Backyard Creations M21039LST User manual

Oceanside Coffee Table
Item #2721898, -1899, -1901 / M21039LST, -40LST, -41LST
Assembly Instructions
Step 1
: Remove protective wrapping and lay all parts on floor. Identify all parts packed in carton against
the parts list.
Step 2: Lay Table Top Frame (A) upside down on floor, so bottom is facing up. Place a protective soft
material on floor before placing table top face down on floor.
Step 3
: Attach each of four legs (B) to the bottom as shown in Diagram 1, using Bolt (D) and Washer ( E).
Then attach Stretcher (C) to Leg (B) using Bolt (D) and Washer ( E) as shown in Diagram 2.
Step 4: After making sure all bolts are aligned properly and tightened sufficiently, place Bolt Covers (F)
over bolts. Turn table over to upright position onto flat surface as shown in Diagram 3.
NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND TIGHTENED
PROPERLY AND SECURELY.
WARNING!
: TABLE IS NOT MEANT FOR SITTING OR STANDING ON. DO NOT SIT / STAND ON OR LEAN
FULL BODY AGAINST TABLE. IMPROPER USE MAY LEAD TO PRODUCT DAMAGE AND/OR BODILY
INJURY.
**TO AVOID POTENTIAL SCRATCHING TO PARTS BY ROUGH GROUND SURFACE, COVER GROUND WITH
SOFT SMOOTH PROTECTIVE MATERIAL ON WHICH TO PLACE PARTS DURING ASSEMBLY. **
Diagram 1
A
B
E
D
F
1 of 2

Diagram 3
Ref Part Name Part Image Qty Ref Part Name Part Image Qty
ATable Top 1 E Washer
(M6) 12
BTable Legs 4 F Bolt Cover 12
CStretcher 1 G Hex
Wrench 1
DBolt (M6) 12
WOODARD
Customer Service Hours
8:00am-5:00pm CST Monday to Friday
Phone: [phone] Fax: [phone]
Diagram 2
PARTS LIST
PRINTED IN CHINA
11-2020
CD
F
E
2 of 2
