaint.Dustwillaffecttheopticalperformance.
Lensesneedtobedisassembledinadust-freeenvironment,preferablyacleanroom.
Paintoverspray-Maskingthedifferentcomponentsoftheeuipmentiscritical.Failuretomasksensitiveareascancauseproblems
withassemblingtheeuipment.Anyareasthatarenotpaintedatfactoryorhaveadifferentsurfacetreatmentthantherestofthe
parts(threads,groundandelectricalcontactsurfaces)mustalsobemaskedtoensurefunction.
2

AXISQ60PTZNetworkCameraSeries
Repainttheproduct
Repainttheproduct
Preparations
•Disassemblethedeviceaccordingtotheinstructionsinthisdocument.
•Cleanallpartstoberepaintedthoroughlytoremovegrease,dust,oroil.
•Toensurereassemblyandfunctionalityoftheproduct,maskanyopeningsbeforeyoupaint.
Pretreatmentofparts
Dependingonthepartmaterialandtypeofpaintappliedatfactory,differentpretreatmentshouldbedoneforthenewpaintto
adhereaswellaspossible.Cleanthepartsproperlytoremoveoil,greaseanddust.
Formoreinformationonthematerialsusedintheproduct,seeitsdatasheetatwww.axis.com
Powdercoatedparts-Useaprimer.Alternatively,removetheoriginalpowdercoatingdowntothebasematerial,usingne
sandpaper,andcleanthepartsbeforepainting.
Anodisedandchromatedparts-Useaprimer.
Uncoatedstainlesssteel-Nospecialpretreatmentisneeded,butmakesurethatthesurfaceiscleanbeforepainting.
Plastic-Useaprimer.
Disassemby
Chassis
1Antilossscrew
2Domeassembly
3Cameraassembly
4Screw
5Powerconnector
1.Loosenthefourantilossscrewsandremovethedomeassemblyfromthecamera.
3

AXISQ60PTZNetworkCameraSeries
Repainttheproduct
2.Loosenthethreescrewsthatholdthecameraassembly.
3.Liftupthecameraassemblyandremovetheconnectorfromthepowercircuitboard.
1avespring
2asher
3Bayonetscrew
4Spring
5Safetyhook
6Screw
7Cablegasket
8Cableholder
9Screw
10Gasket
11Lidassembly
12Antilossscrew
4.Removethetwobayonetscrewswithwashersandwavesprings.
5.Removethescrew,thesafetyhook,andthespring.
6.Removethescrewandthetwocableholders.
7.Loosenthethreeantilossscrewsandremovethelidassemblyandthegasket.
8.Removethecablegasket.
4

AXISQ60PTZNetworkCameraSeries
Repainttheproduct
Dome
1Screw
2Domebracket
3Dome
4Domering
5Antilossscrew
6Compassring
1.Removethefourantilossscrewsfromthedomering.
2.Removethefourscrews,thedomebracketandthedome.
3.Snapthecompassringofthedomering.
Lid
1Screw
2Lid
3Bayonetscrew
4asher
5avespring
1.Removethethreescrewsfromthelid.
2.Removethebayonetscrewwithwasherandwavespring.
5

AXISQ60PTZNetworkCameraSeries
Repainttheproduct
Masking
Chassis
1.Maskallscrewholes.
2.Masktheopeningthatwascoveredbythelidassembly.
3.Masktheentireopeninginthebottomofthechassis.Nopaintisallowedinsidethechassis.
Dome
1.Maskthedomegasket.
2.Maskallscrewholes.
Lid
1.Maskallscrewholes.
2.Maskthebottomsideofthelid.
Repainting
1.Makesureallnecessarypreparationsofthechassis,thedome,andthelidhavebeenmade,seePreparationsonpage3.
2.Applyathinandevenlayerofspraypaintaccordingtotheinstructionsofthepaintmanufacturer.
3.Letthepaintdry.
4.Togetabettercoverageandclearercolor,applyasecondlayerofspraypaint.
5.Whenthepaintisdry,removethemasking.
6

AXISQ60PTZNetworkCameraSeries
Repainttheproduct
Reassemby
Dome
1Screw
2Domebracket
3Dome
4Domering
5Antilossscrew
6Compassring
1.Orientthecompassringasshownbelowandsnapitontothedomering.
2.Orientthedomebracketasshownbelowandassemblethedomebracketandthedomewiththefourscrews.Tighten
thescrewswith0.5Nm(0.4lbft)torue.
3.Fitthefourantilossscrewsbackinthedomering.
Lid
1Screw
7

AXISQ60PTZNetworkCameraSeries
Repainttheproduct
2Lid
3Bayonetscrew
4asher
5avespring
1.Assemblethebayonetscrewwithwasherandwavespring.Tightenthescrewswith1.8Nm(1.3lbft)torue.
2.Fitthethreescrewsbackinthelidassembly.
Chassis
1avespring
2asher
3Bayonetscrew
4Spring
5Safetyhook
6Screw
7Cablegasket
8Cableholder
9Screw
10Gasket
11Lidassembly
12Antilossscrew
1.Pushthecablegasketintotheslot.
2.Putbackthecableholdersandthescrew.
3.Putbackthegasketandthelidassembly.Tightentheantilossscrewswith0.4Nm(0.3lbft)torue.
4.Putbackthespring,thesafetyhook,andthescrew.
5.Screwinthetwobayonetscrewswithwashersandwavesprings.Tightenthescrewswith1.8Nm(1.3lbft)torue.
8

AXISQ60PTZNetworkCameraSeries
Repainttheproduct
1Antilossscrew
2Domeassembly
3Cameraassembly
4Screw
5Powerconnector
6.Connectthecameraassemblytothepowercircuitboard.
7.Putbackthecameraassemblyandthethreescrews.Tightenthescrewswith4Nm(3lbft)torue.
8.Putbackthedomeassembly.Tightentheantilossscrewswith4Nm(3lbft)torue.
