Azden 1200BT User manual

120 0
1200
1200
S
ERIES
Gold Mount®
1200URX/AB IDX®"V" Mount
1200URX/VM 1200URX-Si
“Slot-In”
1200URX/AB Gold Mount®
1200URX/VM IDX®"V" Mount
1200URX-Si “Slot-In”
The all new receivers and transmitters include:
• New compander circuit for more natural sound
• Improved frequency response with lower noise levels
• New DTV-compatible (188) frequencies covering 4 UHF TV bands
• True diversity system with 2 complete front-ends and
high-gain antennas
• Proprietary Diversity Logic Control circuitry for reduced drop-outs
• Dielectric filters throughout, for improved image rejection and
superior diversity isolation
• High 5th-order filters for improved S/N ratio
• Multi-function LCD shows channel, frequency, battery info, AF level,
and diversity operation
Transmitters also feature: New circuitry, powered by only 2-"AA"
batteries, new plug-in transmitter with 48V phantom power capability
Bodypack transmitter
(1200BT) with reduced
current-drain for improved
battery life, is available
with an Azden EX-503H or
Sony®ECM-44H lavalier
microphone.
Plug-in XLR
transmitter (1200XT)
works with
phantom power.
Whether you use a Panasonic
®
or Ikegami
®
camera with "slot-in" receiver
capabilities, or use the Anton-Bauer
®
Gold Mount
®
, or a V-Mount battery,
there's an Azden 1200 designed specifically for your use.
HIGH-PEFORMANCE TRUE-DIVERSITY
BROADCAST WIRELESS MICROPHONES
ALL NEW FREQUENCY RANGE (638.125-661.875 MHz)

Overall SystemOverall System
Overall SystemOverall System
Overall System
Operating Range 200-300 feet
Operating Frequency UHF band, 638.125 to 661.875 MHz
Number of Channels 188 User-selectable
Receiving System True Diversity
Modulation Mode FM
Oscillator Phase Lock Loop synthesizer
Display LCD
Operating Temp. Range -10o C to +50o C (-50o F to -122o F)
1200URX/Si Slot-In Receiver1200URX/Si Slot-In Receiver
1200URX/Si Slot-In Receiver1200URX/Si Slot-In Receiver
1200URX/Si Slot-In Receiver
Frequency Response 50 Hz - 15 kHz
RF Squelch level -95 dBm
Adjacent Chan. Selectivity ≥70dB
Intermodulation ≥65 dB
Noise Reduction Expander (THAT)
Audio Output (unbalanced) -20 dBm - 1 kHz @ ± 40 kHz Deviation
Output Impedance 300 Ω
S/N Ratio 62 dB (± 5 kHz) “A” Weighted
Power Reqirement 12VDC (10.5 - 17.0 VDC) from Camera
Dimensions
Display: 80W x 22H x 35D mm (3.15 x 0.87 x 1.38 in)
Insertion: 68W x 84H x 18D mm (2.68 x 3.3 x 0.7 in)
Weight ≅250 g (8.8 oz) w/antennas
1200URX/AB Anton Bauer1200URX/AB Anton Bauer
1200URX/AB Anton Bauer1200URX/AB Anton Bauer
1200URX/AB Anton Bauer®Mount ReceiverMount Receiver
Mount ReceiverMount Receiver
Mount Receiver
Frequency Response 50 Hz - 15 kHz
RF Squelch level -95 dBm
Adjacent Chan. Selectivity ≥ 70 dB
Intermodulation ≥65 dB
Noise Reduction Expander (THAT)
Audio Output (balanced) +4 dBm @ ± 40 kHz Deviation (Line)
-40 dBm @ ± 40 kHz Deviation (Mic)
Output Impedance 600 Ω
S/N Ratio 62 dB (± 5 kHz) “A” Weighted
Power Reqirement 12VDC (11.0 - 15.0 VDC)
Dimensions 93W x 119H x 49D mm
3.66W x 4.68H x 1.93D inches
Weight ≅450 g (15.87 oz) w/antennas
1200URX/VM IDX “V” Mount1200URX/VM IDX “V” Mount
1200URX/VM IDX “V” Mount1200URX/VM IDX “V” Mount
1200URX/VM IDX “V” Mount
Frequency Response 50 Hz - 15 kHz
RF Squelch level -95 dBm
Adjacent Chan. Selectivity ≥ 70 dB
Intermodulation ≥65 dB
Noise Reduction Expander (THAT)
Audio Output (balanced) +4 dBm @ ± 40 kHz Deviation (Line)
-40 dBm @ ± 40 kHz Deviation (Mic)
Output Impedance 600 Ω
S/N Ratio 62 dB (± 5 kHz) “A” Weighted
Power Reqirement 12VDC (11.0 - 15.0 VDC)
Dimensions 82W x 150H x 60D mm
3.23W x 5.9H x 2.36D inches
Weight ≅750 g (26.45 oz) w/antennas
1200BT Belt-pack Transmitter1200BT Belt-pack Transmitter
1200BT Belt-pack Transmitter1200BT Belt-pack Transmitter
1200BT Belt-pack Transmitter
RF Power 25 mW
Antenna ¼ wavelength (internal)
Frequency Response 50 Hz - 15 kHz
Reference Deviation ± 5 kHz (-60 dBm - 1 kHz input, Mic)
± 40 kHz max deviation
Noise Reduction Compander (THAT)
Power Reqirement 2 “AA” Batteries (Alkaline)
6-8 hours runtime
Dimensions 63W x 98H x 28.5D mm
2.48W x 3.86H x 1.12D inches
Weight ≅180 g (6.35 oz) w/batteries
1200XT Plug-in Transmitter1200XT Plug-in Transmitter
1200XT Plug-in Transmitter1200XT Plug-in Transmitter
1200XT Plug-in Transmitter
RF Power 25 mW
Antenna ¼ wavelength (internal)
Frequency Response 50 Hz - 15 kHz
Reference Deviation ± 5 kHz (-60 dBm - 1 kHz input, Mic)
± 40 kHz Maximum
Noise Reduction Compander (THAT)
Power Reqirement 2 “AA” Batteries (Alkaline)
6-8 hour runtime
Dimensions 40W x 114H x 40D mm
1.57W x 4..49H x 1.57D inches
Weight ≅180 g (6.35 oz) w/batteries
SpecificationsSpecifications
SpecificationsSpecifications
Specifications**
**
*
* Due to constant improvements, specifications are subject to change without notice.
Availablesystems:
1200ABT 1200UPR/AB w/1200BT & EX-503H
1200ABS 1200UPR/AB w/1200BT & ECM-44H
1200ABX 1200UPR/ABw/1200XT
1200VMT 1200UPR/VM w/1200BT & EX-503H
1200VMS 1200UPR/VM w/1200BT & ECM-44H
1200VMX 1200UPR/VMw/1200XT
1200SiT 1200UPR/Si w/1200BT & EX-503H
1200SiS 1200UPR/Si w/1200BT & ECM-44H
1200SiX 1200UPR/Siw/1200XT
